Banana Pi BPI-M2+ User manual
0
1
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
1.10
1.11
1.12
1.13
1.14
1.15
1.16
1.17
2
2.1
2.2
2.2.1
2.3
2.3.1
2.3.2
2.3.2.1
2.3.3
2.3.3.1
2.3.3.2
TableofContents
AboutBPI-M2+(M2plus)
BPI-M2+hardware
BPI-M2+hardwareinterface
BPI-M2+hardwarespec
BPI-M2+Pindefine
BPI-M2+SDcardslot
BPI-M2+GigELAN
BPI-M2+eMMCflash
BPI-M2+WIFIinterface
BPI-M2+wifiantennaslot
BPI-M2+bluetoothinterface
BPI-M2+IRinterface
BPI-M2+HDMIinterfact
BPI-M2+USBinterface
BPI-M2+OTGinterface
BPI-M2+CSIcamerainterface
BPI-M2+Powerinterface
BPI-M2+schematicdiagram
BPI-M2+DXFand3Ddesign
BPI-M2+software
BPI-M2+QuickStart
Androidsoftware
HowtoburnandroidimagetoeMMC
Linuxsoftware
HowtoburnLinuximagetoeMMC
LinuxforKernel3.4image
howtouseBPI-M3imageonBPI-M2+,usebpi-bootsel
mainlineLinux
uboot
mainlinekernel
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
2
2.4
2.5
3
4
4.1
4.2
4.3
4.4
4.5
4.6
4.7
5
5.1
5.2
5.3
Armbian
BPI-M2+WiringPi
BPI-M2+sourcecodeongithub
Referencedocuments
H3Linux-sunxiwiki
H3Manualbuildhowto
BPI-M2+linux-sunxiwiki
Bananapiwikipediawiki
BPI-M2+onlinevideo
AllwinnerGPL_Violations
Linuxmainliningeffort
BPI-M2+qualityguarantee
BPI-M2+BT4.0Labtest
BPI-M2+WIFILabtest
BPI-M2+CE,FCCRoHSCertification
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
3
AboutbananapiBPI-M2+(M2plus)
BananaPIBPI-M2+istheopensourcehardwareplatform,BananaPIBPI-M2+isanquad
coreversionofBananaPi,itsupportWIFIonboard.useAlliwnnerH3chiponboard.and
minisizeonly65mm*65mm
BananaPiBPI-M2+seriesrunAndroid,Debianlinux,Ubuntulinux,RaspberryPiimageand
othersimage.BananaPIPBI-M2hardware:1GhzARM7quad-coreprocessor,1GBDDR3
SDRAM,8GeMMCflashonboard,andSDIOwifimoduleonboard.
BananaPIBPI-M2+withGigabitethernetport,ItcanrunwithAndroid4.4smoothly.itcan
easilyrunwiththegameitsupport1080Phighdefinitionvideooutputand4Ksupport,the
GPIOcompatiblewithRaspberryPiB+andcansupportraspbianImage
Note:
BananaPiBPI-M2+notsupportsataport,soyouneeduseUSBforhardisk
BananapiBPI-M2+notsupportLCDinterface.
Forcostdownversion,wemayremove8GeMMCandonboardwifimodule.so,everyone
canfreeDIYonthisboard.
forum:http//www.banana-pi.org
forum:http://www.bananapi.com
product:http://www.banana-pi.com
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
4AboutBPI-M2+(M2plus)
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
5AboutBPI-M2+(M2plus)
FirstLookBPI-M2+
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
6BPI-M2+hardware
BPI-M2+hardwareinterface
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
7BPI-M2+hardwareinterface
BPI-M2+(BPI-M2plus)hardwarespec
Hardwarespecification
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
8BPI-M2+hardwarespec
CPU H3Quad-coreCortex-A7H.265/HEVC4K
GPU Mali400MP2GPU@600MHz,SupportsOpenGLES2.0
Memory
(SDRAM) 1GBDDR3(sharedwithGPU)
Onboard
Storage
TFcard(Max.64GB)/MMCcardslot,upto2Ton2.5SATAdisk,8GB
EMMCFlash
Onboard
Network 10/100/1000MEthernetRJ45
Onboard
WIFI SDIOAP6212（optionAP6181、AP6335）
Video
Input
ACSIinputconnectorCamera:1Supports8-bitYUV422CMOSsensor
interface,2SupportsCCIR656protocolforNTSCandPAL,3Supports
SMpixelcamerasensor,4Supportsvideocapturesolutionupto
1080p@30fps
Video
Outputs
SupportsHDMIoutputwithHDCP,SupportsHDMICEC,SupportsHDMI
30function,IntegratedCVBS,SupportssimultaneousoutputofHDMIand
CVBS
Audio
Output HDMI
Power
Source DCinputcansupplypower,butUSBOTGinputdon’tsupplypower
USB2.0
Ports twoUSB2.0HOST,oneUSB2.0OTG
Buttons PowerButton,RecoveryButton,UbootButton
Low-level
peripherals 40PinsHeader,compatiblewithRaspberryPiB+
uart
GPIO(1x3)
pin
UART,ground
LED Powerled&Statusled
IR IRinputonboard
Supported
OS Android,Ubuntu,Debian,RasberryPiImage
Product
size 65mm×65mm
Weight 48g
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
9BPI-M2+hardwarespec
BPI-M2+Pindefine
BananaPiBPI-M2+40-pinGPIO
BananaPiBPI-M2+hasa40-pinGPIOheaderthatmatchesthatoftheModelB+Raspberry
Pi.FollowingistheBananaPiGPIOPinout:
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
10BPI-M2+Pindefine
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
11BPI-M2+Pindefine
GPIOPinName DefaultFunction Function2：GPIO Function3
CON2-P01 VCC-3V3
CON2-P02 VCC-5V
CON2-P03 TWI0-SDA PA12-EINT12
CON2-P04 VCC-5V
CON2-P05 TWI0-SCK PA11-EINT11
CON2-P06 GND
CON2-P07 PWM1 PA6-EINT6
CON2-P08 UART3-TX PA13-EINT13 SPI1-CS
CON2-P09 GND
CON2-P10 UART3-RX PA14-EINT14 SPI1-CLK
CON2-P11 UART2-RX PA1-EINT1
CON2-P12 UART3-CTS PA16-EINT16 SPI1-MISO
CON2-P13 UART2-TX PA0-EINT0
CON2-P14 GND
CON2-P15 UART2-CTS PA3-EINT3
CON2-P16 UART3-RTS PA15-EINT15 SPI1-MOSI
CON2-P17 VCC-3V3
CON2-P18 PC4 PC4
CON2-P19 SPI0-MOSI PC0
CON2-P20 GND
CON2-P21 SPI0-MISO PC1
CON2-P22 UART2-RTS PA2-EINT2
CON2-P23 SPI0-CLK PC2
CON2-P24 SPI0-CS PC3
CON2-P25 GND
CON2-P26 PC7 PC7
CON2-P27 TWI1-SDA PA19-EINT19
CON2-P28 TWI1-SCK PA18-EINT18
CON2-P29 PA7-EINT7 PA7-EINT7
CON2-P30 GND
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
12BPI-M2+Pindefine
CON2-P31 PA8-EINT8 PA8-EINT8
CON2-P32 PL2-S-EINT2 PL2-S-EINT2
CON2-P33 PA9-EINT9 PA9-EINT9
CON2-P34 GND
CON2-P35 PA10-EINT10 PA10-EINT10
CON2-P36 PL4-S-EINT4 PL4-S-EINT4
CON2-P37 PA17-EINT17 PA17-EINT17 SPDIF-OUT
CON2-P38 PA21-EINT21 PA21-EINT21
CON2-P39 GND
CON2-P40 PA20-EINT20 PA20-EINT20
CSICameraConnectorspecification:
TheCSICameraConnectorisa24-pinFPCconnectorwhichcanconnectexternalcamera
modulewithpropersignalpinmappings.ThepindefinitionsoftheCSIinterfaceareshown
asbelow.ThisismarkedontheBananaPiboardas“CSI″.
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
13BPI-M2+Pindefine
CSIPinName DefaultFunction Function2：GPIO
CN3-P01 NC
CN3-P02 GND
CN3-P03 CSI0-SDA PE13
CN3-P04 CSI0-AVDD
CN3-P05 CSI0-SCK PE12
CN3-P06 CSI0-Reset PE14
CN3-P07 CSI0-VSYNC PE3
CN3-P08 CSI0-PWDN PE15
CN3-P09 CSI0-HSYNC PE2
CN3-P10 CSI0-DVDD
CN3-P11 CSI0-DOVDD
CN3-P12 CSI0-D7 PE11
CN3-P13 CSI0-MCLK PE1
CN3-P14 CSI0-D6 PE10
CN3-P15 GND
CN3-P16 CSI0-D5 PE9
CN3-P17 CSI0-PCLK PE0
CN3-P18 CSI0-D4 PE8
CN3-P19 CSI0-D0 PE4
CN3-P20 CSI0-D3 PE7
CN3-P21 CSI0-D1 PE5
CN3-P22 CSI0-D2 PE6
CN3-P23 GND
CN3-P24 CSI0-DOVDD
UARTspecification:
ThejumperCON3istheUARTinterface.FordevelopersofBananaPi,thisisaneasyway
togettheUARTconsoleoutputtocheckthesystemstatusandlogmessage.
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
14BPI-M2+Pindefine
CON3PinName DefaultFunction GPIO
CON3P03 UART0-TXD PA4
CON3P02 UART0-RXD PA5
CON3P01 GND
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
15BPI-M2+Pindefine
BPI-M2+SDcardslot
BPI-M2+havesupportaTFcardslot.youcanburnimagetoTFcard,anduseitbootBPI-
M2+sameasraspberrypi.
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
16BPI-M2+SDcardslot
BPI-M2+GigELAN
BananaPIBPI-M2+withoneGigabitethernetport,useRTL8211Echiponboard.
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
17BPI-M2+GigELAN
BPI-M2+eMMCflash
BPI-M2+havesupport8GeMMCflashonboardbydefaults.forcustomizationuser,wecan
add4-64Gemmconboard.
So,youcanburnyourimagetoeMMCflashandbootfromeMMCflash.
HowtoburnAndroidimagetoeMMC
pleasereadthisbook：
2.2.1HowtoburnandroidimagetoeMMC
HowtoburnLinuximagetoeMMC
pleasereadthisbook:
2.3.1HowtoburnlinuximagetoeMMC
Note:
thefirstbootisfrommicroSDcard.ifyouwanttobootfromeMMCflash,pleaseremove
microSDcardfromBPI-M2+microSDcardslots.
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
18BPI-M2+eMMCflash
BPI-M2+WIFIinterface
BPI-M2+supportAP6212wifimoduleonboard.used.itsupport802.11/b/g/nwifi.
testreport,pleasesee:5.2BPI-M2+wifiLabtest
aboutAP6212wifi&BTmodulespec:
http://wiki.friendlyarm.com/wiki/images/5/57/AP6212_V1.1_09022014.pdf
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
19BPI-M2+WIFIinterface
BPI-M2+wifiantennaslot
bananapiBPI-M2+havesupportap6212wifi&BTmoduleonboard
BPI-M2+havewifiantennaslotonboard
wifiextendantennaslotspec:
soyoucanuse3DB/5DBwifiantennaonBPI-M2+
BPI-M2+（BPI-M2Plus）H3quadcordsingleboardcomputer
20BPI-M2+wifiantennaslot
