Chapter 1: HARDWARE
Introduction
The Port Expander (232PE) adds four asynchronous serial data
ports to the Expandable Smart Switch (232XSS). Up to fifteen Port
Expanders can be connected to a single 232XSS via the Port
Expansion Bus. Refer to Figure 1. This expands the eight ports on
the 232XSS to a maximum of sixty-eight ports. RS-232 ports are
standard on the 232PE, RS-422/485 ports are optional. RS-232
ports are configured as DTE ports and support signals TD, RD,
RTS, CTS, DTR, and DSR or CD. Ports configured as RS-422/485
support only signals TD and RD.
There are five red indicator LED's on the front of the 232XSS.
Four LED's represent ports "A" through "D" and indicate the
selected port. The fifth LED is the "Power On" indicator. Refer to
Figure 7. There are five connectors located on the back of the
232PE, a twenty pin expansion bus connector, four DB-25P male
connectors for ports "A" through "D", and an eleven inch bus
expansion ribbon cable. Refer to Figure 8.
In order to select a port on a Port Expander, each expander is
assigned its own unique address. A four position DIP switch in the
Port Expander is used to set this address. An address field is part
of the port selection control string that is received by the master
port of the Expandable Smart Switch. Refer to the Expandable
Smart Switch manual for more details regarding port selection.
There is no delay through the Port Expander and the data is not
buffered.
Figure 1. Simplified Functional Diagram
This diagram illustrates only the transmit data (TD) signal.

2232PE3095 Manual
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH [phone] -- FAX [phone]
Checklist
The following equipment should be in the shipping carton:
1. Port Expander
2. Instruction Manual
If any of the items above are damaged or missing contact the
shipper immediately.
Port Expansion Bus
The number of serial ports on the Expandable Smart
Switch can easily be expanded to a maximum of sixty-eight ports
by daisy chaining Port Expander units on the 232XSS's expansion
bus. A maximum of fifteen Port Expander units can be added to a
232XSS. Each Port Expander unit (232PE) adds four additional
serial ports. The Port Expansion Bus connects each port to the
electronic switch control circuit in the 232XSS.
Setting The Address
Port Expanders must be assigned their own unique address.
Located inside the 232PE is a four position DIP switch (SW1) which
sets the unit's address. Refer to Figure 2. Select an unused
address from "1" to "15" using Table 1.
CAUTION: Always power down the 232PE before removing its
cover.
Do not select an address that is used by another Port
Expander, data collisions can occur and data will be
lost!

232PE3095 Manual 3
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH [phone] -- FAX [phone]
Figure 2. Printed Circuit Board Outline
* PC board for optional RS-422/485 port.

4232PE3095 Manual
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH [phone] -- FAX [phone]
Connecting To The Bus
Connecting the Port Expander to the Expandable Smart Switch
bus is a simple task. On the rear panel of the Port Expander is an
expansion bus cable, refer to Figure 3. This cable simply plugs into
the bus expansion connector located on the back of the last unit
connected to the Expandable Smart Switch bus.
Table 1. Address Switch
DIP Switch 1
1 2 3 4 Address
0000 Invalid
1000 1
0100 2
1100 3
0010 4
1010 5
0110 6
1110 7
0001 8
1001 9
0 1 0 1 10
1 1 0 1 11
0 0 1 1 12
1 0 1 1 13
0 1 1 1 14
1111 15*
1 = OFF 0 = ON
* = FACTORY DEFAULT
Figure 3. Bus Connection Diagram

232PE3095 Manual 5
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH [phone] -- FAX [phone]
Port Configuration
The 232PE has four selectable ports labeled "A" through "D".
Refer to Figure 8. Any of the ports can be manufactured to meet
either RS-232 or RS-422/485 electrical characteristics.
RS-232 Configuration
RS-232 ports will be wired as DTE ports. Refer to Table 2 for
pin out, signal name, and signal direction information. Also, refer to
Figure 4 for a simplified schematic showing the relationship
between the master port of the 232XSS and any RS-232 port of the
232PE. Refer to Appendix B for cable charts.
Table 2. RS-232 DTE PORTS A - D
Pin # Signal Description
RS-232 Signal
Direction of
DTE Ports A
through D
2TD Transmit Data Output
3RD Receive Data Input
4RTS Request to Send Output
5CTS Clear to Send Input
6*DSR Data Set Ready Input
7SG Signal Ground <------>
8* CD Carrier Detect Input
20 DTR Data Term Ready Output
* Pins 6 & 8 are tied together inside the 232PE and
share the same input, refer to Figure 4.

6232PE3095 Manual
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH [phone] -- FAX [phone]
RS-422/485 Option
The RS-232 transmit and receive data signals on the master
port of the 232XSS will be converted to balanced full-duplex RS-
422 or half-duplex RS-485 signals with this option.
Figure 4. Simplified RS-232 Schematic
Table 3. RS-422/485 PORTS A - D
Pin # Signal Description
RS-422/485
Signal Direction
of Ports A - D
2TD(A) Transmit Data (A) Output
14 TD(B) Transmit Data (B) Output
7SG Signal Ground <------>
3RD(A) Receive Data (A) Input
16 RD(B) Receive Data (B) Input

232PE3095 Manual 7
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH [phone] -- FAX [phone]
When a port has this option, an additional printed circuit board
will be mounted to the main board. Use Figure 2 to locate its
position. Refer to Table 3 for pin out, signal name, and signal
direction information. Also, refer to Figure 5 for a simplified
schematic showing the relationship between the master port and a
port configured with the RS-422/485 option.
NOTE: This option only supports transmit and receive data signals
(TD & RD) from the master port.
Refer to Appendix B for cable charts.
RS-422 Mode
To configure the port for RS-422 four-wire mode, five jumpers
must be set. Jumper JP1 must be placed in the “SD” position.
Both JP2 jumpers must be placed in the four-wire “4W" position.
Jumper JP3 must be place in the "ON" position. Jumper JP4
should be placed in the "ON" position. Refer to Figure 6 for these
jumper locations.
Figure 5. Simplified RS-422/485 Schematic

8232PE3095 Manual
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH [phone] -- FAX [phone]
The EIA RS-422 Specification labels data lines with "A" and "B"
designators. Some RS-422 equipment uses a "+" and "-"
designator. In almost all cases, the "A" line is the equivalent of the
"-" line and the "B" line is the equivalent of the "+" line.
RS-485 Mode
There are two methods that can be used to control the RS-
422/485 driver: handshake control (RTS) and send data (SD)
control. These methods are jumper selectable (JP1 "SD" & "RTS").
Handshake control requires that the software use a handshake
signal to enable/disable the RS-485 driver. The handshake signal
RTS (pin 4) is used when the master port is configured as a DCE
port and CTS (pin 5) is used when the master port is configured as
a DTE port.
SD control automatically enables the RS-485 driver by sensing
the leading edge of the first character transmitted from the device
connected to the master port. After the last character is transmitted
the send data timer circuit waits one character time (1 millisecond
at 9600 baud) before disabling the RS-485 driver.
There are two components on the main printed circuit board, a
resistor (R1) and a capacitor (C1), that are part of the send data
control circuit. These components are factory selected for 9600
baud, which allows the send data control to operate at 9600 baud or
higher. With these two components the RS-485 driver will be
disabled approximately 1 millisecond after the last character has
Figure 6. P.C. Board for Optional RS-422/485 Port

232PE3095 Manual 9
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH [phone] -- FAX [phone]
been sent. To change to a baud rate lower than 9600 baud, or to
configure the send data control to match a specific baud rate,
change R1 and C1 to the value specified in Table 4. Use Figure 2
to locate R1 and C1. Note that these timing components are not
used when the handshake control method is selected.
The ECHO jumper (JP3) selects how the RS-485 receiver is
controlled. It can be set to ECHO ON which constantly enables the
receiver (RS-422, 4-wire mode) or to ECHO OFF which allows the
receiver to be automatically enabled when the RS-485 driver is
disabled (2-wire mode). When in the ECHO OFF position and in 2-
wire mode, the data being sent from the RS-232 device connected
to the master port will not be echoed back to the master port.
To configure a port for RS-485 two-wire mode, five jumpers
must be set. Jumper JP1 must be placed either the “SD” or the
“RTS” position, depending on how you control the RS-485 driver.
Both JP2 jumpers must be placed in the two-wire “2W” position.
Jumper JP3 must be place in the "OFF" position. Jumper JP4
should be placed in the "ON" position if this port is located at either
end of the multi-drop line, otherwise it should be in the "OFF"
position. Refer to Figure 6 for these jumper locations.
Table 4. Component Values For Send Data Timing
Baud Rate Time (ms) Resistor Value R1 (ohms) Capacitor Value C1(microfarads)
300 33.3 330K .1
600 16.6 160K .1
1200 8.33 820K .01
2400 4.16 430K .01
4800 2.08 200K .01
9600 1.04 100K .01
19.2K 0.520 56K .01
38.4K 0.260 27K .01
57.6K 0.176 16K .01
115.2K 0.0868 8.2K .01

10 232PE3095 Manual
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH [phone] -- FAX [phone]
Specifications
Model: 232PE
Size: 8"w x 6.3"d x 2.7"h
Power: 120Vac 60hz 16w
Figure 7. Front View
Figure 8. Rear View

232PE3095 Manual Appendix A A-1
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH [phone] -- FAX [phone]
Appendix A: Cable Charts

A-2Appendix A 232PE3095 Manual
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH [phone] -- FAX [phone]
These charts indicate some common cable wiring based on the
DCE/DTE configuration of the 232XSS Master Port. Refer to the
Port Configuration section of the 232XSS manual for information on
Master Port configurations.
Chart 1. IBM PC DB25 Connector to Master Port
Master Port configured as a DCE port.
IBM PC
Serial Port
DB25 Connector Signal Direction
232XSS
Master Port (DCE)
DB25 Connector
2-----------> 2
3<----------- 3
4-----------> 4
5<----------- 5
6<----------- 6*
7<---------> 7
8<----------- 8*
20 -----------> 20
* Pins 6 & 8 are tied together inside the 232XSS and share the
same output.
Chart 2. IBM PC DB9 Connector to Master Port
Master port configured as a DCE port.
IBM PC
Serial Port
DB9 Connector Signal Direction
232XSS
Master Port (DCE)
DB25 Connector
1<----------- 8*
2<----------- 3
3-----------> 2
4-----------> 20
5<---------> 7
6<----------- 6*
7-----------> 4
8<----------- 5
* Pins 6 & 8 are tied together inside the 232XSS and share the
same output.

232PE3095 Manual Appendix A A-3
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH [phone] -- FAX [phone]
Chart 3. Modem DB25 Connector to Master Port
Master port configured as a DTE port.
Async Modem
Serial Port
DB25 Connector Signal Direction
232XSS
Master Port (DTE)
DB25 Connector
2<----------- 2
3-----------> 3
4<----------- 4
5-----------> 5
7<---------> 7
8-----------> 8*
20 <----------- 20
* Pins 6 & 8 are tied together inside the 232XSS and share the
same input.
NOTE: When using chart 3 above and connecting a DTE device
to ports A - H of the smart switch, refer to Charts 7 and 8.
Chart 4. DCE Device w/DB25 Connector to Ports A - D (DTE)
Master port of 232XSS configured as a DCE port.
DCE Device
Serial Port
DB25 Connector Signal Direction
232PE
Ports A - D (DTE)
DB25 Connector
2<----------- 2
3-----------> 3
4<----------- 4
5----------> 5
6----------> 6*
7<---------> 7
8-----------> 8*
20 <----------- 20
* Pins 6 & 8 are tied together inside the 232PE and share the
same input.

A-4Appendix A 232PE3095 Manual
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH [phone] -- FAX [phone]
Chart 5. IBM PC DB25 Connector to Ports A - D (DTE)
Master port of 232XSS configured as a DCE port.
IBM PC
Serial Port
DB25 Connector Signal Direction
232PE
Ports A - D (DTE)
DB25 Connector
2-----------> 3
3<----------- 2
4-----------> 5
5<---------- 4
6<---------- 6*
7<---------> 7
8<----------- 8*
20 -----------> 20
* Pins are tied together inside the 232PE and share the same
input.
Chart 6. IBM PC DB9 Connector to Ports A - D (DTE)
Master port of 232XSS configured as a DCE port.
IBM PC
Serial Port
DB9 Connector Signal Direction
232PE
Ports A - D (DTE)
DB25 Connector
2<----------- 2
3-----------> 3
4-----------> 6*
5<---------> 7
6<----------- 20
7-----------> 5
8<----------- 4
* Pins 6 & 8 are tied together inside the 232PE and share the
same input.

232PE3095 Manual Appendix A A-5
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH [phone] -- FAX [phone]
Chart 7. IBM PC DB25 Connector to Ports A - D (DTE)
Master port of 232XSS configured as a DTE port with a
modem connected (see Chart 3).
IBM PC
Serial Port
DB25 Connector Signal Direction
232PE
Ports A - D (DTE)
DB25 Connector
2-----------> 3
3<----------- 2
4-----------> 5
5<----------- 4
6<---- ----> 6*
7<---------> 7
8<----------- 20
20 -----------> 6*
* Pins 6 & 8 are tied together inside the 232PE and share the
same input.
Chart 8. IBM PC DB9 Connector to Ports A - D(DTE)
Master port of 232XSS configured as a DTE port with a modem
connected (see Chart 3).
IBM PC
Serial Port
DB9 Connector Signal Direction
232PE
Ports A - D (DTE)
DB25 Connector
3-----------> 3
2<----------- 2
7-----------> 5
8<----------- 4
6<---- ----> 6*
5<---------> 7
1<----------- 20
4-----------> 6*
* Pins 6 & 8 are tied together inside the 232PE and share the
same input.

A-6Appendix A 232PE3095 Manual
B&B Electronics -- PO Box 1040 -- Ottawa, IL 61350
PH [phone] -- FAX [phone]
Chart 9. RS-422/485 4-Wire Device to Port (A - D) Configured
as an RS-422 /485 Port.
Master port of 232XSS configured as an RS-232 DCE port.
RS-422/485
4-Wire
Device Signal Direction
232PE
Ports A - D
DB25 Connector
TD (A)* -----------> 3 - RD (A)
TD (B)* -----------> 16 - RD (B)
Signal Ground <----------> 7 - SG
RD (A)* <----------- 2 - TD (A)
RD (B)* <----------- 14 - TD (B)
* If the device being connected uses "+" and "-" in place of "B"
and "A", the "+" replaces the "B" and the "-" replaces the "A".
NOTE: Make sure the port's set up jumpers are in the proper
position for four-wire communications.
Chart 10. RS-422/485 2-Wire Device to Port (A - D) Configured
as an RS-422/485 Port.
Master port of 232XSS configured as an RS-232 DCE port.
RS-422/485
2-Wire
Device Signal Direction
232PE
Ports A - D
DB25 Connector
Data (A)* <----------> 2 - TD (A)
Data (B)* <----------> 14 -TD (B)
Signal Ground <----------> 7 - SG
* If the device being connected uses "+" and "-" in place of "B"
and "A", the "+" replaces the "B" and the "-" replaces the "A".
NOTE: Make sure the port's set up jumpers are in the proper
position for two-wire communications.
