Section 1 - Introduction Vlinx VESR4x4 Serial Server
Page 7 of 67 www.bb-elec.com/
www.bb-europe.com/
SECTION 1
Introduction
Thank you for purchasing a VESP211 Serial Server product! This product
has been manufactured to the highest standards of quality and performance to
ensure your complete satisfaction.
Figure 1. A VESP211 Serial Server
About VESP211 Serial Servers
VESP211 Serial Servers connect serial devices (RS-232, RS-422 or RS-485)
to Ethernet networks, allowing the serial device to become a node on the
network. The serial port can be accessed over a LAN/WAN using Direct IP
Mode, Virtual COM Port, or Paired Mode connections. VESP211 Serial Servers
support 10BaseT or 100BaseTX copper networks. The product is built for use
in industrial environments, and features a heavy duty metal enclosure that is
panel (standard) or DIN rail mountable (with optional adapter). The product
includes a DC power supply with a 2.1mm barrel connector.

Section 1 - Introduction Vlinx VESR4x4 Serial Server
Page 8 of 67 www.bb-elec.com/
www.bb-europe.com/
VESP211 Serial Server Model Numbering
The VESP211 Serial Server family of products includes three models:
VESP211-232, which uses a DB-9M connector and supports the RS-232
serial interface
VESP211-485, which uses a pluggable, five-position terminal strip and
supports the RS-485 serial interface
VESP211 which uses a DB-9M connector and supports the RS-232, RS-
422 and RS-485 serial interfaces
All models incorporate one serial connection and one Ethernet connection.
VESP211 Features
Multi-interface serial port (VESP211)
DB-9M serial port connector (VESP211 and VESP211-232)
Five-position pluggable terminal strip (VESP211-485)
Configuration can be done via network or direct serial connection
Rugged panel mountable metal case
Accepts 12 VDC power (power adapter included)
10/100 Mbps Ethernet with Auto Selection
LAN and WAN Communications
TCP Client or Server, or UDP operation - configurable
Virtual COM port and Paired Mode capabilities
Firmware Upload over the network for future revisions/upgrades
Software Support - XP (32/64 bit), 2003 Server (32/64 bit), Vista (32/64
bit), 2008 Server (32/64 bit), Windows 7 (32/64 bit)
Configuration of Ethernet and serial port settings using Vlinx Manager
software
Vlinx Manager Configuration Software
Vlinx Manager configuration software enables you to find connected serial
servers, configure them, upgrade serial server firmware, and save/load
configuration files. It features a graphical user interface (GUI) that is
convenient and easy to use. The software also makes it easy to add and
remove virtual COM ports on your computer.

Section 2 - VESP211 Hardware Vlinx VESR4x4 Serial Server
Page 9 of 67 www.bb-elec.com/
www.bb-europe.com/
SECTION 2
VESP211 Hardware
VESP211 Serial Servers are enclosed in a rugged panel mountable enclosure
and feature:
LED indicators
Power, Ethernet and serial connectors
A recessed Reset (mode) switch.
Package Checklist
VESP211 Serial Servers are shipped with the following items included:
VESP211 Serial Server Module
Quick Start Guide
CD with User Manual, Quick Start Guide
DC Power Supply
VESP211 Serial Server Enclosures and Mounting
All VESP211 models are built into similar enclosures. Modules are panel
mountable.
Figure 2. Front View of the VESP211 Serial Server

Section 2 - VESP211 Hardware Vlinx VESR4x4 Serial Server
Page 10 of 67 www.bb-elec.com/
www.bb-europe.com/
LED Indicators
VESP211s have three LED indicators: a Ready LED, an Ethernet LED, and a
Serial LED.
Figure 3. Front Panel of the VESP211
Ready LED
The Ready LED (green) blinks once per second if the system is operating
correctly. If the LED is off, it indicates the system is not operating correctly (or
that it is in Console Mode).
Ethernet LED
The Ethernet LED illuminates if the Ethernet port is connected and blinks
when data is transmitted or received.
Serial LED
The serial port has an associated LED. The Serial Port LED blinks (green)
when data is being transmitted or received on the serial port. When the LED is
On, it indicates that the serial port is open.

Section 2 - VESP211 Hardware Vlinx VESR4x4 Serial Server
Page 11 of 67 www.bb-elec.com/
www.bb-europe.com/
Note: LEDs on the serial server are also used to indicate various Reset modes, as described in the
following section.
Reset Switch
A recessed momentary Reset switch is located on the side of the enclosure.
To activate the switch, insert a small plastic tool through the hole in the
enclosure and press lightly.
Figure 4. Ethernet Connector, Reset Switch (recessed) and Power Connector
The Reset switch can be used to:
Initiate a Hardware Reset
Enter Console Mode
Reload factory defaults
Using the Reset Switch to Initiate a Hardware Reset
Hold the Reset switch in for 0 to 2 seconds. The Ready LED stops blinking
while the switch is being held in. The Serial LED illuminates while the switch is
being held in. Release the switch in less than two seconds or the serial server
will enter Console Mode.
Using the Reset Switch to Enter Console Mode
Hold the Reset switch for between two and ten seconds. The Ready LED stops
blinking while the switch is being held in. The Serial LED illuminates for the
first two seconds; then Serial LED goes out and the Ready LED illuminates.
Release the switch in less than 10 seconds or the serial server will reset to
factory default settings.

Section 2 - VESP211 Hardware Vlinx VESR4x4 Serial Server
Page 12 of 67 www.bb-elec.com/
www.bb-europe.com/
Using the Reset Switch to exit Console Mode
Press and hold the Reset switch for two seconds, or remove power from the
serial server, wait a few seconds, and turn the power on again. The LEDs go
back to their normal states when the device resumes normal operation.
Using the Reset Switch to Reload Factory Default Settings
Hold the Reset switch for more than ten seconds. The Serial LED illuminates
for the first two seconds; then the Ready LED illuminates. After 10 seconds,
both the Serial and Ready LEDs illuminate. Release the switch after more than
10 seconds. The serial server will reset to factory default settings.
Ethernet Connector
The Ethernet connection uses an RJ45 receptacle. The serial server is
connected to a standard Ethernet network drop using a straight-through RJ45
(male) Ethernet cable.
Note: Refer to Appendix D for connection pin-outs.
Serial Port Connectors
VESP211 Serial Servers feature two serial port connector configurations,
depending on the model:
VESP211 and VESP211-232 use DB-9M connectors for RS-232, RS-422
and RS-485 connections.
Figure 5. DB-9M Serial Port Connector

Section 2 - VESP211 Hardware Vlinx VESR4x4 Serial Server
Page 13 of 67 www.bb-elec.com/
www.bb-europe.com/
VESP211-485 serial servers use five-position removable terminal blocks
for RS-422 and RS-485 connections.
Figure 6. Five-Position Pluggable Terminal Blocks
Note: Refer to Appendix D for connection pin-outs.
Power Connector
VESP211 serial servers use a barrel jack connector for power. The connector
accepts a 2.1 millimeter plug and requires 12 VDC at 2.5 W maximum.
Figure 7. Ethernet Connector, Reset Switch (recessed) and Power Connector

Section 2 - VESP211 Hardware Vlinx VESR4x4 Serial Server
Page 14 of 67 www.bb-elec.com/
www.bb-europe.com/
Figure 8.
Mounting Hardware
VESP211 Serial Server modules can be panel mounted using the built-in
mounting brackets.
Figure 9. VESP211 Enclosure with Panel Mount Bracket
An optional DIN rail mount adapter is available from B&B Electronics.

Section 3 - Initial Setup and Connections Vlinx VESR4x4 Serial Server
Page 15 of 67 www.bb-elec.com/
www.bb-europe.com/
SECTION 3
Initial Setup and Connections
This section describes how to setup and connect VESP211 Serial Servers.
Note: In this section devices to be connected to the serial server’s serial connection are simply referred to
as the “serial device”.
Connecting the Power Supply
Connect a DC power supply by plugging a 12 VDC power source into the
barrel jack on the top of the serial server. The center connection must be
positive (+). (Polarity of the connection is indicated on the label on the front of
the serial server.) The power supply must be capable of supplying 2.5 watts
maximum.
Connecting VESP211 Serial Servers to Serial Devices
VESP211 Serial Servers can be connected to serial devices using RS-232, RS-
422, RS-485 2-wire and RS-485 4-wire.
RS-232
The RS-232 interface supports seven RS-232 signal lines (TD, RD, DTR,
DSR, RTS, CTS, DCD) plus Signal Ground.
Signals are single ended and referenced to Ground. Default communications
parameters are 9600, 8, N, 1 and no flow control implemented.
Note: The VESP211 is configured as a DTE. If it is connected to a serial device configured as a DTE, use
a null modem (cross-over) cable. If the serial device is a DCE, use a straight-through cable.
RS-422
The RS-422 interface supports two signal pairs: TDA (-), TDB (+), RDA (-),
RDB (+) and GND. The data lines are differential pairs (A & B) in which the B
line is positive relative to the A line in the idle (mark) state. Ground provides a
common mode reference.

Section 3 - Initial Setup and Connections Vlinx VESR4x4 Serial Server
Page 16 of 67 www.bb-elec.com/
www.bb-europe.com/
RS-485
The RS-485 interface supports 2-wire or 4-wire operation.
When configured for 4-wire operation the connection supports two signal
pairs: TDA (-), TDB (+), RDA (-), RDB (+) and GND. This makes full-duplex
operation possible. The data lines are differential pairs (A & B) in which the B
line is positive relative to the A line in the idle (mark) state. Ground provides a
common mode reference.
When configured for 2-wire operation the connection supports one signal
pair: Data A (-) and Data B (+) signal channels using half-duplex operation.
The data lines are differential with the Data B line positive relative to Data A in
the idle (mark) state. Ground provides a common mode reference.
Note: Refer to Appendix D for connector pinout information.
Figure 10. VESP211 Connections
Connecting VESP211 Serial Servers to a Network
Ethernet Connection (10BaseT/100BaseTX)
The Ethernet connection uses a standard RJ45 connector. A standard
network cable is connected from the serial server to a network drop. PCs
configuring and/or communicating with the serial server are also connected to
the network.

Section 3 - Initial Setup and Connections Vlinx VESR4x4 Serial Server
Page 17 of 67 www.bb-elec.com/
www.bb-europe.com/
VESP211 Serial Server Configuration Connections
VESP211 Serial Servers can be configured using several methods:
Via the network using Vlinx Manager software
Via the network using a web browser
Via the serial port using Vlinx Manager software (Console Mode)
Configuring via the Network using Vlinx Manager
VESP211 Serial Servers can be configured over the network using Vlinx
Manager software running on a networked PC. Vlinx Manager includes a
discovery function that makes it possible to detect the serial server on the
network whether you know its IP address or not. Once the serial server has
been detected, the Manager can be used to configure its settings.
Note: For more information on how to use Vlinx Manager to configure your serial server, refer to Section 4:
Configuring the Serial Server
Figure 11. Network Setup
Configuring via the network using a Browser
VESP211 Serial Servers can also be configured over the network using a
standard internet browser such as Internet Explorer or Firefox running on a
networked PC. To do so you must know the IP address of the serial server.
Your serial server comes from the factory pre-configured to receive an IP
address from a DHCP Server. If DHCP assignment is not available it will
default to 169.254.102.39

Section 3 - Initial Setup and Connections Vlinx VESR4x4 Serial Server
Page 18 of 67 www.bb-elec.com/
www.bb-europe.com/
Note: For more information on how to use Vlinx Manager to configure your serial server, refer to Section 4:
Configuring the Serial Server
Configuring via the Serial Port using Vlinx Manager (Console Mode)
Your serial server can be configured via the serial port using Vlinx Manager. To
use this feature the serial port must be connected to the serial port of a PC
(using a null modem cable).
Figure 12. Console Mode Setup
To configure the serial server it must be put into Console Mode, using the
Reset switch.
Note: Refer to Section 2 for information on how to use the Reset switch to enter Console Mode.
VESP211 Serial Server Operational Connections
VESP211 Serial Servers can operate in Direct IP, Virtual COM Port and Paired
Modes.
In Direct IP Mode applications using TCP/IP or UDP/IP socket programs can
communicate with the COM ports on the serial server. In this type of
application the serial server is configured as a TCP or UDP server. The socket
program running on the PC establishes a communication connection with the
serial server. The data is sent directly to and from the serial port on the
server.

Section 3 - Initial Setup and Connections Vlinx VESR4x4 Serial Server
Page 19 of 67 www.bb-elec.com/
www.bb-europe.com/
Figure 13. Direct IP and Virtual COM Port Connection
In Virtual COM Port Mode a PC can communicate across the network to the
serial server as if the serial ports on the serial server are the PC’s serial ports.
When a virtual COM port is configured on the PC (using Vlinx Manager) a new
COM port appears in the Device Manager. Windows programs using standard
Windows API calls are able to interface to virtual COM ports. When a program
on the PC opens the new COM port, it communicates directly with the remote
serial device connected to the serial server.
In Paired Mode, two serial servers (connected to serial devices via their serial
ports) are connected to the network. The serial devices communicate directly,
transferring data between devices as a point-to-point serial connection. Paired
Mode is set up as shown in the following diagram and configured using Vlinx
Manager software or web interface.
Figure 14. Paired Mode Setup

Section 3 - Initial Setup and Connections Vlinx VESR4x4 Serial Server
Page 20 of 67 www.bb-elec.com/
www.bb-europe.com/
Installing and Starting Vlinx Manager
Vlinx Manager is a Windows-based application used to configure serial servers.
Install it on your PC from the included CD. Installation should launch
automatically when the CD is placed in the CD-ROM drive. If it does not
automatically launch, click Start on the Windows Desktop and, at the Run
command, type the drive letter and Vlinx Manager.exe. Follow the prompts to
install the software.
Once the program is installed, go to the Start > Programs menu and run the
program.
The Vlinx Manager Discovery window appears.
Figure 15. Discovery Window
Discovering Serial Servers
If you are configuring the serial server via the network, select Network; if you
are configuring it via the serial port, select Serial Port.
If you already know the IP address of the serial server, click The device is at
this IP address; if not, leave I don’t know the IP address of the device
selected.
Click Connect. The Progress bar provides information to indicate whether
serial servers are detected.
The text in the Progress box appears in various colors, depending on the
message type.
