NMEA 2000®REMOTE BUTTON
INSTALLATION GUIDE
1. NMEA 2000®remote button
2. Micro-C connector (male)
3. NMEA 2000® Micro-C T-connector
Parts included
Disclaimer
This product is not a substitute for proper training and prudent seamanship. It is the owner’s sole responsibility to install and use the equipment in a manner that
will not cause accidents, personal injury or property damage. The user of this product is solely responsible for observing maritime safety practices.
Navigational features that appear in this guide are not a substitute for proper training and prudent seamanship. They do not replace a human navigator and
SHOULD NOT be relied on as a sole or primary source of navigation. It is the operator’s sole responsibility to use more than one navigational methods to ensure the
route suggested by the system is safe.
NAVICO HOLDING AS AND ITS SUBSIDIARIES, BRANCHES AND AFFILIATES DISCLAIM ALL LIABILITY FOR ANY USE OF THIS PRODUCT IN A WAY THAT
MAY CAUSE ACCIDENTS, DAMAGE OR THAT MAY VIOLATE THE LAW.
This manual represents the product as at the time of printing. Navico Holding AS and its subsidiaries, branches and affiliates reserve the right to make changes to
the product and/or specifications at any time without notice. Please contact your nearest distributor if you require any further assistance.
Compliance statements
Australia and New Zealand
Complies with the requirements of level 2 devices of the Radiocommunications (Electromagnetic Compatibility) standard 2017.
Europe
NMEA 2000®remote button complies with CE under EMC Directive 2014/30/EU. The relevant Declaration of conformity is available in the product’s section at
the following website: www.lowrance.com, www.simrad-yachting.com, www.bandg.com.
United Kingdom
NMEA 2000®remote button complies with UKCA under The Electromagnetic Compatibility Regulations 2016. The relevant Declaration of conformity is available
in the product’s section at the following website: www.lowrance.com, www.simrad-yachting.com, www.bandg.com.
United States of America
Warning: The user is cautioned that any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
Trademarks
®Reg. U.S. Pat. & Tm. Off, and ™ common law marks. Visit www.navico.com/intellectual-property to review the global trademark rights and accreditations for
Navico Holding AS and other entities.
Copyright
Copyright © 2022 Navico Holding AS.
Warranty
The warranty card is supplied as a separate document. In case of any queries, refer to the brand website of your unit or system:
www.lowrance.com, www.simrad-yachting.com, www.bandg.com.
*988-13101-001*

Wiring
Mounting
Overview
Power
The NMEA 2000® remote button is powered by the NMEA 2000®network at 12 V DC via an NMEA 2000®Micro-C connector
(male).
Create Crew Overboard waypoint
To create a Crew Overboard waypoint at your vessel’s location, press the NMEA 2000® remote button once. When pressed, the LED
light around the button lights up at maximum level.
Delete Crew Overboard waypoint
A Crew Overboard waypoint can only be deleted from the MFD or a compatible instrument display (such as Triton2).
The NMEA 2000®remote button is an external push button, connected to the NMEA®backbone, used to mark a Crew Overboard
waypoint at the vessel’s location. If an emergency occurs, you can create a Crew Overboard waypoint by pressing the NMEA 2000®
remote button. Pressing the remote button repeatedly creates multiple waypoints.
A GPS sensor
B MFD
C NMEA 2000®remote button
Dimensions
20.0 mm
(0.78”)
12.0 mm
(0.47”)
87.7 mm
(3.45”)
41.2 mm
(1.62”)
16730.0 mm
(658.66”)
Ø 25.0 mm
(0.98”)
TT
A
B
C
12 V DC
T
NMEA 2000®
Terminator
NMEA 2000®
Backbone
NMEA 2000®
Drop cables
NMEA 2000® remote button
Technical specifications
Environmental
Operating temperature -15°C to +55°C (5°F to 131°F)
Waterproof rating IP67
Electrical
Power supply voltage 12 V DC
Operating voltage 9 V DC - 18 V DC
Power consumption 1 LEN, 0.39 W (28 mA at 13.8 V)
Reverse polarity protection Yes
Physical
Weight 0.13 kg (0.3 lbs)
Supported sentences
Sentence Description PGN RX TX
MOB Crew Overboard Notification 127233 
NMEA 2000® remote button label
1:1 Scale
Ø 52.0 mm
(2.04”)
Ø 22.5 mm
(0.88”)
