Bang & Olufsen BEOVISION 10-32 User manual

BeoVision 10-32

This Getting Started contains information about the daily use of your Bang& Olufsen
product and connected equipment. We expect your retailer to deliver, install and
set up your product.
Your television offers more features and functions than described in this Getting Started.
Among other things; Timer functions and auto standby, editing and naming channels.
These and other features are described in more detail in a Guide.
The Guides are found on www.bang-olufsen.com/guides
DVB functions are described in a separate Guide. The Guides are kept up to date if
new software introduces new or modied features and functions in your television.
On www.bang-olufsen.com you can also nd further information and relevant
FAQs about your product.
Your Bang& Olufsen retailer is your rst stop for all your service queries.
To nd your nearest retailer, visit our website…
www.bang-olufsen.com
Dear Customer
3510709 1009
Technical specications, features and the use
thereof are subject to change without notice.

Cautions
– Ensurethatthetelevisionispositioned,setup
andconnectedinaccordancewiththe
instructionsinthisGettingStarted.
–Placeyourtelevisiononarm,stablesurface.
Topreventinjury,useBang&Olufsenapproved
standsandwallbracketsonly!
–Donotplaceanyitemsontopofyourtelevision.
– Donotsubjectthetelevisiontorain,high
humidityorsourcesofheat.
– Thetelevisionisdevelopedforindooruseindry,
domesticenvironmentsonly.Usewithina
temperaturerangeof10–40°C(50–105°F),and
atanaltitudeofnomorethan1,500m
(5,000ft).
– Donotplacethetelevisionindirectsunlight,
asthismayreducethesensitivityoftheremote
controlreceiver.
– Leaveenoughspacearoundthetelevisionfor
adequateventilation.
–Connectallcablesbeforeconnectingor
reconnectinganyoftheproductsinyoursystem
tothemains.
– Nonakedamesources,suchaslightedcandles
shouldbeplacedontheapparatus.
– Donotattempttoopenthetelevision.Leave
suchoperationstoqualiedservicepersonnel.
– Donotstriketheglasswithhardorpointed
items.
– Thetelevisioncanonlybeswitchedoffcompletely 
bydisconnectingitfromthewallsocket.
– Thesuppliedmainscordandplugarespecially
designedforthetelevision.Ifyouchangethe
plugorinanywaydamagethemainscord,
itcanaffecttheTVperformance.
Readtheseinstructions.
Keeptheseinstructions.
Heedallwarnings.
Followallinstructions.
Donotusethisapparatusnearwater.
Cleanonlywithdrycloth.
Donotblockanyventilationopenings.Installin
accordancewiththemanufacturer’sinstructions.
Donotinstallnearanyheatsourcessuchas
radiators,heatregisters,stoves,orotherapparatus
(includingampliers)thatproduceheat.
Donotdefeatthesafetypurposeofthepolarized
orgrounding-typeplug.Apolarizedplughastwo
bladeswithonewiderthantheother.Agrounding
typeplughastwobladesandathirdgrounding
prong.Thewidebladeorthethirdprongare
providedforyoursafety.Iftheprovidedplugdoes
nottintoyouroutlet,consultanelectricianfor
replacementoftheobsoleteoutlet.
Protectthepowercordfrombeingwalkedon
orpinchedparticularlyatplugs,convenience
receptacles,andthepointwheretheyexitfrom
theapparatus.
Onlyuseattachments/accessoriesspeciedbythe
manufacturer.
WARNING:Toreducetheriskoffireor
electricshock,donotexposethis
appliancetorainormoisture.Donot
exposethisequipmenttodrippingor
splashingandensurethatnoobjects
filledwithliquids,suchasvases,are
placedontheequipment.
Tocompletelydisconnectthisequipment
fromtheACMains,disconnectthemains
plugfromthewallsocket.Thedisconnect
deviceshallremainreadilyoperable.
Thelightningflashwitharrowhead
symbolwithinanequilateraltriangle,
isintendedtoalerttheusertothe
presenceofuninsulated“dangerous
voltage”withintheproduct’s
enclosurethatmaybeofsufficient
magnitudetoconstituteariskof
electricshocktopersons.
Theexclamationpointwithinan
equilateraltriangleisintendedtoalert
theusertothepresenceofimportant
operatingandmaintenance(servicing)
instructionsintheliterature
accompanyingtheproduct.

Daily use
Contents
Daily use
6 How to use your remote control
8 Introduction
10 Watch television
12 Look up teletext
14 Watch television via the DVB module
16 Change sound type and picture format
Installation
18 Set up your television
20 Connection panels
22 First-time setup of your television

TV LIGHT RADIO
DTV DVD CD
V.MEM TEXT A.MEM
7 8 9
4 5 6
LIST 0 MENU
1 2 3
STOP PLAY
BACK
How to use your remote control
Important – for more information: www.bang-olufsen.com
Select colour specic functions
Adjust volume
To mute, press the middle of the button
The Beo4 display shows you the activated source or function
Navigation and centre button; move left, right, up and down , , and – move in
menus by pressing the button in the direction you need
Centre button is used for selecting and accepting
Rewind or wind, search backwards or forwards
Start playback of a DVD, CD or recording
Switch on the DVB module and watch digital television
Standby
Bring up the main menu of the active source
Pause and stop playback or recording
Switch on the TV*1
Select channels and enter information in on-screen menus
Step through channels
Hold for continuous step
Move backwards through menus and the Beo4 list. Long press to exit menus
completely
Beo4 operation
Your television can be operated with the Beo4 remote control.
Switch on teletext
Display extra “buttons” for functions or sources in the Beo4 display. Use or to
step in the list
Some buttons can be recongured during the setup process. See the Guide for further information.
NOTE! For general information about remote control operation, see the Guide enclosed with your remote control.
1*Beo4 buttons
TV
PLAY
TV
DTV
0 – 9
STOP
MENU
BACK
TEXT
LIST
6

STOP
PLAY
BACK
Living Room
TV V.MEM RADIO
DTV N.MUSIC N.RADIO
PC DVD CD
Daily use
2*About buttons
3*Coloured buttons
Actual zone
Soft buttons on Beo5
Light grey buttons indicate that you have to press a text in the display. Dark grey buttons indicate that you have to
press a hard button.
Press the wheel next to the colour to activate a coloured button.
Indicates the actual zone on Beo5 as it was named during the setup process.
Depending on the activated source, different soft buttons appear on the screen. Touch the screen to activate the function.
Start playback of a DVD, CD or recording
Step through channels or recordings
Hold for continuous step
Navigation button left, right, up and down – move in menus by pressing the
button in the direction you need
Standby
Rewind or wind, search backwards or forwards
Pause and stop playback or recording
Soft button, touch screen to select*2
Switch on a source or select a function
Centre button is used for selecting and accepting
Turn to adjust volume
To mute, turn quickly counter-clockwise
Bring up SCENE buttons, such as Zones or Speaker
Press again to return
Select colour specic functions*3
Press volume wheel next to the colour
Bring up digits to select for example channels
Press again to return
Back up through Beo5 displays
Move backwards through menus. Long press to exit menus completely
Beo5 operation
You can also operate your television with a Beo5. When Beo5 operation
is different from Beo4 operation, it is described separately.
PLAY
STOP
TV
BACK
+
7

Navigate in menus and select settings using your remote control. Pressing MENU
brings up the menus for the selected source*1.
Information about the selected source is shown at
the top of the screen. On-screen menus allow you
to adjust settings.
Display and menus
Introduction
Show menu*1 Switch on TV Switch on connected equipment
or
Important
On the rst pages in this Getting Started, you will nd an overview of the buttons on Beo4 and Beo5.
For general information about remote control operation, see the Guide enclosed with your remote
control.
While using the digital tuner or external equipment, you must press MENU twice to bring up the TV
SETUP menu.
Remote control
1*TV SETUP menu
TV SETUP
SLEEP TIMER
PLAY TIMER
OPTIONS
select
TV V. MEM MENU
8
Menu name
Menu options
Information eld
Example of on-screen menu

Daily use
When a menu is on the screen, you can move
between menu options, reveal settings or enter
data.
Navigate in menus
Select option/
setting
Enter data Bring up sub-
menu/store
setting
Select option Move
backwards
through menus
BEO4 SETTING menu
In the OPTIONS menu, you can bring up the BEO4 SETTING menu. In this menu you must set up your
television to be operated with a Beo4 with or without a navigation button. Remember to set your Beo4
remote control to the correct mode. See the Beo4 Guide or contact your Bang& Olufsen retailer for
further information. This Getting Started and the Guide describe operation with the BEO4 SETTING
menu set to NAVIGATION BUTTON and the remote control set to MODE 1.
or
Press and hold to
exit menus
0 – 9 BACK BACK
9

Watch television
Select a TV channel, bring up a channel list or adjust the
sound volume. Beo4 operation
Activate the TV source to use these functions Switch on the TV
Select a TV channel
Adjust the volume
Bring up a channel list
Switch off the TV
Turn the TV
If your television is equipped with a motorised stand, you can turn it
by means of the remote control.
Useful hints
1*TV positions Position1 is the far left position and Position9 is the far right.
TV CHANNEL LIST
CNN 1
… 2
DISCOVER 3
CWNBC 4
BBCWORLD 5
… 6
… 7
… 8
SUPER CH 9
… 10
CRIME TV 11
CINEMA 12
… 13
MOVIE NW 14
… 15
… 16
… 17
… 18
more select
10
Channel name
Channel number
Indicates that more channels are
available

Daily use
Beo5 operation
Press
Select Select channel Select previous channel
Press
Hold for
channel list
Select page Select
channel Accept
Adjust volume
up or down
Press in the middle
to mute sound
Press to bring back sound
Press
Press
Select Activate numbers and
select channel
Previous
channel
or
Hold for channel list and
select page or channel
Accept
Adjust volume. To mute,
turn quickly counter-
clockwise
Turn either way to
bring back sound
Press to nd
STAND
Bring up
STAND
Turn TV Select position*1 Press Turn TV Select
position*1
or or
or
or
TV
TV
0–9
0–9 Previous 0
+
Stand Turn
Position
1…9
LIST 1–9
11

Look up teletext
Operate teletext through the menu bar at the top of the
teletext page or the arrow buttons on your remote control. Beo4 operation
Activate teletext to use these functions Start teletext
Move to page
Stop subpages from turning
Enlarge teletext page
MEMO pages
Exit teletext
Useful hints
MEMO pages
Dual screen
REVEAL
For quick access, store a teletext page as a MEMO page. See the Guide for further information.
When teletext is activated, pressing TEXT swaps between dual screen and full screen mode.
To reveal hidden text on a teletext page, move to REVEAL and press the centre button.
Access the start page of teletext.
Access teletext pages you wish to see.
MEMO is only available, when memo pages are stored.
PAGE MEMO HALT LARGE REVEAL SETUP
P100 BBC S100 Wed 13 Oct 12:39:34
12
Current page
Enlarge teletext pages
Stop subpage
turning
Reveal hidden text on
‘REVEAL’ and make
settings on ‘SETUP’

Daily use
Press repeatedly to change screen mode
Select page Move to PAGE and step Go to index pages
(100, 200, 300…)
Stop turning Move to HALT Select subpage Restart
turning
Move to LARGE Press to switch between upper and lower half of page
and normal viewing
Press repeatedly to change screen mode
Select page Move to PAGE and step
Stop turning Select subpage
Move to
LARGE
Switch between upper and lower
half and normal viewing
Switch
between
MEMO pages
Press
Press
Press
Press to switch between
MEMO pages
Teletext subtitles If you would like available subtitles to appear automatically for a particular channel, store the teletext
subtitles page as MEMO page9.
Restart
turning
Step up or
down in
pages
Beo5 operation
Move to MEMO and switch between stored MEMO
pages
Move to MEMO and switch between
pages
Step up or
down in
pages
TextTEXT
0–9
0–9
STOP 0–9
BACK
STOP
BACK
0–9
13
or or
or or
or
or
or or
or

Watch television via the DVB module
Useful hints
DVB Guide
1*Activate DVB module
For more extensive and updated information, please look up the DVB Guide on www.bang-olufsen.com/guides.
If the TV tuner is deactivated, use the TV button to switch on the DVB module. See the Guide for further information.
When your television is equipped with the DVB module,
you can receive digital terrestrial, cable and satellite
programmes depending on your module options.
Beo4 operation
Switch on the TV and the DVB module*1
Select a DTV channel
Bring up and use the menu overlay
Step between groups
Bring up a channel or station list
Switch off the TV
Activate the DTV source to use these functions
RADIO
PROGRAMME GUIDE
MENU
INFORMATION
CHANNEL GROUPS
SUBTITLES LANGUAGE
AUDIO LANGUAGE
SETUP
CHANNEL LIST
CA UNITS
1
2
3
4
5
6
14
DVB function
Beo4 button

Daily use
Select Select channel
or
Press
Press
Activate the desired function
Step between groups
Hold for
channel list
Select page Select channel Accept
Press
Press
Select Activate numbers and select
channel
Use the designated buttons in the display
Step between groups
Hold for channel list,
select page or
channel
Accept
Press
Beo5 operation
NOTE! Press MENU twice to bring up the TV
SETUP menu.
0–9
DTV
MENU 0–9
DTV
0–9
Menu
Groups+ Groups-
+
15
or
or
or

1*LIST menu
2*Optimise
3*Move picture up or down
4*Variation
In order to display SOUND and FORMAT on Beo4, you must rst add it to the Beo4 list of functions.
The picture format is optimised, if you press the centre button on Beo4. On Beo5, press Optimise.
The picture can only be moved up or down in FORMAT 1 and 2.
In FORMAT 1, you can select variations of the format. On Beo5, press Variation.
Sound type and picture format
While you watch TV, you can switch between available sound types. You can also
adjust the picture format.
Change sound type or language
Switch between available sound types and
languages.
Bring up SOUND in your Beo4
display*1Press repeatedly to
switch between
available sound types
Useful hints
Select picture format
The TV automatically adapts the picture to ll out
as much of the screen as possible when you select
a source, but you can select a format yourself.
Bring up FORMAT in your Beo4
display*1Select format*2 Move picture up or down*3 or
select variation*4
The picture is
adjusted vertically
For a genuine
16:9 widescreen
For panoramic
view or 4:3
The bars can be
removed and the
picture is shown
in a 16:9 format
Extended Wide Zoom Standard*4
FORMAT 1 FORMAT 2 FORMAT 3 FORMAT 4
or
1–4
16

Installation and setting up
18 Set up your television
20 Connection panels
22 First-time setup of your television
Contents – Installation and setting up 17

Set up your television
Important
Ventilation
Front glass
The television has several placement options. Follow the guidelines for placement
and connection.
Handling
We recommend that you place the TV in the
packaging while you fasten the wall bracket or the
bracket for the stand to the back of the TV.
Wall bracket and stand
The wall bracket can manually be turned 45˚ left or
right depending on your setup. Remember to leave
enough space around the TV to allow it to turn
and tilt freely.
Placement options
The TV can be placed on a motorised stand or
mounted on a wall bracket. Refer to www.bang-
olufsen.com for available stands and brackets or
contact your Bang & Olufsen retailer.
To ensure proper ventilation, allow enough space around the screen. Do not cover the fans. At over heating
(ashing standby indicator and an on-screen warning), switch the TV to standby, not off, in order for
the TV to cool down. You cannot operate the TV during this time.
If the front screen glass should crack or chip, or if it should be damaged in any way, it must be
replaced immediately, as it could otherwise cause injury. You can order replacement front screen
glass from your Bang& Olufsen retailer.
Due to the weight of the TV, any moving or lifting
of the TV should be performed by qualied
personnel – using the proper equipment.
Three protection proles have been enclosed with
the TV. Use these when moving the TV to avoid
scratching the frame.
18

Installation and setting up
Run cables
You can fasten the cables to either side or in the
middle, depending on wall bracket or stand
placement.
Overview
If you have a motorised stand, make sure that
there is enough slack in the cables to allow the
TV to turn to either side before you fasten the
cables with cable strips to make a neat bundle.
Fasten the front cloth cover
Locate the connection panel and other important
items:
When the TV is placed on a wall bracket or stand
you can attach the front cloth cover.
Hold the front cover with both hands and guide
the pins through the holes at the bottom. Then
carefully attach it to the top and adjust its position
before letting go.
During cleaning it is recommended to remove the
front cloth cover. Avoid spraying liquid directly on
the screen as this may damage the speakers, use a
soft cloth instead.
Carefully remove the front cover by supporting it
in the side and at the bottom.
1 Mounting bracket for wall bracket.
2 Mounting slot for stand or wall bracket.
3 Cover for the connection panel. Here you also
nd the mains supply connection. Pull out at
the bottom to remove the cover.
4 Depending on your setup lead the cables
through the hole in the middle of the cover or
remove the right (1A) or left cover (1B). The
middle part of the cover can be removed using
a pair of tongs.
Maintenance
Screen
Cabinet and controls
Never alcohol
Regular maintenance, such as cleaning, is the responsibility of the user.
Use a mild window cleaning uid and lightly clean the screen without leaving streaks or traces. Some micro-bre cloths
may harm the optical coating due to their strong abrasive effect.
Wipe dust off the surfaces using a dry, soft cloth. To remove stains or dirt, use a soft, damp cloth and a solution of water
and mild detergent, such as washing-up liquid.
Never use alcohol or other solvents to clean any parts of the TV.
Cleaning
19
1A 1B

Connection panels
Any equipment you connect to the main connection panel must be registered in
the CONNECTIONS menu.
Useful hints
HDMI IN (A, B and C)
For High Denition Multimedia Interface video
source or PC. The sources can be registered to any
of the AV socket groups. To expand the number
of HDMI sockets, connect an HDMI Expander/
MATRIX to the HDMIC socket.
SPDIF (1–2)
Digital audio input socket, e.g. DVD player. You can
use the socket in conjunction with an AV socket or
HDMI socket.
PUC (1–4)
For IR control signals to external equipment
connected to an AV socket.
AV 1, AV 2
21-pin sockets for connection of additional video
equipment, such as a DVD player, set-top box,
a decoder or video recorder.
POWER LINK
Sockets for connection of a Bang& Olufsen
subwoofer and/or external loudspeakers. See the
Guide for further information.
VGA (AV 3)
For connection of a PC to receive analogue
graphics.
AV 3 (R, L, video)
For audio connection (right and left sound
channel respectively) and video signals from an
external source.
Y – Pb – PR (AV 2–AV 4, AV 6)
For video signals from an external source, e.g. HDTV
source. You can use the socket in conjunction
with an AV socket or a digital audio socket.
DVB-T/C*1
Aerial input socket for an external aerial/cable TV
network.
DVB-S*1
Aerial input socket for a digital satellite signal.
1*DVB The number and types of DVB sockets depend on which optional DVB module is installed in the television.
20
Standard sockets
DVB Module sockets (optional)
