BANTE inststruments PHscan10L User manual

PHscan10L Pocket pH Tester
Instruction Manual
BANTE INSTRUMENTS CO., LTD

PHscan10L Pocket pH Tester
1
Thank you for selecting the PHscan10L pocket pH tester. This manual provides a step-by-step guide to help you operate the meter, please carefully read the
following instructions before use.
Installing the Batteries
•Remove the battery compartment lid.
•Insert the three G13A batteries into the battery compartment, note polarity.
•Replace the battery compartment lid and turn clockwise until it is tight.
Keypad Information
INDEX:
KEY
FUNCTION
MEAS/HOLD
• Switches the tester ON/OFF.
• Locks the measured value, press the key again to resume measuring.
• Exits the calibration and returns to the measurement mode.
CAL
• Starts calibration.
• Press the key again to select the pH buffer options.
ENTER
• Confirms the calibration or displayed option.

PHscan10L Pocket pH Tester
2
Prior to Use
•Remove the electrode protective cap from the tester.
•If the glass sensitive membrane on the electrode dries out, soak the electrode in 3M KCL solution or tap water for at least 15 minutes. DO NOT use
distilled or deionized water, it will render the electrode useless.
Preparing the pH Buffer Solutions
•Open the pH7.00 buffer packet, place the reagent into a 250ml volumetric flask. Pour the distilled water 250ml to scale line, mix the solution until the
reagent is completely dissolved.
•Preparation of pH4.01 and 10.01 standard buffer solutions are the same as above. Prepared standard buffer solutions should be stored in hermetically
sealed glass containers.
Switching the Tester On and Off
•Press the Meas key to switch on the tester, the display shows measured value.
•Press and hold the Meas key for 5 seconds, the tester will switch off.
•If you do not press any key for 8 minutes, the tester will automatically switch off to conserve energy.
Power On
5 sec.
Power Off
Glass Sensitive Membrane

PHscan10L Pocket pH Tester
3
pH Calibration
PHscan10L pocket pH tester must be calibrated prior to first use or new electrode replaced. To ensure accuracy, regular calibration is recommended. DO NOT
reuse the pH buffer solution after calibration, contaminants in solution will affect the calibration and eventually the accuracy of the measurement.
1. Rinse the electrode with distilled water. Press and hold the Cal key for 3 seconds, the display
shows CAL 7-4. If necessary, press the Cal key again, the display shows CAL 10-7.
2. Select the pH buffer option you require. Press the Enter key, the tester shows first calibration
point, pH7.00.
3. Place the electrode into the pH7.00 standard buffer solution, the end of the electrode must be
completely immersed into the calibration solution. Stir the tester gently to create a
homogeneous solution.
4. Press the Enter key, the tester begins the calibration. Wait for the reading to stabilize, the
calibration value will flash three times indicating that the first calibration point is completed.
The display automatically shows CAL 4 or CAL 10.

PHscan10L Pocket pH Tester
4
5. Rinse the electrode with distilled water. Place the electrode into the pH4.01 (or 10.01)
standard buffer solution. Stir the tester gently.
6. Press the Enter key. Wait for the reading to stabilize, the calibration value will flash
three times and the CAL icon disappears from the display. Calibration is completed.
If you want to exit the calibration, press the Meas key, the tester will immediately return
to the measurement mode.
pH Measurement
•Rinse the electrode thoroughly with distilled water.
•Place the electrode into the sample solution, stir the tester gently.
•Record the measured value when the reading is stable.
Data Hold
During the measurement, press the Hold key, the tester immediately locks the displayed value, the icon appears on the display. Press the key again
to resume measuring.
Electrode Care and Maintenance
•For best results, please always keep the glass sensitive membrane wet.
•Ensure that the electrode is thoroughly washed with distilled or deionized water after use.
•If you do not use the tester for long periods, store the electrode into the 3M KCL solution.

PHscan10L Pocket pH Tester
5
Electrode Replacement
When the tester fails to calibrate or gives fluctuating readings for calibration standards, you need to replace the electrode.
1. Twist the electrode collar counter clockwise, pull the old electrode away from the tester.
2. Align the slot on the new electrode, gently push the electrode into the tester.
3. Twist the electrode collar clockwise until it is tight. Installation is completed.
Troubleshooting
LCD DISPLAY
CAUSE
CORRECTIVE ACTION
Electrode dried out
Soak the electrode in 3M KCL solution at least 20 minutes.
Measured value is out of range
Check the electrode whether clogged, dirty or broken.
Incorrect pH buffer solutions
Using the fresh pH buffer solutions for calibration.
Electrode is broken
Replace the electrode.
pH Electrode Selection Guide
PHscan10L pocket pH tester installed with a long-reach pH electrode that is used to measure the pH of the small volume samples. If this electrode can not
meet your measurement requirements, please refer to the table below to select an applicable sensor.
ELECTRODE
ORDER CODE
DESCRIPTION
E-PHSCAN-S
General purpose pH electrode, suitable for measuring the non-viscous,
non-corrosive liquids.
E-PHSCAN-F
Flat surface pH electrode, suitable for measuring the semisolid
substances, e.g., cheese, meats, paper, etc.

PHscan10L Pocket pH Tester
6
Specifications
Model
PHscan10L
Range
0.0~14.0pH
Accuracy
± 0.1pH
Resolution
0.1pH
Calibration Points
2 points
pH Buffer Options
USA (pH4.01/7.00/10.01)
Automatic Buffer Recognition
Yes
Sensor Type
E-PHSCAN-L
Operating Temperature
0~60° C, 32~140° F
Relative Humidity
< 80%
Power Requirements
3 × 1.5V "G13A" batteries
Dimensions
240 (L) × 40 (Dia.) mm
Weight
100g

Hazardous Substance Statement
Bante Instruments is committed to the reduction and eventual elimination of all hazardous substances in both the manufacturing process and finished
products we supply. We have an active manufacturing and procurement program to minimize and eliminate the use of harmful heavy metals such as
cadmium, lead, mercury and the like. New technologies and design parameters are also promoting these efforts and we expect to have little or no such
materials in our product in the coming years. We welcome our customer suggestions on how to speed up these efforts.
Warranty
The warranty period for tester is one year from the date of shipment. Above warranty does not cover the sensor and calibration solutions. Out of warranty
products will be repaired on a charged basis. The warranty on your tester shall not apply to defects resulting from:
•Improper or inadequate maintenance by customer.
•Unauthorized modification or misuse.
•Operation outside of the environment specifications of the products.
For more information, please contact the nearest authorized distributor.
BANTE INSTRUMENTS CO., LTD
E-mail: [e-mail]
Phone: [phone]
Website: www.bante-china.com
The information in this document is subject to change without notice. Copyright © Bante Instruments, 2018. All rights reserved.
