Baquapure HIGH RATE SAND FILTER User manual

OWNER’S MANUAL
HIGH RATE SAND FILTER
T ROUBLE S HOOTING
WARNING: NEVER RUN PUMP WITH SLICE VALVE CLOSED!
WARNING: NEVER CHANGE VALVE POSITION WITH PUMP RUNNING!
CCSS 5000DX W ATER P OLISHER U SE
Warning: To reduce the risk of injury and product damage when using optional polishers:
• Never use any chemicals or components other than as recommended
• Never mix chemicals.
• Always wear protection for eyes, skin and clothing.
• Do Not Smoke. Avoid sparks and open Flames.
• Turn off pump and close valves before installing or servicing water polisher.
W INTERIZATION
1. Backwash filter system completely. See Cleaning Instructions.
2. Run a filter cleaning chemical through filter system as per cleaner instructions.
3. Turn pump off. Disconnect hoses from skimmer and return fitting.
4. Remove drain plug cap from bottom of filter tank. Do Not remove hex drain assembly, #28.
5. Unscrew drain plugs located at bottom of pump trap and front of pump housing. Let water drain completely.
6. Disconnect filter to pump connection. Loosen union connection on discharge of pump and remove from pump. Do Not lose 2″
union gasket. Lift and remove pump and pump base from filter base. Store inside.
Limited Warranty:
Leisure Bay manufactures its products and equipment in accordance with very high standards of
workmanship. We use the best materials available and maintain the highest quality procedures practical
in the industry. In accordance, Leisure Bay warrants its products as follows:
Warranty only applies to
OEM’s and Distributor’s of Waterway.
All parts manufactured by Leisure Bay will be replaced or repaired of the defects as determined by
Leisure Bay for a period of THREE YEARS from the date of purchase. The warranty does not cover O-
rings, pressure gauges, pump seals or any other parts not manufactured by Leisure Bay.
Baquapure pumps are covered by a limited warranty from any defects in material or workmanship for a
period of THREE YEARS from the date of purchase. This warranty includes the motor but excludes the
motor seal.
All rotational molded sand filter bodies have a warranty of TENYEARS, warranted on a pro-rated basis.
If a defect becomes apparent during the first three (3) years, the body will be exchanged for a new body
if the defects are determined by Leisure Bay to be the responsibility of Leisure Bay. If a defect becomes
apparent after three (3) years from the date of purchase and in the opinion of Leisure Bay will require
\replacement, the body will be exchanged on an adjusted on a pro-rated basis. Charges to the owner,
based on a pro-rated basis will be determined by the actual number of months installed beginning with
the date of purchase.
Products that fail or become defective during the warranty period, except as a result of improper instal-
lation, bad water chemistry, accidents or negligence on behalf of the owner, freezing, earthquake, fire,
floods, or any other acts of nature, shall be repaired or replaced at Leisure Bay option without charge to
the owner. This process will be completed within 90 days of receipt of the defective product barring
delays caused by the acquisition of component parts not manufactured at our facility.
To obtain warranty replacements or repair, defective products should be returned (transportation paid)
to the place of purchase or to Leisure Bay. It should include a description of the defect and the
circumstances surrounding the incident or problem.
Warranty begins on the date of purchase. Leisure Bay shall not be responsible for cartage, removal and/or
installation or any other costs incurred in obtaining warranty replacements.
This warranty gives you specific legal rights. You may also have other rights which vary from state
to state.
M OTOR D OES N OT S TART :Make sure motor is plugged in.
Circuit breaker in OFF position.
Thermal Overload in tripped position.
Wiring installation incorrect.
Incorrect line voltage.
Defective wiring.
T
HERMAL O VERLOAD T RIPS :Low Voltage.
Wiring installation incorrect.
Dual voltage pumps mis-wired.
Inadequate ventilation.
N
O W ATER F LOW :Obstruction of suction or return line.
Clogged impeller.
Suction system air leaks.
Slice Valve Closed.
Clogged Hose Fitting.
Clogged Basket.
Dirty Sand.
E
XCESSIVE P UMP N OISE :Worn Bearings.
Suction Line Clogged.
Pump incorrectly mounted.
Hose Fitting partially closed.
Slice Valve partially closed.
Clogged Trap Basket.
I
NADEQUATE F ILTERING :Sand level too low.
Inadequately cleaned system.
Excessive dirt load.
Chemical imbalance.
Inadequate system pressure.
WATERWAY PLASTICS 2200 EAST STURGIS RD. OXNARD, CA 93030
111402 810-0081-LB R8

FLOW
26
23
19
4
14
29
25
17
15
12
11
10
9
7
45
2
21
16
13
30
32
28
24
22
20
18
1
33
31
27
34
35
36
37
38
39
See Valve Functions
Instruction Sheet for
proper valve alignment.
2
3
3
2
4
Filter
Front
Label
32
33
10
11
6
SAVE THESE INSTRUCTIONS
Read all instructions prior to installation
IMPORTANT: Follow all national and local building and safety codes.
Your Baquapure Sand Filter System is shipped with all needed components ready for assembly and installation.
S AFETY
Warning: A GFCI is required. System will require a 110Volt / 20 Amp service. DO NOT use extension cords. Use will void warranty
on pump motor. The pool equipment should be located between the pool skimmer and return line. The filtration system should not be installed
less than 2' and no more than 5' from the pool. The Baquapure Sand Filter System needs to be on a completely flat / level surface. (patio block,
cement slab, etc.). Assemble filter system only after above ground pool is installed. Fill pool with water. Important: Do Not raise water level
above pool return line or skimmer throat until installation is complete. Note: Open shipping carton in an upright position, checking con-
tents, as follows:
SEE ENCLOSED WATER POLISHER ASSEMBLY INSTRUCTIONS
1. Pump and trap assemblies
2. Pump mounting base
3. Filter and base
4. One filter / pump hose
5. Two corrugated hoses
6. One fittings bag
7. One Collar Wrench
8. Water Polisher
9. Water Polisher Base
R EPLACEMENT P ARTS
Inlet
Pump
Outlet
Pool
Multi-Port Valve Ports
C LEANING I NSTRUCTIONS
Note: When pressure gauge reading is 5 PSI or higher than original starting pressure, the filter needs to be cleaned. The Baquapure Sand Filter
System features our exclusive 7 Position Multiport Valve, which ensures safe and simple filter maintenance.
Pressurized vessel. Never attempt to loosen or open Collar Assembly, #16, P/N 718-1960 and #17, P/N 819-0015, while system is
running. It could cause severe injury or harm to user.
1. Turn off pump.
2. Attach Backwash hose (optional) to waste port adapter.
3. Rotate Multiport Valve handle to Backwash position, Turn pump on and run for 90 second intervals or until discharge water is clear. Turn pump off.
4. Rotate Multiport Valve handle to Rinse position. Turn pump on for 30 seconds.
5. Repeat steps 3 & 4 until all discharge water is clear while pump is turned on.
6. Rotate Multiport Valve handle to Filter position. Turn pump on. Valve is now in normal operating position
Item Part No. Description
1 LB5501860 22″ Model, Hose Assembly
LB5501870 26″Model, Hose Assembly
2 711-4000 11⁄2″Gasket
3 417-4161 11⁄2″Buttress x 11⁄2″MPT
4 805-0224 O-Ring
5 419-4161 2″ NPT x 11⁄2″Buttress Coupling
6 902-2000 Teflon Tape
7 CCSS-5000 Water Polisher
8 819-0004 Screw (4) #10x1 PPH
9 CABASE-V Water Polisher Base
10 600-8171 Check Valve Adapter Assembly
11 872-0011 Hose Clamp, Stainless Steel
12 872-9002 Corrugated Hose, Black
13 830-2000-LB 0-30 PSI Gauge
14 WVS003-BP Multiport Valve Assembly
15 425-1928 Waste Adapter Fitting
16 505-1970 Collar Wrench
17 505-3010 Split Nut, Sand Filter Assembly
18 819-0015 Screw, 1⁄4″ 20 PPH X 2″
19 820-0013 Hex Nut, Serrated 1⁄4″ 20
20 805-0435 O-Ring
21 505-2060 22″ Lateral and Manifold Assembly
505-2080 26″ Lateral and Manifold Assembly
Item Part No. Description
22 505-3000 Threaded Sleeve for Split Nut
23 LB5152000 22″ Sand Filter Body
LB5152060 26″ Sand Filter Body
24 502-2011 Sand Fill Guide
25 505-2020 Drain Assembly
26 505-2030 Drain Cap Assembly
27 820-0017 Washer 3⁄8″Flat
28 819-0016 Bolt for 22″, 26″Sand Filter 3⁄8″16x 11⁄2″Hex
29 672-7211 Filter Base
30 672-7201 Pump Base
31 PB2200 2 HP, 2 SPD Baquapure Pump
PB2250 2.5 HP, 2 SPD Baquapure Pump
32 429-7300 Pin & Anchor Assembly
33 711-4010 2″ Gasket
34 LB5501821 22″Sand Filter Hose Assembly
LB5501831 26″Sand Filter Hose Assembly
35 319-3230 6″Basket Assembly (Not Shown)
36 319-2170 6″ Pump Trap Body
37 805-0436 O-Ring
38 319-3260 6″Pump Trap Lid
39 WV001U Slice Valve with Gasket
810-0081-LB R8 Instruction Sheet
6
REPLACEMENT PARTS DIAGRAM
Optional for hard plumbing
11⁄2″ #7 Union Assembly
11⁄2″ Slip Pump end
Not Included
P/N# 400-4060
Pin & Anchor
Assembly
#31
Screw (4)
#10x1 PPH
#8
