Barazza 1MCFY User manual

Instructions for Use EN
Istruzioni di uso IT
1MCFY
1630881-b

2
EN
Contents
Safety Information ..............................................................................................................................3
Safety Instructions .............................................................................................................................7
The advantages of microwaves.........................................................................................................8
Description of your oven....................................................................................................................9
Description of Functions..................................................................................................................10
Basic controls...................................................................................................................................11
Basic Functions................................................................................................................................13
Special functions..............................................................................................................................18
Using the Browning Plate ................................................................................................................21
When the oven is working................................................................................................................22
Defrosting..........................................................................................................................................23
Cooking with a microwave oven .....................................................................................................25
Cooking with the Grill.......................................................................................................................27
Roasting and baking.........................................................................................................................30
What kind of ovenware can be used?.............................................................................................32
Oven Cleaning and Maintenance.....................................................................................................34
What should I do if the oven doesn’t work?...................................................................................36
Technical characteristics.................................................................................................................37
Installation instructions ...................................................................................................................38
Installation.........................................................................................................................................76
Dear Customer,
Thank you for choosing this BARAZZA product.
We ask you to read the instructions in this booklet very carefully as this will allow you to get the best
results from using it.
KEEP THE DOCUMENTATION OF THIS PRODUCT FOR FUTURE REFERENCE.
Always keep the instruction manual handy. If you lend the appliance to someone else give them
the manual as well!
The user manual is also available for download at www.barazzasrl.it

3
EN
Safety Information
Before the installation and use of the appliance, carefully read
the supplied instructions. The manufacturer is not responsible if an
incorrect installation and use causes injuries and damages. Always
keep the instructions with the appliance for future reference.
CHILDREN AND VULNERABLE PEOPLE SAFETY
Warning! Risk of suffocation, injury or permanent disability.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they are
supervised by an adult or a person who is responsible for their
safety.
Do not let children play with the appliance.
Keep all packaging away from children.
Warning: Keep children away from the appliance when it
operates or when it cools down. Accessible parts are hot.
If the appliance has a child safety device, we recommend that
you activate it. Children under 3 years must not be left
unsupervised in the vicinity of the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
GENERAL SAFETY
This appliance is intended to be used in household and similar
applications such as:
–staff kitchen areas in shops, offices and other working
environments;
–farm houses;
–by clients in hotels, motels and other residential environments;
–bed and breakfast type environments.
Internally the appliance becomes hot when in operation. Do not
touch the heating elements that are in the appliance. Always use
oven gloves to remove or put in accessories or ovenware.

4
EN
Safety Information
Warning: Do not heat liquids and other foods in sealed
containers. They are liable to explode.
Only use utensils that are suitable for use in microwave ovens.
When heating food in plastic or paper containers, keep an eye on
the appliance due to the possibility of ignition.
The appliance is intended for heating food and beverages. Drying
of food or clothing and heating of warming pads, slippers,
sponges, damp cloth and similar may lead to risk of injury,
ignition or fire.
Warning! The oven cannot be used if:
- The door is not closed correctly;
- The door hinges are damaged;
- The surfaces of the contact between the door and the oven front
are damaged;
- The door window glass is damaged;
- There is frequent electrical arcing inside the oven even though
there is no metal object inside.
The oven can only be used again after it has been repaired by a
Technical Assistance Service technician.
If smoke is emitted, switch off or unplug the appliance and keep
the door closed in order to stifle any flames.
Microwave heating of beverages can result in delayed eruptive
boiling. Care must be taken when handling the container.
The contents of feeding bottles and baby food jars shall be stirred
or shaken and the temperature checked before consumption, in
order to avoid burns.
Eggs in their shell and whole hard-boiled eggs should not be
heated in the appliance since they may explode, even after
microwave heating has ended.
INSTALLATION
The electrical installation is to be set up so that the appliance can
be isolated from the mains with a minimum 3mm all-pole contact
separation.

5
EN
Safety Information
Suitable separation devices include e.g. cutouts, fuses (screw
fuses are to be taken out of the holder), RCD’s and contactors.
This installation must comply with current regulations.
If the electrical connection is done through a plug and this
remains accessible after installation, then it is not necessary to
provide the mentioned separation device.
Protection against electric shock must be provided by the
electrical installation
Warning: The oven must be earthed.
CLEANING
The appliance should be cleaned regularly and any food deposits
removed.
Failure to maintain the appliance in a clean condition could lead
to deterioration of the surface that could adversely affect the life
of the appliance and possibly result in a hazardous situation.
Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the glass door since they can scratch the surface, which
may result in shattering of the glass.
Do not use a steam cleaner to clean the appliance.
The door contact surfaces (the front of the cavity and the inside
part of the doors) must be kept very clean in order to ensure the
oven functions correctly.
Please follow the instructions regarding cleaning in the section
"Oven Cleaning and Maintenance".
REPAIRS
Warning: Before maintenance cut the power supply.
Warning: Only a competent person can carry out any service or
repair operation that involves the removal of a cover which gives
protection against exposure to microwave energy.
Warning: If the door or door seals are damaged, the appliance
must not be operated until it has been repaired by a competent
person.

6
EN
Safety Information
If the power cable is damaged it should be substituted by the
manufacturer, authorized agents or technicians qualified for this
task in order to avoid dangerous situations. Furthermore, special
tools are required for this task.
Repair and maintenance work, especially of current carrying
parts, can only be carried out by technicians authorized by the
manufacturer.

7
EN
Safety Instructions
Warning! Do not heat pure alcohol or
alcoholic drinks in the microwave. FIRE
RISK!
Beware!
To avoid food overheating or burning it is
very important not to select long time periods
or power levels that are too high when
heating small quantities of food. For example,
a bread roll can burn after 3 minutes if the
power selected is too high.
For toasting, use just the grilling function and
watch the oven all the time. It you use a
combined function to toast bread it will catch
fire in a very short time.
Make sure you never catch the power cables
of other electrical appliances in the hot door
or the oven. The cable insulation may melt.
Danger of short-circuiting!
Take care when heating liquids!
When liquids (water, coffee, tea, milk, etc.)
are nearly at boiling point inside the oven and
are taken out suddenly, they may spurt out of
their containers.
DANGER OF INJURIES AND BURNS!
To avoid that type of situation when heating
liquids, put a teaspoon or glass rod inside the
container.
Avoid damaging the oven or other
dangerous situations by following these
instructions:
Do not switch on the oven without the
turntable support, the turntable ring and the
respective plate being in place.
Never switch on the microwave when it is
empty. If there is no food inside there may be
an electrical overcharge and the oven could
be damaged.
RISK OF DAMAGE!
For carrying out oven programming tests put
a glass of water inside the oven. The water
will absorb the microwaves and the oven will
not be damaged.
Do not cover or obstruct the ventilation
openings.
Use only dishes suitable for microwaves.
Before using dishes and containers in the
microwave, check that these are suitable
(see the section on types of dishes).
Never remove the mica cover on the ceiling
of the oven interior! This cover stops fat and
pieces of food damaging the microwave
generator.
Do not keep any inflammable object inside
the oven as it may burn if the oven is
switched on.
Do not use the oven as a pantry.
Do not use the oven for frying as it is
impossible to control the temperature of oil
heated by microwaves.
Do not lean or sit on the open oven door.
This may damage the oven, especially in the
hinge zone. The door can bear a maximum
weight of 8 kg.
The turntable and the grills can bear a
maximum load of 8 kg. To avoid damaging
the oven, do not exceed this load.

8
EN
The advantages of microwaves
In conventional ovens, heat radiated by electrical
elements or gas burners slowly penetrates the
food from outside to inside. On account of this
there is a major amount of energy is wasted
heating the air, the oven components and the food
containers.
In a microwave oven, heat is generated by the
food itself and the heat travels from inside to
outside. No heat is lost to the air, the walls of the
oven cavity or the dishes and containers (if these
are suitable for use in microwave oven), in other
words, only the food is heated.
Microwave ovens have the following advantages:
1. Shorter cooking times; in general these are
up to 3/4 less than the time required for
conventional cooking.
2. Ultra-fast food defrosting, thus reducing the
danger of bacterial development.
3. Energy savings.
4. Conservation of the nutritional value of foods
due to the shorter cooking times.
5. Easy to clean.
How a microwave oven works
In a microwave oven there is a high tension valve
called a magnetron which converts electrical
energy into microwave energy. These
electromagnetic waves are channelled to the
interior of the oven through a wave guide and
distributed by a metallic spreader or through a
turntable.
Inside the oven the microwaves propagate in all
directions and are reflected by the metal walls,
uniformly penetrating the food.
Why food heats up
Most foods contain water and water molecules
vibrate when subjected to microwaves.
The friction between molecules produces heat
which raises the temperature of the food, de-
freezing it, cooking it or keeping it hot.
Since the heat arises inside the food:
This can be cooked with little or no liquid or
fats/oils;
De-freezing, heating or cooking in a
microwave oven is quicker than in a
conventional oven;
The vitamins, minerals and nutritional
substances in the food are conserved;
The natural colour and aroma of the food are
unchanged.
Microwaves pass through china, glass, cardboard
or plastic but do not go through metal. For this
reason, metal containers or ones with metal parts
must not be used in a microwave oven.
Microwaves are reflected by metal...
... but go through glass and china...
... and are absorbed by foods.

9
EN
Description of your oven
1.
Function lights
4a.
Power/Weight indication lights
2.
Function selection key
5.
Clock/ Time selection key
3.
Oven Temperature selection key
5a.
Clock/ Time indication lights
3a.
Oven Temperature indication light
6.
Start and Stop/ Safety blocking keys
4.
Power/Weight selection key
23:15
12
6
5
4
3
800
160
3a 4a 5a
1. Control panel
6. Turntable support
2. Door window glass
7. Turntable ring
3. Lateral supports
8. Turntable plate
4. Catches
9. Rectangular Glass tray
5. Hot Air Output
10. Rectangular Rack
11. Browning Plate

10
EN
Description of Functions
Symbol
Function
Microwave Power
Output
Foods
Microwave
200 W
Slow defrosting for delicate foods; keeping food hot.
400 W
Cooking with little heat; boiling rice.
Rapid defrosting, heating baby food.
600 W
Heating and cooking food.
800 W
Cooking vegetables and food.
Cooking and heating carefully.
Heating and cooking small portions of food.
1000 W
Rapidly heating liquids.
Microwave
+ Grill
200 W
Toasting food.
400 W
Grilling poultry and meat.
600 W
Cooking pies and cheese-topped dishes.
Grill
Grilling food.
Grill + Fan
---
Grilling meat and fish.
Grilling poultry.
Potatoes –deep-frozen, defrosting and roasting.
Hot-Air
---
Roasting and baking.
Microwaves +
Hot-Air
200-600 W
Quick meat, fish and poultry roasting.
Baking cakes.

11
EN
Basic Controls
Setting the clock
After your microwave oven is first plugged in or
after a power failure, the clock display will flash to
indicate that the time shown is not correct. To set
the clock, proceed as follows:
1. Press the Clock key. The hour numbers will
start to flash.
2. Press key “-” and “+”to set the hours.
3. Press again the Clock key to set the minutes.
The minute numbers will start to flash.
4. Press key “-” and “+”to set the minutes.
5. To finish, press the Clock key again.
Hiding/Displaying the Clock
If the clock display disturbs you, you can hide it by
pressing the Clock key for 3 seconds. The dots
that separate the hours and minutes will flash but
the rest of the clock display will be hidden.
If you want to see the clock display again, press
the Clock key again for 3 seconds.
Safety blocking
The oven functioning can be blocked (for
example, to stop it being used by children).
1. To block the oven, press the Stop key for 3
seconds. You will hear a sound signal and the
display will show the word “SAFE”. The oven is
blocked in this state and cannot be used.
2. To unblock the oven, press the Stop key
again for 3 seconds. You will hear a sound
signal and the display will show the time
again.

12
EN
Basic Controls
Stopping the rotating plate
1. To stop the rotating plate, press the “+”key and
the “Stop”key at the same time 2. To start plate rotation again, press the “+”Key and the “Stop”key at the same again.

13
EN
Basic Functions
Microwave oven
Use this function to cook and heat vegetables, potatoes, rice, fish and meat.
1. Press the Microwave function key. The
function key lights up.
2. Press the Power Selection key to change the
microwave power. The respective light will start
to flash. If you do not press this key, the oven
operates at 800 W power.
3. To change the microwave power press key “-”
and “+”.
4. Press the Time Selection key to change the
operating time. The correspondent light will
start to flash.
5. Press key “-”and “+”, to change the function
time (e.g. 1 minute).
6. Press the START key. The oven will start to
operate
NOTE: When 1000 W power is selected, the
operating time is limited to a maximum of 15
minutes.
Microwave oven –Quick Start
Use this function to rapidly heat foods with high water content, such as water, coffee, tea or thin soup.
1. Press the Start key. The oven starts to operate
in the Microwave function at maximum power
for 30 seconds.
2. If you want to increase the operating time press
the Start key again. Each time you press this
key the operating time will be increased by 30
seconds.
NOTE: When 1000 W power is selected, the
operating time is limited to a maximum of 15
minutes.
00:30
1000
1,2

14
EN
Basic Functions
Grill
Use this function to brown the top of food quickly.
1. Press the function key Grill. The function key
lights up.
2. Press the Time Selection key to change the
operating time. The correspondent light will
start to flash.
3. Press key “-”and “+”, to change the function
time (e.g. 15 minutes).
4. Press the Start key. The oven will start to
operate.
Microwave + Grill
Use this function to cook lasagne, poultry, roast potatoes and toasted foods.
1. Press the function key Microwave + Grill. The
function key lights up.
2. Press the Power Selection key to change the
microwave power. The respective light will
flash. If you do not press this key, the oven
operates at 600 W power.
3. To change the microwave power press key “-”
and “+”.
4. Press the Time Selection key to change the
operating time. The respective light will start to
flash.
5. Press key “-”and “+”, to change the function
time (e.g. 10 minutes).
6. Press the Start key. The oven will start to
operate.
NOTE: In combined mode, the microwave oven
power is limited to 600 W.

15
EN
Basic Functions
Hot air
Use this function to bake and roast.
1. Press the function key Hot air. The function
key lights up.
2. Press the Temperature Selection key to
change the temperature. The respective light
will flash. If you do not press this key, the
oven operates at 160 ºC.
3. To change the temperature press key “-”and
“+”.
4. Press the Time Selection key to change the
operating time. The respective light will start
to flash.
5. Press key “-”and “+”, to change the function
time (e.g. 12 minutes).
6. Press the Start key. The oven will start to
operate.
Microwave + Hot air
Use this function to bake and roast
1. Press the function key Microwave + Hot air.
The function key lights up.
2. Press the Temperature Selection key to
change the temperature. The respective light
will flash. If you do not press this key, the
oven operates at 160 ºC.
3. To change the microwave power press the
“-“and “+” keys.
4. Press the Power Selection key to change
the power. The respective light will start to
flash. If you do not press this key, the oven
operates at 400 W.
5. Press key “-”and “+”, to change the
temperature.
6. Press the Time Selection key to change the
operating time. The respective light will start
to flash.
7. Press key “-”and “+”, to change the function
time (e.g. 12 minutes).
8. Press the Start key. The oven will start to
operate,
NOTE: In combined mode, the microwave
oven power is limited to 600 W.
20:00
160
4
1
3,5
6
2
20:00
400
160
6
4
1
3,5,7
8
2

16
EN
Basic Functions
Grill with Fan
Use this function for crispy roast meat, fish, poultry or French fries
1. Press the function key Grill with Fan. The
function key lights up.
2. Press the Temperature Selection key to
change the temperature. The respective light
will flash. If you do not press this key, the
oven operates at 160 ºC.
3. To change the temperature press key “-”and
“+”.
4. Press the Time Selection key to change the
operating time. The respective light will start
to flash
5. Press key “-”and “+”, to change the function
time (e.g. 12 minutes).
6. Press the Start key. The oven will start to
operate.
Defrosting by time (manual)
Use this function to defrost any type of food quickly.
1. Press the function key Defrosting by time.
The function key lights up.
2. Press the Time Selection key to change the
function time. The respective light will flash.
3. Press key “-”and “+”, to change the function
time (e.g. 10 minutes).
4. Press the Start key. The oven will start to
operate.
20:00
160
4
1 3,5
6
2

17
EN
Basic Functions
Defrosting by weight (automatic)
Use this function to defrost meat, poultry, fish, fruit and bread quickly.
1. Press the function key Defrosting by
weight. The function key lights up.
2. Press the Food Type selection key to
change the food type. The respective lights
will flash.
3. Press key “-”and “+”, to change the
programme, e.g. “Pr 01” (see following
table).
4. Press the Weight Selection key to define
the food weight. The respective light will
flash.
5. Press key “-”and “+”, to change the weight.
6. Press the Start key. The oven will start to
operate.
Note: Turn the food whenever the oven lets out
a sound signal and the display flashes the
word: .
The following table shows the defrosting by weight function programmes, indicating weight intervals, and
defrosting and standing times (in order to ensure the food is of a uniform temperature).
Programme
Food
Weight (g)
Time (min)
Standing time (min)
Pr 01
Meat
100 –2000
2 –43
20 –30
Pr 02
Poultry
100 –2500
2 –58
20 –30
Pr 03
Fish
100 –2000
2 –40
20 –30
Pr 04
Fruit
100 –500
2 –13
10 –20
Pr 05
Bread
100 –800
2 –19
10 –20
Important Note: see “General instructions for defrosting”.

18
EN
Special functions
Special Function P1: Heating food
Use this function to heat various types of food.
1. Press the function key Special function P1.
The function key lights up.
2. Press the Food Type selection key to
change the food type. The respective lights
will flash.
3. Press key “-”and “+”, to change the
programme, e.g. “A 01” (see following table).
4. Press the Weight Selection key to define
the food weight. The respective light will
flash.
5. Press key “-”and “+”, to change the weight.
6. Press the Start key. The oven will start to
operate.
The following table shows the Special Function P1 programmes, indicating weight intervals, and
defrosting and standing times (in order to ensure the food is of a uniform temperature).
Programme
Food
Weight (kg)
Time (min)
Standing time
(min)
A 01
Soup
200 –1500
3 –15
Turn 1-2 x, keep
covered, 1-2 min.
A02
Pre-prepared dishes
dense food
200 –1500
3 –20
Turn 1-2 x, keep
covered, 1-2 min.
A 03
Pre-prepared dishes
e.g. goulash
200 –1500
3 –18
Turn 1-2 x, keep
covered, 1-2 min.
A 04
Vegetables
200 –1500
2,6 –14
Turn 1-2 x, keep
covered, 1-2 min.
Important Notes:
Always use dishes for use in the
microwave oven and a lid or cover to avoid
loss of liquids.
Stir or mix the foods several times during
heating.
The time required to heat the food will
depend on its initial temperature. Food
taken straight from the fridge will take
longer to heat up than food that is at room
temperature. If the food temperature is not
what is wanted, select a greater or lesser
weight next time you heat up the food.
After heating, stir the food or shake the
container and then leave the food to stand for
some time to allow the temperature to become
uniform throughout the food.
Warning! After heating the container may be very
hot. Although microwaves do not heat up most
containers, these may heat up through heat
transmission from food.

19
EN
Special functions
Special Function P2: Cooking
Use this function to cook fresh food.
1. Press the function key Special function P2.
The function key lights up.
2. Press the Food Type selection key to
change the food type. The respective lights
will flash.
3. Press key “-”and “+”, to change the
programme, e.g. “b 01” (see following table).
4. Press the Weight Selection key to define
the food weight. The respective light will
flash.
5. Press key “-”and “+”, to change the weight.
6. Press the Start key. The oven will start to
operate.
The following table shows the Special Function P2 programmes, indicating weight intervals, and
defrosting and standing times (in order to ensure the food is of a uniform temperature).
Programme
Food
Weight (kg)
Time (min)
Note
b 01
Potatoes
200 –1000
4 –17
Turn 1-2 x, keep
covered
b 02
Vegetables
200 –1000
4 –15
Turn 1-2 x, keep
covered
b 03
Rice
200 –500
13 –20
One part rice, two
parts water, keep
covered
b 04
Fish
200 –1000
4 –13
Keep covered
Important Notes:
Always use dishes for use in the
microwave oven and a lid or cover to avoid
loss of liquids.
Stir or mix the foods several times during
heating.
Warning! After heating, the container may be
very hot. Although microwaves do not heat up
most containers, these may heat up through
heat transmission from food.
Preparation instructions:
Fish pieces –Add 1 to 3 soup spoons of water
or lemon juice.
Rice –Add water equivalent to twice or three
times the quantity of rice.
Unpeeled potatoes –Use potatoes of the
same size. Wash them and prick the skin
several times. Do not add water.
Peeled potatoes and Fresh vegetables–Cut
into pieces of the same size. Add a soup
spoon of water for every 100 g of vegetables,
and salt to taste.
b01
200
2
4
1 3,5
6

20
EN
Special functions
Special Function P3: Defrosting & Toasting
Use this function to cook and toast various types of food.
1. Press the function key Special function P3.
The function key lights up.
2. Press the Food Type selection key to
change the food type. The respective lights
will flash.
3. Press key “-”and “+”, to change the
programme, e.g. “C 01” (see following table).
4. Press the Weight Selection key to define
the food weight. The respective light will
flash.
5. Press key “-”and “+”, to change the weight.
6. Press the Start key. The oven will start to
operate.
The following table shows the Special Function P3 programmes, indicating weight intervals, and
defrosting and standing times (in order to ensure the food is of a uniform temperature).
Programme
Food
Weight (kg)
Time (min)
Note
C 01
Pizza
300 –550
8 –12
Rack
C 02
Deep frozen food
350 –500
8 –14
Turn 1 x, keep
covered
C 03
Potato dishes, frozen
200 –450
10 –12
Glass plate
Important Notes:
Always use dishes that are suitable for
microwaving and heat resistant (eg baking
dishes). The oven produces very high
temperatures. For programme C 02 always
use a lid, to prevent loss of liquids.
Warning! After heating, the container may be
very hot. Although microwaves do not heat most
containers, they can get very hot due to heat
transfer
Preparation instructions:
Frozen pizza –Use pre-cooked frozen pizzas
and pizzas-rolls.
Deep-frozen food –Use lasagne, cannelloni,
prawn soufflé, all frozen. Keep covered.
Potato dishes, frozen –Chips, potato
croquettes and fried potatoes must be suitable
for preparation in the oven.
