Barco Matrix-PRO HD-SDI Setup guide

Manual #26-0301100-00/ Revision A
INSTALLATION AND OPERATOR’S MANUAL
16x Series
MatrixPROTM – Wideband A/V Switcher

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
ii
RECORD OF CHANGES
REV # DATE
ECO #
DESCRIPTION Approved By
A 8/16/04 1278 Release to Production J. Wickenhiser

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
iii
Operators Safety Summary
The general safety information in this summary is for operating personnel.
Do Not Remove Covers or Panels
There are no user-serviceable parts within the unit. Removal
of the top cover will expose dangerous voltages. To avoid
personal injury, do not remove the top cover. Do not
operate the unit without the cover installed.
Power Source
This product is intended to operate from a power source that
will not apply more than 230 volts rms between the supply
conductors or between both supply conductor and ground. A
protective ground connection by way of grounding conductor
in the power cord is essential for safe operation.
Grounding the Product
This product is grounded through the grounding conductor
of the power cord. To avoid electrical shock, plug the power
cord into a properly wired receptacle before connecting to
the product input or output terminals.
A protective-ground connection by way of the grounding
conductor in the power cord is essential for safe
operation.
Use the Proper Power Cord
Use only the power cord and connector specified for your
product. Use only a power cord that is in good condition.
Refer cord and connector changes to qualified service
personnel.
Use the Proper Fuse
To avoid fire hazard, use only the fuse having identical
type, voltage rating, and current rating characteristics.
Refer fuse replacement to qualified service personnel.
Do Not Operate in Explosive Atmospheres
To avoid explosion, do not operate this product in an
explosive atmosphere.
Terms In This Manual and Equipment Marking
Highlights an operating procedure,
practice, condition, statement, etc.,
which, if not strictly observed, could result
in injury to or death of personnel.
NOTE Highlights an essential operating
procedure, condition or statement.
CAUTION
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
AVERTISSEMENT!
Le point d´exclamation dans un triangle
equilatéral signale à alerter l´utilisateur qu´il
y a des instructions d´operation et d´entretien
tres importantes dans la litérature qui
accompagne l´appareil
WARNING
VORSICHT ein Ausrufungszeichen innerhalb eines
gleichwinkeligen Dreiecks dient dazu,
den Benutzer auf wichtige Bedienungs-und
Wartungsanweisungen in der Dem
Great beiliegenden Literatur aufmerksam zu
machen.

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
iv
CONTENTS
RECORD OF CHANGES .......................................................................................................................... II
CONTENTS................................................................................................................................................IV
CHAPTER ONE........................................................................................................................................... 1
1.0 Introduction......................................................................................................................... 2
1.1 About the MatrixPROTM 16x Series........................................................................................... 2
1.2 Features....................................................................................................................................... 2
1.3 Technical Description................................................................................................................. 3
CHAPTER TWO.......................................................................................................................................... 5
2.0 Installation........................................................................................................................... 6
2.1 Rear Panel Connectors................................................................................................................ 6
2.2 Rack-Mount Installation............................................................................................................. 6
2.3 Power Cord/Line Voltage Selection........................................................................................... 7
2.4 Dual Power Supply Version .......................................................................................................7
2.5 Video Input Connections............................................................................................................ 8
2.6 Video Output Connections ......................................................................................................... 9
2.7 Audio Input Connections............................................................................................................ 9
2.8 Audio Output Connections......................................................................................................... 9
CHAPTER THREE.................................................................................................................................... 11
3.0 Operation.................................................................................................................................. 12
3.1 Power-Up Initialization for MatrixPRO................................................................................... 12
3.2 MatrixProTM16x Front Panel Operation.................................................................................... 13
3.3 MP Control GUI Operation...................................................................................................... 17
CHAPTER FOUR...................................................................................................................................... 21
4.0 Connectivity Diagram............................................................................................................... 22
CHAPTER FIVE........................................................................................................................................ 23
5.0 Software Upgrade Instructions.............................................................................. 24
5.1 Overview .................................................................................................................................. 24
5.2 Hardware Requirements ...........................................................................................................24
5.3 Software Requirements............................................................................................................. 24
5.4 Connecting to Barco Folsom.................................................................................................... 24
5.5 Downloading Necessary Files .................................................................................................. 24
5.6 Installing the MatrixPRO Software Files and Flash File Loader.............................................. 24
5.7 Preparing to Upgrade the MatrixPROTM 16x............................................................................ 25
5.8 Starting the MatrixPROTM Flash File Loader Utility................................................................ 25

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
v
5.9 Verifying Communications between the Computer and MatrixPRO Unit............................... 25
5.10 Uploading Files to the MatrixPRO Unit................................................................................... 26
CHAPTER SIX........................................................................................................................................... 27
6.0 Serial Command Syntax Specification..................................................................................... 28
6.1 Uploading Files to the MatrixPROTM Unit............................................................................... 28
6.2 RS-232/485 Remote Control Connections................................................................................ 29
6.3 RS-232 Mode............................................................................................................................ 29
6.4 RS-485 Mode............................................................................................................................ 30
6.5 MatrixPROTM Remote Commands........................................................................................... 32
6.5.1 MatrixPROTM Serial Command List/Description................................................................. 32
CHAPTER SEVEN.................................................................................................................................... 39
7.0 Barco Folsom Warranty............................................................................................................ 40
7.1 Return Material Authorization (RMA)..................................................................................... 40
7.2 Barco Folsom Contact Information .......................................................................................... 40
APPENDIX ................................................................................................................................................. 43
8.0 MatrixPROTM 16x Technical Specifications............................................................................. 44
POWER ..................................................................................................................................................... 45
ENVIRONMENTAL................................................................................................................................... 46
AGENCY................................................................................................................................................... 46

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
vi

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
1
CHAPTER ONE
1
Introduction
What you will find in this chapter…
About the MatrixPROTM
Features
Technical Description

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
2
1.0 INTRODUCTION
1.1 ABOUT THE MATRIXPROTM 16X SERIES
The MatrixPROTM High-Resolution Matrix Switcher is designed to route universal
inputs such as composite video, s-video, component, and computer video sources
(640x480 to 2048x1536). Audio routing is an option.
MatrixPROTM is an ideal switcher to provide professional-quality video signal routing.
The operator can save up to 16 "looks" from the front panel and 16 from the MP
Control GUI. Typical applications include live staging events, corporate boardroom
presentations, and educational and training events.
Attention to the Installation and Operation Sections of this manual is important to
ensure trouble-free operation. Should you have any questions regarding the
operation of this unit, please consult the factory.
1.2 FEATURES
•375MHz (-3dB) @ 0dBm, minimum bandwidth, full loaded (One input driving
all outputs)
•Mute on a per output basis
•Universal Inputs accept Composite, S-Video, Component Video, HDTV, RGBHV
and stereo audio
•Stereo Audio Input and Output Signals Balanced or Unbalanced (optional)
•Volume Control on a per input basis
•Audio follow or breakaway
•Output audio gain and attenuation (-75dB to +20dB)
•IP (Ethernet) Control standard (Static IP Required)
•Front Panel Lockout Mode
•Memory Presets save individual I/O configurations for recall via the front
panel or RS-232/485
•I/O Grouping allows specific outputs to be grouped together making
installation and control easier.
•VREF (for Vertical Interval Switching) In with Loop Through or Channel 1
VSync or Extracted Composite VSync Input from Channel 1 Green

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
3
•Vertical Interval Switching capability provides glitch-free switches when used
with synchronous video source. RGB delay used when video not
synchronously locked
•MP Control Software GUI for setup and control via serial or Ethernet control
•Aux RS-485 connector for RS-485 pass through for daisy chaining multiple
matrix switchers
•Optional MatrixPROTM Remote Control Panel (MPRC) for remote operation via
RS-485
1.3 TECHNICAL DESCRIPTION
MatrixPROTM 16x is an RGBHV matrix switcher with 375MHz video bandwidth. It's
available with 16 inputs and either 16 or 8 outputs. Output gain is unity into 75 ohm
loads. All video signals are carried on BNC's for the highest signal quality. Audio
routing card is available as an option.
A matrix switcher can route any input to any output or outputs. The matrix switcher
has built in capabilities to group outputs and/or inputs with specific outputs.
The analog video section maintains flat response in the critical 0-10MHz band to
prevent video smearing. The analog video section has excellent crosstalk immunity,
good offset pass though, and output drive capabilities. The system can pass
2048x1536 signals with minimal degradation. The analog video section can pass
RGB, RsGsBs, RGsB, component, composite, and S-video with significant input
offset.
The horizontal and vertical sync sections reconstruct the sync signal to provide the
most accurate output sync signals.
The audio section accepts and outputs both balanced and unbalanced audio signals
on five contact Phoenix quick disconnect screw terminals. A 600 ohm resistor must
be placed across the inputs if 600 ohm characteristic impedance is required.
The MatrixPROTM 16x series can be controlled by the front panel, RS-232, RS-485, or
Ethernet. The MP Control GUI allows control of the MatrixPROTM router from a PC via
serial and Ethernet interfaces. Barco Folsom also offers the compact 1RU
MatrixPROTM Remote Control Panel which provides 16 input and 16 output buttons for
simple remote operation of the MatrixPROTM router.

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
4

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
5
CHAPTER TWO
2
Installation
What you will find in this chapter…
Rear Panel Connectors
Rack-Mount Installation
Power Cord/Line Voltage Selection
Video Input & Output Connections

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
6
2.0 INSTALLATION
2.1 REAR PANEL CONNECTORS
ETHERNET OUTIN V REF
LR91261
SH
SH
9RL
+- +SH
V
9
1R
+
L
+-SH
T250V 2A FUSE
C
L
+-
10 +
-R-+SH 11
10
-
L
+- 2
11
-
R
+SH 3
-
R
+
L
+-SH L +-
12
-
R
+-
L
+SH
12
-
L
+
4
CAUTION:
AGAINST RISK OFFIRE, REPLACE ONLY
WITH SAME TYPE AND RATING OF FUSE.
FOR CONTINUED PROTECTION
1
9
H/C
1
B/CB
9
1
G/Y
9
1
2
10
3
11
2 3
4
12
4
2
10
3
11
2
10
3
11
4
12
4
12
R/CR
9
1
10 11
2 3
12
4
T250V 2A FUSE
AGAINSTRISK OF FIRE, REPLACE ONLY
FOR CONTINUED PROTECTION
WITH SAME TYPE AND RATING OF FUSE.
15
15
7
RS-485 LOOP
+
+
RS-232/485 IN
US
-
-
R-+ 13 R
+
L
+-SH
13
-
R
+5R
+-
L
+SH
SH
L
+-
14 R-+ 15
SH
14
-
L
+
6
15
-
R
+7
SH
SH
R-+ L-SH L
+-
16
-
R
+-
LSH
16
-
L
+
8
R-+ L
+-SH
9
-
R
+
9
-
L
+SH
1
L
L
L
+
R-+ 10 R-+-SH
L
10
+-
R
+2-
R
+-SH
L
+-SH
11 +
R-+ 12
11
-
L
+SH
3
12
+-
R
+4
LR91261
CUS
+
+
13
R-+-SH L
+-SH
13
-
R
+-SH -
L
+SH
5
-
L
+
R-14 R-+SH
-
14
L
+-
R6-
R
+SH
47-63Hz, 1.5A
85-264 V CAUTION:
AESRE HRC
-
-
+
L
+-SH L
+
R-16
+-
L
+SH
16
L
+-
R8
R-+SH
V
-
R
+SH
15
7
7
15
7
7
15
15
7
5
13
5
6
14
7
15
6 7
5
13
5
13
6
14 15
7
6
14 15
7
8
16
8
9
1
1
8
16
8
16
1
9
1
9
13
INPUTS
5
14 15
6 7
16
8
9
1
10
2
2
11
3
12
4
3 4
2
10
10
2
3
11
4
12
11
3
12
4
13
5
5
14
6
6
13
5
13
5
6
14
14
6
10
2
11 12
3 4
13
OUTPUTS
5
14
6
16
8
8
H/C
8
16
8
16
B/CB
G/Y
16
8
R/CR
Figure 2-1: MatrixPROTM 16x16A Rear Panel
•AC Power connector
•BNC Video Input and Output connectors
•DB-25 connector
•Loop through DB-25 connector
•Ethernet Connector
•Vertical Sync Reference input and output
2.2 RACK-MOUNT INSTALLATION
MatrixPROTM 16x units are designed to be rack mounted. Due to the size of the
MatrixPROTM 16x, Barco Folsom suggests using optional rear rack mount extension

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
7
kit provided by Barco Folsom or L-brackets that would be supplied by the rack
manufacturer.
When rack mounting the unit, remember that maximum ambient operating
temperature for the unit is 40° C. Leave at least one inch of space front and rear to
make sure that the airflow through the fan and vent holes is not restricted. When
installing equipment into a rack, distribute the units evenly to prevent hazardous
conditions that may be created by uneven weight distribution. Connect the unit only
to a properly rated supply circuit. Reliable Grounding (Earthing) of Rack-Mounted
Equipment should be maintained.
2.3 POWER CORD/LINE VOLTAGE SELECTION
The MatrixPROTM 16x Matrix Switcher performs line Voltage Selection automatically.
No user controls are required for line voltage selection. The AC power cords must be
accessible so that the cords can be removed during field servicing.
2.4 DUAL POWER SUPPLY VERSION
For dual power supply models, plug both power cord into the AC supply. Each power
supply is independent and can be plugged into different sources. If desired, only one
supply needs to be plugged in for proper operation.
When the MatrixPROTM 16x is used in the 230-volt mode, a UL listed line cord rated
for 50 volts at 15 amps must be used. This cord will be fitted with a tandem prong-type
plug.
Tandem Plug
La choix de la ligne de voltage se réalise automatiquement par le
MatrixPRO 16x Transformateur Graphique. On n'a pas besoin du
controller usager pour la choix de la ligne de voltage.
Das MatrixPRO 16x-Gerät mu beim Anschlu an 240V ~ mit einer vom VDE auf
250V/10A geprüften Netzleitung mit einem Schukostecker ausgestattet sein.
WARNING
AVERTISSEMENT
WARNUNG

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
8
2.5 VIDEO INPUT CONNECTIONS
The video input section on the MatrixPROTM rear panel provides 16 universal inputs.
Each input can accept RGB, YUV, S-Video (Y/C), or composite (NTSC or PAL) video
signals. The connections for each input channel are made via five BNC connectors.
Connection points for each type of video signal are specified below.
Input Connections
Format – RGB
(Typical Devices: Computers) Format – YUV or Y Pr Pb (Betacam) (Typical Devices: DVD Player or Betacam Deck)
Source to MatrixPRO Source to MatrixPRO
R R/CR Y G/Y
G G/Y Pr R/CR
B B/CB Pb B/CB
H H/C or
V V Y G/Y
U R/CR
Format – S-Video (Y/C)
(Typical Devices: S-Video VCR) V B/CB
Source to MatrixPRO Format – NTSC/PAL (Typical Devices: Composite/PAL
VCR)
Y G/Y Source to MatrixPRO
C B/CB Composite/PAL G/Y

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
9
2.6 VIDEO OUTPUT CONNECTIONS
Sixteen or eight independently buffered outputs are provided. Outputs provide RGB
video signals. Connect the outputs labeled R, G, and B on the rear panel of the
MatrixPROTM unit to the correspondingly labeled connectors on the output device.
Model # of
Inputs # of Outputs Audio Dual Power
Supply
MP-1616 16 16 No No
MP-1608 16 8 No No
MP-1616A 16 16 Yes No
MP-1608A 16 8 Yes No
MP-1616D 16 16 No Yes
MP-1608D 16 8 No Yes
MP-1616AD 16 16 Yes Yes
MP-1608AD 16 8 Yes Yes
2.7 AUDIO INPUT CONNECTIONS
The MatrixPROTM 16x has 16 audio inputs that accept balanced and unbalanced
signals. If a 600 ohm load impedance is desired a 600 ohm resistor must be
connected across the input terminals. Connect each type of audio input source to
MatrixPROTM as indicated in the following diagram:
2.8 AUDIO OUTPUT CONNECTIONS
The MatrixPROTM 16x has 16 outputs which drive unbalanced and balanced signals.
Connect each type of audio output to the MatrixPROTM as shown above.
L+
-
+
-
R
SH
Stereo Input/Output Connector Wiring
L+
-
+
-
R
SH
Balanced Wiring Unbalanced Wiring
Jumpers
L+
-
+
-
R
SH
Mono Input/Output Connector Wiring
L+
-
+
-
R
SH
Balanced Wiring Unbalanced Wiring
Jumpers Jumpers

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
10

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
11
CHAPTER THREE
3
Operation
What you will find in this chapter…
Power-up Initialization
Console Installation
Front Panel Operation
GUI Configuration
Optional MP Remote Control Panel
MatrixPROTM 16x Field Servicing

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
12
3.0 OPERATION
This portion of the manual provides instructions that indicate how to control all
MatrixPROTM functions. There are many means to control the unit available to the
user. First, the front panel is available for status and control. Two keys and display
on the MatrixPROTM front panel are used for signal routing, to save and recall looks,
mute audio sources, for volume control, and for other system configuration.
A second means of control is through the use of the MP Control software. The GUI
can interface to the MatrixPROTM through RS-232 or Ethernet.
Barco Folsom also makes a Remote Control Switch Panel for controlling the
MatrixPROTM remotely via RS-485. And finally the unit can be controlled remotely by
various third-party controllers.
This section also describes field servicing the MatrixPROTM 16x.
3.1 POWER-UP INITIALIZATION FOR MATRIXPRO
After plugging in the MatrixPROTM to the wall socket (two are provided for dual power
supply models), locate the Power Switch(s) on the back of the frame and turn the
power ON. The LED's on the buttons will light, the display will show the Main Menu
screen, and the last saved or recalled setup will be recalled.

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
13
3.2 MATRIXPROTM16X FRONT PANEL OPERATION
ESC
SEL
REES RA HC
Figure 3-1 MatrixPRO 16x Front Panel
The front panel of the MatrixPROTM 16x allows local control and monitoring of the
matrix switcher. It displays power information for the dual power supply model.
The front panel displays an emergency message if one of the dual power supplies
fails or the AC power is removed from one of the supplies.

MatrixPROTM 16x Series
Manual #26-0301100-00/ Revision A
14
3.2.1 MENU STRUCTURE
The menu has 5 main menus (6 for dual power supply version) and each menu item
will have a sub-menu.
3.2.1.1 MAIN MENU
MP 16x
_________________________________________
A/V SEL FILES
ROUTING CONFIG
VOLUME STATUS - dual PS version only
To enter into the Submenus, rotate the Selector Knob until the cursors are around
the desired menu then press SEL. Once in the Submenu, move the cursor down or
up to position the cursor next to the item to change. Press SEL to modify the
selected item. Except in the routing menu, to back out of item without modifying it,
press ESC, to enter the selection press SEL. In the routing menu, to have the
modification take effect, press ESC again. This returns back to the Main Menu. In all
other menus once the SEL button is pressed the modification takes effect. To return
to the main menu, an ESC press is required.
For dual power supply versions, when an AC or DC fault occurs the front panel
display indicates the type of fault and which supply has the fault. To access the
menu rotate the Selector Knob or press one of the buttons. The message will appear
again after 1 minute of inactivity.
3.2.1.2 A/V SEL
AUDIO/VIDEO MODE MENU
_________________________________________
( AUDIO FOLLOW VIDEO )
VIDEO ONLY
AUDIO ONLY
This mode selects whether audio is routed with the video or video or audio is routed
separately in the Routing menu. If audio is not installed in the system, video only is
the only choice.
