Bardic Premium CILLEDNSWP User manual

CILLEDNSWP
LED TWINSPOT EMERGENCY FLOODLIGHT
WITH SEALED NICKEL CADMIUM BATTERY
WiNET & SENTINEL COMPATIBLE
THE BARDIC WARRANTY
Our goods come with guarantees that cannot be excluded under
the Australian Consumer Law. You are entitled to a replacement
or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have
the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
If the BARDIC emergency lighting fitting (the unit) is found to be
defective due to faulty workmanship or faulty materials used in
its manufacture (but excluding defects due to neglect, misuse or
abuse of the unit by any person) within twelve months of the date of
purchase, it will be repaired free of charge (except the fluorescent
tube and/or the incandescent globe which are not covered by this
warranty) or, at the sole discretion of the manufacturer, replaced. In
either case, return to the purchaser, freight paid.
Any faulty unit should be forwarded FIS to the point of purchase,
accompanied by the sales voucher to establish the date of purchase.
The unit must be clearly marked with the name and address of
the purchaser and the nature of the fault. If the sales voucher is
unavailable at the time of claim, the warranty will be deemed to have
commenced from the packaging date as indicated by the unit date
stamp.
All warranty claims on the unit in question must be received by the
distributor within the twelve month warranty period. This warranty
does not apply to any unit which is situated outside of Australia.
This warranty is in addition to all other warranties rights and remedies
implied by or available under any laws in force in Australia. Any civil
liability of the manufacturer howsoever arising shall insofar as the
same may be legally done be limited at the manufacturer’s option as
follows:
a. Any liability for breach of warranty, subject to the said limitations,
is limited in a case of goods to any one or more of the following
(as selected by the manufacturer):
(i) The replacement of the goods or the supply of equivalent
goods; or
(ii) The repair of the goods; or
(iii) The payment of the cost of replacing the goods or
requiring equivalent goods; or
(iv) The payment of the cost of having the goods repaired
b. And in the case of services such liability shall be limited to any
one of the following (as selected by the manufacturer)
(i) The supplying of the services again;
(ii) The payment of the cost of acquiring those services
again; The manufacturer shall not be liable for any
indirect or consequential loss however and whatsoever
arising.
MPower manufactures a range of emergency lighting fittings without
integral batteries (commonly termed as Slaves), for operation in
conjunction with central power supplies.
MPower will not be responsible for any damages to slave units as a
result of connection to central power supplies operating outside the
voltage parameters specified for these slave units.
Installation - Maintenance
Testing Instructions
and Warranty
MAINTENANCE RECORD
OWNER: __________________________________________________
ADDRESS: _________________________________________________
INSTALLATION DATE: _____________ LOCATION: ________________
SIX MONTHS CHECK
DATE LIGHT TEST LED TEST LAMP CHECK TESTER
TWELVE MONTHS CHECK
DATE LIGHT TEST LED TEST LAMP CHECK TESTER

BARDIC EMERGENCY LIGHTING
SINGLE POINT UNITS (S.P.U.)
BARDIC LED TWINSPOT FLOODLIGHT
CILLEDNSWP
NICKEL-CADMIUM BATTERY POWERED
WARNING! DISCONNECT SUPPLY BEFORE INSTALLING,
DECOMMISSIONING OR MODIFYING THIS FITTING!
WARNING! The control box should not be opened and
should only be handled by a qualified competent person.
WARNING! This luminaire is intended only for mounting
in locations where the plug and socket are protected from
unauthorized disconnection.
DESCRIPTION
The Bardic Twin LED Emergency Floodlight is designed to provide
indirect emergency lighting to large, high ceiling areas, such as factories
and warehouses. It features Ultra bright High performance 2 x 10W LED
floodlights, low standby power consumption and integrated advanced
two stage charging to ensure the high Temperature Ni-Cd batteries are
correctly charged. Designed and tested in accordance to AS/NZS 2293,
AS60598.2.22, EMC.
Box Contents
• Installation Leaflet
• CLIIEDNSWP fitting
When the mains supply fails, these units initially provide 2 hours illumination
from a fully charged battery following a 16 hours charge. All models are
intended for connection to 240 V.A.C. +5% -10% 50Hz supply via an
unswitched active.
This model is manufactured to accept the BARDIC SENTINEL automatic
tester or BARDIC WiNET as an optional extra. The SENTINEL will
automatically test the single point units (SPU) every 91 days for operation
in the emergency condition (operation on battery) for a minimum duration
of 90 minutes. The results of the test, fail or pass is Indicated by flashing the
LED (mounted on the SPU) at Intervals:
• flash at 4 seconds on, 1 second off - Pass
• flash at 0.5 second on, 0.5 second off - fail
The SENTINEL test program can also be manually initiated. The SENTINEL
option is packed complete with instructions and plugs into the main printed
circuit board (PCB). For further information about BARDIC SENTINEL or
BARDIC WiNET, contact your local dealer or visit www.mpower.com.au.
PRODUCT SPECIFICATIONS
Nominal Voltage: 240V
Nominal Frequency: 50Hz
IP Rating: IP65
Rated Maximum Ambient Temperature: 40oC
Power Consumption: 12VA Maximum
IMPORTANT!
A faulty battery can place severe overloads upon electrical components
in the fitting therefore it is important that the faulty battery be replaced as
soon as possible.
FUNCTIONS
The unit is designed for connection to the mains supply via an unswitched
active, it comes complete with an automatic current and voltage regulated
charger, Nickel Cadmium battery and mains fail sensing capability. The
battery powers two 12 Volt 10W LED floodlights which are switched on
automatically when the A.C. supply fails and are switched off when:
1. The battery reaches low voltage cutout, or
2. When AC is restored, or 8 minutes after if the delay function is enabled.
This delay feature is to allow sufficient time for the general lighting to restart.
A RED light emitting diode (LED) charge monitor indicates a healthy mains
supply and functioning charger. A test switch to simulate a mains power
failure is included for testing an emergency operation when the mains
supply is healthy.
The LED floodlights are both powered by the 12 Volt battery but are parallel
connected to ensure independent operation if one lamp fails.
Note: The fitting is shipped with the 8mins delay option enabled by default.
Remove the jumper on the control board to deactivate this feature.
INSTALLATION
NOTE: If the BARDIC SENTINEL or BARDIC WI NET option is to be
fitted, check the installation instructions provided with that product before
proceeding further.
• Remove the screw securing the front panel and take off panel
• The mounting hole centres of the mounting slots located in the back of the
case are 330mm apart.
• Mark the wall in the desired mounting position keeping the mounting height
of the unit as high as possible above the floor.
• Drill and plug the mounting screw holes and fit a 38mm x No.8 dome head
screw in each hole allow 7mm of the shaft exposed
• Place the unit onto the mounting screws and fully tighten screws.
• Pass the mains leads through the cable entry hole provided and connect
the active lead to active (A) terminal, neutral lead to neutral (N) terminal and
the earth wire to the earth (E) terminal.
• One lead of the battery has been disconnected to prevent discharge while
in storage. Reconnect this lead.
• Write the date of installation on the battery label.
• Refit the front panel and switch on the A.C. mains supply.
WARNING: Do not touch the surface of the lamp with bare fingers!
COMMISSIONING
IMPORTANT! If the BARDIC SENTINEL or BARDIC WiNET has been fitted
to this spu, then follow their respective commissioning instructions.
1. Switch on mains supply. The charge monitor LEDs will illuminate and the
floodlights will turn on for approximately 8 minutes and then go off.
2. Depress the test switch to ensure the floodlights light up.
3. Release the test switch and note that the floodlights will remain illuminated
for 8 mins.
4. Allow the unit to operate for 16 hours to fully charge the battery after
which time the unit is ready for duty.
5. A 2 hour discharge test is required as part of the commissioning process
as per AS2293
MAINTENANCE
1. MONTHLY - inspect to ensure charge monitor is illuminated.
2. SIX MONTHLY (or at the discretion of the enforcing Authority) - isolate
the mains supply to unit and allow it to operate until the lamp extin-
guishes. Should the unit provide less than 90 minutes illumination be-
tween 10°c and 40°C ambient temperature following a 16 hour charge,
the unit is faulty and steps should be taken to rectify the fault.
3. TWELVE MONTHLY - Clean all light-emitting/ reflecting surfaces.
4. FIVE YEARS TEST - Check fitting runtime against L70 lifetime and
determine if it is still suitable for use.
NOTE: The 6 monthly test should be undertaken wherever possible at times
of least risk (e.g. during daylight hours). This is because of the possibility
of a failure of the normal lighting supply whilst the battery is discharged).
SIX MONTHS CHECK
DAT E LIGHT TEST LED TEST LAMP CHECK TESTER
TWELVE MONTHS CHECK
DAT E LIGHT TEST LED TEST LAMP CHECK TESTER
