baridi DH4 User manual

Baridi 12 Bottle Wine Cooler/Fridge
Digital Touch Screen Control, LED Light,
Energy Class A - Black
Model No. DH4
Thank you for purchasing a Baridi product from the Dellonda range. Manufactured to a high standard,
this product will, if used according to these instructions, and properly maintained, give you years of
trouble free performance.
DH4 v1 Issue 3 24/04/2020

2
Important Information
Please read these instructions carefully and note any safe operational requirements, warnings &
cautions. Use the product correctly and with care for the purpose for which it is intended. Failure
to do so may cause damage and/or personal injury and will invalidate the warranty. Keep these
instructions safe for future use.
• ELECTRICAL SAFETY
• WARNING! It is the user’s responsibility to
check the following:
• Check all electrical equipment and appliances
to ensure that they are safe before using.
Inspect power supply leads, plugs and all
electrical connections for wear and damage.
Dellonda recommend that an RCD (Residual
Current Device) is used with all electrical
products. You may obtain an RCD by
contacting your local domestic stockist.
If the product is used in the course of
business duties, it must be maintained in a
safe condition and routinely PAT (Portable
Appliance Test) tested.
• Electrical safety information: It is important
that the following information is read and
understood.
• Ensure that the insulation on all cables and on
the appliance is safe before connecting it
to the power supply.
• Regularly inspect power supply cables and
plugs for wear or damage and check all
connections to ensure that they are secure.
• Important: Ensure that the voltage rating on
the appliance suits the power supply to be
used and that the plug is tted with the correct
fuse - see fuse rating in these instructions.
• DO NOT pull or carry the appliance by the
power cable.
• DO NOT pull the plug from the socket by the
cable.
• DO NOT use worn or damaged cables, plugs or
connectors.
• Ensure that any faulty item is repaired or
replaced immediately by a qualied electrician.
• This product is tted with a BS1363/A 13 Amp
• 3 pin plug. If the cable or plug is damaged
during use, switch off the electricity supply
and remove from use. Ensure that repairs are
carried out by a qualied electrician.
• Replace a damaged plug with a BS1363/A 13
amp 3 pin plug. If in doubt contact a qualied
electrician.
A) Connect the GREEN/YELLOW
earth wire to the earth terminal ‘E’.
B) Connect the BROWN live wire to the
live terminal ‘L’.
C) Connect the BLUE neutral wire to
the neutral terminal ‘N’.
• Ensure that the cable outer sheath extends
inside the cable restraint and that the restraint
is tight.
• Dellonda recommend that repairs are carried
out by a qualied electrician.
• GENERAL SAFETY
• DO NOT store explosive substances such as
aerosol cans with a ammable propellant in
this appliance.
• WARNING: Ensure the supply cord is not
trapped or damaged.
• WARNING: DO NOT locate multiple portable
socket-outlets or portable power supplies at
Replacement fuse rating:
13A
Refer to
instructions
Indoor use
only

3
the rear of the appliance.
• This appliance is intended to be used in
household and similar applications such as
staff kitchen areas in shops, ofces and other
working environments; holiday homes, hotels
and other residential settings; and catering
and similar non-retail applications.
• This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of knowledge and
experience if they have been given supervision
or instruction concerning the use of the
appliance in a safe way and understand the
hazards involved. Children shall not play with
the appliance. Cleaning and user maintenance
shall not be made by children without
supervision.
• INTRODUCTION
• Sleek and compact design with tempered
mirror glass door to reect UV light and help
protect your wine. Slim design with an overall
width of only 25.2cm, this space saving, single
zone wine cooler is perfect to store up to
12 bottles of wine at home. Thermoelectric
cooling eliminates humming, uses less
electricity and causes less vibration making it
ideal for the home environment. Temperature
range between 10-18°C controlled by touch
screen controls. (Recommended ambient
temperature up to 25°C). Energy efciency
rating Class ‘A’.
• SPECIFICATION
• Model no: DH4
• Capacity: 12 bottles
• Max. bottle height: 315mm
• Volume: 32L
• Temperature range: 10-18°C
• Power rating: 65W
• Voltage: 230V
• Frequency: 50Hz
• Energy consumption: 0.33kWh/24h
• Energy efciency class: 33bD
• Noise level: 33dB
• INSTALLATION
• The unit is designed to be free-standing.
Ventilation Space - a minimum space of 20mm
is required for the rear and top of the fridge
and 30mm for both sides. This will maximise
the efciency, performance and life of the
fridge and also ensure that there is sufcient
space for the hinge to operate effectively.
Locate the unit away from direct sunlight or
sources of heat i.e. radiator, stove etc. Extreme
or cold ambient temperatures may also
prevent the unit working effectively.
• DO NOT locate the unit in a damp or moist
location.
• Ensure that the oor surface is strong and
stable enough to support the unit when it is
fully loaded.
• Level the unit when in location by using the
adjustable levelling feet in each corner.
• Once in position allow the unit to rest for an
hour before turning it on.
• Allow the unit 2 - 3 hours to reach set
temperature after switching on before placing
any items in the compartment.
• OPERATION
• To turn the unit on, press the symbol.
• The unit’s control panel will automatically lock
out after 20 seconds of non-use.
• To unlock the control panel hold the
symbol for approximately 2 seconds when
an audible noise will be emitted to signify an
active state.
• To turn on internal light press symbol.
The light will turn off after 10 minutes.
• To change the temperature units displayed,
press and hold the symbol for
approximately 2 seconds.
• To set the required operating temperature use
the symbol to increase it, and the
symbol to decrease it. Each press will cause a
1o change in the set value.
• MAINTENANCE
• Remove the power plug from the supply when
performing cleaning or maintenance.
• DO NOT use abrasive or chemical cleaning
materials on any surface of the unit.
• Wipe interior and exterior surfaces with a
damp cloth and dry thoroughly with a clean
dry cloth.
• For more soiled surfaces use a neutral
detergent, wipe down with a clean damp cloth
and dry thoroughly with a clean dry cloth.

Dellonda Limited, Sole UK Distributor of Baridi
Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
Troubleshooting
Environment Protection, Waste Electrical and Waste
Electronic Equipment Regulations (WEEE)
Recycle unwanted packaging materials. When this product is no longer required, or has
reached the end of its useful life, please dispose of in an environmentally friendly way.
Drain any uids (if applicable) into approved containers, in accordance with local waste
regulations. It is our policy to continually improve products and we reserve the right to alter
data, specications and parts without prior notice. No liability is accepted for incorrect use
of this product. Guarantee is 12 months from purchase date, proof of which is required for
any claim.
Symptom Solution
Unit does not operate. Not plugged in.
Fuse/circuit breaker failure.
Turns on and off frequently.
Poor cooling.
Room temperature higher than normal.
Door opened too often.
Door not properly closed.
Temperature control incorrectly set.
Door gasket not sealing.
Not enough space around unit.
Vibrations Check to assure unit is level.
Noisy unit Contraction/expansion of panels.
Unit not level.
Check fan operation.
Check heat pump.
Door will not close properly Unit not level.
Gasket distorted.
Internals out of position.

EC DECLARATION
OF CONFORMITY
Description and Function:�����������������������������������������������������������������������������������������������������������������������������������������������������������
Model/Type: ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������
Manufacturing Date/Serial Number where applicable: ���������������������������������������������������������������������������������������������������������������
This declaration of conformity is issued under the sole responsibility of the manufacturer:
Dellonda, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
Declaration of Conformity in accordance with the above Directive(s)�
Technical le compiled by: Dellonda
Being the responsible person appointed by the manufacturer.
Signed�������������������������������������������������������������������������������������������
Date�����������������������������������������������������������������������������������������������
Name���������������������������������������������������������������������������������������������
Position�����������������������������������������������������������������������������������������
Place: Bury St Edmunds
Baridi Wine Cooler 12 Bottle
DH4 v1
2014/30/EU EMC Directive
2014/35/EU Low Voltage Directive
2011/65/EU RoHS Directive
References to harmonised standard(s)
EN 55014-1:2017 �������������������������������������������������������������������
EN 55014-2:2015 �������������������������������������������������������������������
EN 61000-3-2:2014 ����������������������������������������������������������������
EN 61000-3-3:2013 ����������������������������������������������������������������
������������������������������������������������������������������������������������������������
������������������������������������������������������������������������������������������������
EN 60335-1:2012+A11:2014=A13:2017���������������������������������
EN 60335-2-24:2010+A11:2014+A2:2019 �����������������������������
EN 62233:2008�����������������������������������������������������������������������
������������������������������������������������������������������������������������������������
������������������������������������������������������������������������������������������������
������������������������������������������������������������������������������������������������
10 October 2019
Steve Buckle�
Marketing Director�
XVII2813
Dellonda Limited
Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

DH4 Issue 2 6/01/20Page 1 of 1
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of product. Spare parts must be fitted by a competent person
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
Parts Information:
Baridi Wine Cooler/Fridge, Digital Touch
Screen Controls, LED Light, Energy Class
A, 12 Bottle - Black
Model No: DH4
Item Part No. Description
1 DH. Glass Door
6 DH. Chrome Shelf
Item Part No. Description
9 DH. Hinged Cover
24 DH. Rubber Feet
