baridi DH90 User manual

Baridi 27 Bottle Dual Zone Drinks Wine
Cooler, Fridge, Touch Screen, LED, Black
Model No. DH90
Thank you for purchasing a Baridi product from the Dellonda range. Manufactured to a high standard,
this product will, if used according to these instructions, and properly maintained, give you years of
trouble free performance.
DH90 Issue 1 12/10/2021

2
Important Information
Please read these instructions carefully and note any safe operational requirements, warnings &
cautions. Use the product correctly and with care for the purpose for which it is intended. Failure
to do so may cause damage and/or personal injury and will invalidate the warranty. Keep these
instructions safe for future use.
• ELECTRICAL SAFETY
• WARNING! It is the user’s responsibility to
check the following:
• Check all electrical equipment and appliances
to ensure that they are safe before using.
Inspect power supply leads, plugs and all
electrical connections for wear and damage.
Dellonda recommend that an RCD (Residual
Current Device) is used with all electrical
products. You may obtain an RCD by
contacting your local domestic stockist.
If the product is used in the course of
business duties, it must be maintained in a
safe condition and routinely PAT (Portable
Appliance Test) tested.
• Electrical safety information: It is important
that the following information is read and
understood.
• Ensure that the insulation on all cables and on
the appliance is safe before connecting it
to the power supply.
• Regularly inspect power supply cables and
plugs for wear or damage and check all
connections to ensure that they are secure.
• Important: Ensure that the voltage rating on
the appliance suits the power supply to be
used and that the plug is tted with the correct
fuse - see fuse rating in these instructions.
• DO NOT pull or carry the appliance by the
power cable.
• DO NOT pull the plug from the socket by the
cable.
• DO NOT use worn or damaged cables, plugs or
connectors.
• Ensure that any faulty item is repaired or
replaced immediately by a qualied electrician.
• This product is tted with a BS1363/A 13 Amp
• 3 pin plug. If the cable or plug is damaged
during use, switch off the electricity supply
and remove from use. Ensure that repairs are
carried out by a qualied electrician.
• Replace a damaged plug with a BS1363/A 13
amp 3 pin plug. If in doubt contact a qualied
electrician.
A) Connect the GREEN/YELLOW
earth wire to the earth terminal ‘E’.
B) Connect the BROWN live wire to the
live terminal ‘L’.
C) Connect the BLUE neutral wire to
the neutral terminal ‘N’.
• Ensure that the cable outer sheath extends
inside the cable restraint and that the restraint
is tight.
• Dellonda recommend that repairs are carried
out by a qualied electrician.
• GENERAL SAFETY
• DO NOT store explosive substances such as
aerosol cans with a ammable propellant in
this appliance.
• WARNING: Ensure the supply cord is not
trapped or damaged.
Replacement fuse rating:
13A
Refer to
instructions
Indoor use
only

3
• WARNING: DO NOT locate multiple portable
socket-outlets or portable power supplies at
the rear of the appliance.
• This appliance is intended to be used in
household and similar applications such as
staff kitchen areas in shops, ofces and other
working environments; holiday homes, hotels
and other residential settings; and catering
and similar non-retail applications.
• This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of knowledge and
experience if they have been given supervision
or instruction concerning the use of the
appliance in a safe way and understand the
hazards involved. Children shall not play with
the appliance. Cleaning and user maintenance
shall not be made by children without
supervision.
• INTRODUCTION
• Sleek design with tempered mirror glass door
to reect UV light and help protect your wine.
Dual zone design means you can control the
temperature of each zone individually, with
the upper zone and the lower zone ranging
from 5-18°C. Soft white LED light. Features
stylish wooden shelves made of beech with
space for up to 12 bottles of wine in the upper
zone and 15 bottles of wine in the lower
zone. Compressor cooling technology with
automatic defrost feature to make this unit as
easy as possible to use. Ventilation Space - a
minimum space of 50mm is required for the
rear of the fridge and 30mm for the top and
both sides. This will maximise the efciency,
performance and life of the fridge and ensure
that there is sufcient space for the hinge to
operate effectively.
• SPECIFICATION
• Model no: ...................................... DH90
• Capacity: .....................................27 bottles
• Max. bottle height: ........................ 320mm
• Volume: ................................................. 74L
• Temperature range: ........................ 5 -18°C
• Rated Current: ..................................... 0.6A
• Voltage: .............................................. 230V
• Frequency: .......................................... 50Hz
• Net weight: ........................................ 28.5kg
• Energy: efciency class: .......................... G
• Noise level: ......................................... 47dB
• Dimensions: ............. 345 x 480 x 1110mm
• INSTALLATION
• The unit is designed to be free-standing.
Ventilation Space - a minimum space of
20mm is required for the rear and top of the
fridge, 30mm for both sides and 50mm under
the base. This will maximise the efciency,
performance and life of the fridge and also
ensure that there is sufcient space for the
hinge to operate effectively. DO NOT locate the
unit in a damp or moist location.
• DO NOT locate the unit in direct sunlight.
• Ensure that the oor surface is strong and
stable enough to support the unit when it is
fully loaded.
• Level the unit when in location by using the
adjustable levelling feet in each corner.
• Once in position allow the unit to rest for an
hour before turning it on.
• Allow the unit 2 - 3 hours to reach set
temperature after switching on before placing
any items in the compartment.
• PARTS AND FEATURES
1
2
5
6
3
4
7
• 1: Upper Hinge
• 2: Door Gasket
• 3: Shelves
• 4: Partitions
• 5: Door Gasket
• 6: Display Shelves
• 7: Adjustable feet

4
• OPERATION
• To unlock settings for the upper section give
one short press on the symbol.
• To unlock settings for the lower section give
one long press on the symbol (2 seconds).
• To turn the light on and off press give one
short press on the symbol for on and again
to turn off.
• The light in the unit will turn off automatically
after 10 minutes if the unit is not used.
• To switch between Celsius and Fahrenheit
press on the symbol for 2 seconds.
• Use the symbol to increase the
temperature setting in either the top or bottom
compartments.
• Use the symbol to lower the temperature
setting in either the top or bottom
compartments.
• When you have set the desired temperatures
leave the keypad for 20 seconds and it will
lock and retain those settings.
• The light and temperature setting button will
work as normal.
• To unlock the keypad press the symbol
again.
• Temperature in the upper section can range
from lowest 5°C/41°F to maximum 18°C/64°F.
• Temperature in the lower section can range
from lowest 5°C/41°F to maximum 18°C/64°F.
• Upper and lower sections operate
independently of each other.
• MAINTENANCE
• Remove the power plug from the supply when
performing cleaning or maintenance.
• DO NOT use abrasive or chemical cleaning
materials on any surface of the unit.
• Wipe interior and exterior surfaces with a
damp cloth and dry thoroughly with a clean
dry cloth.
• For more soiled surfaces use a neutral
detergent, wipe down with a clean damp cloth
and dry thoroughly with a clean dry cloth.

Dellonda Limited, Sole UK Distributor of Baridi
Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757575 [email protected] www.dellonda.co.uk
5
Troubleshooting
Environment Protection, Waste Electrical and Waste
Electronic Equipment Regulations (WEEE)
Recycle unwanted packaging materials. When this product is no longer required, or has
reached the end of its useful life, please dispose of in an environmentally friendly way.
Drain any uids (if applicable) into approved containers, in accordance with local waste
regulations. It is our policy to continually improve products and we reserve the right to alter
data, specications and parts without prior notice. No liability is accepted for incorrect use
of this product. Guarantee is 12 months from purchase date, proof of which is required for
any claim.
Symptom Solution
Unit does not operate. Not plugged in.
Fuse/circuit breaker failure.
Turns on and off frequently.
Poor cooling.
Room temperature higher than normal.
Door opened too often.
Door not properly closed.
Temperature control incorrectly set.
Door gasket not sealing.
Not enough space around unit.
Vibrations Check to assure unit is level.
Noisy unit Contraction/expansion of panels.
Unit not level.
Check fan operation.
Check heat pump.
Door will not close properly Unit not level.
Gasket distorted.
Internals out of position.
