Barletta Double Canopy User manual

Double Canopy Assembly
Instructions
Please read all the instruction before installation.

23’
25’
Step 1
Remove the bow furniture and skirt
trim on port and stbd side to assure
no damage and to route wires.
Step 2
Put tape on rails to minimize
scratching to top surface. Mark the
width in dimension and place
mechanism on the rail and mark for
wire and fastening holes. (repeat for
other side)
Step 3
Drill with proper bit for the fasteners
and wires placements. (repeat for
other side)
Step 4
Attach hardware to rails tightly, wires
coming out of rail cannot be bare.
Please use the conduit out of hole so
wires are not cut. (repeat for other
side)
Step 5
Reinstall furniture and test.
Double Canopy Assembly Instructions
Wires
Wires
Trailer Legs
Trailer Legs
To switch in helm
To switch in helm

Assembled: This is what it looks like folded down. Make sure
the trailer legs and mounted properly. Slight adjustments can
be made to assure the feet are setting flat on the rail.
Double Canopy Assembly Instructions
