Maxi-Mix®Vortex Mixer
OPERATION MANUAL
AND PARTS LIST
SERIES 1329
Model Voltage
M16714 100 Volt
M16715 120 Volt
M16710-33 230 Volt
LT1329X1 • 3/21/05

Environmental Conditions
Operating:
17°C - 27°C; 20% - 80% relative humidity, non-condensing.
Installation Category II (over-voltage) in accordance with IEC
664. Pollution Degree 2 in accordance with IEC 664.
Altitude limit: 2,000 meters.
Storage: -25°C - 65°C; 20% to 85% relative humidity.
Declaration of Conformity
Barnstead International hereby declares under its sole
responsibility that this product conforms with the technical
requirements of the following standards:
EMC: EN 61000-3-2 Limits for Harmonic Current Emissions
EN 61000-3-3 Limits for Voltage Fluctuations and Flicker
EN 61326 Electrical Equipment for Measurement,
Control, and Laboratory Use; Part I:
General Requirements
Safety: EN 61010-1 Safety Requirements for Electrical
Equipment for Measurement, Control
and Laboratory Use; Part I:
General Requirements
EN 61010-2-051 Part II: Particular Requirements for
Laboratory Equipment for Mixing and Stirring
per the provisions of the Electromagnetic Compatibility Directive
89/336/EEC, as amended by 92/31/EEC and 93/68/EEC, and per the provi-
sions of the Low Voltage Directive 73/23/EEC, as amended by 93/68/EEC.
The authorized representative located within the European Community is:
Electrothermal Engineering, Ltd.
419 Sutton Road
Southend On Sea
Essex SS2 5PH
United Kingdom
Copies of the Declaration of Conformity are available upon request.
2

3
Unpacking
Do not overlook extra foam rubber replacement top,
shipped with each Maxi-Mix.
Set-up
Place on bench top or other flat surface. It is not neces-
sary that the suction cup feet adhere to the surface
unless larger vessels are used, when there is a tendency
toward “walking.”
For adherence, the surface must be very smooth; mois-
tening the cups with water or glycerin will also help.
Operation
Depress the small disc (On/Off knob) with your finger or
the vessel to be stirred. The larger disc will begin oscillat-
ing. Touching the vessel to the larger disc will initiate the
vortex action.
Mixing action will intensify as a vessel is held nearer its
top and as greater pressure is exerted against the foam
disc.
To stop the mixer, again depress the smaller disc (On/Off
knob).
Mixing in Larger Vessels
There is no absolute limit on the maximum size of vessel
which can be used; much depends on technique, the
shape of the vessel, the viscosity of the contents, and the
amount of liquid. In general, about 100 ml in volume rep-
resents an upper limit.
Maintenance
The foam top will occasionally require replacement.
Merely peel off the old top, remove the paper backing
from the new top, and apply.
Warning
To avoid electrical shock, use with a
properly grounded electrical outlet of
correct voltage and current handling
capacity.
Note
Some misalignment of the motor bear-
ings in this product may have occurred
during shipping and handling. Prior to
first use, the stirrer should be run at
maximum speed for 10 minutes to
realign the motor bearings.
Warning
To avoid personal injury, do not use in
the presence of flammable or com-
bustible materials; fire or explosion
may result. This device contains com-
ponents which may ignite such materi-
als.
Note
IMPORTANT NOTICE:
The smaller disc on the top of this unit
is the Push Button for the ON/OFF
Push Button Switch. Do NOT attempt
to turn it.
Warning
Disconnect from the power supply
prior to maintenance and servicing.
Refer servicing to qualified personnel.
Hot Surface
Hot surfaces alert you to a possibility of
personal injury if you come in contact
with a surface during use or for a period
of time after use.

4
Replacement Parts
Part Number Description
PT167X2 Foam Mixing Surface, self-adhesive back
PT167X5B Cast Aluminum Top Plate
KB268X1 Knob for ON/OFF Switch
SWX48 ON/OFF Switch, with nut and lock washer
CT1329X1 Plastic Outer Case
CW167X1 Counterweight
MTX17 Motor, 120 volt for Model M16714 & M16715
MTX20 Motor, 230 volt for Model M16710-33
CR1329X1 Cord and Plug Set for Model M16714 & M16715
CR1329X2 Cord and Plug Set for Model M16710-33
FZX59 Fuse for Model M16714 & M16715
FZX35 Fuse for Model M16710-33
(For assistance on replacement parts not listed above, contact our
Customer Service Department.)
Ordering Procedures
Please refer to the Specification Plate for the complete model number,
serial number, and series number when requesting service, replacement
parts or in any correspondence concerning this unit.
All parts listed herein may be ordered from the Barnstead International
dealer from whom you purchased this unit or can be obtained promptly
from the factory. When service or replacement parts are needed we ask
that you check first with your dealer. If the dealer cannot handle your
request, then contact our Customer Service Department at 563-556-2241
or 800-553-0039.
Prior to returning any materials to Barnstead International, please contact
our Customer Service Department for a “Return Goods Authorization”
number (RGA). Material returned without a RGA number will be refused.

5

6

7

8
One Year Limited Warranty
BARNSTEAD INTERNATIONAL (“BARNSTEAD”) warrants that if a product manufactured by Barnstead shall
be free of defects in materials and workmanship for one (1) year from the first to occur of (i) the date the prod-
uct is sold by BARNSTEAD or (ii) the date the product is purchased by the original retail customer (the
“Commencement Date”). Except as expressly stated above, BARNSTEAD MAKES NO OTHER WARRANTY,
EXPRESSED OR IMPLIED, WITH RESPECT TO THE PRODUCTS AND EXPRESSLY DISCLAIMS ANY AND
ALL WARRANTIES, INCLUDING BUT NOT LIMITED TO, WARRANTIES OF DESIGN, MERCHANT ABILITY
AND FITNESS FOR A PARTICULAR PURPOSE.
An authorized representative of BARNSTEAD must perform all warranty inspections. In the event of a defect
covered by BARNSTEAD’s warranty, BARNSTEAD shall, as its sole obligation and exclusive remedy, provide
free replacement parts to remedy the defective product. In addition, for products sold by BARNSTEAD within
the continental United States or Canada, BARNSTEAD shall provide provide free labor to repair the products
with the replacement parts, but only for a period of ninety (90) days from the Commencement Date.
BARNSTEAD’s warranty provided hereunder shall be null and void and without further force or effect if there
is any (i) repair made to the product by a party other than BARNSTEAD or its duly authorized service repre-
sentative, (ii) misuse (including use inconsistent with written operating instructions for the product), mishan-
dling, contamination, overheating, modification or alteration of the product by any customer or third party or
(iii) use of replacement parts that are obtained from a party who is not an authorized dealer of BARNSTEAD.
Heating elements, because of their susceptibility to overheating and contamination, must be returned to the
BARNSTEAD factory and if, upon inspection, it is concluded that failure is due to factors other than excessive
high temperature or contamination, BARNSTEAD will provide warranty replacement. As a condition to the
return of any product, or any constituent part thereof, to BARNSTEAD’s factory, it shall be sent prepaid and a
prior written authorization from BARNSTEAD assigning a Return Goods Number to the product or part shall
be obtained.
IN NO EVENT SHALL BARNSTEAD BE LIABLE TO ANY PARTY FOR ANY DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES, OR FOR ANY DAMAGES RESULTING FROM LOSS OF
USE OR PROFITS, ANTICIPATED OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THE
SALE, USE OR PERFORMANCE OF ANY PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CON-
TRACT, TORT (INCLUDING NEGLIGENCE), ANY THEORY OF STRICT LIABILITY OR REGULATORY
ACTION.
The name of the authorized Barnstead International dealer nearest you may be obtained by calling 1-800-446-
6060 (319-556-2241) or writing to:
2555 Kerper Boulevard
P.O. Box 797
Dubuque, Iowa 52001-0797
Phone: [phone] or 800-553-0039
Fax: [phone]
E-mail: [email protected]
www.barnstead.com
