Barracuda CloudGen Firewall User manual

Barracuda CloudGen Firewall
Barracuda NG Firewall F10 Revision A 1 / 4
Barracuda NG Firewall F10 Revision A
https://campus.barracuda.com/doc/12198249/
Opening your Barracuda Networks appliance or removing its warranty label unless instructed to
do so by Barracuda Networks support will void your warranty and hardware support.
Barracuda Networks Appliance Safety Instructions
Always use the power supply shipped with the appliance.
General
Revision A
Front
Back
Minimum
Firmware
Requirement
Default Port Configuration
Label OS Notation Speed/Type Management Port
1 port1 10/100 MBit RJ45 X
2 port2 10/100 MBit RJ45
3 port3 10/100 MBit RJ45
4 port4 10/100 MBit RJ45
Hardware Specifications
Component Specifications

Barracuda CloudGen Firewall
Barracuda NG Firewall F10 Revision A 2 / 4
CPU VIA 500 MHz
Memory 256 MB
Flash Disk 4 GB
USB 2x USB 2.0
Form Factor Mini Desktop
Dimensions (W/D/H) 24 x 16.6 x 3 cm
9.4 x 6.1 x 1.2 in
Net Weight 2 kg / 4.4 lbs
Power Supply Single, external
Power Supply Input Voltage 100 - 240 V, AC
Power Supply Output Voltage 12 V, DC
Power Supply Voltage 47 Hz - 63 Hz
Power Supply Watts 60 W
Storage Temperature -20 °C - +70 °C
Operation Temperature 0 °C - 40 °C
Relative Humidity 5% - 95%, non-condensing
Certifications CE, FCC, ROHS
The hardware specifications list was valid at the time this manual was published. The listed
components are subject to change at any time, as Barracuda Networks may change hardware
components due to technological progress. Therefore, the list may not reflect the current
hardware configuration of the Barracuda Networks NG Firewall or NG Control Center appliance it
was delivered with.
Status LED
Your appliance is equipped with a variety of LEDs. One of them is the Status LED. It is either
labeled with a heart symbol or the term Status. It indicates the appliance’s operational state by
changing colors between green, orange and red and by changing between blinking and steady
glowing. The table below shows the different meanings of the different glowing states.
Color Glowing
State Meaning installation
Meaning Normal Operation or
Active Recovery Technology
Operation
Off Off
Appliance is powered off or
installation has not initialized far
enough for LED control when
installation is started.
Appliance is powered off.

Barracuda CloudGen Firewall
Barracuda NG Firewall F10 Revision A 3 / 4
Green Blinking Normal installation. Appliance is either booting, shutting
down or performing a system update.
Green Steady
Installation was completed
successfully, appliance is halted for
reboot or installation was not yet
initialized far enough for LED
control.
Barracuda NG Firewall is up and running.
Red Blinking Error during installation.
An error has appeared preventing
Barracuda NG Firewall from entering the
up state.
If no orange light available: appliance is
in ART mode.
Red Steady - Appliance is halted and may be
disconnected.
Orange Blinking - -
Orange Steady - Appliance is in ART mode.
Not all appliances support orange and/or red LED colors. Depending on the appliance type, the
status LED might be on by default and it might take some time during boot and installation to
start either blinking or changing the color. Furthermore, the status LED might blink at different
frequencies.
Serial Console Port
In order to establish a console connection to the appliance using a serial cable (RJ45), you need to
configure the serial port on the terminal using the following parameters:
Parameter Value
Baud 19200
Bits 8
Stop bit 1
Parity None
Handshake None

Barracuda CloudGen Firewall
Barracuda NG Firewall F10 Revision A 4 / 4
Figures
F10-A-Front.png1.
F10-A-Back.png2.
