Barrett 4050 User manual

4050 Dual Port Antenna Switch Unit
(P/N BCA40506)
BCM40506/2
The Barrett 4050 HF SDR Transceiver can support a secondary antenna through the use of a Dual Port Antenna Switch Unit. This
allows the transceiver to be connected to two antennas instead of one. Two examples of dual antenna use are a mobile unit
utilising both a 2019 Automatic Tuning Mobile HF Antenna and a 2018 Mobile Magnetic Loop Antenna, or a base station with
one long wire antenna set up orientated North-South with a second long wire set-up East-West.
12019 Automatic Tuning Mobile HF Antenna - P/N BC401900
2Interface and coaxial cable - 6 metres - P/N 4019-00-02
3Dual Port Antenna Switch Unit - P/N BCA40506
42018 Mobile magnetic loop HF antenna - P/N BC201801
5Ground (earth)
6Coax cable - P/N BCA90028
ATU cable - P/N 2065-00-06
Ground (earth)
4050 HF SDR Transceiver (rear) - P/N BC405000
Example Connection Diagram

Head Ofce:
Barrett Communications Pty Ltd
47 Discovery Drive, Bibra Lake,
WA, 6163 AUSTRALIA
Tel: [phone]
Fax: [phone]
Email: [email protected] www.barrettcommunications.com.au
BCM40506/2
1. Swipe left to right from the left edge of the 4050 display.
2. Select Settings, then I/O.
3. Tap Antenna 1 Type from the IO screen to display the Antenna 1 Type screen.
4. Select the antenna connected to the Antenna 1 connector on the Dual Port Antenna
Switch Unit
Please note: an antenna with memory tune or GPS functionality should be
connected to the Antenna 1 port on the Dual Port Antenna Switch Unit i.e.
2019 antennas
5. Select Antenna 2 Type from the I/O menu.
6. Select the antenna connected to the Antenna 2 connector on the Dual Port Antenna
Switch Unit.
Please note: a 4075 Linear Amplier cannot be connected to the Antenna 2
port. It is recommended that the amplier be connected directly to the trans-
ceiver.
Settings I/O
Operation
Settings Channels
I/O Settings
Channel Settings
Channels require a specic Antenna socket to be assigned to them. Ensure that the cor-
rect Antenna (1 or 2) is assigned for correct functionality.
Before rst use of dual antennas, the Barrett 4050 HF SDR Transceiver must be properly congured. For further information on
the operation of a Barrett 4050 transceiver, please refer to the Barrett 4050 HF SDR Transceiver Operating and Installation Man-
ual (BCM40500).
