1. General Information 24
1.1 Information about the instruction manual 24
1.2 Key to symbols 24
1.3 Liability and Warrantees 25
1.4 Copyright protection 25
1.5 Declaration of conformity 25
2. Safety 26
2.1 General information 26
2.2 Safety instructions for use of the device 26-27
2.3 Intended use 27
3. Delivery, packaging and storage 28
3.1 Delivery check 28
3.2 Packaging 28
3.3 Storage 28
4. Technical data 29
4.1 Overview of parts 29-30
4.2 Technical specification 31
5. Installation and operation 31
5.1 Safety instructions 31-32
5.2 Installation and connection 32-34
5.3 Operating 35-38
6. Cleaning and maintenance 39
6.1 Safety advice 39
6.2 Cleaning 39-40
6.3 Safety instructions for maintenance 40
7. Possible Malfunctions 40-41
8. Waste disposal 42
Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten phone: [phone]
Germany fax: [phone]
Keep this instruction manual
ready to hand at the product!
GB/UK

- 24 -
1. General information
1.1 Information about the instruction manual
This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.
Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
The instruction manual forms part of the product and should be kept near the device and
easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning.
1.2 Key to symbols
In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to avoid
any risk of accident, personal injury or material damage.
WARNING!
This symbol highlights hazards, which could lead to injury.
Please follow the instructions very carefully and proceed with particular attention
in these cases.
WARNING! Electrical hazard!
This symbol draws attention to potential electrical hazards. If you do not follow
the safety instructions, you may risk injury or death.
CAUTION!
This symbol highlights instructions, which should be followed to avoid any risk of
damage, malfunctioning and/or breakdown of the device.
NOTE!
This symbol highlights tips and information, which have to be followed for
an efficient and trouble-free operation of the device.

- 25 -
1.3 Liability and Warrantees
All the information and instructions in this manual take into account standard safety
regulations, current levels of technical engineering as well as the expertise and
experience we have developed over the years.
The instruction manual was translated with all due care and attention. However, we do
not accept liability for any translation errors. The German version of this instruction
manual is definitive.
If the delivery consists of a special model, the actual scope of delivery may differ from
the descriptions and illustrations in this manual. This is also the case for special orders
or when the device has been modified in line with new technology. If you have any
questions, you should contact the manufacturer.
NOTE!
Read the instruction manual carefully before using the device. The manufacturer
does not accept liability for any damage or malfunction resulting from not
following the instructions for use.
The instruction manual should be kept near the device, easily accessible for anyone
wishing to work with or using it. We reserve the right to make technical changes for
purposes of developing and improving the useful properties.
1.4 Copyright protection
The instruction manual including any texts, drawings, images or other illustrations is
copyright. No part of this publication may be reproduced, transmitted or used in any form
or by any means without permission in writing from the manufacturer. Any person who
commits any unauthorized act in relation to this publication shall be liable to claims for
damages. All rights reserved.
NOTE!
The contents, texts, drawings, pictures and any other illustrations are copyright
and subject to other protection rights. Any person unlawfully using this
publication is liable to criminal prosecution.
1.5 Declaration of conformity
The device complies with the current standards and directives of the EU.
We certify this in the EC declaration of conformity.
If required we will be glad to send you the according declaration of conformity.

- 26 -
2. Safety
This section provides an overview of all important safety aspects.
In addition every chapter provides precise safety advice for the prevention of dangers
which are highlighted by the use of the above mentioned symbols.
Furthermore, attention should be paid to all pictograms, markers and labels on the
device, which must be kept in a permanent state of legibility.
By following all the important safety advice you gain an optimal protection against all
hazards as well as the assurance of a safe and trouble-free operation.
2.1 General Information
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.
Knowing the contents of the instruction manual as well as avoiding mistakes and thus
operating this device safely and in a fault-free manner is very essential to protect
yourselves from the hazards.
To prevent hazards and to ensure optimum efficiency, no modifications or alterations to
the device that are not explicitly approved by the manufacturer may be undertaken.
This device may only be operated in technically proper and safe condition.
2.2 Safety instructions for use of the device
The specifications regarding the industrial safety are based on the Regulations of the
European Union applicable at the time of manufacturing the device.
If the device is used commercially, the user is obliged to ensure that the said industrial
safety measures concur with the state of the rules and regulations applicable at the time
in question for the entire period of use of the device and to comply with the new
specifications.
Outside the European Union, the industrial safety laws applicable at the place of
installation of the device and the regional territorial provisions must be complied with.
Besides the industrial safety instructions in the instruction manual, the general safety and
accident prevention regulations as well as environment protection regulations applicable
for area of application of the device must be followed and complied with.

- 27 -
CAUTION!
oThe device is not intended for use by individuals (including children) with physical or
mental disabilities, insufficient experience, and/or insufficient knowledge unless such
persons are under the care of a person responsible for their safety or have received
instructions regarding appropriate use of the device.
oChildren should be observed to ensure that they are not playing with the device.
o Preserve this manual safely. When passing on/selling the device to a third party, the
manuals must be handed over along with the device.
o Every person using the device must act in accordance to the manuals and under
consideration of the safety advice.
o The device is to be used indoors only.
2.3 Intended use
Safe operation is only guaranteed when using the device for its intended purpose.
Any technical interventions, as well as assembly and maintenance are to be made by a
qualified customer service only.
The deep freezer is intended only for freezing and long-term storage of appropriate
food products and for making ice cubes.
CAUTION!
Any use going beyond the intended purpose and/or any different use of the device
is forbidden and is not considered as conventional.
Any claims against the manufacturer or his authorized representative as a
consequence of experiencing damages resulting from unconventional use are
impossible.
The operator is liable for all damages resulting from inappropriate use.

- 28 -
3. Transport, packaging and storage
3.1 Delivery check
Please check the delivery upon completeness and transport damage immediately after
receipt.
In case of visible damage do not accept or accept the delivery with reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
3.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
NOTE!
If you liked to dispose the packing, consider the regulations applicable in your
country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.
3.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
-Do not store outdoors.
-Keep it dry and dust-free.
-Do not expose it to aggressive media.
-Do not expose it to direct sunlight.
-Avoid mechanical shocks and vibration.
-In case of longer storage (> 3 months) make sure you
check the state of the packaging and the parts regularly.
If required refresh or renew.

- 29 -
4. Technical data
4.1 Overview of parts
➀
Control panel and indicators
➁
Door handle
➂
Door
➃
Adjustable legs
➄
Drawers for storage of frozen food products (3)
➅
Rapid-freeze shelf (3)
➆
Shield for ice cube shelf
➆
➅
➄
➀
➃
➂
➁

- 30 -
Indicators and control functions
1 – Temperature indicator
2 – Rapid-freeze indicator (yellow)
3 – Rising temperature indicator (red)
4 – Standby control light (green)
5 – Temperature dial
Indicator functions
1
Temperature indicator
This indicator displays the unit’s internal temperature
2
Rapid-freeze indicator (yellow)
After rapid-freeze mode is activated, the yellow indicator light comes on.
(See also 5.3 "Freezing food products")
3
Rising temperature indicator (red)
This indicator comes on when the freezer’s internal temperature goes
above -14°C.
4
Standby control light (green)
This control light comes on when the unit is connected to a power source.
5
Temperature dial (levels: 0-5, S)
The dial is located below the control panel and indicators.
Temperature regulation is off when the dial is set to „0“. By turning the
dial clockwise, a lower temperature can be set.
1
5
2
3
4

- 31 -
4.2 Technical specification
Name Deep freezer 205 L
Article no. / model:
700.340
Construction: Interior and exterior: white, switchable door hinges
Coolant: R600a
Temperature range: -18°C to -24°C
Ambient temperature: +16°C to +32°C
Net capacity: 205 litres
Power: 0.135 kW / 230 V
Dimensions: W 600 x D 590 x H 1450 mm
Weight 50.0 kg
Equipment: ice cube tray
We reserve the right to make technical changes!
5. Installation and operation
5.1 Safety instructions
WARNING! Electrical hazard!
The device must only be connected to a properly installed single socket with
protective contact.
Never yank cord to disconnect from outlet.
Cable must not touch any hot parts.
•See that the cable does not touch any heat sources or sharp edges. Do not let the
cable dangle over the counter edge.
•Do not use the device in case it does not function properly, has been damaged or
dropped.
•Do not use any accessory or spare parts that have not been recommended by the
manufacturer. These can be dangerous for the user or lead to damages of the device
or personal injury, and further, the warranty expires.
•Do not lay the cable over carpets or heat insulations. Do not cover the cable. Keep
away the cable from operating range and do not dunk it into water.

- 32 -
WARNING! Electrical hazard!
Avoid water splashes on the deep freezer and do not expose the device to rain
water, dripping water or any other kind of moisture.
•Do not keep heavy, poisonous or rusty objects in the deep freezer.
•Take caution not to damage any part of the cooling system (compressor, etc.) to
avoid a coolant leak.
WARNING!
If coolant does leak from the cooling system, remove the device's plug from the
power source and call the customer service centre.
WARNING! Hazard via electrical current!
The device can cause injuries due to improper installation!
Before installation the local power grid specification should be compared with that
of the device (see type label). Connect the device only in case of compliance!
Take note of the security advice!
5.2 Aufstellen und Anschließen
NOTE!
The unit should be set up by two people!
•Unpack the unit.
•Remove the unit from the foam base. Remove the cellophane tape.
•Remove support A from the lower cover of the
unit (dia. 1). Remove the red cellophane tape,
which is only needed during transport.
•Dispose of packing material in accordance with
regulations.
•
Take the brackets (1) and insert them into the
guides (2) in the upper part of the unit’s rear wall
(dia. 2).
•Place the unit on a flat, safe surface that can
support its weight.
dia. 1
dia. 2

- 33 -
•Never place the unit on a flammable surface (e.g. carpet, etc.).
•Do not place the unit near an open flame, electric oven, cookers or any other source
of heat, nor in direct sunlight. High temperatures can damage the unit’s surface as
well as reduce its effectiveness and increase energy use.
•To avoid damaging the compressor, do not tilt the deep freezer to an angle over 45°
during setup and transport. Be careful when handling the condenser and doors, as
damage to them will negatively impact the unit’s functioning.
•Place the unit in a dry, well-ventilated space.
CAUTION!
The deep freezer must not be located or used in unheated spaces or on balconies!
•Do not locate the deep freezer in places with high humidity, as such conditions can
damage the unit and negatively impact its cooling capacity.
•The ventilation ducts at the top of the unit must not
be blocked or covered, and free air circulation must
be ensured.
•Maintain a minimum distance of 10 cm between the top
of the unit and objects located above it (e.g. cupboards).
Otherwise, the unit may use more energy or the
compressor may overheat (dia. 3).
•If the unit is to be located in a corner, leave at least 1 cm
space around the side walls of the unit and ensure that
the door can be opened wide enough to remove the
drawers.
•Do not place the unit against a wall.
•For the unit’s door to close on its own, the deep freezer
should be tilted back by regulating the front legs to a
uniform height. To regulate the deep freezer’s height,
tilt it gently backward so that the front legs are off the
floor.
•Do not drill any holes nor mount any objects on the inside or outside of the deep freezer.
•The electrical outlet should be secured to a minimum of 16A. Only connect the unit
directly to a wall socket; do not use extension cords or power strips.
•Locate the unit so that the socket is easily accessible in case it is necessary to
quickly disconnect it from its power source.
dia. 3

- 34 -
Switching door ’s hinges (dia. 4, 5)
•If necessary, the door’s hinges can be switched. To do so, you will need a no. 8 and
no. 10 screwdriver and a Phillips head screwdriver.
CAUTION!
When switching the door’s hinges, do not place the deep freezer in a horizontal
position!
•To switch the door’s hinges, disconnect the
unit from its power source by removing the
plug from its socket.
•Remove the lower shield (1).
•Remove the lower mounting (2) along with
peg, washer and plastic seals.
•Remove the unit’s door. Remove the
stopper (4) from the door and insert it into
the opening at the other side.
•Turn the peg (5) counter clockwise and
remove it with the nut and washer.
•Insert and turn the peg (5) with nut and
washer on the opposite side. Place the
door on the tightly-secured peg (5).
•Turn the lower handle (6) together with the
peg and attached washer and plastic seal in
the place of the handle (2). Screw the handle
(2) in the place for the handle (6).
•Remove the nuts (a) and stoppers (b). Unscrew the screws from the door hinge. Place
the hinge on the other side. Screw in the door hinge again. Insert the stoppers (b) in
the door openings, cover the screws with washers (a).
•Replace the lower shield (1).
dia.
5
dia.
4
1

- 35 -
5.3 Bedienung
Before first use
•Wash the unit before first use (6.2 „Cleaning“).
•Connect the unit to a single grounded outlet.
•The green standby control light will come on. The fan will come on and operate
constantly.
Temperature regulation
•The temperature is factory set to -18°C. It can be adjusted according to requirements.
•The temperature is regulated using a 5-level temperature dial.
When set to „O“ the compressor will turn off. The unit is still connected to its
power source.
When the temperature dial is turned clockwise, the temperature will fall.
The lowest temperature (deepest freezing) can be reached by setting the
temperature dial to „5“.
•When the door is closed, the temperature can be viewed on the temperature indicator.
NOTE!
First, set the temperature dial to „3“, then if the unit cools too strongly, set to „1-3“;
if it does not cool strongly enough, set to „3-5“.
•During first use and before placing food products inside the unit, wait for the deep
freezer to reach the desired temperature. This usually takes around 2 to 3 hours.
Freezing food products
•When freezing fresh foods, set the unit to rapid-freeze mode: turn the temperature
dial to the position market „S“ . The yellow rapid-freeze indicator will come on.
The compressor will function in this mode without interruption.
•Rapid-freeze shelves are marked with the symbol .
•Place the products for deep freezing on the rapid-freeze shelves and close the
shelves and deep freezer.
•After 24 hours, remove the frozen food products from the rapid-freeze shelves and
place them into the drawer below.
•Set the temperature dial to its initial position. The yellow rapid-freeze indicator light
will go off.

- 36 -
CAUTION!
Rapid-freeze mode will not shut off automatically.
The unit can not be left to function in rapid-freeze mode for longer than 3 days, or
damage to the compressor may result!
CAUTION!
Do not exceed a maximum of 24 kg of frozen products per 24 hours.
•Keep a minimum distance of 2.5 mm between frozen
food products (dia. 6).
Food products that are to be frozen should not be touching
food products that have already been frozen.
•Freeze only appropriate food products that are suitable
for low temperatures.
•Freeze only fresh foods.
•Use appropriate storage materials and properly pack the product. The packaging
cannot let out air and humidity, as this may cause the product to dry out. Foils and
bags must be soft and elastic so that they stick tightly to their contents. Do not place
unpacked food products into the deep freezer.
•Do not store glass bottles containing liquids. Liquids expand after freezing and the
bottles may burst.
•Remember to never re-freeze products that have thawed out or started to thaw out.
Thawed products should be prepared and consumed within max. 24 hours.
•Follow the producer’s instructions for freezing a given food product.
•It is best to freeze and thaw out small portions. This ensures quick, even freezing
and thawing. On the packing, write the contents and date of freezing.
•When freezing larger quantities of fresh foods the unit’s temperature may rise for a
short time. This has no effect on products already frozen and stored.
•Do not open the unit’s door during the freezing process.
NOTE!
To avoid using excess energy, use proper temperature settings.
•In case of an interruption in the power supply, do not open the unit’s door. This will
delay the rise in the unit’s internal temperature.
dia. 6

- 37 -
Storage of frozen food products
•Follow the instructions found on the packaging for food products. If there is no such
information, store frozen food products for a maximum of 3 months from the date of
purchase.
•Follow these rules for storage of frozen fresh foods:
fish and sausage: not longer than 6 months;
cheese, poultry, pork, veal: not longer than 8 months;
beef, fruits and vegetables: not longer than 12 months.
•Factory-frozen food product packaging should contain information on the time and
temperature of storage. Follow the producer’s instructions for the storage and
preparation of such food products,
•Select only appropriately-packaged food products with complete information, kept in
freezers at a minimum temperature of -18°C.
•When purchasing deep-frozen food products, transport them in appropriate containers
to avoid thawing out. Place them as quickly as possible into another freezer.
•Do not purchase food products covered in frost, as such products have already thawed
out several times.
•Protect food products from thawing out or beginning to thaw out, as increases in
temperature shortens storage times and reduces the products’ quality.
•Partially or fully-thawed out products should be consumed immediately.
Low temperatures preserve food products, but microorganisms are not killed. They
quickly reactivate, and the food products spoil rapidly. Partial thawing reduces the
nutritional value of food products, especially of fruits, vegetables and prepared meals.
•If the packaging is damaged or artificially inflated, it is very possible that the products
inside have been improperly stored and are spoiled.
Making ice cubes
•Ice cubes can be made using the ice cube tray. Fill each square to ¾ with potable
water.
•Place the ice cube tray on one of the rapid-freeze shelves.
•Leave the ice cubes at room temperature for approx. 5 minutes and place them into an
ice cube container.

- 38 -
Defrosting
•Defrost the unit at least two times per year, to avoid the layer of ice exceeding 5 mm.
CAUTION!
Before defrosting, disconnect the unit from its power supply by removing the plug
from its socket.
•Remove all food products from the unit. They will not thaw out if covered with a thick
blanket and kept in a cool place.
•
Remove the lower shield (dia. 7).
•
Place an appropriately large container under the unit in
order to gather water formed from the melting ice.
•Wait 10 - 20 minutes and remove the plug located in
the middle of the unit’s base to allow the water formed
from melting ice to flow out of the unit.
•Leave the unit’s door open while defrosting.
Dia. 7
CAUTION!
Do not use any sharp tools or other instruments to remove ice!
•After the ice has melted, wipe the interior of the unit dry with a soft cloth.
•Close the door and turn the unit on, leaving it to reach the desired temperature
before replacing the frozen food products inside.
•In case of a sudden power failure, open the door as rarely as possible to avoid loss
of cold air.
•After a power failure or after removing the plug from its socket, do not reconnect the
deep freezer for at least 15 minutes to a power source.
•Disconnect the unit if it is not to be used (turn the temperature dial to „0“ and remove
the plug from its socket). Defrost the unit following the instructions given above.
•If the unit will be left unused for a longer time, leave the door open.

- 39 -
6. Cleaning and maintenance
6.1 Safety advice
o Before beginning with repair or cleaning works make sure the device has been
disconnected from power socket (pull the power plug!!!) and has cooled down.
o Do not use any acid agents and make sure no water ingresses the device.
o To protect yourself from electric shock, never immerse the device, its cables and the
plug in water or other liquids.
CAUTION!
The device is not suited for direct washing via water jets. Therefore, you must not
use any kind of pressure water jet for cleaning the device!
6.2 Cleaning
oClean the unit regularly.
oProtect the unit’s surface and all plastic elements from greases, acids and sauces.
If such substances get on the unit’s surface, immediately wash with warm water and
a mild cleaning agent.
oClean the interior and exterior of the unit with warm water and a mild cleaning agent.
Wash with clean water.
oDry all washed surfaces thoroughly.
oRegularly clean and dry the door seals.
oRegularly clean the equipment (drawers, ice cube tray) with warm water and dry
before replacing it in the deep freezer.
CAUTION!
Never use hot water to wash the unit!
Never use harsh cleaning substances such as scouring powder, thinners, benzene
etc. as they can damage plastic elements and paint.
o Regularly remove dirt and dust from the rear wall of the unit and compressor with a
dry, soft brush, electrostatic cloth or vacuum cleaner.
CAUTION!
Never wash the compressor with water!
NOTE!
A dirty compressor has a negative impact on the unit’s functioning and increases
energy use!

- 40 -
WARNING! Danger of burns!
The compressor may be hot when in use.
Do not touch it with bare hands. Use protective gloves!
6.3 Safety instructions for maintenance
o Check the mains connection cable for damage from time to time. Never operate the
device when the cable is damaged. A damaged cable must immediately be replaced
by customer service or a qualified electrician to avoid dangers.
o In case of damage or malfunction, please contact your stockist or our customer
service centre. Pay attention to the troubleshooting tips in pt. 7.
o Only a qualified technician and using original spare parts and accessories should
carry out repairs and maintenance of the device. Do not attempt to repair the
device yourself.
7. Possible Malfunctions
Problem Cause Solution
The deep freezer
does not work, the
green standby light
does not come on
•The plug is not properly
inserted into a socket.
•The safety fuse is damaged.
•There is a power failure.
•Properly insert the plug.
•Check the power supply.
•Check the power supply.
The rising
temperature
indicator is red
•The unit is turned on for the
first time or was left off for a
longer period of time (e.g.
to defrost or following a
power outage).
•The unit’s door is opened
and closed too often.
•A large amount of fresh
food products has
caused the temperature
to go above -14°C.
Locate the source of the
problem and remove it if
possible.
If the rising temperature
indicator does not go off
after 6 hours, this means
the compressor is working
without interruption or is
not turning on. If this
occurs, contact service or
a sales agent.

- 41 -
Problem Cause Solution
The temperature
inside the unit is
high, breaks in the
compressor’s
functioning are
short
•The door is not closed
properly or is open for too
long.
•Too much food inside the
unit.
•The products inside the unit
are too warm.
•Close the door, pay
attention to the time the
door is left open.
•Remove excess food
products from the unit.
•Before freezing, let
products cool to room
temperature.
The unit is making
unusual or loud
sounds
•The deep freezer is not on
a flat surface.
•The deep freezer is in
contact with a wall or other
object.
•Place the deep freezer on
a flat surface.
•Ensure there is enough
space between the unit
and walls or other objects.
The rubber seal
comes off when the
door is opened
•The seal is dirty (e.g.
sticky food products) •Wash, dry and replace the seal.
The unit’s surface is
covered in mould •The ambient humidity is
above 70 %. •Air the unit out and remove the source of the humidity
if possible.
The problems described above are only examples, and should help you in locating
the source of the problem. If these or other problems occur, disconnect the unit
immediately and do not use it. If you are unable to fix the problems yourself,
contact a customer service or sales agent.
The following situations are not malfunctions or problems:
A short, quick noise or clicking when the compressor comes on.
The sound of running water. This is common during normal use and is the sound of
the coolant circulating through the system.
