True TM-52F User manual

Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
ROUGH-IN DATA
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366
[phone] • Fax [phone] • [phone] • Intl Fax# [phone]
Parts Dept. (800)424-TRUE • Parts Dept. Fax# [phone] • www.truemfg.com
Model:
TRUE FOOD SERVICE
EQUIPMENT, INC.
Project Name:
Location:
Item #: Qty:
Model #:
AIA #
SIS #
Printed in U.S.A.
APPROVALS: AVAILABLE AT:
T RUE R EFRIGERATION
MADE IN
SINCE 1945
U.S.A.
.S.A.
TM
U.S.A.
TM-52F
TM-52F
Model Doors
Capacity
(Cu. Ft.)
(liters) Shelves
Cabinet Dimensions
(inches)
(mm)
LD
†H*HP Voltage Amps
NEMA
Config.
Cord
Length
(total ft.)
(total m)
Crated
Weight
(lbs.)
(kg)
TM-52F 2 52
1473
654
1/8
1375
291/2
750
781/4
1988
3/4
1
115/60/1
230-240/50/1
13.0
6.4
5-20P
▲
9
2.74
525
239
†Depth does not include 23/8
" (61 mm) for upper rear condensate enclosure. ▲Plug type varies by country.
*Height does not include 5
" (127 mm) for castors or 6 " (153 mm) for optional legs.
6/07
R
True’s solid door reach-in’s are
designed with enduring quality
that protects your long term
investment.
Designed using the highest
quality materials and components
to provide the user with colder
product temperatures, lower
utility costs, exceptional food
safety and the best value in
today’s food service marketplace.
Extra large evaporator coil
balanced with higher horsepower
compressor and large condenser;
maintains -10°F (-23.3°C) cabinet
temperatures. Ideally suited for
both frozen foods and ice cream.
300 series stainless steel solid
doors and front. The very finest
stainless with higher tensile
strength for fewer dents and
scratches.
Adjustable, heavy duty PVC
coated shelves.
Positive seal self-closing doors.
Lifetime guaranteed door hinges
and torsion type closure system.
Automatic defrost system
time-initiated, temperature-
terminated. Saves energy
consumption and provides
shortest possible defrost cycle.
TM Series:
Reach-In Top Mount Solid Door Freezer
®

STANDARD FEATURES
Model:
TRUE FOOD SERVICE EQUIPMENT
2001 East Terra Lane • P.O. Box 970 • O’Fallon, Missouri 63366 • [phone] • Fax [phone] • [phone] • Intl. Fax# [phone] • www.truemfg.com
WARRANTY
One year warranty on all parts
and labor and an additional 4
year warranty on compressor.
(U.S.A. only)
METRIC DIMENSIONS ROUNDED UP TO THE
NEAREST WHOLE MILLIMETER
SPECIFICATIONS SUBJECT TO CHANGE
WITHOUT NOTICE
Model Elevation Right Plan 3D
PLAN VIEW
KCL
TM-52F TFEY21E TFEY41S TFEY41P TFEY413
TM-52F
DESIGN
• True’s commitment to using the
highest quality materials and oversized
refrigeration systems provides the user
with colder product temperatures, lower
utility costs, exceptional food safety and
the best value in today’s food service
marketplace.
REFRIGERATION SYSTEM
• Factory engineered, self contained,
capillary tube system using
environmentally friendly (CFC free) R404A
refrigerant.
• Extra large evaporator coil balanced
with higher horsepower compressor and
large condenser; maintains -10°F (-23.3°C)
cabinet temperature. Ideally suited for
both frozen foods and ice cream.
• Sealed, cast iron, self-lubricating
evaporator fan motor(s) and larger
fan blades give True reach-in’s a more
efficient low velocity, high volume airflow
design. This unique design ensures
faster temperature recovery and shorter
run times in the busiest of foodservice
environments.
• Top mounted condensing unit.
• Automatic defrost system time-initiated,
temperature-terminated. Saves energy
consumption and provides shortest
possible defrost cycle.
CABINET CONSTRUCTION
• Exterior - 300 series stainless steel doors
and front. Anodized quality aluminum
exterior ends and back.
• Interior - attractive, NSF approved, white
aluminum liner. 300 series stainless floor
with coved corners.
• Insulation - entire cabinet structure and
solid doors are foamed-in-place using
high density, CFC free, polyurethane
insulation.
• Welded, heavy duty galvanized frame rail
dipped in rust inhibiting enamel paint for
corrosion protection inside and out.
• Frame rail fitted with 4" (102 mm)
diameter stem castors - locks provided on
front set.
DOORS
• 300 series stainless steel exterior with
white aluminum liners to match cabinet
interior. Doors extend full width of
cabinet shell. Door locks standard.
• Lifetime guaranteed recessed door
handles. Each door fitted with 12"
(305 mm) long recessed handle that
is foamed-in-place with a sheet
metal interlock to ensure permanent
attachment.
• Positive seal self-closing doors. Lifetime
guaranteed door hinges and torsion type
closure system.
• Magnetic door gaskets of one piece
construction, removable without tools for
ease of cleaning.
SHELVING
• Six (6) adjustable, heavy duty PVC coated
wire shelves 249/16"L x 223/8"D (624 mm
x 569 mm). Four (4) chrome plated shelf
clips included per shelf.
• Shelf support pilasters made of same
material as cabinet interior; shelves are
adjustable on 1/2" (13 mm) increments.
LIGHTING
• Incandescent interior lighting - safety
shielded lights activated by rocker switch
mounted above doors.
MODEL FEATURES
• Exterior temperature display.
• Evaporator is epoxy coated to eliminate
the potential of corrosion.
• NSF-7 complaint for open food product.
ELECTRICAL
• Unit completely pre-wired at factory and
ready for final connection to a 115/60/1
- 20 amp dedicated outlet. Cord and plug
set included.
OPTIONAL FEATURES/ACCESSORIES
Upcharge and lead times may apply.
❒230-240V / 50 Hz.
❒6" (153 mm) standard legs.
❒6" (153 mm) seismic/flanged legs.
❒Alternate door hinging (factory installed).
❒Novelty baskets.
❒Additional shelves.
❒Half door bun tray racks. Each holds up
to eleven 18"L x 26"D (458 mm x
661 mm) sheet pans (sold separately)
(airflow guards need to be removed).
❒Full door bun tray racks. Each holds up to
twenty-two 18"L x 26"D (458 mm x
661 mm) sheet pans (sold separately)
(airflow guards need to be removed).
❒Remote cabinets (condensing unit
supplied by others; system comes standard
with 404A expansion valve and requires
R404A refrigerant). Consult factory
technical service department for BTU
information.
TM Series:
Reach-In Top Mount Solid Door Freezer
ELEVATION PLAN VIEW
541/8 "
(1375 mm)
2517/32 "
(649 mm)
5711/32 "
(1457 mm)
291/2 "
(750 mm)
13/16"
(31 mm)
5"
(127 mm)
77"
(1956 mm)
833/16"
(2113 mm)
191/16 "
(485 mm)
115/60/1
NEMA-5-20R
783/16"
(1986 mm)
4"
(102 mm)
