BASETech BR116 User manual

Bestimmungsgemäße Verwendung

Das Produkt ist zum Anschluss an einen USB-Port eines Computers vorgesehen und dient dort
zum Digitalisieren eines analogen AV-Signals (FBAS-/SVideo-Signal und Stereo-Audiosignal).
Dieses Produkt erfüllt die gesetzlichen, nationalen und europäischen Anforderungen. Alle ent-
haltenen Firmennamen und Produktbezeichnungen sind Warenzeichen der jeweiligen Inhaber.
Alle Rechte vorbehalten.
Lieferumfang

• Video-Grabber mit Anschlusskabel
• CD mit Treiber/Software
• Bedienungsanleitung
Sicherheitshinweise

Bei Schäden, die durch Nichtbeachten dieser Bedienungsanleitung verur-
sacht werden, erlischt die Gewährleistung/Garantie! Für Folgeschäden über-
nehmen wir keine Haftung!
Bei Sach- oder Personenschäden, die durch unsachgemäße Handhabung
oder Nichtbeachten der Sicherheitshinweise verursacht werden, übernehmen
wir keine Haftung! In solchen Fällen erlischt die Gewährleistung/Garantie.
• Aus Sicherheits- und Zulassungsgründen (CE) ist das eigenmächtige Umbauen
und/oder Verändern des Produkts nicht gestattet. Öffnen/zerlegen Sie es nicht!
• Das Produkt ist kein Spielzeug, es gehört nicht in Kinderhände.
• Das Produkt darf nicht feucht oder nass werden.
• Lassen Sie das Verpackungsmaterial nicht achtlos liegen, dieses könnte für Kin-
der zu einem gefährlichen Spielzeug werden.
• Gehen Sie vorsichtig mit dem Produkt um, durch Stöße, Schläge oder dem Fall
aus bereits geringer Höhe wird es beschädigt.
Treiber-/Software-Installation

Installieren Sie zuerst den Treiber und die die mitgelieferte Software, schließen Sie
den Video-Grabber noch nicht an!
• Starten Sie das Betriebssystem (Windows XP oder höher) und warten Sie, bis es vollständig
geladen ist.
• Legen Sie die mitgelieferte CD in das entsprechende Laufwerk Ihres Computers ein.
Sollte das Installationsprogramm nicht automatisch starten, so führen Sie es manuell aus.
Zum Zeitpunkt der Erstellung dieser Bedienungsanleitung war dazu das Programm „Autorun.
exe“ im Hauptverzeichnis der CD starten. Anschließend ist der Treiber zu installieren („Install
Drivers“ anklicken). Folgen Sie allen Anweisungen der Software.
Nach der Treiberinstallation muss die Software, mit der Videosignale digitalisiert werden kön-
nen, installiert werden. Klicken Sie dazu im Installationsprogramm auf „Install VHS to DVD“.
Folgen Sie allen Anweisungen der Software.
• Sie können das Fenster der Installationssoftware nun schließen.
Anschluss

• Installieren Sie zuerst den Treiber und die die mitgelieferte Software, falls noch nicht gesche-
hen, siehe vorangegangenes Kapitel.
• Schließen Sie den Video-Grabber an einen freien USB2.0-Port des Computers an. Beim
ersten Anschluss an den Computer erkennt Windows neue Hardware und schließt die Trei-
berinstallation ab.
• Starten Sie die Software.
• Schließen Sie eine AV-Quelle z.B. an den 3 Cinch-Buchsen an (die gelbe ist für das Videosig-
nal, die anderen beiden für das Audiosignal). Alternativ kann der SVideo-Anschluss für das
Videosignal und die rote/weiße Cinch-Buchse für das Audiosignal verwendet werden.
Tipps und Hinweise

• Verwenden Sie unbedingt einen USB2.0-Port, andernfalls gibt es Aussetzer und Ruckler bei
der Videoaufzeichnung.
• Installieren Sie immer zuerst den Treiber und anschließend die Software, bevor der Video-
Grabber an den Computer angeschlossen wird. Andernfalls funktioniert der Video-Grabber
nicht korrekt.
• Auf der CD nden Sie die englischsprachige Anleitung des Herstellers zur Software. Zum
Betrachten benötigen Sie ein Programm, das PDF-Dateien öffnen kann (z.B. den Acrobat
Reader, den Sie kostenlos bei www.adobe.com herunterladen können).
Entsorgung

Entsorgen Sie das Produkt am Ende seiner Lebensdauer gemäß den geltenden
gesetzlichen Bestimmungen.
D Bedienungsanleitung Version 03/15
°
USB2.0 Video-Grabber „BR116“
Best.-Nr. 1168633
Dies ist eine Publikation der Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
Alle Rechte einschließlich Übersetzung vorbehalten. Reproduktionen jeder Art, z. B. Fotokopie, Mikroverlmung, oder die Erfassung in
elektronischen Datenverarbeitungsanlagen, bedürfen der schriftlichen Genehmigung des Herausgebers. Nachdruck, auch auszugs-
weise, verboten. Die Publikation entspricht dem technischen Stand bei Drucklegung.
© Copyright 2015 by Conrad Electronic SE.

 Operating instructions
USB2.0 Video-Grabber „BR116“
Item no. 1168633
Version 03/15
°
Intended use

The product is intended to be connected to a USB port of a computer for digitising an analogue
AV signal (FBAS/SVideo signal and stereo-audio signal).
This product complies with the applicable national and European requirements. All names of
companies and products are the trademarks of the respective owner. All rights reserved.
Contents

• Video grabber with connection cable
• CD with driver/software
• Operating instructions
Safety Instructions

The warranty will be void in the event of damage caused by failure to observe
these safety instructions! We do not assume any liability for any consequen-
tial damage!
Nor do we assume any liability for material and personal damage caused by
improper use or non-compliance with the safety instructions! In such cases,
the warranty will be null and void.
• The unauthorised conversion and/or modication of the product is not permitted for
safety and approval reasons (CE). Do not open/disassemble!
• The product is not a toy and should be kept out of the reach of children.
• The product must not get damp or wet.
• Do not leave packaging material carelessly lying around, since it could become a
dangerous plaything for children.
• Handle the product with care, it can be damaged by impacts, blows, or accidental
drops, even from a low height.
Software/Drive Installation

First install the driver and the software in the delivery package, do not yet connect
the video grabber!
• Start the operating system (Windows XP or higher) and wait until it is completely loaded.
• Place the enclosed CD in the appropriate drive of your computer.
If the installation program does not start automatically, then load it manually. When these
operating instructions were written, there was a program “Autorun.exe” in the main directory
of the CD. Then install the drive (click on “Install Drivers”). Follow the software’s directions.
After the driver installation the software that enables digitalization of the video signal must
be installed. For this, click on “Install VHS to DVD” in the installation program. Follow the
software’s directions.
• Now you can close the window for the installation software.
Connection

• First install the driver and the enclosed software; if this has not been done, see previous
chapter.
• Connect the video grabber to a free USB 2.0 port on the computer. The rst time it is used,
the computer recognizes Windows’ new hardware and completes the installation.
• Start the software.
• Connect an AV source to the 3 RCA jacks (yellow for the video signal, the two others for the
audio signal). Alternatively, the SVideo connection can be used for the video signal and the
red/white RCA jack connectors for the audio signal.
Tips and Information

• Only use a USB 2.0 port otherwise there could be gaps and shakes in the video record.
• Always install the driver rst and then the software before the video grabber is connected to
the computer.
• On the CD you will nd the English language manufacturer’s directions for the software. To
view this you need a program that can open a PDF le (for example Acrobat Reader, which
can be downloaded for free at www.adobe.com).
Disposal

Dispose of the unserviceable product according to the relevant statutory regulations!
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microlming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represent
the technical status at the time of printing.
© Copyright 2015 by Conrad Electronic SE.

 Mode d'emploi
Numériseur USB2.0 « BR116 »
N° de commande 1168633
Version 03/15
°
Utilisation conforme

Le produit est conçu pour être connecté au port USB d´un ordinateur où il sert à numériser un
signal AV (signal FBAS / SVideo et signal stéréo-audio).
Cet appareil satisfait aux prescriptions légales nationales et européennes. Tous les noms d’en-
treprises et les appellations d’appareils figurant dans ce manuel d’utilisation sont des marques
déposées de leurs propriétaires respectifs. Tous droits réservés.
Contenu de la livraison

• Numériseur avec câble de raccordement
• CD avec pilote/logiciel
• Mode d’emploi
Consignes de sécurité

Tout dommage résultant d’un non-respect du présent manuel d’utilisation ent-
raîne l’annulation de la garantie ! Nous déclinons toute responsabilité pour les
dommages consécutifs !
De même, nous n’assumons aucune responsabilité en cas de dommages ma-
tériels ou corporels résultant d’une manipulation de l’appareil non conforme
aux spécications ou du non-respect des présentes consignes de sécurité !
Dans de tels cas, la garantie prend n.
• Pour des raisons de sécurité et d’homologation (CE), il est interdit de modier la
construction ou de transformer l’appareil de son propre gré. Ne l’ouvrez pas et ne
le démontez pas !
• Ce produit n’est pas un jouet ; gardez-le hors de portée des enfants.
• Le produit ne doit être ni humide ni mouillé.
• Ne laissez pas traîner le matériel d’emballage. Cela pourrait constituer un jouet
dangereux pour les enfants.
• Cet appareil doit être manipulé avec précaution ; les coups, les chocs ou une
chute, même de faible hauteur, peuvent l’endommager.
Installation des pilotes/du logiciel

Installez d‘abord le pilote et le logiciel fourni. Ne connectez pas encore la carte
d‘acquisition vidéo !
• Lancez le système d‘exploitation (Windows XP ou version ultérieure) et attendez qu‘il soit
complètement chargé.
• Insérez le CD fourni dans le lecteur correspondant de votre ordinateur.
Si le programme d’installation ne démarre pas automatiquement, exécutez-le manuellement.
Au moment de la rédaction de ce mode d‘emploi, il était nécessaire d‘exécuter le chier
« Autorun.exe » dans le répertoire racine du CD. Ensuite, le pilote doit être installé (cliquez
sur « Install Drivers »). Suivez toutes les instructions du logiciel.
Après l‘installation du pilote, le logiciel, avec lequel les signaux vidéo peuvent être numéri-
sés, doit être installé. Pour ce faire, cliquez sur « Install VHS to DVD » dans le programme
d‘installation. Suivez toutes les instructions du logiciel.
• Vous pouvez maintenant fermer la fenêtre du logiciel d‘installation.
Connexion

• Installez d‘abord le pilote et le logiciel fourni, si ce n‘est pas déjà fait, voir le chapitre précé-
dent.
• Branchez la carte d‘acquisition vidéo sur un port USB 2.0 libre de l‘ordinateur. Lors de la
première connexion à l‘ordinateur, Windows reconnaît le nouveau matériel informatique et
termine l‘installation du pilote.
• Lancez le logiciel.
• Raccorder une source AV p. ex. aux trois douilles Cinch (jaune pour le signal vidéo, les deux
autres pour le signal audio). Alternativement la connexion SVideo pour le signal vidéo et la
prise RCA rouge/blanche peuvent être utilisées pour le signal audio.
Trucs et astuces

• Utilisez impérativement un port USB 2.0, sinon il y aura des interruptions et des sauts dans
l‘enregistrement vidéo.
• Installez toujours d‘abord le pilote puis le logiciel avant de connecter la carte d‘acquisition
vidéo à l‘ordinateur. Sinon, la carte d‘acquisition vidéo ne fonctionnera pas correctement.
• Vous trouverez sur le CD le mode d‘emploi en anglais du fabricant pour le logiciel. Pour pou-
voir lire le chier, vous avez besoin d‘un programme qui puisse ouvrir les chiers PDF (p. ex.
Adobe Reader, que vous pouvez télécharger gratuitement à partir du site www.adobe.com).
Disposal

Jetez l’appareil devenu inutilisable suivant les lois en vigueur.
Ceci est une publication de Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
Tous droits réservés, y compris de traduction. Toute reproduction, quelle qu‘elle soit (p. ex. photocopie, microlm, saisie dans des
installations de traitement de données) nécessite une autorisation écrite de l‘éditeur. Il est interdit de le réimprimer, même par
extraits. Cette publication correspond au niveau technique du moment de la mise sous presse.
© Copyright 2015 by Conrad Electronic SE.

 Gebruiksaanwijzing
USB2.0 Video-grabber „BR116“
Bestelnr. 1168633
Versie 03/15
°
Beoogd gebruik

Het product is bedoeld voor aansluiting op een USB-poort van een computer om er een analoog
audiovisueel signaal mee te digitaliseren (FBAS-/SVideo-signaal en stereo-audiosignaal).
Dit product voldoet aan de wettelijke, nationale en Europese eisen. Alle voorkomende bedrijfs-
namen en productaanduidingen zijn handelsmerken van de betreffende eigenaren. Alle rechten
voorbehouden.
Omvang van de levering

• Video-grabber met aansluitsnoer
• Cd met stuurprogramma‘s/software
• Gebruiksaanwijzing
Veiligheidsaanwijzingen

Bij schade, veroorzaakt door het niet in acht nemen van deze gebruiksaanwi-
jzing, vervalt het recht op waarborg/garantie! Voor gevolgschade zijn wij niet
aansprakelijk!
Wij aanvaarden geen aansprakelijkheid voor materiële schade of persoonlijk
letsel, veroorzaakt door ondeskundig gebruik of het niet opvolgen van de vei-
ligheidsaanwijzingen! In dergelijke gevallen vervalt de waarborg/garantie.
• Om redenen van veiligheid en toelating (CE) is het eigenmachtig ombouwen en/of
wijzigen van het product niet toegestaan. Het product niet openen of demonteren!
• Het product is geen speelgoed, het is niet geschikt voor kinderen.
• Laat het product niet vochtig of nat worden.
• Laat verpakkingmateriaal niet rondslingeren, dit kan voor kinderen gevaarlijk
speelgoed zijn.
• Behandel het product voorzichtig: door stoten, schokken of een val - zelfs van
geringe hoogte - kan het beschadigd raken.
Driver-/software-installatie

Installeer eerst de driver en de meegeleverde software, sluit de video grabber nog
niet aan!
• Start het besturingssysteem (Windows XP of hoger) en wacht totdat het volledig geladen is.
• Leg de meegeleverde cd in het juiste station van uw computer.
Als het installatieprogramma niet automatisch start, voer het dan handmatig uit. Op het
moment van de samenstelling deze gebruiksaanwijzing moest daarvoor het programma
„Autorun.exe“ in het hoofdmenu van de cd starten. Daarna moet de driver geïnstalleerd wor-
den („Install Drivers“ aanklikken). Volg alle aanwijzingen van de software op.
Nadat de driver geïnstalleerd is, moet de software waarmee de videosignalen gedigitaliseerd
worden, geïnstalleerd worden. Klik daarvoor in het installatieprogramma op „Install VHS to
DVD“. Volg alle aanwijzingen van de software op.
• U kunt het venster van de installatiesoftware nu sluiten.
Aansluiten

• Installeer eerst de driver en de meegeleverde software, als dat nog gebeurt is, zie vorig
hoofdstuk.
• Sluit de video grabber op een vrije USB2.0-poort van de computer aan. Als u de video grab-
ber voor het eerst op de computer aansluit dan herkent Windows de nieuwe hardware en sluit
de driverinstallatie af.
• Start de software.
• Sluit een audiovisuele bron aan op bijvoorbeeld de drie cinch-bussen (de gele is bedo-
eld voor het videosignaal, de beide anderen voor het audiosignaal). Als alternatief kan de
S-video-aansluiting voor het videosignaal en de rood/witte cinch-bus voor het audiosignaal
worden gebruikt.
Tips en aanwijzingen

• Zorg ervoor dat u een USB 2.0-poort gebruikt, anders worden er frames overgeslagen of
gaan ze verloren tijdens de video-opname.
• Installeer altijd eerst de driver en dan de software voordat u de video grabber aan de com-
puter aansluit. Anders werkt de video grabber niet goed.
• Op de cd staan de instructies van de fabrikant van de software in het Engels. Om deze te
bekijken heeft u een programma dat de PDF-bestanden kan openen nodig (bijvoorbeeld
Adobe Acrobat Reader, dat u gratis kunt downloaden op www.adobe.com).
Verwijdering

Verwijder het product aan het einde van zijn levensduur af in overeenstemming met
de geldende wettelijke bepalingen.
Dit is een publicatie van Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
Alle rechten, vertaling inbegrepen, voorbehouden. Reproducties van welke aard dan ook, bijvoorbeeld fotokopie, microverlming of de
registratie in elektronische gegevensverwerkingsapparatuur, vereisen de schriftelijke toestemming van de uitgever. Nadruk, ook van
uittreksels, verboden. De publicatie voldoet aan de technische stand bij het in druk bezorgen.
© Copyright 2015 by Conrad Electronic SE. V2_0315_01/SM
