basIP SP-02 User manual

SP-02
SP-02
Exported on 07/11/2019

– 2
Table of Contents
Device description................................................................................................ 5
Technical parameters.......................................................................................... 6
Main features ................................................................................................................................. 6
Functional capabilities ............................................................................................................... 6
Configuration throught web interface...........................................................7
Login ..................................................................................................................................................7
Main ....................................................................................................................................................7
System information......................................................................................................................................................7
Registration status .......................................................................................................................................................7
Configuration................................................................................................................................. 8
Network/Print logs settings .....................................................................................................................................8
Network settings...........................................................................................................................................................9
Log display settings.....................................................................................................................................................9
Network applications ..................................................................................................................................................9
Phone settings .............................................................................................................................................................10
SIP/NAT settings.......................................................................................................................................................... 11
SIP settings..................................................................................................................................................................... 11
Emergency call settings ............................................................................................................................................ 11
NAT settings .................................................................................................................................................................. 11
Dial plan settings......................................................................................................................................................... 12
Speed dial ...................................................................................................................................................................... 13
Provisioning Settings................................................................................................................................................. 13
SIP accounts settings ................................................................................................................................................ 14
Call settings................................................................................................................................................................... 15
Audio settings .............................................................................................................................................................. 16
Admin settings.............................................................................................................................16
Dial a number ............................................................................................................................................................... 17
Dial a number ............................................................................................................................................................... 17
Dialed calls..................................................................................................................................................................... 17
Chat.................................................................................................................................................................................. 18
Chat historty ................................................................................................................................................................. 18
Phone number.............................................................................................................................................................. 18

– 3
Message to send.......................................................................................................................................................... 18
Firmware upgrade...................................................................................................................................................... 19
Firmware upgrade...................................................................................................................................................... 19
Configuration upgrade ............................................................................................................................................. 19
Configuration Backup ............................................................................................................................................... 19
Setup password........................................................................................................................................................... 19
Reboot ...........................................................................................................................................................................20
Restore default ...........................................................................................................................................................20

– 4
•Device description(see page 5)
•Technical parameters(see page 6)
•Configuration throught web interface(see page 7)

Device description– 5
Device description
SIP handset BAS-IP SP-02P supports P2P SIP and SIP 2.0.
On the handset there is a button for quick access to the concierge, programmable buttons for
calling other subscribers and a button for opening the lock.
Also, this SIP handset has a call waiting function, an emergency call function, a "do not disturb"
mode and a doorbell.

Technical parameters– 6
Technical parameters
Main features
Number of VoIP accounts supported: 2
Supported protocol type: IPv4 and IPv6
Network connection: 1 PoE port IEEE 802.3af
Power supply: 1 PoE port IEEE 802.3af
Type of supported codecs: G.711μ/ A; G.722; ILBC; G.729
Sound processing algorithms: VAD; CNG; AEC; PLC; AJB; AGC
Additional function: Doorbell
Audio Transmission Method: Full Duplex
Number of control keys: 3
Configuration and programming method: WEB-interface
Installation Method: Wall and Desktop
Dimensions: 203 × 55 × 55 mm
Available colors: Black, White
Functional capabilities
Answering machine: Yes
Software update: Via Ethernet
Optional: Connecting the call button; SIP P2P, Do not disturb mode

Configuration throught web interface– 7
Configuration throught web interface
To enter the WEB interface of the handset, you need to connect it to the router, wait for the
download and pick up the handset. If there is a dial tone on the handset, it received an IP
address via DHCP. If there is no dial tone, you need to check that the DHCP mode is enabled on
the router.
Login
In order to find out the IP address of the device, you need to pick up the phone and enter the
combination *12345#. The speaker will be announced a sequence of numbers in English.
Next you need to enter the IP-address in the address bar of the browser, username and
password.
Main
After entering the WEB interface, the following menu will be displayed:
System information
Product: Device Model.
MAC address: MAC address.
IP address: IP address of the handset.
Hardware Version: The current hardware version of the hardware.
Firmware datecode: Software Version.
Registration status
By default login is admin and password admin.

Configuration throught web interface– 8
Account 1, 2: Registration status of the account.
Also this menu has tabs:
Home: Current Menu
Admin:Advanced configration menu.
Configuration:Basic configuration menu.
Call Log: All Calls Menu.
Configuration
This menu shows the main settings of the device.
•Network/Print logs settings(see page 8)
•Network applications(see page 9)
•Phone settings(see page 10)
•SIP/NAT settings(see page 11)
•Dial plan settings(see page 12)
•Speed dial(see page 13)
•Provisioning Settings(see page 13)
•SIP accounts settings(see page 14)
•Call settings(see page 15)
•Audio settings(see page 16)
Network/Print logs settings
In this menu, the basic network settings and the log display are set.

Configuration throught web interface– 9
Network settings
DHCP:Enable/disable the mode of receiving network settings automatically.
IP:DeviceIP address.
Subnet mask:Subnet mask.
Default gateway:Default gateway address.
Primary DNS Server: The primary DNS server address.
Secondary DNS server:The address of the secondary DNS server.
Protocol:The network protocol used (IPv4 or IPv6).
Log display settings
Enable Print:Enable/disable logging mode.
Log level:Select the preferred logging level, where 0 is the minimum level, 7 is the most detailed
log.
Enable low-level logging:Enable/disable low-level logging to display it further.
Output to:Select the preferred output of log files (console, local file, syslog, and local file).
Syslog Server IP:The IP address of the log collection server.
Local file:The path to the location of the local file
Network applications
This menu displays TFTP and NTP server settings
TFTP server IP: Address of TFTP server.
By default, the SP-02 can have a DHCP mode enabled.
Option is enabled if DHCP is disabled.

Configuration throught web interface– 10
NTP enable: Enable/disable NTP server of timesynchronization
NTP server address: Address of NTP server.
Phone settings
Enable Dial Time Out: Enable/disable delay before dialing number.
Dial timeout: Set dial timeout.
Ring volume: Set ring volume.
Speaker volume: Set speaker volume.
Handset volume: Set handset volume.
Country zone: Select country zone.
Time Zone: Select time zone.

Configuration throught web interface– 11
SIP/NAT settings
SIP settings
Transport: Choose type of transport, TCP ot UDP.
Session timer: Enable session timer.
Update: Enable/disable session update.
PRACK: Enable/disable usage of PRACK.
NATPR: Enable/disable usage NATPR.
Flush button same account: Enable/disable usage of the same account for outgoing calls.
Local SIP port: Field to enter SIP port for registration.
Memory key: Field to enter direction to call when press INFObutton on the handset.
Emergency call settings
Emergency call number: Field to enter direction to call when you pick up the handset for
emergenct call.
Emergency call timeout:Choose timeout before call an emergency number.
NAT settings

Configuration throught web interface– 12
NAT mode:Enable/disable NAT.
STUN address: IP address or domain name of the STUN server.
STUN port:Field to enter STUN port.
RTP port start: Field to enter start RTP port.
RTP port stop: Field to enter end RTP port.
Dial plan settings
Dial plan enable: Enable/disable usage of dial plan foroutging calls.
Dial plan: Dial plan rule.
Dial map enable: Eable/disable usage of dial map for outgoing calls.
Dial map timeout: Timeout before dial map start working.
Dial map: Field to enter dial map.

Configuration throught web interface– 13
Speed dial
Speed dial enable:Enable/disable speed dial for outgoing calls.
Speed dial:Field to enter number to press to dial sip number which is entered in the"Dial
number"line.
Dial number:Field to enter direction to call when speed dial button is pressed.
Provisioning Settings

Configuration throught web interface– 14
Mode:Choose provisioning settings mode,(Disabled, Software, Configuration or both software
and configuration).
DHCP option:Choose preferred DHCP option.
URL:URL of provisioning server.
Time:Set time when handset will send info to provisioning server for checking data.
Day of week:Choose day of week for provisioning data from server.
SIP accounts settings
Registration Status:Current registration status of the account.
Display Name:Name, that will be dispalyed during outgoing calls.
Register Name:Login for registration on the server.
User Id:User IDfor registration on the server.
Password:Password for this SIP account.
Use Account:Enable/disable SIP account.
Registrar IP:IP address or domain name of the server.
Registrar Port:Registration port.
Proxy Server Address:IP address or domain name of the proxy server.
Expiry Time:Session expiry time.
Backup Registrar IP:Alternative IP address or domain name of the server.
Backup Registrar Port:Alternative registration port.

Configuration throught web interface– 15
Call settings
Call Forward Mode: Choose call forwarding mode, (Never, On no answer, On busy, Always).
Call Forward Start time: Enter a time in seconds after which the call forwarding will action.
Call Forward Number: A number to forward calls.
Call Waiting: Enable/disable call waiting.
DND: Themode "Do not disturb" allows you to turn off the sound of an incoming call and signal
the call by flashing the LED.
Auto Answer: Enable/disable automatic answer all incoming calls.
Hide Id: Enable/disable option to hideID of the SIP number during outging calls.
Reject Anonymous:Enable/disable rejection of anonymous calls.
To activate this mode from the handset, you need to hold down the "*" key for three
seconds, after which the handset will emit a long beep, which means the activation of
the "Do Not Disturb" mode.

Configuration throught web interface– 16
Audio settings
DTMF Mode:Choose DTMF mode, (RFC2833, Inband or SIP INFO).
SRTP Mode:Enable/disableencryption, message authentication and integrity, and replay attack
protection to the RTP data in both unicast and multicast applications.
Silence Suppression:Enable/disable silence suppression during calls.
Jitter:Choose preferred jitter level.
Packetization Time:Choose preferred paketization time.
Audio Codec 1-7:Choose preferred audio codec.
ToS:Choose ToS level.
Admin settings
•Dial a number(see page 17)
•Chat(see page 18)
•Firmware upgrade(see page 19)
•Setup password(see page 19)
•Reboot(see page 20)
•Restore default(see page 20)

Configuration throught web interface– 17
Dial a number
Dial a number
Phone number:Field to enter a number to dial from the web interface.
Dialed calls
Dislpays all dialed calls.

Configuration throught web interface– 18
Chat
Chat historty
Displays a history of all chats.
Phone number
Field to enter a phone number to start chat.
Message to send
Input field for message.

Configuration throught web interface– 19
Firmware upgrade
Firmware upgrade
Select the firmware file to update the handset.
Configuration upgrade
Select the configuration file to update the handset.
Configuration Backup
Create a backup configuration file.
Setup password
Username:Change admin login. By default, login isadmin.

Configuration throught web interface– 20
Password:Create new admin password.By default, password isadmin.
Confirm Password:Confirm new password.
Mask password:Hide password.
Reboot
In this tab you can make soft reboot of the handset.
Restore default
In this tab you can restore default settings of the handset.
