Batavia FIXXPACK 12 V BT-CAG003 User manual

Page 1
Model: BT-CAG003
Item-No.: 7064219
www.bataviapower.com
Cordless angle grinder
Akku-Winkelschleifer
Meuleuse d’angle sans l
Accu haakse slijper
Smerigliatrice angolare senza li
Amoladora de ángulo inalámbrica
Amoladora angular sem os
Bezprzewodowa szlierka kątowa
Operating instructions
PACK 12 V
7064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 17064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 1 22-03-2022 11:2022-03-2022 11:20

2
Page 2
2
DESCRIPTION OF THE SYMBOLS
The use of symbols in this manual is intended to draw your attention to possible
risks. The safety symbols and the explanations that accompany them must be
perfectly understood. The warnings in themselves do not remove the risks and
cannot replace correct actions for preventing accidents.
This symbol, marking a point of safety, indicates a caution, warning or danger.
Ignoring this warning can result in an accident to yourself or others. To limit the risks
of injury, fire or electrocution, always follow the recommendations indicated.
WARNING – To reduce the risk of injury, user must read instruction manual.
Before any use, refer to the corresponding section in this user manual.
These symbols indicates the requirement of wearing ear protection, eye protection
and gloves when using the product.
The crossed-out wheeled bin symbol indicates that the item should be disposed of
separately from household waste. The item should be handed in for recycling in
accordance with local environmental regulations for waste disposal. By separating a
marked item from household waste, you will help reduce the volume of waste sent to
incinerators or land-fill and minimize any potential negative impact on human health
and the environment.
4
personal injury.
e) Do not overreach. Keep a proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use
of dust collectors can reduce dust-related hazards.
4. Power tool use and care
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the rate
for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power source and/or the battery pack form
the power tool before making any adjustments, changing accessories or
storing the power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of the moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc., in accordance with
these instructions, taking into account the working conditions and the
work to be performed. The use of the power tool for operations different from
those intended could result in hazardous situations.
5. Service
a) Have your power tool serviced by qualified repair person using only
identical replacement parts. This will ensure that the safety of the power tool
is maintained.
b) Caution!
If the replacement of the supply cord is necessary, this has to be done by the
manufacturer or his agent in order to avoid a safety hazard.
SAFETY WARNINGS SPECIFIC FOR GRINDING OPERATIONS
a) This power tool is intended to function as a grinder. Read all safety
warnings, instructions, illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below may result in electric
shock, fire and/or serious injury.
b) Operations such as wire sanding, wire brushing, polishing or cutting-off are
not recommended to be performed with this power tool. Operations for which
the power tool was not designed may create a hazard and cause personal injury.
c) Do not use accessories which are not specifically designed and
recommended by the tool manufacturer. Just because the accessory can be
attached to your power tool, it does not assure safe operation.
Prefer a digital instead of a paper manual
or another language than English?
EN: Go to bataviapower.com or scan the QR-code. Less paper, more digital.
DE: Gehen Sie zu Bataviapower.com oder scannen Sie den QR-Code
FR: Allez sur Bataviapower.com ou scannez le code QR
NL: Ga naar Bataviapower.com of scan de QR-code
IT: Vai a Bataviapower.com o scansiona il codice QR
ES: Ir a Bataviapower.com o escanear el código QR
PT: Ir a Bataviapower.com ou digitalizar o código QR
PL: Wejdź na stronę Bataviapower.com lub zeskanuj kod QR
PL
7064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 27064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 2 22-03-2022 11:2022-03-2022 11:20

3
2
DESCRIPTION OF THE SYMBOLS
The use of symbols in this manual is intended to draw your attention to possible
risks. The safety symbols and the explanations that accompany them must be
perfectly understood. The warnings in themselves do not remove the risks and
cannot replace correct actions for preventing accidents.
This symbol, marking a point of safety, indicates a caution, warning or danger.
Ignoring this warning can result in an accident to yourself or others. To limit the risks
of injury, fire or electrocution, always follow the recommendations indicated.
WARNING – To reduce the risk of injury, user must read instruction manual.
Before any use, refer to the corresponding section in this user manual.
These symbols indicates the requirement of wearing ear protection, eye protection
and gloves when using the product.
The crossed-out wheeled bin symbol indicates that the item should be disposed of
separately from household waste. The item should be handed in for recycling in
accordance with local environmental regulations for waste disposal. By separating a
marked item from household waste, you will help reduce the volume of waste sent to
incinerators or land-fill and minimize any potential negative impact on human health
and the environment.
4
personal injury.
e) Do not overreach. Keep a proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep hair,
clothing and gloves away from moving parts. Loose clothes, jewellery or
long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use
of dust collectors can reduce dust-related hazards.
4. Power tool use and care
a) Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the rate
for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and must be
repaired.
c) Disconnect the plug from the power source and/or the battery pack form
the power tool before making any adjustments, changing accessories or
storing the power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of the moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc., in accordance with
these instructions, taking into account the working conditions and the
work to be performed. The use of the power tool for operations different from
those intended could result in hazardous situations.
5. Service
a) Have your power tool serviced by qualified repair person using only
identical replacement parts. This will ensure that the safety of the power tool
is maintained.
b) Caution!
If the replacement of the supply cord is necessary, this has to be done by the
manufacturer or his agent in order to avoid a safety hazard.
SAFETY WARNINGS SPECIFIC FOR GRINDING OPERATIONS
a) This power tool is intended to function as a grinder. Read all safety
warnings, instructions, illustrations and specifications provided with this
power tool. Failure to follow all instructions listed below may result in electric
shock, fire and/or serious injury.
b) Operations such as wire sanding, wire brushing, polishing or cutting-off are
not recommended to be performed with this power tool. Operations for which
the power tool was not designed may create a hazard and cause personal injury.
c) Do not use accessories which are not specifically designed and
recommended by the tool manufacturer. Just because the accessory can be
attached to your power tool, it does not assure safe operation.
7064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 37064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 3 22-03-2022 11:2022-03-2022 11:20

4
5
d) The rated speed of the accessory must be at least equal to the maximum
speed marked on the power tool. Accessories running faster than their rated
speed can break and fly apart.
e) The outside diameter and the thickness of your accessory must be within
the capacity rating of your power tool. Incorrectly sized accessories cannot be
adequately guarded or controlled.
f) Threated mounting of accessories must match the grinder spindle thread.
For accessories mounted by flanges, the arbour hole of the accessory must
fit the locating diameter of the flange. Accessories that do not match the
mounting hardware of the power tool will run out of balance, vibrate excessively
and may cause loss of control.
g) Do not use a damaged accessory. Before each use inspect the accessory such
as abrasive wheels for chips and cracks, backing pad for cracks, tear or excess
wear for loose or cracked wires. If power tool or accessory is dropped, inspect for
damage or install an undamaged accessory. After inspecting and installing an
accessory, position yourself and bystanders away from the plane of the rotating
accessory and run the power tool at maximum no-load speed for one minute.
Damaged accessories will normally break apart during this test time.
h) Wear personal protective equipment. Depending on application, use face
shield, safety goggles or safety glasses. As appropriate, wear dust mask,
hearing protectors, gloves and workshop apron capable of stopping small
abrasive or workpiece fragments. The eye protection must be capable of stopping
flying debris generated by various operations. The dust mask or respirator must
be capable of filtrating particles generated by your operation. Prolonged exposure
to high intensity noise may cause hearing loss.
i) Keep bystanders a safe distance away from work area. Anyone entering the
work area must wear personal protective equipment. Fragments of workpiece
or of a broken accessory may fly away and cause injury beyond immediate area
of operation.
j) Hold the power tool by insulated gripping surfaces only, when performing
an operation where the cutting accessory may contact hidden wiring or its
own cord. Cutting accessory contacting a "live" wire may make exposed metal
parts of the power tool "live" and could give the operator an electric shock.
k) Position the cord clear of the spinning accessory. If you lose control, the cord
may be cut or snagged and your hand or arm may be pulled into the spinning
accessory.
l) Never lay the power tool down until the accessory has come to a complete
stop. The spinning accessory may grab the surface and pull the power tool out of
your control.
m) Do not run the power tool while carrying it at your side. Accidental contact
with the spinning accessory could snag your clothing, pulling the accessory into
your body.
n) Regularly clean the power tool’s air vents. The motor’s fan will draw the dust
inside the housing and excessive accumulation of powdered metal may cause
electrical hazards.
o) Do not operate the power tool near flammable materials. Sparks could ignite
these materials.
p) Do not use accessories that require liquid coolants. Using water or other
liquid coolants may result in electrocution or shock.
q) Use only wheel types that are recommended for your power tool and the
specific guard designed for the selected wheel. Wheels for which the power
tool was not designed cannot be adequately guarded and are unsafe.
r) The guard must be securely attached to the power tool and positioned for
maximum safety, so the least amount of wheel is exposed towards the
operator. The guard helps to protect operator from broken wheel fragments and
accidental contact with wheel and sparks that could ignite clothing.
6
s) Wheels must be used only for recommended applications. For example: do
not grind with the side of cut-off wheel. Abrasive cut-off wheels are intended
for peripheral grinding, side forces applied to these wheels may cause them to
shatter.
t) Always use undamaged wheel flanges that are of correct size and shape for
your selected wheel. Proper wheel flanges support the wheel thus reducing the
possibility of wheel breakage. Flanges for cut-off wheels may be different from
grinding wheel flanges.
u) Do not use worn down wheels from larger power tools. Wheel intended for
larger power tool is not suitable for the higher speed of a smaller tool and may
burst.
Kickback and Related Warnings
Kickback is a sudden reaction to a pinched or snagged rotating wheel, backing pad,
brush or any other accessory. Pinching or snagging causes rapid stalling of the
rotating accessory which in turn causes the uncontrolled power tool to be forced in
the direction opposite of the accessory’s rotation at the point of the binding.
For example, if an abrasive wheel is snagged or pinched by the workpiece, the edge
of the wheel that is entering into the pinch point can dig into the surface of the
material causing the wheel to climb out or kick out. The wheel may either jump
toward or away from the operator, depending on direction of the wheel’s movement
at the point of pinching. Abrasive wheels may also break under these conditions.
Kickback is the result of power tool misuse and/or incorrect operating procedures or
conditions and can be avoided by taking proper precautions as given below.
a) Maintain a firm grip on the power tool and position your body and arm to
allow you to resist kickback forces. Always use auxiliary handle, if provided,
for maximum control over kickback or torque reaction during start-up. The
operator can control torque reactions or kickback forces, if proper precautions are
taken.
b) Never place your hand near the rotating accessory. Accessory may kickback
over your hand.
c) Do not position your body in the area where power tool will move if kickback
occurs. Kickback will propel the tool in direction opposite to the wheel’s movement at
the point of snagging.
d) Use special care when working corners, sharp edges etc. Avoid bouncing
and snagging the accessory. Corners, sharp edges or bouncing have a tendency
to snag the rotating accessory and cause loss of control or kickback.
e) Do not attach a saw chain woodcarving blade or toothed saw blade. Such
blades create frequent kickback and loss of control.
WARNING
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth defects or
other reproductive harm. Some examples of these chemicals are:
- lead from lead-based paints,
- crystalline silica from bricks and cement and other masonry products, and
- arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of
work. To reduce your exposure to these chemicals: work in a well ventilated area,
and work with approved safety equipment, such as those dust masks that are
specially designed to filter out microscopic particles.
7064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 47064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 4 22-03-2022 11:2022-03-2022 11:20

5
5
d) The rated speed of the accessory must be at least equal to the maximum
speed marked on the power tool. Accessories running faster than their rated
speed can break and fly apart.
e) The outside diameter and the thickness of your accessory must be within
the capacity rating of your power tool. Incorrectly sized accessories cannot be
adequately guarded or controlled.
f) Threated mounting of accessories must match the grinder spindle thread.
For accessories mounted by flanges, the arbour hole of the accessory must
fit the locating diameter of the flange. Accessories that do not match the
mounting hardware of the power tool will run out of balance, vibrate excessively
and may cause loss of control.
g) Do not use a damaged accessory. Before each use inspect the accessory such
as abrasive wheels for chips and cracks, backing pad for cracks, tear or excess
wear for loose or cracked wires. If power tool or accessory is dropped, inspect for
damage or install an undamaged accessory. After inspecting and installing an
accessory, position yourself and bystanders away from the plane of the rotating
accessory and run the power tool at maximum no-load speed for one minute.
Damaged accessories will normally break apart during this test time.
h) Wear personal protective equipment. Depending on application, use face
shield, safety goggles or safety glasses. As appropriate, wear dust mask,
hearing protectors, gloves and workshop apron capable of stopping small
abrasive or workpiece fragments. The eye protection must be capable of stopping
flying debris generated by various operations. The dust mask or respirator must
be capable of filtrating particles generated by your operation. Prolonged exposure
to high intensity noise may cause hearing loss.
i) Keep bystanders a safe distance away from work area. Anyone entering the
work area must wear personal protective equipment. Fragments of workpiece
or of a broken accessory may fly away and cause injury beyond immediate area
of operation.
j) Hold the power tool by insulated gripping surfaces only, when performing
an operation where the cutting accessory may contact hidden wiring or its
own cord. Cutting accessory contacting a "live" wire may make exposed metal
parts of the power tool "live" and could give the operator an electric shock.
k) Position the cord clear of the spinning accessory. If you lose control, the cord
may be cut or snagged and your hand or arm may be pulled into the spinning
accessory.
l) Never lay the power tool down until the accessory has come to a complete
stop. The spinning accessory may grab the surface and pull the power tool out of
your control.
m) Do not run the power tool while carrying it at your side. Accidental contact
with the spinning accessory could snag your clothing, pulling the accessory into
your body.
n) Regularly clean the power tool’s air vents. The motor’s fan will draw the dust
inside the housing and excessive accumulation of powdered metal may cause
electrical hazards.
o) Do not operate the power tool near flammable materials. Sparks could ignite
these materials.
p) Do not use accessories that require liquid coolants. Using water or other
liquid coolants may result in electrocution or shock.
q) Use only wheel types that are recommended for your power tool and the
specific guard designed for the selected wheel. Wheels for which the power
tool was not designed cannot be adequately guarded and are unsafe.
r) The guard must be securely attached to the power tool and positioned for
maximum safety, so the least amount of wheel is exposed towards the
operator. The guard helps to protect operator from broken wheel fragments and
accidental contact with wheel and sparks that could ignite clothing.
6
s) Wheels must be used only for recommended applications. For example: do
not grind with the side of cut-off wheel. Abrasive cut-off wheels are intended
for peripheral grinding, side forces applied to these wheels may cause them to
shatter.
t) Always use undamaged wheel flanges that are of correct size and shape for
your selected wheel. Proper wheel flanges support the wheel thus reducing the
possibility of wheel breakage. Flanges for cut-off wheels may be different from
grinding wheel flanges.
u) Do not use worn down wheels from larger power tools. Wheel intended for
larger power tool is not suitable for the higher speed of a smaller tool and may
burst.
Kickback and Related Warnings
Kickback is a sudden reaction to a pinched or snagged rotating wheel, backing pad,
brush or any other accessory. Pinching or snagging causes rapid stalling of the
rotating accessory which in turn causes the uncontrolled power tool to be forced in
the direction opposite of the accessory’s rotation at the point of the binding.
For example, if an abrasive wheel is snagged or pinched by the workpiece, the edge
of the wheel that is entering into the pinch point can dig into the surface of the
material causing the wheel to climb out or kick out. The wheel may either jump
toward or away from the operator, depending on direction of the wheel’s movement
at the point of pinching. Abrasive wheels may also break under these conditions.
Kickback is the result of power tool misuse and/or incorrect operating procedures or
conditions and can be avoided by taking proper precautions as given below.
a) Maintain a firm grip on the power tool and position your body and arm to
allow you to resist kickback forces. Always use auxiliary handle, if provided,
for maximum control over kickback or torque reaction during start-up. The
operator can control torque reactions or kickback forces, if proper precautions are
taken.
b) Never place your hand near the rotating accessory. Accessory may kickback
over your hand.
c) Do not position your body in the area where power tool will move if kickback
occurs. Kickback will propel the tool in direction opposite to the wheel’s movement at
the point of snagging.
d) Use special care when working corners, sharp edges etc. Avoid bouncing
and snagging the accessory. Corners, sharp edges or bouncing have a tendency
to snag the rotating accessory and cause loss of control or kickback.
e) Do not attach a saw chain woodcarving blade or toothed saw blade. Such
blades create frequent kickback and loss of control.
WARNING
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth defects or
other reproductive harm. Some examples of these chemicals are:
- lead from lead-based paints,
- crystalline silica from bricks and cement and other masonry products, and
- arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of
work. To reduce your exposure to these chemicals: work in a well ventilated area,
and work with approved safety equipment, such as those dust masks that are
specially designed to filter out microscopic particles.
7064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 57064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 5 22-03-2022 11:2022-03-2022 11:20

6
7
INTENDED USE
The device is intended for the dry cutting, rough grinding and brushing of metal and
stone. Any other use or modification to the device shall be considered as improper
use and could give rise to considerable dangers. We will not accept liability for loss or
damage arising from improper use.
LIST OF MAIN PART
1. On-Off switch
2. Speed control button
3. Battery indicator
4. Spindle lock button
TECHNICAL SPECIFIATIONS
Voltage:
12 V
Rated speed:
12000-19500 minˉ¹
Drive spindle diameter:
M5
Max. grinding disc size:
Φ76mm
Sound pressure level LpA
75,6 dB(A) k=3dB(A)
Sound power level LwA
86,6 dB(A) k=3dB(A)
vibration level
0,732 m/s
²
k=1,5m/s
²
NOISE/VIBRATION INFORMATION
Measured sound values determined according to EN 60745.
Wear hearing protection!
Vibration total values (triax vector sum) determined according to EN 60745:
The vibration emission level given in this information sheet has been measured in
accordance with a standardized test given in EN 60745 and may be used to compare
one tool with another.
It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool.
However if the tool is used for different applications, with different accessories or poorly
maintained, the vibration emission may differ. This may significantly increase the
exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the
times when the tool is switched off or when it is running but not actually doing the job.
This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration
such as: maintain the tool and the accessories, keep the hands warm, organisation of
8
work patterns.
Vibration risk limitation suggestions:
1) Wear glove during operation
2) Limit operating time and shorten trigger time.
OPERATION
Before use
Remove any packing material and loose parts from unit.
Check the accessories before use. It should be fit with the machine and your
purpose.
If the machine is new, the battery must first be charged.
Attention!
After long time storage, the battery capacity will be reduce.
Battery is housed in the handle, press the battery retention clips, and remove battery
from handle.
A substantial drop in operating period per charge indicates that the battery is worn
out and must be replaced.
Battery charger
The power voltage supply must conform to that specified on the rating plate of the
rapid charger.
Always inspect battery charger, cord and plug before use.
Always have damage repaired by a qualified professional.
Protect battery charger against humidity and operate only in dry areas.
The supplied charger is suitable for charging batteries only.
Charging the battery
To start the charging process plug the charger into the battery, then plug in the
battery charger to the main
The battery and charger become warm during the charging process, this is normal.
After termination of the charging process, pull charger plug out of mains socket
unplug charger from battery.
LED indicator on charger: red indicator: charging.
green indicator: charge finished.
About the charger
Disconnect the feeding before connecting or disconnecting the battery
The charger must be used only with rechargeable battery. Never use un-
rechargeable battery.
Do not expose the charger to rain or water
Spindle lock function
Press the spindle lock to prevent spindle rotation when installing or removing discs.
Battery retention clip
7064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 67064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 6 22-03-2022 11:2022-03-2022 11:20

7
7
INTENDED USE
The device is intended for the dry cutting, rough grinding and brushing of metal and
stone. Any other use or modification to the device shall be considered as improper
use and could give rise to considerable dangers. We will not accept liability for loss or
damage arising from improper use.
LIST OF MAIN PART
1. On-Off switch 2. Speed control button
3. Battery indicator 4. Spindle lock button
TECHNICAL SPECIFIATIONS
Voltage: 12 V
Rated speed: 12000-19500 minˉ¹
Drive spindle diameter: M5
Max. grinding disc size: Φ76mm
Sound pressure level LpA 75,6 dB(A) k=3dB(A)
Sound power level LwA
86,6 dB(A) k=3dB(A)
vibration level 0,732 m/s² k=1,5m/s²
NOISE/VIBRATION INFORMATION
Measured sound values determined according to EN 60745.
Wear hearing protection!
Vibration total values (triax vector sum) determined according to EN 60745:
The vibration emission level given in this information sheet has been measured in
accordance with a standardized test given in EN 60745 and may be used to compare
one tool with another.
It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool.
However if the tool is used for different applications, with different accessories or poorly
maintained, the vibration emission may differ. This may significantly increase the
exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the
times when the tool is switched off or when it is running but not actually doing the job.
This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration
such as: maintain the tool and the accessories, keep the hands warm, organisation of
8
work patterns.
Vibration risk limitation suggestions:
1) Wear glove during operation
2) Limit operating time and shorten trigger time.
OPERATION
Before use
Remove any packing material and loose parts from unit.
Check the accessories before use. It should be fit with the machine and your
purpose.
If the machine is new, the battery must first be charged.
Attention!
After long time storage, the battery capacity will be reduce.
Battery is housed in the handle, press the battery retention clips, and remove battery
from handle.
A substantial drop in operating period per charge indicates that the battery is worn
out and must be replaced.
Battery charger
The power voltage supply must conform to that specified on the rating plate of the
rapid charger.
Always inspect battery charger, cord and plug before use.
Always have damage repaired by a qualified professional.
Protect battery charger against humidity and operate only in dry areas.
The supplied charger is suitable for charging batteries only.
Charging the battery
To start the charging process plug the charger into the battery, then plug in the
battery charger to the main
The battery and charger become warm during the charging process, this is normal.
After termination of the charging process, pull charger plug out of mains socket
unplug charger from battery.
LED indicator on charger: red indicator: charging.
green indicator: charge finished.
About the charger
Disconnect the feeding before connecting or disconnecting the battery
The charger must be used only with rechargeable battery. Never use un-
rechargeable battery.
Do not expose the charger to rain or water
Spindle lock function
Press the spindle lock to prevent spindle rotation when installing or removing discs.
Battery retention clip
7064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 77064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 7 22-03-2022 11:2022-03-2022 11:20

8
9
Speed adjustment
The tool has a variable speed control with 1+six settings for precise speed
adjustment. Set it to the required speed for operation. The required speed is depend
on the material and is to be determined by a practical trial.
On/Off Trigger
1. Switching on
Move the On/Off switch forward to the tool head and press the front part of it down
until it latched. Then you can release the switch, it will lock on for continuous use.
2. Switching off
Push down the back of the On/Off switch and move it backwards to the rear of the
tool to switch off.
Working advice
After heavily straining the power tool, continue to run it at no-load for several minutes
to cool down the cutting/grinding tool.
Discs become very hot while working; do not touch until they have cooled.
Don’t use the machine near inflammable materials, the flying sparks are very hot and
could cause fire or personal injury.
Please always make sure grinding disc touch with workpiece at approximately 15° to
30º and move slowly.
WARNING
Don’t apply big pressure to the machine.
Best results can be obtained by only a slight pressure on the tool; Forcing and
excessive pressure will damage the disk and cause serious personal injury.
Instruction for abrasive wheels and discs
10
Abrasive wheels should not be mounted on makeshift apparatus. They should be
mounted on the type of machine for which they are intended. These appear to be
obvious precautions, but accidents still occur because wheels are mounted on home-
made or improvised apparatus quite unsuitable for the work. Likewise, accidents are
caused by heavy wheels being fitted to spindles designed to take only the lightest of
wheels. As a result, vibration is excessive and breakages occur. On no account
should an abrasive wheel be screwed on to the tapered spindle of a buffing machine.
This dangerous method of mounting is likely to result in the breaking of the wheel
owing to the wedging action of the tapered spindle.
The new wheels should be carefully unpacked, cleaned with a brush and examined
for possible damage in transit. In unpacking, the careless use of a tool may cause
damage to the wheel. The soundness of wheels can be further checked by tapping
them with a light, non-metallic implement. This is known as the ‘ring’ test. Wheels
must be dry and free from sawdust for the ring test otherwise the sound will be
deadened. It should also be noted that organic bonded wheels do not emit the same
clear metallic ring as inorganic bonded wheels. Heavy wheels should be supported
on a clean hard floor for the ring test while light wheels should be suspended from
their hole on a finger or small pin. If the wheel sounds dead, for example due to
cracking, it should not be used.
All abrasive wheels are relatively fragile. It should not be assumed that organic
bonded wheels (resin, shellac, rubber) will stand rough handling.
As the wheel wears down in use, the effective peripheral surface speed will reduce if
the rotational speed remains constant and may result in a reduced grinding efficiency.
To make sure the machine work smoothly, the wheel should be replace with the
maximum diameter less than 80 mm.
MAINTENANCE
Keep the ventilation openings clear and clean the product regularly.
If something unusual occurs during use, switch off the supply and disconnect the
plug. Inspect and repair the tool before using it again.
Repair of the tool must only be carried out by a qualified repair technician.
Repair or maintenance by unqualified personnel can lead to a risk of injury.
Use only identical spare parts for repairing a tool. Follow the instructions in
the maintenance section of this user manual.
Clean the housing only with a damp cloth-do not uses any solvents! Dry thoroughly
afterwards.
STORING
Store the machine, operating instructions and where necessary the accessories in
the original packaging. In this way you will always have all the information and parts
ready to hand.
Pack the device well or use the original packaging in order to avoid transit damage.
Always keep the machine and its accessories in dry place.
Instruction for abrasive wheels and discs
Stack and support wheels carefully on trucks so that they will not topple over and be
damaged. Do not pile heavy castings or tools on top of abrasive wheels.
Suitable racks, bins or compartmented drawers should be provided to accommodate
the various types of wheels used. Most plain and tapered wheels are best supported
on their edges or on a central support.
To minimise deterioration, wheels must be stored in a room which is dry and not
subject to extreme temperatures. It is recommended that wheels should be marked
with the date they are received from the supplier. Older wheels should be issued
before newer wheels and if there is any doubt, or if wheels have been in stock for
more than three years, the manufacturer should be consulted about their suitability
for use.
7064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 87064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 8 22-03-2022 11:2022-03-2022 11:20

9
9
Speed adjustment
The tool has a variable speed control with 1+six settings for precise speed
adjustment. Set it to the required speed for operation. The required speed is depend
on the material and is to be determined by a practical trial.
On/Off Trigger
1. Switching on
Move the On/Off switch forward to the tool head and press the front part of it down
until it latched. Then you can release the switch, it will lock on for continuous use.
2. Switching off
Push down the back of the On/Off switch and move it backwards to the rear of the
tool to switch off.
Working advice
After heavily straining the power tool, continue to run it at no-load for several minutes
to cool down the cutting/grinding tool.
Discs become very hot while working; do not touch until they have cooled.
Don’t use the machine near inflammable materials, the flying sparks are very hot and
could cause fire or personal injury.
Please always make sure grinding disc touch with workpiece at approximately 15° to
30º and move slowly.
WARNING
Don’t apply big pressure to the machine.
Best results can be obtained by only a slight pressure on the tool; Forcing and
excessive pressure will damage the disk and cause serious personal injury.
Instruction for abrasive wheels and discs
10
Abrasive wheels should not be mounted on makeshift apparatus. They should be
mounted on the type of machine for which they are intended. These appear to be
obvious precautions, but accidents still occur because wheels are mounted on home-
made or improvised apparatus quite unsuitable for the work. Likewise, accidents are
caused by heavy wheels being fitted to spindles designed to take only the lightest of
wheels. As a result, vibration is excessive and breakages occur. On no account
should an abrasive wheel be screwed on to the tapered spindle of a buffing machine.
This dangerous method of mounting is likely to result in the breaking of the wheel
owing to the wedging action of the tapered spindle.
The new wheels should be carefully unpacked, cleaned with a brush and examined
for possible damage in transit. In unpacking, the careless use of a tool may cause
damage to the wheel. The soundness of wheels can be further checked by tapping
them with a light, non-metallic implement. This is known as the ‘ring’ test. Wheels
must be dry and free from sawdust for the ring test otherwise the sound will be
deadened. It should also be noted that organic bonded wheels do not emit the same
clear metallic ring as inorganic bonded wheels. Heavy wheels should be supported
on a clean hard floor for the ring test while light wheels should be suspended from
their hole on a finger or small pin. If the wheel sounds dead, for example due to
cracking, it should not be used.
All abrasive wheels are relatively fragile. It should not be assumed that organic
bonded wheels (resin, shellac, rubber) will stand rough handling.
As the wheel wears down in use, the effective peripheral surface speed will reduce if
the rotational speed remains constant and may result in a reduced grinding efficiency.
To make sure the machine work smoothly, the wheel should be replace with the
maximum diameter less than 80 mm.
MAINTENANCE
Keep the ventilation openings clear and clean the product regularly.
If something unusual occurs during use, switch off the supply and disconnect the
plug. Inspect and repair the tool before using it again.
Repair of the tool must only be carried out by a qualified repair technician.
Repair or maintenance by unqualified personnel can lead to a risk of injury.
Use only identical spare parts for repairing a tool. Follow the instructions in
the maintenance section of this user manual.
Clean the housing only with a damp cloth-do not uses any solvents! Dry thoroughly
afterwards.
STORING
Store the machine, operating instructions and where necessary the accessories in
the original packaging. In this way you will always have all the information and parts
ready to hand.
Pack the device well or use the original packaging in order to avoid transit damage.
Always keep the machine and its accessories in dry place.
Instruction for abrasive wheels and discs
Stack and support wheels carefully on trucks so that they will not topple over and be
damaged. Do not pile heavy castings or tools on top of abrasive wheels.
Suitable racks, bins or compartmented drawers should be provided to accommodate
the various types of wheels used. Most plain and tapered wheels are best supported
on their edges or on a central support.
To minimise deterioration, wheels must be stored in a room which is dry and not
subject to extreme temperatures. It is recommended that wheels should be marked
with the date they are received from the supplier. Older wheels should be issued
before newer wheels and if there is any doubt, or if wheels have been in stock for
more than three years, the manufacturer should be consulted about their suitability
for use.
7064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 97064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 9 22-03-2022 11:2022-03-2022 11:20

10
DISPOSAL
Do not dispose of electric power
tools with domestic refuse.
The electric power tool is shipped in
packaging to reduce transport damage. This
packaging is a raw material and as such can
either be reused or can be fed back into the
raw material cycle. The electric power tool and
its accessories are made from various
materials such as metals and plastics. Take
defective components to a special refuse
collection point. Ask about these at your
specialist shop or local council. The product
and the user manual may be subject to
changes. Technical data may be changed
without prior notice.
Batteries
Think of the environment when disposing of
batteries. Contact your local authorities to nd
out where your nearest disposal area is. Do
not dispose of batteries with domestic refuse.
Do not dispose of by burning, risk of explosion.
EC-DECLARATION OF CONFORMITY
We, the Batavia B.V., Weth.
Wassebaliestraat 6d, NL-7951 SN
Staphorst, declare by our own responsibility
that the product Cordless Angle Grinder,
Model BT-CAG003, Item-No 7064219 is
according to the basic requirements, which are
dened in the European Directives
Electromagnetic Compatibility 2014/30/EU
(EMC), 2006/42/EC (Machinery), 2011/65/EU
(RoHS) and their amendments. For the
evaluation of conformity, the following
harmonized standards were consulted:
EN60745-1:2009/A11:2010
EN60745-2-3:2011/A13:2015
AfPS GS 2019:01 PAK
EK9-BE-91(V4):2020
EN55014-1:2017
EN55014-2:2015
Staphorst, 10 March 2022
Meino Seinen, QA Representative
Batavia B.V., Weth. Wassebaliestraat 6d,
7951 SN Staphorst, Netherlands
7064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 107064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 10 22-03-2022 11:2022-03-2022 11:20

7064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 117064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 11 22-03-2022 11:2022-03-2022 11:20

Model: BT-CAG003
Item-No.: 7064219
www.bataviapower.com
[email protected]
2YEARWARRANTY
This product has got a 2 year warranty
Dear Client, if for any reason this product is not working, please ensure you contact our Client Service Centre. Ensure you have your original
receipt of purchase. This warranty covers all defects in workmanship or materials in this Batavia product for a two year period from the date
of purchase. The warranty does not cover any malfunction, or defect resulting from misuse, neglect, alteration, or repair.
Dieses Produkt hat 2 Jahre Garantie
Sehr geehrter Kunde, unsere Produkte unterliegen einer strengen Qualitätskontrolle. Sollte dieses Gerät nicht einwandfrei sein, so
wenden Sie sich bitte immer zuerst an unseren Kunden-Service. Bitte bewahren Sie unbedingt den Kaufbeleg auf. Die Garantieleistung
gilt nur für Material-oder Fabrikationsfehler. Ausgeschlossen sind Mängel die durch häugen Gebrauch, missbräuchlicher und
unsachgemäßer Behandlung oder Gewalteinwirkung verursacht worden sind.
Ce produit a 2 ans de garantie
Cher client, Si pour une raison quelconque, ce produit ne fonctionne pas, veuillez contacter notre Centre de service après-vente.
Conservez le bon d’achat original. Cette garantie couvre tous les défauts de matériau et de main d’oeuvre constatés sur ce produit
Batavia pendant une période de deux ans à compter de la date d’achat. Les défauts de fonctionnement et autres résultant d’abus ou
de mauvais emploi, de négligence, de modifications ou réparations non autorisées sont exclus de la garantie.
Dit product heeft 2 jaar garantie
Geachte klant, onze producten ondergaan een streng kwaliteitscontrole proces. Wanneer dit product niet correct functioneert, wend u zich
alstublieft altijd eerst tot onze klantenservice. Bewaar altijd uw aankoopbewijs. De garantieservice is alleen van toepassing op materiaal- of
productiefouten. Uitgesloten zijn gebreken veroorzaakt door intensief gebruik, misbruik en incorrecte behandeling of extern geweld.
Questo prodotto è garantito per 2 anni
Gentile Cliente, se per una qualche ragione il prodotto non funziona, La invitiamo a mettersi in contatto con il nostro
Centro Assistenza Clienti. Si accerti di avere la ricevuta originale dell’acquisto. La garanzia copre tutti i difetti di fabbricazione o di
materiale in questo prodotto Batavia per un periodo di 2 anni dalla data di acquisto. La garanzia non copre malfunzionamenti o difetti
derivanti da uso inappropriato, improprio, da modiche o riparazioni.
Este producto tiene dos años de garantía
Estimado cliente: si por cualquier razón este producto no funciona, póngase en contacto con nuestro Centro de Atención al Cliente.
Asegúrese de tener a mano la factura de compra original. Esta garantía cubre todos los defectos de mano de obra o materiales
de este producto de Batavia por un período de dos años a partir de la fecha de compra. La garantía no cubre ningún mal
funcionamiento o defectos resultantes del mal uso, negligencia, alteración o reparación.
Este produto tem uma garantia de 2 anos
Estimado Cliente, se, por qualquer motivo, este produto não estiver a funcionar devidamente, contacte o nosso
Centro de Apoio ao Cliente. Certique-se de que possui a prova de compra original. Esta garantia cobre todos os defeitos de
fabrico ou materiais do produto Batavia durante um período de dois anos, a contar da data de compra. A garantia não
cobre quaisquer avarias ou defeitos resultantes de um uso indevido, negligência, modicações ou reparações.
Produkt posiada 2-letnią gwarancję.
Szanowny Kliencie! Jeśli z jakiegokolwiek powodu niniejszy produkt nie działa, prosimy skontaktować się z
naszym Centrum obsługi serwisowej. Upewnij się, że posiadasz oryginalny dowód zakupu. Niniejsza
gwarancja obejmuje wszystkie wady produkcyjne i materiałowe w produktach Batavia przez okres dwóch lat
od daty zakupu. Gwarancja nie obejmuje żadnych usterek lub uszkodzeń wynikających z nieprawidłowego
użycia, zaniedbania, modykacji lub naprawy.
Deutschland – Kundenservice – Montag bis Freitag von 9 bis 17 Uhr
01805 937 832*
Other European countries – Customer Services /
Autres pays d’Europe – Service clientèle /
Overige landen Europa – Klantenservice
Monday till Friday from 8 am until 4 pm / Lundi jusqu’à Vendredi
de 9 - 17 heure / Maandag t/m vrijdag van 9 tot 17 uur
00800 664 774 00
BATAVIA B.V. | Weth. Wassebaliestraat 6d | 7951SN Staphorst | Netherlands
7064219/1 EN ONLY
*Nur €0,14 /Minute aus dem dt. Festnetz,
max. €0,42/Minute aus den Mobilfunknetzen
WARRANTY
2 YEARS
7064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 127064219-Cordless_Angle_Grinder-Ma-EN-2203-10.indb 12 22-03-2022 11:2022-03-2022 11:20
