BATHSELECT BST6112L User manual

Plumbers Tape Tape Measure Adjustable Wrench
Screwdriver
Drill
Hex Wrench
Level
Pencil or Marker
Thread Sealant
*not included
POSSIBLE TOOLS REQUIRED*
Please read installation instructions below. All plumbing should be
installed in accordance with applicable building codes and regulations.
Unpack and inspect the items for any shipping damages. If you find
damages, do not install.
All products must be installed by a professional and certified plumber
otherwise warranty may be voided.
PRIOR TO INSTALLATION
LIMA-THERMOSTATIC-SHOWER-SYSTEM WITH CONCEALED
MIXER INSTALLATION INSTRUCTIONS
Product code: BST6112L
Customer Service: 800-500-9895
bathselect.com
1

Wall Mount Shower Installations Instructions
Step 1: Step 2:
Step 3: Step 4:
Step 5: Step 6:
Customer Service: 800-500-9895
bathselect.com
2

1. Remove the old shower head by using the channel lock pliers or monkey wrench. Be
sure to turn the pliers counter-clockwise to loosen the old shower head. (tip: right is tight,
left is loose.)
2. Remove the shower arm by turning it by hand counter-clockwise.Make sure you
remember to apply putty or tape to the new arm. (tip: using teflon tape is less messy)
3. Apply teflon tape to the threading of the shower arm by wrapping it around the threads,
go all the way around 3 or 4 times depending on the quality of the teflon tape.
4. Install the new shower arm by going clockwise by hand until it is tight, then put painters
tape around the arm and tighten the arm with the channel lock or monkey wrench.
5. Place teflon tape around the threads on the shower head and then place the shower
head onto the shower arm by turning the shower head clockwise after the shower arm is
already in the wall.t
Step 7: Step 8:
Step 9 (Note):
Product shown is only for installation display purpose
Customer Service: 800-500-9895
bathselect.com
3

Hand Shower Installations Instruction
0.19” (4.8mm) Max
1
2
1
1. SUPPLY ELBOW INSTALLATION
Apply plumber tape to threaded ends of 1/2" (13 mm)
iron pipe nipple (not supplied) and thread into
shower riser elbow so that nipple extends past the
finished wall no more than 0.19" (4.8 mm) and no less
than 1/16" (1.6 mm). Place the supplied installation
gasket (1) behind the elbow (2). Screw the supply
elbow onto the nipple making sure that the supply
elbow outlet is in a downward facing position.
Minimum diameter for hole is 1" (25 mm) with a
maximum of 1 1/2" (38 mm).
CAUTION: To avoid damage to the supply elbow or
hose finish during installation, wrap with a cloth or
tape and use only a smooth-jawed wrench.
DO NOT OVERTIGHTEN CONNECTIONS.
3. WALL BAR INSTALLATION
Note: Hole size will be determined by your use of just the screw or
anchor and screw for installation. Drill hole for mounting of bottom
post. Start with a smaller drill bit size, 1/8" is recommended, and drill
hole. If you hit a wall stud, go to next step. If you do not hit a wall stud,
change to a drill bit size suitable for the anchors, 1/4" is recommended,
and re-drill hole.
Anchors are for use on drywall or tile. For fiberglass, acrylic and flat
plastic surfaces, use toggle bolts (not included).
Before drilling top mounting hole, it is recommended that you place
the assembled slide bar and post assembly (1) on its side next to the
hole locations you have marked. Make sure posts are pressed fully onto
bar. Align center of bottom post with bottom hole that was just drilled
and make sure center of top post aligns with mark for top hole. If not,
re-mark top hole location. If it aligns, drill top hole in location as
marked.
2. Mark the place for drilling the hole for the lower
post. Mark using a level, in a vertical line from the
lower hole, the placement of the upper post hole.
Distance approximately 25.7" (653 mm).
Step 1: Step 2:
Step 3:
Customer Service: 800-500-9895
bathselect.com
4

1
2
3
4
1
6
2
3
4
5
6
7
8
9
1
2
3
4
5. Slide the slide mechanism (1) and elbow (2)
onto the wall bar (3). Slide wall bar over bracket
tabs (4) and secure the wall bar unit with screws
(5) provided. Install caps (6) into ends of wallbar.
Lower elbow (7) & screw (8) was pre-installed
prior to shipping, tighten screw (9) if you find it
is sliding inside bar.
6. INSTALLATION OF THE SHOWER SET
Connect the shower hose to the wall outlet (1)
and the hand held piece (2), ensuring that the
internal gaskets (3) are present in the shower
hose nuts. Normal 1/2” rubber gaskets can be
used.
Place the conical nut of the hose (4) that is
connected to the hand held piece, in the slide
bar holder (5) and turn it to desired position.
To slide the mechanism up or down, push in on
the button (6) of the mechanism and slide it on
the bar.
4. Insert anchors (1) into drilled holes. Slide
covers (2) over brackets (3), and insert screws (4)
into bracket/cover assembly. Secure assembly
to wall with screws.
Step 4:
Step 5: Step 6: Completed
Customer Service: 800-500-9895
bathselect.com
5

Body Jets Spray Installations Instruction
Step 2: Apply teflon tape to threaded tail pipe
of the body spray
G2
Step 3: Press the escutcheon against the
finished wall
Step 4: Screw the Body spray tightly into the
female of water Supply
Step 1: Attach the escutcheon to the body
spray.
Pressure Balancing Loop:
•If installing bodysprays in a bank of 3 or
fewer, a pressure balancing loop is not
necessary.
•If installing bodysprays in a bank of 4 or
greater, a pressure balancing loop must be
used to keep the pressure even between the
bodysprays.
Customer Service: 800-500-9895
bathselect.com
6

Mixer Installations Instructions
Step 2
Step 1
Step 3 ( Connection)
Hot water
Cold water
Rough-in Body
Anchor
Positioning
Bar
Tapping Screw 1
Tapping Screw 2
Plate
Cover
Button
Screw 1
Diverter
Handle
Temp.
Handle
On/Off
Handle
Hex Wrench
Hot Water In Cold Water In
Function 1
Function 2
Function 3
Customer Service: 800-500-9895
bathselect.com
7

All products manufactured and supplied by BathSelect are safe and comply to legislative
requirements. Providing they are installed correctly and receive regular maintenance in
accordance with these instructions your user experience will not be affected.
1. The product can be cleaned with warm water, a mild soap and a clean soft cloth.
2. Clean progressively and gently.
3. It is not required to use any abrasive cleaning pads, wire wool or cloths to clean the
product.
4. Avoid a vigorous cleaning action, as this could contribute to denaturing and dulling
5.Abrasive or strong cleaning products containing ammonia, bleaches, alcohol, dyes,
acids (hydrochloric, formic, phosphorus, chlorine or acetic) will be not be affected.
6. If using a spray cleaner, apply the cleaning agent onto a soft cloth, never directly spray
onto the product as the cleaner may enter gaps and openings and cause damage. Do
not allow the cleaner to remain on the product for a period of time. After cleaning, rinse
thoroughly with clean water.
Acid
General Information
Care & Cleaning
