Baudcom BD-FE1-IP-G User manual

FE1 over Gigabit Ethernet Multiplexer
MODEL: BD-FE1-IP-G BD-2FE1-IP-G BD-4FE1-IP-G
User Manual
SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website: http://www.baudcom.com.cn
Email: [email protected]
Tel: [phone]
Fax: [phone]

Contents
Chapter 1 Introduction ............................................................................................................................................. 4
1.1 overview ................................................................................................................................................ 4
1.2 Applications ......................................................................................................................................... 4
1.3 Features ................................................................................................................................................. 5
1.4 Technical Specifications ............................................................................................................... 5
Chapter 2 Operation.................................................................................................................................................. 9
2.1 Turning on the Unit ......................................................................................................................... 9
2.2 Device’s Panel .................................................................................................................................... 9
2.3 Indicators............................................................................................................................................ 10
2.4 Turning Off the Unit...................................................................................................................... 12
Chapter 3 NMS Configuration............................................................................................................................... 13
3.1 User Login........................................................................................................................................... 13
3.2 System Settings .............................................................................................................................. 13
3.3 Service Configuration .................................................................................................................. 15
Chapter 4 Technical Specifications ........................................................................................................................ 21
4.1 Operating Environment............................................................................................................... 21
4.2 Power Supply Section .................................................................................................................. 21
4.4 E1 Interface ....................................................................................................................................... 21
4.5 Ethernet Electrical Interface ................................................................................................... 22
4.6 Ethernet Optical Interface ........................................................................................................ 22
4.7 Physical Characteristics.............................................................................................................. 22
Chapter 5 Installation.............................................................................................................................................. 23
5.1 Safety Requirement ...................................................................................................................... 23
5.2 Inspection upon Unpacking ..................................................................................................... 24
5.3 Power Supply.................................................................................................................................... 24
5.4 Test ......................................................................................................................................................... 24
5.5 Set Up and Connection ................................................................................................................ 25

Preface
Version Description
Manual version: V1.0
Copyright Notice
The copyright of this manual is reserved to our company, who retains
the final rights of explanation and revision to this manual and notice.
No part of this manual may be photocopied, excerpted, reproduced,
revised, transmitted, translated into other languages, or used for
commercial purpose in full or in part, without the prior written
permission of the Company.
Disclaimer
This manual is made according to currently available information and
subject to change without further notice. Whilst every effort has been
made to ensure the accuracy and reliability of the contents contained
herein, the Company cannot be held liable for any harm or damage
resulting from any omissions, inaccuracies or errors contained in the
manual.
Brief Introduction
This User Manual describes the installation and operation of E1
communications conversion device. Before you use our device for
the first time,please read all the included materials carefully, and
install and operate this series of products in keeping with items listed
in the manual, so as to avoid damaging the device resulting from
malpractice. Thank you for choosing our products.
Environmental Protection
This product complies with the design requirements associated with
environmental protection. The storage, use and disposal of the
product should be conducted in accordance with related national laws
and regulations.
We welcome you to put forward advice and suggestion to our
work, which shall be viewed as the ultimate support to us.

Chapter 1 Introduction
1.1 overview
The FE1 over GE Multiplexer Series Gateway ensure the circuit
emulation traffic priority. Restructuring any slot group of each E1
interface with built-in time slot allocation circuit-TSA, providing
Channel associated signal processing capability. Having the
performance of high transmission efficiency, low transmission delay,
high precision clock recovery.
Support 1-4 E1 interface and IP internet transmission of 4 1000M
Ethernet interface .
1.2 Applications
FE1 over GE series devices can establish 1-4 E1 transparent channels
over Ethernet or IP network for the provision of voice, images and
other real-time business, Typical applications as shown in figure.
In the Figure above, FE1 over GE provide 1~4 channels of E1 over
Ethernet to connect the base station controller, the PSTN access
network equipment and other E1 terminal equipment. The two
routers at two sides can share local Ethernet data by any Ethernet
port of FE1 over GE. The internal QoS mechanisms of FE1 over GE can
ensure the priority of E1 signal.

1.3 Features
Up to 4 independent E1 interface, E1 interface impedance support
75Ω and 120 Ω
Support L2TPv3/IPv4, UDP/IPv4, Metro Ethernet (MEF-8) and
MPLS (MFA-8) and other agreements
E1 interface complies with G.703, G.704 standard
Support two 1000 Mbps Ethernet optical interface
Configure via CLI/Web/SNMP(v1/v2c/v3)
Support Tag VLAN (802.1q)
Support software and firmware upgrade
Support Ring Protection(recovery time<20ms) and 1+1 Protection
Support NTP, SNMP, RSTP protocol
Support TACACS+
Support Qos setting
Support for log management and configuration file import and
export
Support Web, Console, Telent, SNMP network management,
remote monitoring and software upgrades, easy to operate and
maintain
1.4 Technical Specifications
E1 Interface
Number of E1 Ports: 4
Interface Standard: G.703 G.704
Line Impedance and Connector
Impedance:120 Ω, balanced
75Ω, unbalanced

Connector Type: RJ-45
Data Rate: 2.048 Mb/s±50ppm
Line Code: HDB3
Framing: unframed, framed, with or without CRC-4
Jitter and Wander Performance:
ITU-T G.823 (for internal, loopback and external clock modes)
Number of differential Clock Input Interface: 1
Point-to-point one-way additional processing delay (Minimum
delay setting): ≤1.2ms
Output frequency stability (adaptive timing, Stable): ≤ 50ppb
Output Jitter (adaptive timing): ≤ 0.03UI
Ethernet Interface
Number of Ports: 2-port UTP and 2-port SFP
Interface Type: 10/100/1000M GE RJ45 ports and 1000M SFP
optical ports
Data Rate: 32Kbps~1000Mbps(Minimum setting unit is 32Kbps)
Protection: 1+1 Protection, Ring Protection (recovery time < 20
msec)
Max Frame Size: 9Kb
Protocol: IPV4，IPV6 (Planning)，MPLS，MEF，UDP
Standard
IEEE 802.3 (10BASE-T)
IEEE 802.3u (100BASE-T)
IEEE 802.3z (1000BASE-X)
IEEE 802.3ab (1000BASE-T)
IEEE 802.1ad (Q in Q)
IEEE 802.3ad (Link Aggregation) (Planning)

IEEE 802.3x (Flow Control)
IEEE 802.1p (COS priority)
IEEE 802.1Q (Virtual LAN)
Magnetic Isolation Protection: 1.5 KV built-in
PSEUDOWIRE
Compliance
IETF: RFC4623 (PWE3), RFC4553 (SAToP), RFC5086 (CESoPSN),
ITU-T: Y.1413 and Y1453
MFA: IA 8.0.0
MEF: 8
Number of PW Connections: 128
Timing
Internal (from internal oscillator) (optional)
External (E1 via dedicated port) (optional)
Loopback (derived from the E1/T1 receive line)
Adaptive (regenerated from Ethernet link)
Adaptive Clock accuracy: ±10 ppb
Jitter Buffer Size: 1 to 256 msec
Internal Bridge
Number of VLANs: 1-4094 with 16 VLAN support
Compliance: 802.1Q
LAN Table: Up to 2K MAC addresses
L2CP handling: transparent and Termination
QoS Priority Queues: 4
Port-Based VLAN: Untagged, tagged, unmodified
Management
Console Port:

Interface standard: RS-232
Connector: RJ-45
Baud rate: 115.2kbps
SNMP: SNMP (v1/v2), SNMPv3 (Planning)
Support: telnet, web, SYSLOG, Activity logging (user activities),
TACACS+, SNTP
Out-of-Band Ethernet Management: Any one of the User Ethernet
port should be configured as an out of band management port.
Power Requirements
AC/DC dual power supply Adaptive input
AC: 100V~240V/50Hz
DC: -36V ~ -72V
Power Consumption: ≤6W

Chapter 2 Operation
This chapter:
• Explains how to power FE1 over GE up and down.
• Describes the device's panel
• Provides a detailed description of the front panel controls and
indicators and their functions.
2.1 Turning on the Unit
To turn on the unit:
• Connect the power cord to the mains.
The PWR indicator turns on and remains on as long as FE1 over GE
receives power.
Once installed, FE1 over GE requires no operator attention, except for
occasionally monitoring the front panel indicators. Intervention is
only required when the unit must be configured to its operational
requirements, or when diagnostic tests are performed.
2.2 Device’s Panel
Figure 3-1 lists the front panel of different specifications
Figure 2-1 4FE1 over GE Device Front Panel Picture
1
PW
R
23 4 RefCL
K1 2 3
AC
T
Conso
le
Reset
115200,8,N,
1
SFP
E1 Ethern
et
SY
S
BD-4FE1-IP-G with 3GE+1FX
1
PW
R
23 4 RefCL
K1 2 Conso
le
Reset
115200,8,N,
1
E1 Ethern
et
SY
S
AC
T
A B
SFP
BD-4FE1-IP-G with 2GE+2FX

Figure 2-2 FE1 over GE Device Rear Panel Diagram
AC100-240V/DC -
48V
POWER RETURN
Figure 2-3 dip the bottom
2.3 Indicators
The unit's LEDs are located on the front panel. Table 2-1 lists the
functions of the LED indicators.
Table 2-1. LEDs and Controls
Name
Colors
Functions
Status
Description
SYS
YELLOW
System
Operating
Indication
Blinking
System is Working
Off
System is Abnormal
PWR
GREEN
Power
Indication
On
Unit is Powered
Off
Unit is Off
E1
Indicator
RED
E1
LOS Indication
On
E1 No Signal, LOS
Alarm
Blinking
E1 LOF Alarm
Off
E1 Normal
Etherne
t Port LEDs
YELLOW
Ethernet
Data
Transceiver
Indication
On
No Data
Transceiving
Blinking
Data Transceiving
Off
Not Connected
GREEN
Ethernet
Speed
Indication
On
1000Mbps Connect
Off
10/100Mbps
Connect

ACT
RED
Optical
port LEDs (No
this function)
On
Connected
Off
Not connected
Blinking
Data Transceiving
E1 Interface
Support 4 E1 interface and a differential clock input, All are used with
the red LED RJ45.
wired according to the following table
Table 2-2 E1 Connector Pinouts
Pin
1
2
3
4
5
6
7
8
Func
tion
Tx
+
Tx-
NC
Rx
+
Rx-
NC
NC
NC
Table 2-3 Differential Clock Input Pinouts
Pin
1
2
3
4
5
6
7
8
Func
tion
NC
NC
NC
CLK
IN+
CLK
IN+
NC
NC
NC
Ethernet Interface
Supports 2-port UTP + 2-port SFP.
Data rate: 1000Mbps.
Console Interface
The Console interface is an 8-pin RJ-45 connector, Support
115200bps baud rates, wired according to Table 2-4.
Table 2-4 Console Pinouts
Pin
1
2
3
4
5
6
7
8
Func
tion
NC
NC
TX
D
GN
D
GN
D
RX
D
NC
NC
Dip the bottom
E1 and differential clock inputs Unbalanced (75Ω) and balance (120Ω)
DIP, the default unbalanced impedance (120Ω).The DIP function
definition as follow:

DIP No.
1
2
3
4
5
6
7
8
Description
1-4 channel
impedance setting
E1 reference CLK
Reserved
75Ω
Setting 75Ω:E1 impedance 75Ω
Setting 120Ω:E1 impedance 120Ω
DIP No.6/7/8
default:120Ω position
120Ω
Reset
Restore to factory default setting by pressing 5 second
Power
The device supports two voltage, AC220V or DC-48V input. Allows
power fluctuations in the range of 10%. Please note that there are
positive and negative polarity DC input. DC-48V: POWER connect to
the cathode, RETURN then negative.
2.4 Turning Off the Unit
To turn off the unit:
• Remove the power cord from the power source.

Chapter 3 NMS Configuration
Operating condition:
PC operating systems: WINDOWS98/XP/Win 7
Network connection: 10/100/1000Base-TX Ethernet interface, the
AUTO MDI / MDI-X. Internet Explorer 5.0 or later
Parameter settings:
IP address settings: PC IP address and subnet mask must be in the
same segment with the device IP address and subnet mask, and must
not be the same IP address.
The default value of FE1 over GE: IP address: 192.168.0.168
Subnet Mask: 255.255.255.0.
3.1 User Login
This product provides Web browser-based configuration interface,
this configuration program is suitable for any MS Windows or UNIX
platforms, browser, for example.
Enter "192.168.0.168" in the address bar, press Enter, you will see
the login screen that below shows. Input user name and password in
the login dialog box (the default factory settings are "admin"), select
the language (in Chinese and English, and here only on the Chinese),
click the submit button.
3.2 System Settings
3.2.1 System Information
This page setting device name, device ID, device address, contact
information and certification mode selection;
Display hardware version, software version, firmware version, MAC
address of the network management device, and other information
equipment uptime.

3.2.2 Network Configuration
This page can set the device network IP address, subnet mask, and
default gateway, display network MAC.
3.2.3 System Reboot
This page can restart the device or restore the factory default
configuration
3.2.4 System Upgrade
Software or firmware upgrade file, reboot the device after the
upgrade is complete

Step1: Upload the upgrade file;
Step 2: Follow the prompts to choose to upgrade software or
configuration files;
Software upgrade is completed automatically reboot.
The firmware upgrade is completed, please reboot manually.
3.2.5 Language Selection
Equipment web pages default English version of this page can be
switched in the Chinese and English version.
3.3 Service Configuration
3.3.1 Simulation Gateway Configuration
Support four network protocol: IPv4/L2TPv3, IPv4/UDP, MEF, MPLS,
supports point to point communication, the purpose of MAC, IP
settings for the end purpose of the same type of equipment source
MAC, source IP, subnet mask and gateway based on where the
network to set up.
Note:

The device has two MAC and IP, one is used for network management,
another for business transfer, gateway simulation parameters source
MAC, source IP for business transfers
Tips:the local device’s destination IP/MAC should set to the remote
device’s source IP/MAC
3.3.2 E1 Branch Configuration
Set E1 frame mode, E1 timeslot, frame size, RTP timestamp mode,
the clock recovery mode, E1 line loopback function enabled and
disabled, E1 alarm settings such as enable and disable.
3.3.3 Ethernet Port Configuration
Set Vlan enable and disable, 1+1 protection mode, RSTP enabled and
disabled, and the port speed configuration Vlan table settings

Tips:under the 1+1 protection mode,master port should be
connected to the other device’s master port.
3.3.4 NTP Configuration
Network Time Protocol (NTP) to enable and disable, when NTP
almighty you need to set the server IP and port number.
3.3.5 SNMP Configuration
Configure SNMP protocol parameters:
When the trap mode select V1 or V2 Mode, you need to set Set_key
and Get_key;
When the trap mode selection V3 Mode, you need to set Auto_proto
and Poli_proto;
When the trap mode select All Mode, you need to set all parameters.

3.3.6 Tacas+ Configuration
Tacacs + authentication protocol parameter settings, you need to set
the authentication IP, audit IP, the session IP and other related
parameters.
3.3.7 Syslog Configuration
Logging turned on and off, open the Local Logging, click View The
Current Log in system logging.
Open the Server Logging, you need to set the log server IP and port
number.

3.4 QoS Configuration
3.4.1 Port’s QoS Configuration
Select the port Qos debug mode, Qos mode, the default priority
setting, the system default port priority
3.4.2 Tos Map
Set Tos value and the priority mapping table.

3.4.3 Cos Map
Set Cos value and the priority mapping table.
3.5 Statistical Information
3.5.1 Ethernet Statistics
Display Ethernet port statistics information.
3.5.2 E1 Statistics
E1 port statistics information display.
3.5.3 E1 Alarm Display
E1 port alarm information display
