Bauer 58310 Assembly instructions

Battery and Charger Sold Separately
Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
For Maximum Performance
Use 3.0 AMP HOUR
Battery or Greater
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 21h
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2021 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service ma y n o t b e i n c l u d e d .
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 58310
SAFETY OPERATION MAINTENANCESETUP
Table of Contents
Safety ........................................................................2
Specifications ............................................................4
Setup .........................................................................4
Operation...................................................................5
Maintenance..............................................................8
Parts List and Diagram.............................................10
Warranty ...................................................................12
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
Instructions Pertaining to a Risk of Fire, Electric Shock, or Injury to Persons
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
To reduce the risk of fire, electric shock, or injury:
1. Do not leave appliance when Battery
Pack is connected. Remove Battery Pack
when not in use and before servicing.
2. Do not allow to be used as a toy. Close attention
is necessary when used by or near children.
3. Use only as described in this manual. Use
only manufacturer’s recommended attachments.
4. Do not use with damaged Battery Pack. If
appliance is not working as it should, has been
dropped, damaged, left outdoors, or dropped
into water, return it to a service center.
5. Do not handle appliance with wet hands.
6. Do not put any object into openings. Do not use
with any opening blocked; keep free of dust, lint,
hair, and anything that may reduce air flow.
7. Keep hair, loose clothing, fingers, and all parts of
body away from openings and moving parts.
8. Turn off all controls before
removing Battery Pack.
9. Use extra care when cleaning on stairs.
10. Do not use to pick up flammable or
combustible liquids, such as gasoline, or
use in areas where they may be present.
11. Do not pick up anything that is burning
or smoking, such as cigarettes,
matches, or hot ashes.
12. Do not use without dust bag
and/or filters in place.
13. FOR HOUSEHOLD USE ONLY.
14. Dry your hands and feet before
touching plug or switch.
15. Do not continue to use the vacuum
when the tank is full of liquid.
16. Do not use to pick up water from containers,
i.e., sinks, tubs, barrels, etc.
17. Stay alert, watch what you are doing and use
common sense when operating an appliance.
Do not use an appliance while you are tired or under
the influence of drugs, alcohol or medication.
A moment of inattention while operating
appliances may result in serious personal injury.

Page 3For technical questions, please call 1-888-866-5797.Item 58310
SAFETYOPERATIONMAINTENANCE SETUP
18. Maintain labels and nameplates
on the appliance. These carry important safety
information. If unreadable or missing, contact
Harbor Freight Tools for a replacement.
19. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure.
20. The warnings, precautions, and instructions
discussed in this instruction manual cannot cover all
possible conditions and situations that may occur.
It must be understood by the operator that
common sense and caution are factors
which cannot be built into this product,
but must be supplied by the operator.
21. Battery appliance use and care
a. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to battery pack, picking up or carrying the
appliance. Carrying the appliance with your
finger on the switch or energizing appliance
that have the switch on invites accidents.
b. Recharge only with the charger specified by
the manufacturer. A charger that is suitable
for one type of battery pack may create a risk
of fire when used with another battery pack.
c. Use appliances only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
d. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from
one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
e. Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with water.
If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the
battery may cause irritation or burns.
f. Do not use a battery pack or appliance that
is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior
resulting in fire, explosion or risk of injury.
g. Do not expose a battery pack or appliance
to fire or excessive temperature.
Exposure to fire or temperature above
265°F may cause explosion.
h. Follow all charging instructions and do
not charge the battery pack or appliance
outside of the temperature range specified
in the instructions. Charging improperly or at
temperatures outside of the specified range may
damage the battery and increase the risk of fire.
i. Have servicing performed by a qualified
repair person using only identical
replacement parts. This will ensure that
the safety of the product is maintained.
j. Do not modify or attempt to repair the
appliance or the battery pack except as
indicated in the instructions for use and care.
k. The battery Charger gets hot during
use. The Charger’s heat can build up
to unsafe levels and create a fire
hazard if it does not receive adequate
ventilation, due to an electrical fault, or if it is
used in a hot environment. Do not place the
Charger on a flammable surface. Do not obstruct
any vents on the Charger. Especially avoid
placing the Charger on carpets and rugs; they
are not only flammable, but they also obstruct
vents under the Charger. Place the Charger on
a stable, solid, nonflammable surface (such as a
stable metal workbench or concrete floor) at least
1 foot away from all flammable objects, such as
drapes or walls. Keep a fire extinguisher and a
smoke detector in the area. Frequently monitor
the Charger and Battery Pack while charging.
Lithium Battery Safety Warnings
LITHIUM BATTERIES STORE
A LARGE AMOUNT OF ENERGY AND
WILL VENT FIRE OR EXPLODE
IF MISTREATED:
a. Keep Battery Pack dry.
b. DO NOT DO ANY OF THE FOLLOWING
TO THE BATTERY PACK:
• Open,
• Drop,
• Short-circuit,
• Puncture,
• Incinerate, or
• Expose to temperatures greater than 265°F.
c. Charge Battery Pack only according
to its Charger’s instructions.
d. Inspect Battery Pack before every use;
do not use or charge if damaged. Li-
Ion BATTERY MUST BE RECYCLED
OR DISPOSED OF PROPERLY.
SAVE THESE INSTRUCTIONS

Page 4 For technical questions, please call 1-888-866-5797. Item 58310
SAFETY OPERATION MAINTENANCESETUP
Grounding
TO PREVENT ELECTRIC SHOCK AND DEATH FROM INCORRECT GROUNDING:
Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded.
Do not modify the power cord plug provided with the charger. Do not use the charger if the power
cord or plug is damaged. If damaged, have it repaired by a service facility before use. If the plug
will not fit the outlet, have a proper outlet installed by a qualified electrician.
Symbology
VVolts
Direct Current
AAmperes
WARNING marking concerning Risk
of Eye Injury. Wear ANSI-approved
safety goggles with side shields.
Read the manual before
set-up and/or use.
WARNING marking
concerning Risk of Fire.
Do not cover Charger
ventilation ducts.
Charge on fireproof surface only.
WARNING marking concerning
Risk of Explosion.
Do not puncture, short, or open
battery packs and do not charge
damaged battery packs.
WARNING marking concerning
Risk of Electric Shock.
Properly connect Charger’s power
cord to appropriate outlet.
Specifications
Battery Type Bauer 20V Li-Ion 64816 (sold separately)
Batttery Charger Bauer 20V Charger 63947 (sold separately)
Tank Capacity 3.5 Gallons
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn Power Switch of appliance off and remove Battery Pack
before performing any procedure in this section.
Note: For additional information regarding the parts listed in the following pages,
refer to the Assembly Diagram near the end of this manual.
Preparation
Remove any stored parts from the Tank before use.

Page 5For technical questions, please call 1-888-866-5797.Item 58310
SAFETYOPERATIONMAINTENANCE SETUP
Components and Controls
Hose
Cartridge Filter
Crevice Tool
Gulper Nozzle
Gulper Nozzle
Storage
Vacuum Port
Switch
Hose Storage
Crevice Tool Storage
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this
manual including all text under subheadings therein before set up or use of this product.
Vacuum Operation
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Switch off and disconnect battery pack from unit before removing the Power Head.
1. Pull Tabs outward and remove Power Head
by handle. Pull up to remove it.
Power Head
Handle
Tab Tab
2. For dry vacuuming: Slide Filter
completely over Filter Cage. Secure Filter
by turning clockwise to tighten.
Filter
3. For wet vacuuming: Remove filter.

Page 6 For technical questions, please call 1-888-866-5797. Item 58310
SAFETY OPERATION MAINTENANCESETUP
4. Attach Power Head to Tank, making
sure Tabs lock into place.
Note: The Power Head must properly
seal onto Tank and must be undamaged
to allow vacuum to create suction.
5. Insert end of Hose with clip securely
into Vacuum Port. Press button on hose
until Clip locks into tab on port.
Tab
Clip
6. If desired, slide Nozzle onto Hose.
7. Make sure that Switch is in its off position.
Insert a fully charged battery and make
sure that it clicks into place securely.
8. Hold the loose Hose end securely. Turn
Switch on to operate Vacuum.
9. WHEN WET VACUUMING:
IMPORTANT! Leave a gap at tip of nozzle opening
to allow air inflow.
Do not immerse nozzle completely in liquid.
When the Motor sound becomes
higher in pitch, the Tank is full and
the float is closing off the motor intake.
IMMEDIATELY:
a. DRY YOUR HANDS AND FEET
b. turn the Vacuum off
c. disconnect battery pack from unit
d. empty the Tank.
WARNING! TO PREVENT SERIOUS INJURY
FROM ELECTRIC SHOCK:
Dry your hands and feet before touching battery
pack or switch.
Do not continue to use the vacuum
when the tank is full of liquid.
10. To prevent accidents,
DRY YOUR HANDS AND FEET,
turn off the appliance and disconnect battery pack
after use.
Empty and clean Tank, dry Tank,
clean Filter (see Cleaning Filter on page 9),
then store the appliance indoors
out of children’s reach.

Page 7For technical questions, please call 1-888-866-5797.Item 58310
SAFETYOPERATIONMAINTENANCE SETUP
Blower Operation
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Switch off and remove battery pack before removing the Power Head.
1. Pull Tabs outward and remove Power Head
by the handle. Pull up to remove it.
2. Clean Tank out before using the appliance as
a Blower. CAUTION! Any material left in the
Tank may be blown out, causing injury.
3. Attach Power Head to Tank, making
sure Tabs lock into place.
4. Remove Hose from the Vacuum Port. Locate
Blower Port opening at the rear of Power
Head. Insert end of the Hose with Clip
into the Blower Port. Press the button on
the Hose until the clip locks into tab.
Blower Port
5. CAUTION! Wear ANSI-approved
safety goggles before use.
6. Make sure that Switch is in its off position.
Insert a fully charged battery and make
sure that it clicks into place securely.
7. Hold the loose Hose end securely.
Turn the Switch on to operate the Blower.
CAUTION! Do not point Hose toward
another person or animal.
8. To prevent accidents, turn off the appliance and
disconnect battery pack after use. Clean, then
store the appliance indoors out of children’s reach.

Page 8 For technical questions, please call 1-888-866-5797. Item 58310
SAFETY OPERATION MAINTENANCESETUP
User-maintenance and Storage
Procedures not specifically explained in this manual must
be performed only by a qualified technician.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch of the appliance off and remove Battery Pack
before performing any procedure in this section.
TO PREVENT SERIOUS INJURY FROM APPLIANCE FAILURE:
Do not use damaged equipment. If abnormal noise or vibration
occurs, have the problem corrected before further use.
Cleaning, Maintenance, and Lubrication
1. BEFORE EACH USE, inspect the
general condition of the appliance. Check for:
• loose hardware
• misalignment or binding of moving parts
• air leakage on the Tank or Power Head connection
• cracked or broken parts
• damaged electrical wiring
• any other condition that may
affect its safe operation.
2. AFTER USE, wipe external surfaces of
the appliance with clean cloth. Store in an
indoor dry area out of reach of children.
3. All parts are permanently lubricated.
Do not use additional lubrication.
4. Disconnect battery pack and store battery pack,
charger, and tool in dry, indoor area out of
reach of children and away from metal objects
(i.e., paperclips, coins) to prevent shorting.
5. Li-Ion BATTERY MUST BE RECYCLED OR
DISPOSED OF PROPERLY.
Do not short, incinerate or open battery.

Page 9For technical questions, please call 1-888-866-5797.Item 58310
SAFETYOPERATIONMAINTENANCE SETUP
Cleaning Filter
To ensure proper operation, clean the Filter regularly. Torn Filter should be replaced:
1. Remove filter.
2. Tap or shake Filter into a waste can.
3. If needed, flush with plain water from
inside. Allow the Filter to dry for at
least one day before reinstalling.
WARNING! TO PREVENT SERIOUS INJURY:
Installing a wet Filter will increase the risk
of electric shock and may damage the
vacuum.
4. Replace Filter
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Page 10 For technical questions, please call 1-888-866-5797. Item 58310
SAFETY OPERATION MAINTENANCESETUP
Part Description Qty
1 Rear Cover (Left) 1
2 Rear Cover (Right) 1
3 Handle 1
4 Power Switch 1
5 Handle Retainer 1
6 Top Cover 1
7 PCBA 1
8 DC Motor 1
9 Baffle 1
10 Lid 1
Part Description Qty
11 Float Seal 1
12 Float 1
13 Filter Cage 1
14 Cartridge Filter 1
15 Clip 2
16 Tank 1
17 Gulper Nozzle Retainer 1
18 Hose 1
19 Gulper Nozzle 1
20 Crevice Tool 1
Parts List and Diagram
Parts List
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available individually as
replacement parts. Specify UPC 193175436849 when ordering parts.

Page 11For technical questions, please call 1-888-866-5797.Item 58310
SAFETYOPERATIONMAINTENANCE SETUP
Assembly Diagram
1
6
32
18
16
17 20
19
4
13
15
14
12
11
10
9
8
7
5

Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards,
and warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly,
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear, or to lack of maintenance. We shall in no event be liable for death, injuries
to persons or property, or for incidental, contingent, special or consequential damages arising from the use of
our product. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation of exclusion may not apply to you. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation charges
prepaid. Proof of purchase date and an explanation of the complaint must accompany the merchandise.
If our inspection verifies the defect, we will either repair or replace the product at our election or we may
elect to refund the purchase price if we cannot readily and quickly provide you with a replacement. We will
return repaired products at our expense, but if we determine there is no defect, or that the defect resulted
from causes not within the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state.
26541 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
