Bauhn IT144052 User manual

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
1
INSTRUCTION MANUAL
Indoor / Outdoor Wi-Fi Range Extender
Model Number: IT144052

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
2
Indoor / Outdoor Wi-Fi Range Extender
Warranty Details
The product is guaranteed to be free from defects in workmanship and parts for a period of 12
months (dependant on product) from the date of purchase. Defects that occur within this warranty
period, under normal use and care, will be repaired, replaced or refunded at our discretion. The
benefits conferred by this warranty are in addition to all rights and remedies in respect of the product
that the consumer has under the Competition and Consumer Act 2010 and similar state and territory
laws.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
3
SR600EX
USER’S GUIDE
1
CONTENTS
Welcome ................................................................................... 4
General Safety Instructions 4
LED Indicators............................................................................ 6
Inside Panel ............................................................................... 7
Power over Ethernet (PoE) Adapter .......................................... 8
MOUNTING INSTRUCTIONS ................................................ 9 -11
SETUP GUIDE............................................................................12
Find a Setup Locaon/ Opmal Posioning ............................ 13
Connect your PC to the Pro Smart Repeater ........................... 12
Access Setup Wizard ............................................................... 14
Welcome to the Smart Setup Wizard ...................................... 15
Scan for a Wireless Network ................................................... 16
Connecng to a Secure Network............................................. 17
Repeater Sengs (SSID).......................................................... 18
Repeater Sengs (Security) .................................................... 19
Setup Summary....................................................................... 20
WIRELESS SETTINGS................................................................ 22
Home Network Sengs .......................................................... 22
Extended Network Sengs ..................................................... 23
Wi-Fi Protected Setup (WPS)................................................... 26
Antenna Sengs......................................................................27
Advanced Sengs....................................................................28
SMART FEATURES....................................................................29
Access Schedule.......................................................................30
User Access Control .................................................................31
Wireless Coverage Controls .....................................................32
IP SETTINGS............................................................................. 33
MANAGEMENT FEATURES ......................................................35
Repeater Status .......................................................................36
Network Stascs ....................................................................37
System Clock............................................................................38
System Logs .............................................................................39
Upgrade Firmware ...................................................................40
Save/Reload Sengs ...............................................................42
Password Sengs ....................................................................43
TECHNICAL SPECIFICATIONS 44
DEFAULT SETTINGS..................................................................45
TROUBLESHOOTING
55
....................................................
.........................................................
..........
Warranty ................................................................................... 2
......................................................
Parts List 5...................................................................................
REPAIR AND REFURBISHEDGOODS OR PARTS NOTICE
- 5346
Warranty.........................................................................................
Welcome........................................................................................
General Safety Instructions..........................................................
Parts List ......................................................................................
LED Indicators..............................................................................
Inside Panel .................................................................................
Power over Ethernet (PoE) Adapter.............................................
SETUP GUIDE
Find a Setup Location/ Optimal Positioning...............................
MOUNTING INSTRUCTIONS
Desktop/Wall/Pole Mounting.......................................................
Access Setup Wizard...................................................................
Welcome to the Smart Setup Wizard...........................................
Scan for a Wireless Network.........................................................
Connecting to a Secure Network.................................................
Extender Settings (SSID).............................................................
Extender Settings (Security)........................................................
Setup Summary............................................................................
Wireless Settings..........................................................................
Extended Network Settings........................................................
Wi-Fi Protected Setup (WPS)......................................................
2
4
4
5
6
7
8
9-10
11-13
14
15
16
17
18
19
20
22
23-25
26
27
28
29
30
31
32
33-34
35
36
37
38
39
40-41
42
43
44
45
46-53
54
55
Antenna Settings........................................................................
Advanced Settings.....................................................................
Smart Features...........................................................................
Access Schedule .......................................................................
User Access Control...................................................................
Wireless Coverage Controls.......................................................
IP Settings...................................................................................
Management Features...............................................................
Extender Status..........................................................................
Network Statistics......................................................................
System Clock.............................................................................
System Logs...............................................................................
Upgrade Firmware.....................................................................
Save/Reload Settings................................................................
Password Settings.....................................................................
Technical Specifications............................................................
Default Settings.........................................................................
Troubleshooting.........................................................................
Notes..........................................................................................
Repair and Refurbished Goods or Parts Notice.......................

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
4
Congratulations on choosing to buy a BAUHN® product. By doing so you now have the assurance
and peace of mind that comes with purchasing a product made by one of the leading manufacturers.
All products brought to you by BAUHN® are manufactured to the highest standards of performance
and safety and, as part of our philosophy of customer service and satisfaction, are backed by our
comprehensive 1 Year Warranty. We hope you will enjoy using your purchase for many years to come.
General Safety Instructions
Read this manual thoroughly before first use and keep it in a safe place for future reference, along with the
warranty card, purchase receipt and carton. The safety precautions enclosed herein reduce the risk of fire,
electric shock and injury when correctly adhered to. Follow all instructions and take notice of all warnings
to reduce the risk of fire or electric shock.
• Do not expose the Wi-Fi Range Extender to extreme temperatures. Follow the instructions provided when
selecting a mounting location to protect the Wi-Fi range extender from extreme weather conditions.
• Do not remove the cover or the back of this product. There are no user-serviceable parts inside this product
• Do not repair the unit yourself. Only have it serviced by qualified personnel
• Supervise young children to ensure they do not play with the product
• Do not expose product to naked flames
• Avoid banging objects against or dropping the Wi-Fi Range Extender
• Do not place or use near magnets
• Avoid using in extremely dusty or extremely humid conditions
• Do not expose to direct sunlight for long periods of time
Welcome

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
5
a. 1 x Wi-Fi Range Extender
b. 1 x Stand
c. Metal Pole Clamp
d. PoE Adaptor
e. Power Adaptor
f. 10m PoE Cable
g. 1m Ethernet Cable
h. Plastic Pole Strap
Parts List
a. b. c.
g.
f.
h.
d.
e.

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
6
SR600EX
USER’S GUIDE
4
LED Indicators
a) Power: When lit, the power is on.
b) Wireless Activity: Blinks rapidly when wireless data
traffic is passing through the
c) LAN: Shows the connecon status and data acvity
of your local network (network devices connected to
the Access Point.
d) POE: Shows the connecon status of the LAN port
on the PoE Adapter
Wi-Fi Range Extender.

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
7
SR600EX
USER’S GUIDE
5
Inside Panel
a) Optional External Antenna Port: RJ-SMA antenna
connector. Compable with all antennas with RP-SMA
connectors. Upgradable to high gain antennas for more
range. See the External Antenna configuraon secon
for setup procedures.
b) PoE Port: Power over Ethernet capable RJ-45 port used
to the included PoE
Adapter for power and data connecvity.
c) LAN Port: RJ-45 port used to connect addional network
devices to the Wi-Fi Range Extender..
to connect the Wi-Fi Range Extender

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
8
SR600EX
USER’S GUIDE
6
Power over Ethernet (PoE) Adapter
a) Power Adapter Port: Connect the included
power adapter to the PoE adapter port for
b) Repeater Port: Connect a PoE cable between
the PoE Adapter’s Repeater port and the PoE
port on the Wi-Fi Range Extender to provide
power and data to the Wi-Fi Range Extender..
c) LAN Port: Connects to your PC for setup or
other wired networking devices for wired network access.
d) Reset Button: The easy to access reset buon is located on the back of the PoE Adapter. Pressing
the reset buon will reboot the Wi-Fi Range Extender. To reset the Wi-Fi Range Extender to default
sengs, hold the reset buon down for 5 -10 seconds and release.
powering the Wi-Fi Range Extender.

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
9
SR600EX
USER’S GUIDE
10
SETUP GUIDE
Find a Setup Location
The locaon of where you install the Wi-Fi Range Extender is very important to how it will funcon. The opmal
setup locaon should be halfway between your wireless router and your wireless dead zone.
SR600EX
USER’S GUIDE
10
SETUP GUIDE
Find a Setup Location
The locaon of where you install the Wi-Fi Range Extender is very important to how it will funcon. The opmal
setup locaon should be halfway between your wireless router and your wireless dead zone.
When mounng
outdoors, the Wi-Fi
extender must be
mounted under the
eaves of a building,
sheltered from severe
weather condions
and direct sunlight.
Find a Setup Locaon
The locaon of where you setup the Wi-Fi Range extender is very important. The opmal setup locaon should be within 3m of your
router and modem. Once setup is complete the extender can be reposioned halfway between your wireless router and your wireless
dead zone.
When mounng
indoors, choose a
locaon which is high,
and posioned out of
direct sunlight.

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
10
SR600EX
USER’S GUIDE
11
Find the Optimal Position for the Wi-Fi Range Extender
Choose the opon below that best fits your installaon scenario. For best results, the signal strength between
the Wi-Fi Range Extender and the Home Network / Hot Spot should be greater than 70%.
Range Extender
Range Extender
SR600EX
USER’S GUIDE
11
Find the Optimal Position for the Wi-Fi Range Extender
Choose the opon below that best fits your installaon scenario. For best results, the signal strength between
the Wi-Fi Range Extender and the Home Network / Hot Spot should be greater than 70%.
Range Extender
Range Extender
FRONT NOTE: Antenna strength is direconal. Signal strength from the
front of the extender is very strong. Weaker signal from the back,
weakest signal from the sides.
Face the extender in the direcon you wish to project your
wireless network signal.
BACK

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
11
SR600EX
USER’S GUIDE
7
MOUNTINGINSTRUCTIONS
Desktop Mounting
a) Place the stand in an opmum locaon.
b) Secure the onto the desktop
mount.
Wi-Fi Range Extender
Mounng Instrucons

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
12
SR600EX
USER’S GUIDE
8
Wall Mounting
a) Place the Wi-Fi Range Extender against the
wall, use a pencil and mark two locaons through
the mounng hole on the wall.
b) Remove the Wi-Fi Range Extender and securely
drill two screws where you’ve marked on the
wall.
c) Now, mount the unit onto the secured
screws.
Mounng Instrucons

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
13
SR600EX
USER’S GUIDE
9
Pole Mounting
a) Place the Wi-Fi Range Extender against the pole.
b) Use the included hose clamp and secure it
through the smaller hole located on the
boom of the mounng bracket. Use a
screw driver to ghten the clamp unl the
adapter is securely mounted to the pole.
Mounng Instrucons

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
14
PWR REPEATER LAN
d
Wireless Network
Wireless Network
Accessing The Smart Setup Wizard
FIG. A FIG. B
a. Connect cables as shown (g. A)
b. Disconnect your computer from any wireless networks (g. B)
c. Open your web browser
d. Type hp://192.168.1.240 into the web address bar
Enter the setup web address into your browser:
http://192.168.1.240
.

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
15
Bauhn Wi-Fi Range Extender
SR600EX
USER’S GUIDE
14
Welcome to the Smart Setup Wizard
When the web menu appears, click Next to connue
to the next page.
The diagram on this page displays the terms used to
describe:
1) The network you are trying to repeat (Home
Network / Wireless Hot Spot)
2) The network that is rebroadcasted and
extended (Extended Network)
Study this diagram carefully as the terms used in the
following instrucons will refer to these names.
Wi-Fi Range Extender
Bauhn Wireless Wi-Fi Range Extender

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
16
SR600EX
USER’S GUIDE
15
Scan for a Wireless Network
Click SCAN to begin searching for available wireless networks
to repeat.
Highlight your network and click Next to connue.
If you fail to find any wireless networks, the Wi-Fi Range
Extender may be placed too far from the wireless network
that you are trying to repeat. Move your Wi-Fi Range
Extender closer to the wireless network that you are trying
to repeat and click SCAN again.
The Scan results page will display informaon regarding the
name of the network (SSID), the wireless channel and the
network details. AP stands for Access Point and is the standard type of wireless network. The results page will
also display whether or not your network has security and what the signal strength is coming from each
specific network detected. Ensure that the network you are repeang has a signal strength of at least 70%. If
it does not, reorient the Wi-Fi Range Extender or your wireless router to achieve a signal strength of 70% or
greater.
Wi-Fi Range Extender
Wireless Wi-Fi Range Extender

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
17
SR600EX
USER’S GUIDE
16
Connecting to a Secure Network
If the wireless network you are trying to repeat has
wireless security enabled, you will be prompted to
enter a security key. If you did not select a secure
network, connue to the next step.
Enter the security key in the space provided. You do
not need to select what type of security it is, just
simply type in the key and click Next.
The Smart Setup Wizard will automacally take care
of the rest. If the key you entered is incorrect it will
prompt you to enter thekey again. If you do not
know the key to the network you are trying to repeat, then click Back and select another network.
Wi-Fi Range Extender

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
18
SR600EX
USER’S GUIDE
17
Extender Settings (SSID)
The default SSID of the is:
Bauhn_Wireless
This SSID for the Extended Network may be changed
by adjusng the name in the field for the Extended
Wireless Network ID.
This ID will be used by wireless users connecng to
the Wi-Fi Range Extender to idenfy the Wi-Fi Range
Extender ’s Extended Network.
It is recommended to use the default sengs.
Wi-Fi Range Extender
Bauhn_Wireless
Bauhn_Wireless
Bauhn_Wireless
Wi-Fi Range Extender
Extender Settings

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
19
SR600EX
USER’S GUIDE
18
Extender Settings (Security)
By default, the Extended Network has security
enabled. The WPA security key is “wireless.” Users
trying to connect to the Wi-Fi Range Extender
wirelessly will be prompted to enter this key.
It is recommended that you use the default sengs
for the wireless security key.
To change the security key, simply retype your new key in the field and click Next. Write your security key
down somewhere safe for future reference.
No security key is necessary for computers connecng to the Wi-Fi Range Extender
using a wired connecon to
the LAN ports.
Aer clicking Next, the Wi-Fi Range Extender will reboot and apply your sengs. Be paent and do not make
any changes or adjustments to the Wi-Fi Range Extender at this me.
Wi-Fi Range Extender.
Wi-Fi Range Extender
Wi-Fi Range Extender

After Sales Support
Telephone: [phone]
Internet: www.winplus.com.au
20
SR600EX
USER’S GUIDE
19
Setup Summary
Once the Wi-Fi Range Extender has rebooted, it will
load the Setup Summary page and provide you with
the details of your setup.
At this me, you may disconnect from the Wi-Fi Range
Extender start a wireless connecon.
If you have any wired devices that you would like to
aach to the you may do so
now as well.
Enjoy your Extended Network.
Bauhn_Wireless
Bauhn Wireless
Wi-Fi Range Extender
Wi-Fi Range Extender
Wi-Fi Range Extender
Wi-Fi Range Extender
SR600EX
USER’S GUIDE
19
Setup Summary
Once the Wi-Fi Range Extender has rebooted, it will
load the Setup Summary page and provide you with
the details of your setup.
At this me, you may disconnect from the Wi-Fi Range
Extender start a wireless connecon.
If you have any wired devices that you would like to
aach to the you may do so
now as well.
Enjoy your Extended Network.
Bauhn_Wireless
Bauhn Wireless
Wi-Fi Range Extender
Wi-Fi Range Extender
Wi-Fi Range Extender
Wi-Fi Range Extender
At this me you may disconnect from the Wi-Fi Range
Extender and start a wireless connecon.
Disconnect the Wi-Fi range extender from your computer
by removing the LAN cable.
Connect to your newly created extended network using
your computer’s wireless connecon.
Windows 7 (example)
Click on the wireless icon to see available wireless net
works. Select your newly created extended network from
the network list, and click “Connect”.
Enter your password to complete the process.
