Bauknecht GSFK61312TRWS User manual

Contents
1
1.Safety and operating instructions _________ 2
2.Installation and hook-up _______________ 14
You are advised to read this manual carefully; it
contains all the information you
need about the
right conditions for the proper, safe use of your
dishwasher.
INSTALLATION INSTRUCTIONS: these are
intended for the qualified technician
who must
carry out the installation, hook-
up and testing of
the appliance.

User instructions
2
1.Safety and operating instructions
THIS MANUAL FORMS AN INTEGRAL PART
OF THE APPLIANCE;
IT MUST ALWAYS BE
KEPT INTACT TOGETHER WITH THE
DISHWASHER FOR FUTURE REFERENCE.
BEFORE USING THE APPLIANCE,
CAREFULLY READ ALL THE INSTRUCTIONS
CONTAINED IN THIS MANUAL.
THEY
CONTAIN IMPORTANT INFORMATION FOR
THE INSTALLATION, USE AND
MAINTENANCE OF THE APPLIANCE. IN THE
EVENT OF SALE OR TRANSFER, ENSURE
THAT THE MANUAL ALW
AYS ACCOMPANIES
THE APPLIANCE.
THIS APPLIANCE IS INTENDED FOR
INDOOR
USE IN A HOUSEHOLD ENVIRONMENT
AND
SIMILAR SUCH AS STAFF KITCHENS OF
SHOPS, OFFICES AND OTHER
WORKPLACES, INSTITUTIONS, AND FOR
THE USE BY
GUESTS AT HOTELS,
HOSTELS, BED AND BREAKFAST AND
OTHER RESIDENTIAL FACILITIES.
THIS APPLIANCE IS DESIGNED TO BE USED
ONLY IN STATIONARY LOCATIONS.

User instructions
3
THIS APPLIANCE
COMPLIES WITH
DIRECTIVES 2006/95/EC AND 2004/108/EC
CURRENTLY IN FORCE, INCLUDING THE
PREVENTION AND ELIMINATION OF RADIO
FREQUENCY INTERFERENCE AND
IS
DESIGNED FOR THE FOLLOWING PURPOSE:
WASHING AND DRYING OF DISHES;
ANY
OTHER USE SHALL BE C
ONSIDERED
IMPROPER.
THE MANUFACTURER
DECLINES ALL RESPONSIBILITY F
OR USES
OTHER THAN THOSE DESCRIBED ABOVE.
DO NOT USE APPLIANCES WHICH HAVE
BEEN DAMAGED DURING TRANSIT!
IF IN
DOUBT, CONSULT YOUR DEALER.
THE APPLIANCE MUST B
E INSTALLED AND
CONNECTED IN ACCORDA
NCE WITH THE
INSTRUCTIONS PROVIDE
D BY THE
MANUFACTURER.
INSTALLATION MUST BE
PERFORMED BY A QUALIFIED TECHNICIAN,
IN COMPLIANCE WITH THE REGULATIONS
IN FORCE.
DO NOT LEAVE THE DIS
CARDED
PACKAGING MATERIALS UNSUPERVIS
ED
WITHIN THE HOME.
DO NOT ALLOW
CHILDREN TO PLAY WIT
H PACKAGING
MATERIALS. SEPARATE THE VARIOUS
MATERIALS WHICH MAKE
UP THE
PACKAGING AND TAKE T
HEM TO THE
NEAREST SORTED WASTE
COLLECTION
CENTRE.

User instructions
4
THE NAME PLATE FEATU
RING THE
TECHNICAL DATA, SERI
AL NUMBER AND
MARKINGS IS VISIBLY
POSITIONED ON THE
INNER EDGE OF THE DOOR.
THE NAME
PLATE MUST NEVER BE REMOVED.
THE APPLIANCE MUST B
E PROVIDED WITH
AN EARTH CONNECTION
IN ACCORDANCE
WITH THE ELECTRICAL
SAFETY
REGULATIONS IN FORCE.
THE MANUFACTURER DEC
LINES ALL
RESPONSIBILITY FOR D
AMAGE TO
PERSONS OR PROPERTY
RESULTING
FROM THE FAILURE TO
EARTH THE
APPLIANCE OR FROM A
DEFECTIVE EARTH
CONNECTION.
DURING THE INSTALLATIO
N THE
APPLIANCE MUST BE D
ISCONNECTED
FROM THE NETWORK.
DO NOT INSTALL THE A
PPLIANCE IN A
PLACE SUBJECT TO FREEZING.
IF THE APPLIANCE IS
INSTALLED ON A
CARPETED OR COVERED
FLOOR, ENSURE
THAT THE OPENINGS ON
ITS UNDERSIDE
ARE NOT OBSTRUCTED.
DO NOT INSTALL THE APPL
IANCE NEAR
EQUIPMENT WITH HIGH
IRRADIATION
TEMPERATURES (EG. GAS BURNERS
,
FIREPLACES, ETC.) AS
THEY MAY CAUSE
DAMAGE.

User instructions
5
IF THE APPLIANCE IS
INSTALLED IN A
COMPARTMENT ABOVE OR
BELOW
ANOTHER EQUIPMENT (E
G. GAS BURNERS,
OVENS, ETC.), READ C
AREFULLY THE
INSTRUCTIONS PROVIDE
D BY THE
MANUFACTURER OF THE
EQUIPMENT. IF
THE INSTRUCTIONS OF
THE EQUIPMENT
DO NOT CONTAIN INFORMATION,
CONTACT
THE MANUFACTURER OF
THE EQUIPMENT
TO ENSURE THAT THE A
PPLIANCE CAN BE
INSTALLED ABOVE OR BELOW IT.
BUILDING-IN THE APPLIANCE UNDERN
EATH
A HOB IS ABSOLUTELY FORBIDDEN.
INSTALL A HOB ON TOP OF A FREE-
STANDING APPLIANCE I
S ABSOLUTELY
FORBIDDEN.
TO ENSURE STABILITY,
INSTALL THE
APPLIANCE ONLY UNDER
CONTINUOUS
WORKTOP, SECURELY FIXED TO AD
JACENT
CABINETS. IF THE APP
LIANCE IS INSTALLED
IN A HIGH CABINET BOTH, THE
APPLIANCE
AND THE CABINET,
MUST BE ADEQUATELY
FIXED.

User instructions
6
IF THE APPLIANCE IS PLACED AT THE END
OF A ROW OF KITCHEN
CABINETS (THERE
IS NO FULL END CABIN
ET), THE DOOR
HINGE AREA MAY BE EX
POSED.TO COVER
UP THIS AREA, THUS A
VOIDING ANY RISK
OF ITEMS BEING PINCH
ED IN THE EXPOSED
DOOR HINGE, YOU ARE
OBLIGATED TO
ATTACH THE HINGE-PROTE
CTION PANELS
THAT ARE SUPPLIED WI
TH THE APPLIANCE
TO THE SIDE PANELS O
F THE APPLIANCE.
THERE IS A LEFT-HAND VERSION FOR THE
LEFT-HAND SIDE OF THE APP
LIANCE AND A
RIGHT-HAND VERSION FOR THE RIGHT-
HAND SIDE OF THE APP
LIANCE. INSTALL
THE PANELS AS SHOWN IN TH
E DRAWING
ATTACHED TO THE KIT,
USING THE
SCREWS PROVIDED WITH THE PANELS.
CHECK THAT THE VOLTA
GE AND THE
FREQUENCY OF THE MAI
NS MATCH THE
RATINGS ON THE NAME
PLATE OF THE
APPLIANCE.
THE PLUG ON THE SUPP
LY CORD AND THE
CORRESPONDING SOCKET
OUTLET MUST
BE OF THE SAME TYPE
AND MEET THE
REGULATION IN FORCE.
DO NOT USE ADAPTORS
OR SHUNT
CONNECTIONS IN ORDER
TO AVOID THE
POSSIBILITY OF OVERH
EATING OR
BURNING.

User instructions
7
THE PLUG OF THE APPL
IANCE MUST BE
ACCESSIBLE AFTER INSTALLATION.
NEVER DISCONNECT THE
PLUG BY
PULLING ON THE POWER CORD.
IF THE APPLIANCE IS
PROVIDED WITH A
PLUGLESS SUPPLY CORD
, A CIRCUIT
BREAKER
PROVIDING A FULL
DISCONNECTION
IN OVERVOLTAGE
PROTECTION CLASS III
MUST BE
INSTALLED IN AN EASI
LY ACCESSIBLE
POSITION ON THE SUPPLY LINE.
THE APPLIANCE MUST B
E CONNECTED TO
THE WATER SUPPLY BY
NEW HOSES; OLD
HOSES MUST NEVER BE REUSED.
IMMEDIATELY AFTER INSTALLING THE
DISHWASHER, PERFORM A QUICK TEST OF
THE APPLIANCE.
IF THE DISHWASHER
FAILS TO OPERATE CORRECTLY,
DISCONNECT IT FROM THE ELECTRICAL
POWER SUPPLY AND CALL THE NEAREST
TECHNICAL SERVICE CENTRE.
DO NOT
ATTEMPT TO REPAIR THE APPLIANCE.

User instructions
8
THIS APPLIANCE CAN BE USE
D BY
CHILDREN AGED FROM 8
YEARS AND
ABOVE AND PERSONS WI
TH REDUCED
PHYSICAL, SENSORY OR
MENTAL
CAPABILITIES OR LACK
OF EXPERIENCE
AND KNOWLEDGE IF THE
Y HAVE BEEN
GIVEN SUPERVISION OR
INSTRUCTION
CONCERNING USE OF TH
E APPLIANCE IN A
SAFE WAY AND UNDERSTAND T
HE
HAZARDS INVOLVED. CHILDREN SHALL
NOT PLAY WITH THE AP
PLIANCE. CLEANING
AND USER MAINTENANCE
SHALL NOT BE
MADE BY CHILDREN WIT
HOUT
SUPERVISION.
DO NOT ALLOW CHILDREN TO PLAY WITH
THE APPLIANCE.
SOME DETERGENTS ARE STRONGLY
ALKALINE. AVOID CONTACT WITH THE SKIN
AND EYES.
DETERGENTS CAN BE
EXTREMELY DANGEROUS IF SWALLOWED.
THEY CONTAIN SUBSTANCES CAPABLE OF
CAUSING PERMANENT DAMAGE TO THE
MOUTH AND THROAT, AND EVEN LEADING
TO SUFFOCATION. OBSERVE ALL
THE
SAFETY INSTRUCTIONS ON THE
PACKAGING OF THESE PRODUCTS.

User instructions
9
KEEP CHILDREN AWAY FROM THE
DISHWASHER WHEN THE DOOR IS OPEN.
ALWAYS CHECK THAT THE DETERGENT
RECEPTACLE IS EMPTY AFTER
COMPLETION OF THE WASH CYCLE.
DO NOT DRINK THE WAT
ER RESIDUES
WHICH MAY BE PRESENT
INSIDE THE
DISHES OR APPLIANCE
AT THE END OF THE
WASHING PROGRAM.
DO NOT INTRODUCE SOL
VENTS SUCH AS
ALCOHOL OR TURPENTINE
IN THE
APPLIANCE, AS THIS
MAY CAUSE AN
EXPLOSION.
DO NOT LOAD DISHES THAT ARE
SOILED
WITH ASH, WAX OR PAINT.
NEVER LEAVE THE DISH
WASHER DOOR
OPEN; PEOPLE MIGHT TRIP OVER IT.
LEANING OR SITTING O
N THE DISHWASHER
DOOR WHEN OPEN MAY C
AUSE THE
APPLIANCE TO OVERTURN.
KNIVES OR OTHER SHARP-
ENDED
COOKING TOOLS MUST BE PLACED IN TH
E
CUTLERY BASKET BLADE-
DOWN, OR LAID
HORIZONTAL IN THE TOP BASKET.
TAKE
CARE NOT TO CUT YOUR
SELF AND
ENSURE THAT THEY DO
NOT PROJECT
FROM THE BASKET.

User instructions
10
THE DISHWASHER MEETS
ALL THE
REQUIREMENTS SET OUT
BY THE
REGULATIONS IN FORCE
CONCERNING
SAFETY AND ELECTRICAL EQUIPMENT.
ANY
TECHNICAL CHECKS SHO
ULD BE
CONDUCTED EXCLUSIVEL
Y BY TRAINED
AND AUTHORISED TECHNICIANS:
REPAIRS
CARRIED OUT BY UNAUT
HORISED
PERSONS WILL INVALID
ATE THE
WARRANTY, AS WELL AS
POSING A
POTENTIAL HAZARD TO THE USER.
IN THE EVENT OF A FA
ULT, DISCONNECT
THE DISHWASHER FROM
THE ELECTRICAL
POWER SUPPLY AND SHU
T OFF THE
WATER TAP.
IN THE EVENT OF DAMA
GE TO THE SUPPLY
CORD, HAVE IT REPLACED
BY THE
MANUFACTURER OR AN A
UTHORIZED
TECHNICAL SERVICE CENTRE.
SOME COMPONENTS ARE LIVE
EVEN WITH
THE ON/OFF BUTTON IN
THE OFF POSITION.
BEFORE MAINTENANCE W
ORK ON THE
APPLIANCE, DISCONNEC
T THE PLUG OR
TURN OFF THE MAINS S
WITCH IN THE
FIXED WIRING.

User instructions
11
C
LEANING AND REGULAR MAINTENANCE
OF THE APPLIANCE BY CHILDREN IS
ONLY
PERMITTED UNDER THE SUPERVISION OF A
PERSON RESPONSIBLE FOR THEIR
SAFETY.
DO NOT USE STEAM CLE
ANERS TO CLEAN
THE DISHWASHER.
MODELS WITH “AQUASTOP” DEVICE
THE “AQUASTOP” DEVICE
PREVENTS
FLOODING IN THE EVENT OF A WATER
LEAK.
WHEN THE “AQUASTOP” DEVICE IS
TRIPPED, CALL IN A QUALIFIED TECHNICIAN
TO IDENTIFY AND REPAIR THE FAULT.
INSIDE THE “AQUASTOP
” WATER INTAKE
HOSE, THERE ARE ELECTRICAL PARTS.
DO
NOT CUT THE HOSE AND DO NOT ALL
OW
THE “AQUASTOP” DEVICE
TO DROP INTO
WATER. IN THE EVENT OF DAMA
GE TO
THE “AQUASTOP” WATER
INTAKE HOSE,
DISCONNECT THE APPLI
ANCE FROM THE
ELECTRICAL SUPPLY AN
D FROM THE
WATER SUPPLY.
MODELS WITH INTERNAL LIGHTING
THE LIGHTING SYSTEM
OF THE APPLIANCE
BELONGS TO RISK GROU
P 1 UNDER THE
IEC/EN 62471 STANDAR
D. THIS MEANS
THAT THERE IS NO PHO
TOBIOLOGICAL
RISK IN NORMAL CONDITIONS OF USE.

User instructions
12
IN ACCORDANCE TO ART
. 26 OF THE
LEGISLATIVE DECREE 1
4 MARCH 2014, NR.
49 “IMPLEMENTATION O
F THE DIRECTIVE
2012/19/EU ON WASTE OF ELECTRIC
AL
AND ELECTRONIC EQUIPMENT (WEEE)”.
THE SYMBOL OF A CROS
SED OUT WHEELIE
BIN ON THE DEVICE OR PAC
KAGE
SHOWS THAT THE PRODU
CT MUST BE
COLLECTED SEPARATE F
ROM OTHER
WASTE, AT THE END OF ITS SERVICE LIFE.
THEREFORE, THE USER HAS TO TAKE
ANY
EQUIPMENT THAT HAS R
EACHED THE END
OF ITS SERVICE LIFE
TO LOCAL WASTE
DISPOSAL CENTRES FOR
ELECTRICAL AND
ELECTRONIC EQUIPMENT WASTE.
AS AN ALTERNATIVE TO
THE IDEPENDENT
MANAGEMENT, IT IS PO
SSIBLE TO DELIVER
THE EQUIPMENT WHICH
HAS TO BE
DISPOSED OF TO
THE DEALER, AT THE
MOMENT OF PURCHASING
A NEW
EQUIVALENT DEVICE AT
THE ELECTRONIC
EQUIPMENT DEALERS WITH A
SALES AREA
OF AT LEAST OF 400 M
2
. ALSO, FOR
DISUSED DEVICES WITH
DIMENSIONS
INFERIOR TO 25 CM, F
REE DELIVERY TO
THE DEALERS IS POSSI
BLE, WITH NO
PURCHASE OBLIGATION
A PROPER SEPARATE WA
STE COLLECTION
AND THE CONSEQUENT H
EADING OF THE
DISUSED DEVICE TOWAR
DS ITS
RECYCLING, TREATMENT
AND

User instructions
13
ENVIRONMENTALLY COMP
ATIBLE
DISPOSAL, CONTRIBUTE
S IN PREVENTING
ANY POSSIBLE NEGATIV
E EFFECTS ON
ENVIRONMENT AND HEA
LTH; ALSO, IT
SUPPORTS THE REUSE A
ND/OR RECYCLE
OF THE MATERIALS WHI
CH COMPOSED THE
DEVICE.
OBSOLETE APPLIANCES
MUST BE
RENDERED UNUSABLE.
CUT OFF THE
MAINS POWER CORD AFT
ER UNPLUGGING
IT FROM THE WALL OU
TLET, AND MAKE
SAFE ANY COMPONENTS WHICH MIGHT
BE
DANGEROUS FOR CHILDR
EN (LOCKS,
DOORS, CABLES, HOSES, ETC.).
The manufacturer declines all responsibility for
damage to persons or property resulting from
failure to observe the above precautions, from
tampering with even a single component of the
appliance, or from the use of non original spare
parts.

User instructions
14
2.Installation and hook-up
0
Usage of gloves during installation
Remove the polystyrene basket retainers.
Position the appliance in the desired place of
installation. The back
or sides of the dishwasher
may be placed up against walls or other furniture
units.
If the dishwasher is installed near a heat
source, fit the special insulating panel to prevent
overheating and malfunction of the appliance.
To ensure stability, install integrated or built-
under dishwashers only under continuous
worktops, and screw them to the adjacent units.
To facilitate the installation procedure, the intake
and drain hoses can be positioned in any
direction; make sure that the hoses are not
kinked, crushed or pulled too tightly.
Make sure
to tighten the locking ring-
nut once the pipes
have been placed in the direction required.
A
hole at least 8 cm in diameter is required to allow
the power supply cable and pipes to pass.
Before
putting the dishwasher in
to its definitive position,
turn on the water tap and check that there are
no leaks from the tap connection, the
dishwasher connection or the hose.
Level the appliance on the floor using its
adjustable feet.
This operation is essential for
ensuring correct operation of the dishwasher.

User instructions
15
Some models are equipped with only one
adjustable foot at the rear, which can be
adjusted by turning the screw on the lower front
part of the appliance.
Building-
in a dishwasher underneath a hob is
absolutely forbidden.
0
Moreover, dishwashers may not be installed
directly touching appliances which are not
conventional built-
in kitchen appliances (e.g.
fireplaces, stoves, etc.).
0
When installing the dishwasher in a compartment
next to one or more
other appliances, it is
essential to comply with all the recommendations
provided by the appliance’s manufacturer
(minimum distances, installation procedures,
etc.).
For free-standing models only:
- Installing a hob on top of a free-
standing
dishwasher is absolutely forbidden.
- If the appliance is not built-
in and is therefore
accessible on one side, the door hinge area
must be covered for safety
reasons (injury hazard). The covering fixtures are
a
vailable as an accessory from specialist
dealers or the After-Sales
Service.
- To build in the dishwasher, the special kit
must
be purchased from authorised dealers or the
After-Sales Service.

User instructions
16
Long door models only:
If the appliance is placed at
the end of a row of
kitchen cabinets (there is no full end cabinet),
the door hinge area may be exposed. To cover
up this area, thus avoiding any risk of items
being pinched in the exposed door hinge, you
are obligated to attach the hinge-
protection
panel
s that are supplied with the appliance to
the side panels of the appliance. There is a left-
hand version for the left-
hand side of the
appliance and a right-hand version for the right-
hand side of the appliance. Install the panels
shown in the drawing atta
ched to the kit, using
the screws provided with the panels.
2.1Water supply connection
Preventing the risk of clogging or damage:
if
the water pipe is new or has not been used for a
long time, before connecting to the water supply
check that the water
is clear and free of
impurities, to prevent damage to the appliance.
The dishwasher must always be connected
to the water system with new hoses; old or
used hoses must never be reused.

User instructions
17
CONNECTING TO THE WATER
SUPPLY
Connect the intake hose to a cold
water supply with ¾” gas thread,
inserting the filter A
supplied with the
dishwasher.
Take care to screw the
hose firmly into place with your
hands and then complete by
tightening about ¼ of a turn with
pliers.
In
dishwashers equipped with the
ACQUASTOP device, the filters is
already fitted inside the threaded
ring.
The dishwasher can also be connected to a hot
water supply not exceeding 60°C
. Supplying the
appliance with hot water cuts down the washing
time by approximately 20 minutes, but slightly
reduces its effectiveness.
Make the connection to
the domestic hot water supply using the same
procedure described for connecting to the cold
water supply.

User instructions
18
DRAIN CONNECTION
Insert the dishwasher’s drain
hose into a drain pipe having a
diameter of at least 4 cm
, or
alternatively, place it inside the
kitchen sink using the plastic
support provided, taking care
not to crush or excessively bend
the hose.
It is important to
preven
t the hose from coming
loose and falling.
For this
purpose, the plastic support is
equipped with a hole for tying it
to the wall or water tap.
The free end should be positioned at a height of
between 30 and 100 cm,
and should never be
submerged in water.
If a horizontal drain
extension hose is used (for a maximum of 3 m)
the drain hose can be placed at a maximum
height of 85 cm from the ground.
Class of protection against moisture: IPX0
APPLIANCE CAN NOT BE OPERATED UNTIL
INSTALLATION PROCESS IS COMPLETE.

User instructions
19
2.2Electrical connection and precautions
CHECK THAT THE VOLTA
GE AND THE
FREQUENCY OF THE MAI
NS MATCH THE
RATINGS ON THE NAME
PLATE OF THE
APPLIANCE POSITIONED
ON THE INNER
EDGE OF THE DOOR.
THE PLUG ON THE SUPP
LY CORD AND THE
CORRESPONDING SOCKET
OUTLET MUST
BE OF THE SAME TYPE
AND MEET THE
REGULATIONS IN FORCE.
THE PLUG MUST BE ACC
ESSIBLE AFTER
INSTALLATION.
NEVER DISCONNECT THE
PLUG BY
PULLING ON THE POWER SUPPLY LEAD.
AFTER CHANGING THE SUPPLY
CORD,
MAKE SURE THAT THE BRACKET
WHICH
SECURES THE CORD IS
FIXED SECURELY
IN PLACE.
DO NOT USE ADAPTORS
, CONVERSION
PLUGS OR SHUNT CONNECTIONS
IN
ORDER TO AVOID THE P
OSSIBILITY OF
OVERHEATING OR BURNING.
EXTENSION
CORD IS NOT ALLOWED.
In the event of damage to the supply
cord,
have it replaced by the manufacturer or an
Authorized Technical Service Centre in order
to avoid any risk.

User instructions
20
Some components are live even with the
ON/OFF button in the OFF position. Before
maintenance work on the appliance, remove
the plug or
turn off the power supply at the
wall switch.
IF THE APPLIANCE IS PROVIDED WITH A
PLUGLESS SUPPLY CORD:
AN OMNIPOLAR CIRCUIT
BREAKER IN
OVERVOLTAGE PROTECTION CLASS III
MUST BE INSTALLED IN
AN EASILY
ACCESSIBLE POSITION
ON THE POWER
SUPPLY LINE.
THE CONNECTION TO TH
E MAINS MUST BE
CARRIED OUT BY A QUALIFIED TECHNICIAN
IN ACCORDANCE TO THE
SCHEME SHOWN
BELOW AND THE REGULATIONS IN FORCE.
L= brown
N= blue
= yellow-green
Class of protection against electric shock: I
