Baumatic MINI4 User manual

IMPORTANT! PLEASE READ THIS MANUAL AND
KEEP IT FOR FUTURE REFERENCE
THIS MANUAL CONTAINS SECTIONS OF SAFETY INSTRUCTIONS, OPERATING
INSTRUCTIONS AND TROUBLESHOOTING TIPS, ETC.
BAUMATIC
MINI4
DISHWASHER
COUNTERTOP
DISHWASHER
20/02/05
INSTRUCTION MANUAL
CAREFULLY READING IT BEFORE USING THE DISHWASHER WILL HELP YOU USE
AND MAINTAIN THE DISHWASHER PROPERLY.

BAUMATIC MINI 4 dishwasher user manual 2
BEFORE CALLING
FOR SERVICE
REVIEWING THE SECTION ON
TROUBLESHOOTING TIPS WILL
HELP YOU SOLVE SOME
COMMON PROBLEMS WITHOUT
THE NEED TO ASK FOR HELP
FROM PROFESSIONAL
TECHNICIANS.
PLEASE NOTE:
THE MANUFACTURER
RESERVES THE RIGHT TO MAKE
MODIFICATIONS TO PRODUCTS
WITHOUT GIVING PRIOR
NOTICE.
CONTENTS
•SAFETY FIRST!
SAFETY INFORMATION .………………………3-4
*Please read this before using your dishwasher!
•KNOWING YOUR
DISHWASHER
YOUR MINI 4 DISHWASHER …………………..5
Incl. Control panel & Display ………………….5
•USING YOUR
DISHWASHER
WATER SOFTENER …………………..………......6
DETERGENT ………………..............................7
RINSE AID ………………….............................7
LOADING YOUR DISHWASHER…..….......8-10
STARTING A WASH CYCLE ……………….11-12
FILTERING SYSTEM ………………..…….…….13
CLEANING AND MAINTAINING
YOUR DISHWASHER …………………….…13-15
•BEFORE YOU CALL FOR
SERVICE…
TROUBLESHOOTING ………………….…..…16
ERROR CODES……………………………….…..17
•MISCELLANEOUS
HOW TO INSTALL ……….…….…..……....18-20
DISHWASHER CHARACTERISTICS …………21
FINAL CHECKLIST BEFORE STARTING…….22
CONDITIONS OF GUARANTEE………………..23
2
CONTACT DETAILS…………………………..…..24

BAUMATIC MINI 4 dishwasher user manual 3
IMPORTANT SAFETY INFORMATION
READ BEFORE USING!
ELECTRICAL SAFETY
•NOTE - This appliance must be grounded. In the event of a
malfunction or breakdown, grounding will reduce the risk of
electric shock by providing a path of least resistance of electrical
current. You will be able to tell if it is because a non-grounded
appliance will give off an electrical discharge.
•IF POWER SUPPLY CORD IS DAMAGED, IT MUST ONLY BE
REPLACED BY THE MANUFACTURER OR ITS SERVICE AGENT OR A
SIMILARLY QUALIFIED PERSON TO AVOID A HAZARD.
•THIS APPLIANCE IS FITTED WITH A SAFETY FUNCTION THAT
AUTOMATICALLY STOPS THE OPERATION OF THE DISHWASHER
WHEN IT IS EXPOSED TO ANY HEAVY DISTURBANCE ON ITS
MAINS.
•THIS APPLIANCE MUST BE POSITIONED SO THAT THE PLUG IS
ACCESSIBLE.
CHILD SAFETY
•DO NOT ABUSE OR FORCE THE DISHWASHER. DO NOT SIT ON OR
STAND ON ITS DOOR OR DISH RACK – TIPPING HAZARD AND YOUR
DISHWASHER COULD BECOME DAMAGED OR DEFORMED.
•KEEP CHILDREN AWAY FROM DETERGENT, RINSE AID AND THE OPEN
DOOR OF THE DISHWASHER AS THERE COULD BE DETERGENT LEFT
INSIDE.
•SUPERVISE YOUNG CHILDREN TO ENSURE THEY DO NOT PLAY WITH
THE APPLIANCE.
•SUPERVISE INFIRM PERSONS IF THEY MUST USE THE APPLIANCE.
•THIS APPLIANCE IS NOT INTENDED FOR USE BY YOUNG CHILDREN.
3

BAUMATIC MINI 4 dishwasher user manual 4
BEFORE USING YOUR BAUMATIC MINI4 DISHWASHER:
•SOME ITEMS ARE UNSUITABLE FOR WASHING IN YOUR DISHWASHER.
PLEASE SEE PAGE 9 FOR A LIST OF THESE ITEMS.
•DO NOT TAMPER WITH THE CONTROLS.
•WHEN LOADING ITEMS TO BE WASHED:
1) Keep sharp items like knives away from the door seal.
2) Load sharp knives with the handles up to prevent injuries.
•DO NOT SPRAY WATER ON THE APPLIANCE. DOING SO MAY CAUSE
THE FAILURE OF ELECTRICAL PARTS OR ELECTRIC SHOCK.
•THE APPLIANCE IS TO BE CONNECTED TO THE WASH MAINS USING
NEW HOSE-SETS. OLD HOSE-SETS SHOULD NOT BE RE-USED.
•THE DISHWASHER SHOULD BE CONNECTED TO THE COLD WATER
SUPPLY ONLY. NOTE THAT THE TEMPERATURE OF THE WATER COMING
INTO YOUR DISHWASHER WILL AFFECT THE TIMES OF YOUR
DISHWASHER’S CYCLES. THIS SHOULD BE BY A NEGLIBLE AMOUNT,
OWING TO THE DIFFERENCES IN THE TEMPERATURES OF WATER MAINS
FROM PLACE TO PLACE AND AT THE TIME OF YEAR.
•DO NOT USE THE DISHWASHER FOR INDUSTRIAL AND COMMERCIAL
USE, OR ANY OTHER PURPOSES.
•THIS DISHWASHER IS DESIGNED FOR NORMAL HOUSEHOLD USE
ONLY
•ONLY USE AUTOMATIC DISHWASHER DETERGENT, NOT SOAP OR
LAUNDRY DETERGENT. NEVER USE SOLVENTS AS THIS COULD RESULT IN
AN EXPLOSION!
DURING USE
•DO NOT USE THE DETERGENT FOR HAND WASHING. THE DETERGENT FOR
THE DISHWASHER SHOULD BE USED FOR NORMAL OPERATION OF THE
APPLIANCE ONLY.
DO NOT OPEN THE DOOR WHEN THE LCD DISPLAY READS: ‘HIGH
TEMPERATURE.’ THE HOT STEAM MAY CAUSE PERSONAL INJURY.
AFTER USE
•ALWAYS KEEP THE DOOR CLOSED TO AVOID DANGER OF TRIPPING.
•CHECK THAT THE DETERGENT DISPENSER IS EMPTY AFTER COMPLETION OF WASH
CYCLE.
4
•IF LEAVING UNUSED FOR A LONG TIME, DISCONNECT THE WATER SUPPLY (SEE
PAGE 20).

BAUMATIC MINI 4 dishwasher user manual 5
Control panel and the LCD display
1. The power
indicator: it
will light up
when the
machine
comes on.
2. The salt
indicator: it
will light up
when the salt
runs low in the softener container. Please add more salt to the container (see p.6) if the salt
indicator light comes on.
3. Program Key: you can select the program by pushing the program key;
4. Pause/Start key: you can start or pause the program by pushing the Pause/Start key;
5
Your MINI 4 Dishwashe
r
Program
High temperature
Warning
Run time
High temperature State

BAUMATIC MINI 4 dishwasher user manual 6
Note on chemicals used by your dishwasher:
Your dishwasher is equipped with rinse aid and water softening dispensers. Using detergent, rinse
aid and salt individually will give the best possible results as this will give the correct dosage of each
chemical to suit your needs.
•Using Two-in-One or Three-in-One tablets may not give the best results when used in your appliance,
and may not be suitable for the type of water supply in your home, as they contain pre-determined
quantities of salt, rinse aid and detergent and cannot be adjusted to the individual requirements.
•If you are going to use 3-in-1 (or 2-in-1) tablets, we suggest that you contact the manufacturer before
use or if you experience poor results in the wash performance and ask for assistance from them.
WARNING:
IF YOU USE 3-IN-1 OR 2-IN-1 TABLETS, BE
SURE NOT TO ADD SALT AND/OR RINSE AID
TO THE APPLIANCE AS THESE TABLET
TYPES ALREADY CONTAIN SALT AND/OR
RINSE AID. ADDING SALT AND RINSE AID
TO YOUR DISHWASHER’S COMPARTMENTS
IN A CYCLE INVOLVING A 3-IN-1 OR 2-IN-1
TABLET WILL RESULT IN OVERDOSING OF
INDIVIDUAL CHEMICALS AND MAY CAUSE
OVERFLOWING OF WATER AND SUDS.
YOUR
DISHWASHER’S
WATER SOFTENING
FEATURE
HOW TO USE THE WATER SOFTENER.
THE HARDNESS OF THE WATER VARIES FROM PLACE
TO PLACE. IF HARD WATER IS USED IN THE
DISHWASHER, DEPOSITS WILL FORM ON THE
DISHES AND UTENSILS. YOUR DISHWASHER IS
EQUIPPED WITH A WATER SOFTENER WHICH USES
A SALT SPECIFICALLY DESIGNED TO ELIMINATE THE
MINERALS FROM THE WATER THAT WOULD
OTHERWISE LEAVE DEPOSITS ON YOUR DISHES
AFTER WASHING.
YOUR WATER SOFTENER’S SALT CONTAINER
NEEDS TO BE LOADED WITH DISHWASHER
SALT BEFORE YOU USE YOUR DISHWASHER
FOR THE FIRST TIME. PLEASE FOLLOW THESE
DIRECTIONS FOR OPTIMUM PERFORMANCE:
LOADING THE SALT INTO THE CONTAINER.
1) UNSCREW THE CAP FROM THE
SALT CONTAINER
ANTICLOCKWISE. THE
CONTAINER IS ON THE RIGHT
HAND SIDE OF THE INNER BOX.
2) LOAD THE SALT INTO THE
CONTAINER. EACH TIME YOU MAY
LOAD 250G OF SALT, WHICH CAN
BE USED FOR 15 CYCLES.
3) FILL THE WATER INTO THE SALT
CONTAINER UNTIL A SMALL
AMOUNT OF WATER COMES OUT
(THIS IS VERY IMPORTANT WHEN
YOU USE IT FOR THE FIRST TIME).
4) SCREW THE CAP BACK ON
CAREFULLY.
NOTE:
1) LOAD THE SALT BEFORE THE BEGINNING OF A WASH CYCLE SO AS TO
PREVENT CORROSION.
2) USE ONLY DISHWASHER SALT. OTHER TYPES OF SALT CAN DO
IRREPARABLE DAMAGE TO YOUR APPLIANCE.
USING A RINSE AID
6
YOU CAN HELP PREVENT UNSIGHTLY SPOTS ON DISHES AND GLASSWARE, AND REDUCE
DRYING TIME BY USING RINSE AID. A RINSE AID IS SPECIALLY FORMULATED TO RINSE AWAY

BAUMATIC MINI 4 dishwasher user manual 7
FOOD AND DETERGENT RESIDUES THAT CAN BE LEFT BEHIND ON YOUR DISHES. USED
REGULARLY, RINSE AID WILL AUTOMATICALLY PROVIDE YOU WITH CLEANER DISHES EVERY
TIME YOU WASH.
•TO FILL THE RINSE AID DISPENSER,
UNSCREW THE DISPENSER CAP LOCATED AT
THE BACK OF THE INNER BOX AT THE TOP
RIGHT.
•ADD THE RINSE AGENT SLOWLY INTO THE
CONTAINER UNTIL IT JUST REACHES THE
BOTTOM OF THE FILLING CAP INSIDE THE
DISPENSER OPENING.
•REPLACE THE CAP.
•THE DISPENSER AUTOMATICALLY RELEASES
THE RINSE AID INTO THE FINAL RINSE
WATER.
USING DETERGENT IN YOUR DISHWASHER
Add the rinse
aid in this hole.
USING THE RIGHT DETERGENT
USE ONLY DETERGENT SPECIFICALLY MADE FOR USE IN DISHWASHERS, AS OTHER
TYPES WILL CAUSE OVERSUDSING AND FROTHING. IF YOUR DETERGENT IS OLD
AND/OR LUMPY, THROW IT AWAY. OLD DETERGENT LOSES ITS WASHING POWER.
LUMPY DETERGENT WON’T DISSOLVE.
HOW MUCH DETERGENT SHOULD YOU USE?
•THIS DEPENDS ON IF YOUR WATER IS ‘HARD’ OR ‘SOFT’.
•HARDER WATER REQUIRES MORE DETERGENT TO GET DISHES CLEAN
•SOFT WATER REQUIRES LESS DETERGENT TO GET DISHES CLEAN.
•THE DETERGENT LOADING GROOVE (pictured above) ON THE INSIDE
DOOR PANEL WILL HOLD APPROX. 7 GRAMS OF DETERGENT. ALWAYS
FOLLOW THE DETERGENT MANUFACTURER’S GUIDELINES.
BEFORE YOU LOAD YOUR DISHWASHER,
MAKE SURE THAT YOUR DISHWASHER IS CONNECTED TO THE COLD WATER SUPPLY.
CHECK THAT THE FILTER (ITEM 11 IN THE DIAGRAM ON PAGE 5) IS SECURELY IN PLACE.
LOADING YOUR DISHWASHER
7
The loading groove
for the detergent

BAUMATIC MINI 4 dishwasher user manual 8
PUSH THE DOOR RELEASE BUTTON (ITEM 3 ON DIAGRAM ON PAGE 5) TO OPEN THE DOOR.
NOTE:
FOR BEST PERFORMANCE, FOLLOW THESE LOADING GUIDELINES. FEATURES AND
APPEARANCE OF RACK & CUTLERY BASKET MAY VARY FROM YOUR MODEL.
IMPORTANT: CLEAN OFF LARGE FOOD SEDIMENTS BEFORE PLACING DISHES IN THE
DISHWASHER. GET RID OF AS MUCH SAUCE AND GREASE AS POSSIBLE AND EMPTY CUPS &
GLASSES.
YOUR DISHWASHER IS DESIGNED TO RECEIVE A STANDARD ‘4 PIECE’ PLACE
SETTING CONSISTING OF THE FOLLOWING:
1. 4 DINNER PLATES
2. 4 BREAD & BUTTER PLATES
3. 4 FRUIT BOWLS
4. 4 CUPS AND SAUCERS
5. 4 GLASS CUPS
6. 4 DINNER FORKS
7. 4 DINNER KNIVES
8. 4 SALAD FORKS
9. 4 TEASPOONS
10. 2 SERVING SPOONS
11. 1 SERVING SPOON
12. 1 SERVING FORK
13. 1 SERVING BOWL
14. 1 OVAL PLATTER
NOTE:
FOR EASE OF LOADING / UNLOADING LARGE SIZE DINNER PLATES FROM THE DISH
RACK, YOU MIGHT HAVE TO (TEMPORARILY) REMOVE THE CUTLERY BASKET. WHEN
LOADING / UNLOADING IS COMPLETE, RETURN THE CUTLERY BASKET TO ITS ORIGINAL
POSITION.
PREPARING YOUR DISHES FOR
WASHING:
8

BAUMATIC MINI 4 dishwasher user manual 9
NOTE: DISHES WITH DRIED-ON FOODS ARE MORE DIFFICULT TO WASH AND MAY NOT COME OUT
CLEAN FROM A NORMAL WASH CYCLE.
WHEN LOADING ITEMS TO BE WASHED:
•PLACE SHARP ITEMS SO THAT
THEY ARE NOT LIKELY TO DAMAGE
THE DOOR SEAL.
•ARRANGE ALL ITEMS WITH
RECESSED OR CURVED SECTIONS
(BOWLS, ETC.) ON A SLANT TO
DRAIN WATER AWAY.
•CUPS, POTS, GLASSES, ETC.
SHOULD BE PLACED UPSIDE
DOWN.
•LOAD SHARP KNIVES WITH THE
HANDLES UP TO REDUCE THE RISK
OF CUT-TYPE INJURIES.
•DO NOT LOAD PLASTIC ITEMS
UNLESS THEY ARE MARKED
‘DISHWASHER SAFE’ OR THE
EQUIVALENT. FOR PLASTIC ITEMS
NOT SO MARKED, CHECK THE
MANUFACTURER’S
RECOMMENDATIONS.
•DO NOT LOAD GLASSES OVER THE
DISH RACK PINS. GLASSES LOADED
OVER DISH RACK PINS ARE NOT
PROPERLY SUPPORTED AND ARE
LIKELY TO GET DAMAGED.
•ITEMS WITH WOODEN OR BONE
HANDLES AND ITEMS JOINED
TOGETHER WITH GLUE ARE
UNSUITABLE AS THEY CANNOT RESIST
HOT WATER.
•DO NOT TOUCH THE HEATING
ELEMENT DURING OR
IMMEDIATELY AFTER USE.
•DO NOT OPERATE YOUR
DISHWASHER UNLESS ALL
ENCLOSURE PANELS ARE
PROPERLY IN PLACE.
•DO NOT TAMPER WITH CONTROLS.
•DO NOT ABUSE, FORCE, SIT ON, OR
STAND ON THE OPEN DOOR OR
DISH-RACK OF THE DISHWASHER.
THE MACHINE MAY TOPPLE OVER.
•PROTECT CABLES AND HOSES
FROM HIGH TEMPERATURES.
DO NOT PUT THESE ITEMS IN YOUR DISHWASHER:
•BRONZE
CUTLERY
•SAUCEPANS
WITH
WOODEN
HANDLES
9
•CUTLERY
WITH
WOODEN,
HORN, CHINA
OR MOTHER
OF PEARL
HANDLES

BAUMATIC MINI 4 dishwasher user manual 10
•PLASTIC
ITEMS THAT
ARE NOT HEAT
RESISTANT
•OLDER
CUTLERY
WITH GLUED
PARTS
•BONDED
CUTLERY
ITEMS OR
DISHES
•PEWTER OR
COPPER ITEMS
•LEAD CRYSTAL
GLASS
•STEEL ITEMS
SUBJECT TO
RUSTING
•WOODEN
PLATTERS
•ITEMS MADE
FROM
SYNTHETIC
FIBRES (eg.
SPONGES)
•DELICATE,
REPAIRED OR
PAINT /
PATTERN
OVERLAID
CHINA
Note:
Do not wash stainless steel and silver cutlery together. Iron objects can rust
and stain other items. Aluminium tends to go black. Copper, pewter & brass
stain.
NOTE:
•WHEN YOU ARE SATISFIED YOU HAVE LOADED ALL THE UTENSILS
AND DISHES YOU WANT TO WASH AND HAVE ADDED THE PROPER
AMOUNT OF DETERGENT TO THE DISPENSER, ENSURE THE RACK IS
PUSHED ALL THE WAY BACK INTO YOUR DISHWASHER AND CLOSE
THE DOOR.
•YOU ARE NOW READY TO START A WASH CYCLE (SEE NEXT PAGE).
•CHECK TO MAKE SURE THAT THE ROTATING SPRAY ARM CAN TURN
FREELY ALL THE WAY ROUND. IF NECESSARY, REMOVE ANYTHING
BLOCKING IT.
STARTING A WASH CYCLE –
OPERATING INSTRUCTIONS
10
TO USE YOUR DISHWASHER:

BAUMATIC MINI 4 dishwasher user manual 11
1. CHECK THAT THE INLET AND DRAIN HOSES ARE CORRECTLY
AND SECURELY CONNECTED.
2. CLOSE THE DOOR FIRMLY.
3. OPEN THE WATER SUPPLY.
4. PUSH THE POWER (ON/OFF) BUTTON.
PUSH BUTTON IN = POWER ON
PUSH SO BUTTON IS OUT = POWER OFF
THE LCD AND THE POWER LIGHT WILL NOW ILLUMINATE INDICATING THE
MACHINE IS RECEIVING POWER.
5. NOW SELECT THE DESIRED PROGRAM BY PRESSING THE
PROGRAM KEY. THE LCD WILL DISPLAY THE WASHING MODE
YOU SELECTED.
Nor Str
6. PRESS THE PAUSE/START KEY TO START. THE LCD WILL FLASH
THE PROGRAM AND THE WASHING STATUS DURING OPERATION.
7. AT THE END OF THE CYCLE, THE DISHWASHER WILL STOP AND
THE LCD WILL STOP FLASHING AND THE DISHWASHER WILL
BEEP. NOTE: THE LCD WILL BE BLACK WHEN THE MACHINE DOES
NOT RUN OR OPERATE FOR MORE THAN 10 MINUTES. THE POWER
LIGHT WILL STAY LIT UNTIL THE POWER (ON/OFF) BUTTON IS
SWITCHED OFF.
8. THE DISHWASHER IS DESIGNED TO STOP IF THE DOOR IS
OPENED ACCIDENTALLY DURING OPERATION.
9. YOU CAN SELECT ANOTHER PROGRAM DURING OPERATION BY
PRESSING THE PAUSE/START KEY FIRST, THEN PRESSING
THE PROGRAM KEY TO THE DESIRED PROGRAM, AND PRESSING
THE PAUSE/START KEY TO START. PLEASE NOTE THAT YOU
HAVE A LIMITED TIME TO CHANGE TO ANOTHER PROGRAM
BEFORE YOUR DISHWASHER BECOMES SET ON THE OLD
PROGRAM.
10.AFTER WASHING, DISHES SHOULD BE ALLOWED TO COOL
DOWN FOR ABOUT 15 MINUTES SO THEY ARE NOT TOO HOT TO
HANDLE. DISHES WILL COOL QUICKER IF THE DOOR IS
OPENED SLIGHTLY.
11
Rap

BAUMATIC MINI 4 dishwasher user manual 12
11.AFTER UNLOADING THE DISWASHER, REMOVE THE FILTER,
CLEAN OFF ANY BITS OF FOOD, AND PUT THE FILTER BACK IN
ITS POSITION.
NOTE: AT THE BEGINNING OF EACH CYCLE, THE DISHWASHER ALWAYS STARTS IN
THE ‘DRAIN’ MODE. THIS IS BECAUSE THE DRAIN PUMP ALWAYS RETAINS A SMALL
AMOUNT OF WATER (IN THE SUMP) FROM THE PREVIOUS CYCLE. THIS IS
NECESSARY TO KEEP THE PUMP PRIMED. THEREFORE, DO NOT BE ALARMED IF YOU
SEE A SMALL AMOUNT OF WATER BEING PUMPED-OUT FROM THE DRAIN HOSE
PRIOR TO THE START OF THE REGULAR WASH CYCLE. THIS IS NORMAL.
THESE ARE THE PROGRAM CYCLES:
PROGRAM
TYPE WATER TEMPERATURE
PROGRAM
DURATION &
HEATING
TIME
WATER USED
STRONG WASH 62 C 75 MINS. 14 LITRES
NORMAL WASH 62 C 67 MINS. 12 LITRES
RAPID WASH 55 C 35 MINS. 6 LITRES
(NOTE: THE WASHING TIME MAY VARY ACCORDING TO THE INCOMING WATER
TEMPERATURE AND THE ENVIRONMENTAL TEMPERATURE. FOR EXAMPLE, A
NORMAL WASHING CYCLE OF 67 C HAS BEEN RECORDED TO LAST FOR 78 MINS.)
FILTERING SYSTEM
FOR YOUR CONVENIENCE, WE HAVE PLACED THE FILTERING SYSTEM
WITHIN EASY REACH INSIDE THE TUB. THE FILTER REMOVES BITS OF
FOOD TRAPPED IN THE FILTER FROM THE WASH WATER SO IT CAN BE
RECIRCULATED DURING THE CYCLE. THERE ARE THREE PARTS TO THE
FILTERING SYSTEM:
12

BAUMATIC MINI 4 dishwasher user manual 13
1) THE STAINLESS STEEL MICRO FILTER - LOCATED AT THE BOTTOM OF THE INNER BOX.
THIS PERFORATED STAINLESS STEEL PLATE TRAPS LARGE PARTICLES OF FOOD THAT
WOULD OTHERWISE BE RECIRCULATED AROUND WITH THE DISHWATER DURING A
CYCLE.
2) THE CONICAL FILTER. THIS IS THE FIRST CIRCULAR-SHAPED FILTER THAT LIES
IMMEDIATELY IN THE HOLE OF THE MICROFILTER PLATE. THIS WILL TRAP LARGE
PIECES OF FOOD, ETC.
3) THE FINE MESH FILTER. THIS IS THE SECOND CIRCULAR-SHAPED FILTER THAT LIES
ON THE OUTSIDE OF THE COARSE FILTER. IT CATCHES AND TRAPS FINER DEBRIS
FROM THE WASH WATER AS IT TRAVELS THROUGH THE FILTERING SYSTEM, ENABLING
THE WASH WATER TO STAY FREE OF FOOD RESIDUES.
Caring for your Dishwasher
CLEANING THE OUTSIDE SURFACES OF YOUR APPLIANCE
•TO CLEAN THE EXTERIOR OF YOUR DISHWASHER (INCLUDING THE CONTROL PANEL), USE A LIGHTLY
DAMPENED CLOTH THEN DRY THOROUGHLY. NEVER USE SHARP OBJECTS, SCOURING PADS OR
HARSH CLEANERS ON ANY PART OF THE APPLIANCE. SOME PAPER TOWELS CAN SCRATCH.
•TO CLEAN THE EDGE AROUND THE DOOR,
ONLY EVER USE A SOFT WARM, DAMP RAG.
DO NOT USE A SPRAY CLEANER HERE OR
WHEN CLEANING THE DOOR PANEL AS THIS
MAY HARM THE DOOR LOCK AND
ELECTRICAL PARTS.
CLEANING THE SPRAY ARMS
THE SPRAY ARMS NEED REGULAR CLEANING AS HARD WATER RESIDUES WILL CLOG THEIR
JETS & BEARINGS. TO REMOVE THE SPRAY ARM, SCREW OFF THE NUT TO TAKE OUT THE
WASHER ON TOP OF THE SPRAY ARM AND REMOVE THE ARM. WASH THE ARMS IN SOAPY
WARM WATER & USE A SOFT BRUSH TO CLEAN THE JETS. REPLACE THE SPRAY ARM AFTER
RINSING IT THOROUGHLY.
13

BAUMATIC MINI 4 dishwasher user manual 14
CLEANING THE FILTERS
•THE FILTER ASSEMBLY MUST BE KEPT CLEAN FOR BEST PERFORMANCE. You should remove the
larger bits of food trapped in the filter after each wash cycle by rinsing them under running water.
To remove the filter assembly, pull up on the cup handle.
•The entire filter assembly should be cleaned at least once a month.
•To clear the coarse filter and the fine filter, use a cleaning brush. Then, reassemble the filter parts
as shown in the figure above and reinsert the entire assembly in the dishwasher in its seat & press
downward to secure it.
•Improper replacement of the filter may impair appliance performance and damage dishes and
utensils.
•Warning - never run the dishwasher without the filters in
place!
•Warning - Before cleaning the inner cavity of the appliance
always allow 15 minutes for the Element to cool down to avoid
injury!
14
HOW TO KEEP YOUR DISHWASHER IN SHAPE
AFTER EVERY WASH,leave the door slightly ajar so that moisture and odours are not trapped
inside.
REMOVE THE PLUG before cleaning or performing maintenance. Never run the risk of electric
shocks.
DO NOT USE SOLVENTS OR ABRASIVE CLEANING AGENTS to clean the exterior and the rubber
parts of the dishwasher. Only use a cloth and warm soapy water. To remove spots or stains
from the surface of the interior, use a cloth dampened with water and a little white vinegar,
or a cleaning product made specifically for dishwashers.

BAUMATIC MINI 4 dishwasher user manual 15
WHEN YOU GO ON HOLIDAY, run a wash cycle with the dishwasher empty. Then unplug it, turn
off the water supply and leave the door slightly ajar to prevent odours and mould from
developing.
MOVING THE APPLIANCE is possible but KEEP IT UPRIGHT.
SEALS can trap food, which in turn will cause odours. Periodic cleaning with a damp cloth or
sponge will prevent this from becoming a problem.
PROTECTING YOUR DISHWASHER AGAINST FREEZING
If your dishwasher is left in an unheated place during the winter, ask a
service technician to:
1) Cut off electrical power to the dishwasher. Remove fuses or trip circuit
breaker.
2) Turn off the water supply and disconnect the water inlet pipe from the water
valve & discharge hoses.
3) Drain water from the inlet pipe and water valve (Use a pan to catch the
water).
4) Reconnect the water inlet pipe to the water valve.
5) Remove the plastic sump cover in the tub bottom and use a sponge to soak
up water in the rubber boot.
COMMON DISHWASHING PROBLEMS AND
SOLUTIONS
NOTE: MANY PROBLEMS CAN BE RECTIFIED BY CONSULTING THE TROUBLE-
SHOOTING CHART. DOING THIS MAY SAVE YOU NEEDING A SERVICE ENGINEER.
PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION
•DISHWASHER NOT
RECEIVING
ELECTRICAL POWER
15
•CHECK ELECTRICAL
CONNECTION, FUSE/CIRCUIT
BREAKER
•DOOR IS UNLATCHED •CLOSE & LATCH DOOR
DISHWASHER WON’T START
•DISHWASHER NOT
LEVEL •LEVEL UNIT.
DISHES NOT CLEAN •IMPROPER LOADING

BAUMATIC MINI 4 dishwasher user manual 16
•ARRANGE DISHES SO SPRAY
ACTION REACHES ALL
SURFACES.
•DO NOT OVERLOAD
DISHWASHER.
•SPRAY ARM NOT
ROTATING FREELY
•CHECK SPRAY ARM TO MAKE
SURE NOTHING (EG.
CUTLERY) IS OBSTRUCTING
SPRAY ARM LOCATION.
•CHECK IF FILTER SCREEN HAS
BECOME DISLODGED AND
OBSTRUCTING SPRAY ARM
ROTATION.
•NOT ENOUGH
DETERGENT AND/OR
IMPROPER
DETERGENT BEING
USED.
•USE MORE DISHWASHER
DETERGENT.
•DO NOT USE DETERGENT
THAT IS HARD OR CRACKED.
•USE ONLY A RECOMMENDED
DISHWASHER DETERGENT.
•IMPROPERLY
PREPARED DISHES
•EXCESS FOOD SOIL AND
LIQUIDS SHOULD BE
REMOVED FROM DISHES
BEFORE LOADING.
•WATER INLET HOSE
KINKED/ BENT DUE
TO IMPROPER
INSTALLATION.
•UNDO KINK OR BEND IN
INLET HOSE.
•THE FILTER LOSES
ITS POSITION
•ENSURE THE FILTER IS
RETURNED TO ITS RIGHT
PLACE.
CHIPPING OR BREAKING
GLASSWARE
•IMPROPER LOADING
OF DISHES
•DO NOT OVERLOAD DISH
RACK. LOAD GLASSES ON
THE BOTTOM RACK ONLY.
•A SMALL AMOUNT OF
WATER (IN SUMP
AREA) IS NORMAL.
•THIS IS NECESSARY TO KEEP
THE PUMP PRIMED AND IS
DRAINED AUTOMATICALLY AT
THE BEGINNING OF EACH
CYLCE.
WATER REMAINS IN BOTTOM
•EXCESSIVE AMOUNT
OF WATER;
•CYCLE NOT
COMPLETED.
•ALLOW DISHWASHER TO
COMPLETE ITS FULL CYCLE.
ERROR CODES - WHAT THEY MEAN
* YOUR DISHWASHER MAY EXPERIENCE A FAULT. SHOULD THIS HAPPEN, A
CODE CONSISTING OF ‘E’ & A NUMBER FROM 1-7 CAN BE DISPLAYED.
USE THIS TABLE TO UNDERSTAND WHAT IS WRONG.
*NOTE*: ALWAYS CALL FOR A Baumatic Ltd ENDORSED / APPROVED
SERVICE TECHNICIAN TO CARRY OUT REPAIRS.
CODE SYMPTOM: CAUSE:
16
WHAT TO DO:

BAUMATIC MINI 4 dishwasher user manual 17
‘E1’ LONGER FILL TIME. FAUCET IS NOT OPENED. Ensure that inlet hose is not
kinked or crushed.
‘E2’ LONGER or EXTENDED DRAINING TIME THE DRAIN PIPE WAS PLACED
TOO HIGH WHEN IT WAS
INSTALLED.
Ensure drainage system is as
per manual and not
extended.
‘E3’ LONGER HEATING TIME – NOT
REACHING REQUIRED TEMPERATURE
MALFUNCTION OF
TEMPERATURE SENSOR OR OF
HEATING ELEMENT.
CALL FOR A QUALIFIED
SERVICE TECHNICIAN.
‘E4’ OVERFILLED
TOO MUCH INLET WATER.
*NOTE * - THERE ARE
NUMEROUS CAUSES OF AN ‘E4’
MESSAGE. REFER TO
APPLIANCE USAGE SECTION
OF THIS MANUAL FOR
GUIDELINES ON HOW TO
PREVENT AN OVERFILL.
Overdosing. 3-in-1 put in
with salt and/or rinse aid in
the appliance =overdose.
Could also be a Water
Pressure problem.
‘E5’
*
SWITCH CANNOT SHUT OFF
AUTOMATICALLY – PROGRAM NOT
FINISHING ITS CYCLE.
LOW VOLTAGE OR POWER
SWITCH FAILURE.
*** NOTE – DEPENDING ON
YOUR MODEL, YOU MAY NOT
RUN INTO THIS ERROR ****
CALL FOR A QUALIFIED
SERVICE TECHNICIAN.
‘E6’ OPEN CIRCUIT THERMOSTAT. CALL FOR A QUALIFIED
SERVICE TECHNICIAN.
‘E7’ SHORT CIRCUIT THERMOSTAT. CALL FOR A QUALIFIED
SERVICE TECHNICIAN.
WARNING!
IF OVERFLOW OCCURS, TURN OFF THE MAIN WATER SUPPLY BEFORE CALLING A SERVICE
TECHNICIAN. IF THERE IS WATER IN THE BASE OF THE TANK PAN BECAUSE OF AN OVERFILL
OR SMALL LEAK, THE WATER SHOULD BE REMOVED BEFORE RESTARTING THE DISHWASHER.
INSTALLATION________
ELECTRICAL NOTES
YOU NEED AN ELECTRICAL SUPPLY OF 220-240 VOLTS ONLY, 50HZ.
17
MAKE SURE YOU HAVE A SUITABLE ELECTRICAL SUPPLY SOCKET CLOSE TO WHERE
YOU WANT TO PLACE THE DISHWASHER. FOR YOUR PERSONAL SAFETY, THE
APPLIANCE MUST BE EARTHED. THE APPLIANCE IS EQUIPPED WITH A POWER
SUPPLY CORD HAVING A 3-PIN GROUNDING PLUG. TO MINIMIZE POSSIBLE SHOCK

BAUMATIC MINI 4 dishwasher user manual 18
HAZARDS, IT MUST BE PLUGGED INTO A MATCHING 3-PIN GROUNDING TYPE
ELECTRICAL OUTLET.
IF THE MAINS PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME OR IS
REMOVED FOR ANY OTHER REASON, THEN THE CUT OFF PLUG SHOULD BE DISPOSED
OF SAFELY TO PREVENT THE HAZARD OF ELECTRIC SHOCK.
INSTALLATION INSTRUCTIONS
1. REMOVE ALL PACKING MATERIALS CAREFULLY
2. THE WATER INLET HOSE FROM THE MACHINE ENDS IN A 3/4” FEMALE CONNECTOR
(IE. - TUBE/HOLE/SOCKET OPENING). THE WATER SUPPLY SHOULD THEREFORE END
IN A SIMILAR MALE CONNECTOR (IE. – PIPE / PRONG ENDED) AND THERE SHOULD
BE A STOPCOCK CLOSE BY IN THE PIPE.
YOU SHOULD CONNECT THE STRAIGHT CONNECTOR OF THE INLET HOSE TO THE
WATER SUPPLY SECURELY. CONNECT THE OTHER END (BENT CONNECTOR) TO THE
WATER INLET VALVE AT THE BACK OF THE DISHWASHER CABINET. DO NOT OVER-
TIGHTEN OR YOU WILL DAMAGE THE THREADS.
3. PREPARE THE DRAINAGE HOSE SO IT HAS A HOOKED END. USE THE PLASTIC U-
BEND FITTING PROVIDED FOR THIS PURPOSE. THE END OF THIS SHOULD BE
DROPPED INTO A DRAINAGE STANDPIPE. THIS STANDPIPE SHOULD BE NO MORE
THAN 6” ABOVE THE BASE OF THE DISHWASHER. TO ALLOW FOR AN AIR GAP
AROUND THE END OF THE DRAIN HOSE, THE DIAMETER OF THE STANDPIPE SHOULD
BE AT LEAST 30MM. CONNECT THE OTHER END OF THE DRAIN HOSE (L-SHAPED) TO
THE DRAIN PORT CONNECTION AT THE BACK OF THE DISHWASHER CABINET (SEE
PAGE 5). TIGHTEN THE DRAIN HOSE END ON TO THE DRAIN PORT USING THE
METAL CLIP INCLUDED IN THE PACKAGE.
4. IF YOU WANT, YOU CAN CONNECT THE WATER INLET HOSE TO THE KITCHEN SINK
TAP. YOU MUST OBTAIN CORRECT FITTINGS / ADAPTORS TO MATCH THE INLET
HOSE CONNECTORS TO ENSURE A SECURE CONNECTION. HOWEVER, PERMANENT
PLUMBING IS RECOMMENDED.
18

BAUMATIC MINI 4 dishwasher user manual 19
5. IF YOU FIND A LEAK, SHUT THE WATER SUPPLY OFF IMMEDIATELY AND CHECK THE
HOSE CONNECTIONS FULLY. TIGHTEN CONNECTIONS, IF NEEDS BE.
6. IF FOR ANY REASON YOU ARE UNABLE TO STOP THE LEAK YOURSELF, PLEASE SEEK
ADVICE FROM A QUALIFIED PLUMBER.
7. THE MINIMUM HEIGHT CLEARANCE REQUIRED TO INSTALL YOUR DISHWASHER ON A
COUNTERTOP SURFACE WITH OVERHEAD CUPBOARDS IS 19” (48CM).
8. MAKE SURE THERE IS AN ELECTRICAL POWER SUPPLY WITHIN EASY REACH OF THE
MACHINE. THE POWER CORD IS 6 FEET (182.8CM) LONG.
9. THE DISHWASHER MUST BE INSTALLED ON A ‘SOLID’ LEVEL SURFACE.
10. TO LEVEL THE DISHWASHER, ADJUST THE 4 LEVEL SCREWS (FEET) UNDER THE
DISHWASHER.
WATER PRESSURE
FOR BEST OPERATING RESULTS, INCOMING WATER PRESURE SHOULD BE BETWEEN 0.5
AND 10 BAR. INCOMING WATER SUPPLY FOR THE DISHWASHER IS CONTROLLED BY A
‘PRESSURE SWITCH’ APPLICATION, SO IF THE WATER PRESSURE IN YOUR HOME IS LOW,
THE DISHWASHER WILL TAKE LONGER TO FILL WITH WATER.
WARNING: DO NOT CONNECT YOUR MINI 4 TO A HOT TAP!
FOR BEST RESULTS:
YOUR DISHWASHER CLEANS BY SPRAYING A MIXTURE OF HOT CLEAN WATER AND
DETERGENT (UNDER PRESSURE) AGAINST THE SOILED SURFACE OF DISHES. THE
WATER IS PUMPED THROUGH A ROTATING SPRAY ARM, DRAINED THROUGH A FILTER
REMOVING FOOD AND SOILED PARTICLES AND PUMPED BACK THROUGH THE SPRAY
ARM.
SOILED WATER IS PUMPED OUT AND REPLACED WITH CLEAN WATER AT THE END OF
EACH CYCLE (THE NUMBER OF TIMES DEPENDS ON THE CYCLE BEING USED). FOR BEST
CLEANING RESULTS, THE WATER TEMPERATURE MUST BE AT LEAST 130 F (55 C). TO
PREVENT DISHWASHER DAMAGE, THE TEMPERATURE OF THE INCOMING WATER SUPPLY
SHOULD NEVER EXCEED 160 F (71 C).
19
NOTE: HARD WATER CONDITIONS WILL REDUCE THE PERFORMANCE EFFECTIVENESS
AND ABILITY OF YOUR DISHWASHER. HARD WATER CONDITIONS WILL ALSO

BAUMATIC MINI 4 dishwasher user manual 20
CONTRIBUTE TO ‘LIME’ (WHITE FILM SUBSTANCE) DEPOSITS AND / OR ‘SCALING’ ON
THE STAINLESS STEEL SURFACE OF THE DISHWASHER TUB AND ‘HEATER ELEMENT’
LOCATED IN THE SUMP UNDERNEATH THE REMOVABLE FILTER SCREEN. TO ASSIST IN
MINIMIZING THESE CONDITIONS, YOU SHOULD PERIODICALLY OPERATE / RINSE THE
INSIDE OF THE DISHWASHER (EMPTY) USING 1 CUP OF VINEGAR (AT LEAST ONCE A
WEEK).
DISCONNECTING YOUR DISHWASHER
•CLOSE THE WATER SUPPLY AT THE STOPCOCK.
•DISCONNECT THE POWER SUPPLY CORD.
•DISCONNECT THE INLET HOSE ASSEMBLY FROM THE WATER SUPPLY. WHEN THE
DISHWASHER IS NOT IN USE, PLACE/STORE THE HOSE ON THE HANGER HOSE
BRACKET LOCATED ON THE REAR WALL OF THE DISHWASHER CABINET.
•APPLIANCES THAT ARE TO BE DISCARDED MUST BE MADE UNUSABLE. PULL OFF
THE PLUG, REMOVE CABLE AND MAKE THE DOOR LOCK AND LATCH USUABLE.
DISHWASHER CHARACTERISTICS
The BAUMATIC MINI 4 dishwasher model is based firmly on convenience. Apart from
having the same general workings as other household dishwashers, it has several
extra features.
Performance of
Dishwasher - Your dishwasher
has a C rated wash performance, C rated
drying performance and C rated energy
efficiency.
CCC
CLASS
20
3
PROGRA
