Baumatic BDWI660 User manual

77
BDWI66
0 60 cm Fully
integrated full height
dishwasher

2
USER MA UAL FOR YOUR BAUMATIC
BDWI660 60 cm Fully
integrated full height dishwasher
NOTE : This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance
GS 02/04/12

3
Contents
Environmental note 4
Important safety information 5 – 7
Specifications 8 – 11
Product and aperture dimensions 8
Product specifications 8 – 9
Electrical details 9
Baumatic consuma les 9
Description of the appliance 10
Control panel 11
Using your dishwasher 11 - 26
Before first use 11
Filling with dishwasher salt 11 – 12
Setting the water softener level 13
Filling with rinse aid 14
Setting the rinse aid level 15
Filling with dishwasher detergent 15 – 16
Concentrated detergent 16 – 17
Detergent ta lets 17
Loading the upper asket 17
Adjusting the upper asket 18
Folding ack the cup shelves 18
Loading the lower asket 19
Folding spikes of lower asket 20
The cutlery asket 20
Loading dishes and cutlery 21 - 22
Program table 22 - 23
Setting a wash program 23 – 24
Changing a wash program 24
Adding more dishes 24 - 25
At the end of a wash program 25
Delay start function 25 – 26
Alternative wash function 26
Saving energy using your dishwasher 27
Cleaning and maintenance 28 - 31
The filter system 28
Cleaning the filters 29
Cleaning the spray arms 30
Cleaning the control panel 30
Cleaning the door 31
Error code failure system 31 – 32
General trou leshooting 33 – 35
Installation 36 - 45
Aperture requirements 36 – 37
Installation stages 37
Preparing and connecting the furniture door 37 – 38
Adjusting the tension of the door spring 39
Connecting to the mains water supply 40
Connecting to the water outlet 40 - 41
Connecting to the power supply 41
Applying the condensation strip 42
Positioning the dishwasher 42 - 43
Levelling the appliance 43
Securing the dishwasher 44
Before first use 45
Baumatic consumables 46
Technical data 47
Contact details 48

4
E VIRO ME TAL OTE
Note : Before discarding an old appliance, switch off and
disconnect it from the power supply. Cut off and render any plug
useless. Cut the cable off directly behind the appliance to prevent
misuse. This should be undertaken by a competent person. Disable
the door lock to make sure that children cannot get stuck inside
the appliance.
oThe packaging materials that Baumatic uses are environmentally
friendly and can e recycled.
oPlease discard all packaging material with due regard for the
environment.

5
IMPORTA T SAFETY I FORMATIO
Your safety is of the utmost inmportance to Baumatic.
Please make sure that you read this instruction ooklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained in this
ooklet, please contact the Baumatic Advice Line.
General Safety
oRepairs to your appliance must only e carried out y a
Baumatic engineer or one of its authorised service agents. Any
attempt y an inexperienced person to repair the appliance,
could result in injury or damage to your dishwasher.
oIf you notice that the mains ca le is damaged. The appliance
must not be used. The same applies if you notice that the
worktop, control panel or ase area is damaged. As this could
allow access to the internal components of the machine.
oThe appliance should e turned off and isolated from the mains
supply, efore either cleaning or maintenance work is attempted.
oThe mains ca le must not e used to pull the plug out of the
electrical socket.
oThe machine should not e sprayed with water.
oThe external surface of the appliance may ecome hot whilst
your dishwasher is in use.
oIt is possi le for small animals to chew either mains ca les or
water hoses, which could cause an electric shock hazard.
Installation
oThe installation instructions contained within this user manual
should e followed.
oIt is o ligatory for the completed installation to comply with all
relevant uilding regulations and local water authority
requirements.
oBefore the first use of the appliance, you should follow the
steps listed in the “Before first use” section on page 11
and page 44 of this manual

6
oCare should e taken not to trap the power supply ca le
underneath the appliance whilst installing it.
oNo attempt should e made to alter or modify the specifications
of this appliance.
In daily use
oThis appliance is only designed to wash normal domestic
washloads. If you use your dishwasher in any other way or it is
incorrectly used, then Baumatic accepts no lia ility for any
damage that might e caused and any guarantee will e void.
oIt is recommended that the appliance is unplugged and the
water supply is turned off after the machine is used.
oThe detergents, rinse aid and salt that you place in this appliance
should e suita le for automatic dishwashers. With regards to
dosage levels, the detergent manufacturer’s recommendations
should e followed.
oSharp knives or ones with long lades are a potential safety
hazard when placed in an upright position in the cutlery asket.
We would recommend that these items are placed horizontally in
the upper asket.
oYou should not wash any items that have come into contact
with corrosive, acidic or alkaline chemicals, paint, petrol, iron or
steel de ris.
oYou should not open the door whilst the appliance is set on a
wash program. Depending on which stage that the wash
program is at, hot water could escape the machine.
oYou should not leave the door of the appliance open, unless
you are loading or unloading the dishwasher.
oYou should not stand or sit on the door when it is open.
Child Safety
oYour dishwasher should only e used y adults. You should not
allow children in the area of the machine unsupervised. You
should not let them touch the controls or play with the appliance.
oIt could e possi le for a child or pet to gain access to the
dishwasher if the door is left open. Therefore please check the
inside of the appliance efore setting it on a wash cycle.

7
oAny packaging that is removed from the machine should e kept
away from children.
oAll detergents should e kept out of children’s reach in a safe
place.
oSome water will remain inside the dishwasher when it has
completed a wash cycle. This water is not suita le for drinking
and may contain residues from the detergents that are used in
the appliance.
Declaration of conformity
This appliance complues with the following European Directives:
-73/23 dated 19/02/1973 Low Voltage Directive and su sequent
modifications.
-89/336 dated 03/05/1989 Electromagnetic Compati ility
Directive and su sequent modifications.
For future reference please record the following information which can
e found on the rating plate and the date of purchase which can e
found on your sales invoice. The rating plate of your dishwasher is
located on the right hand side of the drop down door.
Model umber …………………………………….
Serial umber …………………………………….
Date of Purchase …………………………………….

8
Specifications
Product dimensions
Height: 815 – 865 mm
Width: 598 mm
Depth: 550 mm
Aperture dimensions
Height: 820 – 870 mm
Width: 600 mm
Depth: 580 mm (MIN)
Product specifications
o14 Place settings
o6 programs: Normal
Intensive
Economy
Glass
Rapid
1 hour
o5 temperatures: 40°C, 50°C, 55°C, 60°C, 65°C
oLED display
oWater consumption (Economy program): 11l/cycle
oNoise level: 49 dB

9
oElectronic aqua stop
oDelay start function
oResidual drying
oAlternative wash function
oConcealed heating element
oSelf-cleaning stainless steel micro-filter
oAnti-leak device
oAnti-flood device
oHeight adjusta le upper asket
oCollapsi le plate racks
oAdjusta le feet
Energy efficiency details
Energy efficiency class: A++
Washing performance class: A
Drying performance class: A
Power consumption
Off mode: 0.45 W
Left on mode: 0.55 W
Electrical details
Rated voltage: 230 Vac 50 Hz
Supply connection: 13 A (dou le pole switched fused outlet
with 3 mm contact gap)

10
Description of the appliance
1) Top spray arm
2) Cutlery asket
3) Upper asket
4) Inner pipe
5) Lower asket
6) Salt container
7) Detergent dispenser
8) Cup shelf
9) Lower spray arm
10) Filter assem ly
11) Inlet pipe connector
12) Drain pipe
13) Adjuster

11
Control panel
1) LED display
2) Alternative wash utton
3) Delay start utton
4) Program utton
5) ON/OFF utton
Using your dishwasher
Before first use
oInstall the appliance as per the installation instructions contained
within this ooklet.
oFill the water softener with 1 litre of tap water and then fill with
specialist dishwasher salt. After this you should set the water
softener level.
oFill the rinse aid dispenser and then set the rinse aid dosage.
Filling with dishwasher salt
IMPORTANT: You should only use salt that is specially
designed for use in a dishwasher If any other type of
salt is used in the appliance (in particular table salt),
it will damage the water softener
oIdeally you should fill the water softener with salt, just efore
you are a out to run a wash program. This will help to clear any
salt that may have overflowed from the water softener during
the salt filling process.
oOpen the door of the dishwasher and then remove the lower
asket. The asket should e empty when you remove it.
oTurn the water softener cap anticlockwise and remove it.
oPour 1 litre of water into the water softener.

12
IMPORTANT: It is only necessary to do this when you fill
the container with salt for the first time
oPour salt into the water softener, using the funnel that is
supplied with the appliance. You should add approximately 1.5
kg of salt into the water softener.
oIt is perfectly normal for a small amount of water to come out of
the water softener, whilst you are filling it with salt. This does
not mean that the water softener is filled with the correct
amount of salt.
oRefit and fully tighten the water softener cap.
o The salt required warning light will go out
shortly after you have filled the water softener
with salt. When the salt indicator lights on the
control panel, then you should follow the filling
with dishwasher salt procedure again.
oIMPORTANT: You do not need to pour 1 litre of water into
the container when you subsequently fill the water
softener with salt

13
Setting the water softener level
It is possi le to regulate the amount of salt that the water softener will
release during a wash cycle. The water softener should e set to a
level that is appropriate for the hardness of your water (please refer to
the ta le elow).
WATER HARDNESS
° dH ° fH ° Clarke Mmol/L
Selector Salt
consumption
(gram/cycle)
Usage
(cycles/1
kg)
0-5 0-9 0-6 0-0.94 H1 0 /
6-11 10-20 7-14 1.0-2.0 H2 20 60
12-17 21-30 15-21 2.1-3.0 H3 30 50
18-22 31-40 22-28 3.1-4.0 H4 40 40
23-34 41-60 29-42 4.1-6.0 H5 50 30
35-55 61-98 43-69 6.1-9.8 H6 60 20
To alter the amount of salt that is released y the water softener, you
should:-
o Open the door and switch on the appliance using the
ON/OFF utton (5).
oPress and hold the program utton (4) for a out 5
seconds to enter the water softener setting mode. The
salt and rinse aid indicators may light in the setting
mode.
oRepeatedly press the program utton (4) to select the
appropriate option according to the hardness of your water. The
LED display will show your choice as shown in the a ove ta le.
oWhen you have made your selection, press the ON/OFF utton
(5) to exit the setting mode.
oIMPORTANT: If you are using 3 in 1 dishwasher tablets and live
in a medium or hard water area, then you should still fill the
water softener with salt. The water softener level should be set
accordingly.

14
Filling with rinse aid
The rinse aid is released during the final rinse and it helps
to prevent water from forming droplets on your dishes.
These droplets will lead to spots and streaks eing left on
items after the wash program has completed.
oYour dishwasher is designed to utilise liquid rinse aid.
oThe rinse aid dispenser is located inside the drop down door,
next to the detergent dispenser.
oTo access the rinse aid dispenser, you should turn the cap
anticlockwise and it will pop out of the hole. Then slowly pour in
liquid rinse aid, the rinse aid dispenser will hold approximately
110 ml of rinse aid.
oBe careful not to overfill the dispenser, as this could cause
oversudsing when a wash program is selected. Wipe away any
rinse aid excess or spillages with a damp cloth.
oReplace the cap and turn it clockwise until it locks into position.
o You should refill the rinse aid dispenser when the
rinse aid indicator lights on the control panel.
oIMPORTANT: If you are using 3 in 1 dishwasher tablets then
you should still fill the rinse aid dispenser.

15
Setting the rinse aid level
The amount of rinse aid that the dishwasher requires also depends on
the hardness of your water. You should experiment with the rinse aid
setting, until you find a level that gives the est results.
oOn the first wash cycle, we would recommend that the rinse aid
level is set to num er 4.
oIf you get water spots and poor drying performance, then you
should turn the arrow anticlockwise and increase the setting to
the next num er.
oYou should continue to adjust the rinse aid level upwards until
you get no water spots.
oIf you get cloudiness or streaking on your dishes, the rinse aid
level is set too high and it is causing foaming during the wash
cycle. Turn the arrow clockwise and lower the setting to the next
num er.
Filling with dishwasher detergent
oThe detergent dispenser must e refilled at the start of each
wash cycle.
oYour dishwasher uses less detergent and rinse aid than a
conventional dishwasher.
oIn general, only one ta lespoon of detergent is needed for a
normal wash load. More heavily soiled items may need more
detergent.
oAlways add the detergent just efore starting the wash program,
otherwise the detergent could get damp and not dissolve
properly.

16
oOpen the lid that closes over the detergent dispenser y pushing
the release utton. The lid will spring open. Place the detergent
inside of the dispenser.
oThe section marked A in the diagram is for the main wash cycle
detergent. Only one detergent ta let should e placed in the
dispenser at any one time. If you are using detergent powder or
liquid, you should follow the detergent manufacturer’s
recommendations.
oThe section marked B in the diagram can have separate
detergent placed in it for any wash cycle that has a pre-wash
element to it, however this is optional. This must e a liquid or
powder detergent, not another detergent ta let.
oShut the detergent dispenser lid and press it until it locks into
place.
oAt the eginning of a wash cycle the clip will open and the
ta let/powder/liquid will enter the dishwasher.
Concentrated detergent
oThe use of the NORMAL program with concentrated detergents
reduces pollution and is good for your dishes.

17
oThis wash program is specifically suited to the dirt-dissolving
properties of the enzymes of concentrated detergent. For this
reason, the NORMAL program, in which concentrated detergent
is used, can achieve the same results achieved in the INTENSIVE
program.
Detergent tablets
oDifferent rands of detergent ta lets dissolve at different speeds.
For this reason, some detergent ta lets cannot dissolve and
develop their full cleaning power during short programs.
oIt is recommended that you use longer programs when using
detergent ta lets to ensure the complete removal of detergent
residues.
Loading the upper basket
The upper basket is most suited to washing delicate and light
dishware, such as glasses, coffee & tea cups, saucers, plates, bowls
and shallow pans (that are not heavily soiled .
1. Cups
2. Saucers
3. Glasses
4. Large serving owl
oYou should position the dishes and cookware in such a way that
they are not moved y the spray of water during the wash cycle.
oUse the diagram a ove as a guide to the most appropriate way
to load the upper asket.
IMPORTANT: Care should be taken when placing long stemmed
glassware, such as champagne glasses in the upper basket. If they are
not positioned correctly, then there is a risk that they may topple over
when the upper basket is pushed in or pulled out.

18
Adjusting the upper basket
Your dishwasher has an adjustable upper basket which you can alter to
the most suitable position for the items you are going to wash in the
upper and lower baskets.
oThe height of the upper asket can e adjusted y placing the
wheels on a different height of the rails. Long items such as
cutlery, salad servers and knives should e placed on the shelf
so they do not o struct the rotation of the spray arms.
oIMPORTANT: The upper basket must be empty when you are
removing it from the guide supports.
Folding back the cup shelves
For easier stacking of pots and pans the cup shelf spikes can be folded
down as shown in the diagram below.
IMPORTANT: Care should be taken to make sure that the spray
arms can move freely when items have been loaded into the
baskets

19
Loading the lower basket
The lower basket is most suited to washing larger and more heavily
soiled items, such as saucepans, saucepan lids and serving dishes. You
can also load bowls and a variety of plates into the lower basket.
oSaucepans and serving owls must always e placed with their
ases upwards.
oDeep saucepans should e slanted, to allow water to run off.
5. Medium serving owl
6. Small serving owl
7. Dessert dishes
8. Dinner plates
9. Soup plates
10. Oval platter

20
Folding spikes of lower basket
oThe ottom rack has prongs that can e
folded downwards, to allow for easier
loading of larger saucepans and serving
owls.
The cutlery basket
Cutlery should be placed inside of the cutlery basket, separately from
each other. You should take care to ensure that cutlery items do not
touch as this may result in a poor wash performance.
1. Soup spoons
2. Forks
3. Knives
4. Teaspoons
5. Dessert spoons
6. Serving spoons
7. Serving forks
8. Gravy ladles
