Baumatic BTM30SS User manual

BTM30SS Microwave oven

1
User Instruction Manual for your
BTM30SS MICROWAVE
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USING
YOUR MICROWAVE OVEN. IF YOU FOLLOW THE INSTRUCTIONS, YOUR
OVEN WILL GIVE YOU MANY YEARS OF GOOD, SAFE SERVICE. PLEASE
KEEP THIS MANUAL SAFELY FOR FUTURE REFERENCE.
* NOTE: This manual is designed to be used either as a whole
or to be used for quick set-up so you can get using your
appliance as soon as possible.
For the
Q
QU UI IC CK KF FI IR RE E V VE ER RS SI IO ON N O OF F T TH HI IS S M MA AN NU UA AL L, ,
y
yo ou u c ca an n G GO O D DI IR RE EC CT TL LY Y T TO O P PA AG GE E 1 17 7. Please also
quickly see the IMPORTANT PAGES. They are marked in
bold on the next page. 11/07/07
!>>>
QUICKFIRE! >>>>>>

2
Specifications………..…………….……………………………….……3
Safety Information ……..…………….…….…..…4-5
Environmental Note ……………………………………….………..5
Avoiding Exposure to Microwave Energy……….6
Never Use Your Microwave Oven to: ..…..…..…7
Your Baumatic Microwave Oven ...…….…………8
Placing your Microwave Oven ………….……….…9
Installing your Microwave Oven ……….….10-13
Before you Start Cooking with
your Microwave….…………………………..……14-15
Materials that you CAN use in your Microwave………16
Materials that you CAN’T use
in your Microwave .…………….…………….….17
Setting your Microwave’s Clock …………..………..………18
Notes on Microwaving Food ……………………………...….19
Using your Microwave Oven ……………...…20-33
Child Lock Function…………………………..………34
Cleaning ..……..……………………………………………………..…35
Troubleshooting …………………………………36-39
Conditions of Guarantee ……………………………………….40
Contact Details……………….………………………………………41
C Co on nt te en nt ts s

3
230V~50Hz, 1400W (Microwave)
230V, 1400W (Convection)
Power Consumption:
230V, 1200W (Heater)
Rated Microwave Power
Output: 900W
Operation Frequency: 2450MHz
Outside Dimensions: 305mm(H)×525mm(W)×478mm(
D)
Oven Cavity Dimensions: 219mm(H)×350mm(W)×384mm(
D)
Oven Capacity: 30Litres
Cooking Uniformity: Turntable System{Φ314mm}
Net Weight: Approx. 22kg
Your Baumatic BTM30SS Microwave has:
97 Functions
1. Baked Potato; 2. Beverage; 3. Popcorn; 4. Reheat; 5. Pizza; 6.
Meat Skewers; 7. Cake
9LED full programmer
911 Power levels
9Pushbutton control operation
9Child Safety Lock
9Stainless Steel Exterior & Cavity
Optional Extra:
BMK3SS - Stainless Steel building-in kit.
Specifications

4
PLEASE READ BEFORE USING!
(To reduce the risk of fire, electric shock, injury or exposure
to Mircowave energy)
ELECTRICAL SAFETY
•NOTE - This appliance must be grounded. In the event of a
malfunction or breakdown, grounding will reduce the risk of electric
shock by providing a path of least resistance of electrical current. You
will be able to tell if it is because a non-grounded appliance will give
off an electrical discharge. Your Microwave’s plug must have a
grounding pin and if you use an extension cord, this must have a 3-pin
inlet/outlet as well as carry the same rating or greater than your
microwave. Only connect to a properly grounded outlet.
•Manufacturer declines all responsibility for any damage due to non-
grounding of appliance.
•DURING THE GUARANTEE PERIOD ONLY BAUMATIC SERVICE ENGINEERS OR
AN AUTHORISED AGENT OF BAUMATIC SHOULD CARRY OUT REPAIRS ON
THIS UNIT. THEREAFTER, IT SHOULD BE SERVICED ONLY BY QUALIFIED
TECHNICIANS.
•DO NOT USE IF THE SUPPLY CORD IS DAMAGED OR IF IT HAS BEEN
IMMERSED IN WATER.
•DO NOT USE IF THE OVEN HAS BEEN DAMAGED OR DROPPED.
•KEEP CORD AWAY FROM HEAT SOURCES.
•DON’T LET THE CORD HANG OVER THE EDGE OF TABLE.
•DO NOT USE YOUR MICROWAVE OUTDOORS OR NEAR A KITCHEN SINK,
SWIMMING POOL, IN A WET BASEMENT OR ANYWHERE CLOSE TO A SOURCE
OF WATER.
•NEVER TRY TO DISASSEMBLE OR REPAIR YOUR MICROWAVE – IT RETAINS A
HIGH POWER VOLTAGE CHARGE EVEN WHEN UNPLUGGED!
Safet
y
Information

5
GENERAL SAFETY
•READ AND FOLLOW THE
“PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY”
(Page 6).
•AS WITH MOST COOKING
APPLIANCES, CLOSE SUPERVISION
IS NEEDED TO REDUCE THE RISK
OF FIRE IN YOUR MICROWAVE
OVEN.
•SHOULD A FIRE START:
1) KEEP THE OVEN DOOR
CLOSED.
2) TURN THE OVEN OFF &
UNPLUG THE APPLIANCE.
3) DISCONNECT THE POWER
AT THE FUSE OR CIRCUIT
BREAKER PANEL.
•ONLY EVER USE YOUR MICROWAVE
FOR ITS INTENDED USE
(HEATING FOODS) AND NEVER
FOR INDUSTRIAL OR
LABORATORY PURPOSES.
•COOKING UTENSILS & DISHES WILL
BE HOT WHEN YOU TAKE THEM
OUT AFTER COOKING –
HANDLE WITH CARE!
•NEVER USE CORROSIVE CHEMICALS
OR VAPOURS IN YOUR
MICROWAVE. WHEN YOU
CLEAN THE DOOR AND OVEN
SURFACES, USE ONLY MILD,
NONABRAISIVE SOAPS OR
DETERGENTS APPLIED WITH A
SPONGE OR SOFT CLOTH.
•DO NOT COVER OR BLOCK ANY
VENTS ON THE OVEN.
•ONLY PLACE YOUR OVEN ON A FLAT,
LEVEL SURFACE.
•DON’T LET CHILDREN PLAY WITH
YOUR MICROWAVE.
•MAKE SURE YOU READ THE SECTION
ON INSTALLING YOUR
MICROWAVE PROPERLY (Pages
9-10).
•MAKE SURE YOU READ THE SECTION
ON COOKING FOODS IN YOUR
OVEN. THERE ARE SOME ITEMS
WHICH SHOULD NOT BE
HEATED IN YOUR MICROWAVE.
(Page 14) AND THINGS YOU
MUST NEVER USE YOUR
MICROWAVE FOR (Page 7).
________________________________
CONFORMITY TO W.E.E.E. DIRECTIVE
Safet
y
Information / Environmental Note

6
AVOIDING POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
IMPORTANT NOTES ABOUT MICROWAVE ENERGY – READING THESE PRECAUTIONS
WILL HELP YOU TO AVOID POSSIBLE EXPOSURE TO MICROWAVE ENERGY
¾NEVER ATTEMPT TO
USE YOUR OVEN
WITH THE DOOR
OPEN. THE DOOR
MUST BE FULLY
CLOSED EVERY
TIME YOU
OPERATE YOUR
OVEN OTHERWISE
YOU RISK
EXPOSING
YOURSELF AND
OTHERS TO
HARMFUL
MICROWAVE
ENERGY.
¾YOUR MICROWAVE IS
FITTED WITH
SAFETY
INTERLOCKS. IT
IS VERY
IMPORTANT THAT
THESE ARE NEVER
TAMPERED WITH!
¾DO NOT PLACE ANY
OBJECT BETWEEN
THE OVEN’S DOOR
AND THE
DOORWAY (FRONT
FACE). NEVER
ALLOW DIRT,
FOOD OR CLEANER
RESIDUE TO
ACCUMULATE ON
THE SEALING
SURFACES
BETWEEN THE
INSIDE OF THE
DOOR AND THE
PART OF THE
DOORWAY WHERE
IT MEETS.
¾YOUR MICROWAVE
HAS SEVERAL
BUILT-IN
SAFETY
SWITCHES TO
ENSURE THE
POWER
REMAINS OFF
WHEN THE
DOOR IS OPEN.
NEVER TAMPER
WITH THESE
SWITCHES.
¾NEVER TRY TO
OPERATE A
DAMAGED
MICROWAVE
OVEN.
APART FROM
MAKING
SURE THAT
THE OVEN
DOOR CAN
CLOSE
PROPERLY,
YOU NEED TO
ALSO CHECK
THAT THERE
IS NO
DAMAGE TO
THE:
1) DOOR (EG.
DENTED)
2) HINGES &
LATCHES
(BROKEN OR
LOOSENED)
3) DOOR SEALS
& SEALING
SURFACES
¾REMEMBER THAT
YOUR
MICROWAVE
OVEN
SHOULD NOT
BE ADJUSTED
OR REPAIRED
BY ANYONE
BUT A
QUALIFIED
SERVICE
TECHNICIAN.
¾NEVER USE THE
INTERIOR OF
YOUR
MICROWAVE
OVEN FOR
STORAGE
PURPOSES.
NEVER STORE
COMBUSTIBLE
ITEMS SUCH AS
BREAD,
COOKIES,
PAPER
PRODUCTS, ETC.
INSIDE THE
OVEN TO
FACILITATE
COOKING.
ACCIDENTAL
OPERATION CAN
CAUSE THESE
ITEMS TO GO
ON FIRE AND
DO DAMAGE TO
YOUR
MICROWAVE,
THEREBY
PUTTING YOU
AT RISK IF YOU
USE IT WHILE
IT IS DAMAGED.
Avoidin
g
Ex
p
osure to Microwave Ener
gy

7
A note on the type of energy used
by your Microwave Oven
Microwaves are electromagnetic waves that transmit energy. When cooking, the
microwave energy penetrates food to a depth of 4cm (1½ inches), causing its
molecules to vibrate. The heat produced by this friction enables food to be
heated, cooked or defrosted.
How quickly a microwave oven cooks will depend on the size, quality and shape of
the food being cooked. Microwave cooking is healthy in that, without the need
for large amounts of cooking liquid, it means that food retains vitamins,
nutrients, aromas and flavour.
Microwave Ovens are also more energy efficient than conventional cooking
because they use up to 70% less energy.
______________________
Never use your Microwave
Oven to:
:Dry clothes or fabrics
:Dry or warm up pets or live animals
:Warm or heat any item other than food and the
appropriate utensil
:Cook sealed containers
:Cook items where you have placed a liquid or mercury
thermometer (eg. Inside roasts or turkeys)
:Heat large quantities of cooking oil (fondue or deep
frying) or drinks with high alcohol contents
Never Use Your Microwave to:

8
1) Door Safety Lock System
2) Oven Window
3) Oven Air Vent
4) Shaft
5) Roller Ring
6) Glass Tray
7) Control Panel
8) Grill Heater
9) Baking Plate
Your Baumatic Microwave Oven

9
o
ONCE YOU ARE SURE THAT YOUR OVEN IS NOT DAMAGED (EG. DENTS OR A BROKEN
DOOR) AND THAT THERE ARE NO PACKING MATERIALS AND ACCESSORIES INSIDE IT, YOU
CAN THEN INSTALL IT ON A FLAT SURFACE SUCH AS A COUNTERTOP. BE SURE THAT THE
SURFACE CAN HOLD AT LEAST YOUR MICROWAVE’S WEIGHT (22 kg).
oBEFORE PLACING ON YOUR COUNTERTOP: REMOVE ANY PROTECTIVE FILM ON THE CABINET
SURFACE.
oBUT DO NOT REMOVE THE LIGHT BROWN MICA COVER THAT IS SCREWED TO THE OVEN CAVITY TO
PROTECT THE MAGNETRON.
oFIND A LEVEL SURFACE THAT PROVIDES ENOUGH OPEN SPACE FOR THE INTAKE AND
OUTLET VENTS.
o
oYOU NEED TO LEAVE A MINIMUM OF 3.0 INCHES (7.5 CM) BETWEEN THE OVEN AND ANY
ADJACENT WALL. ONE SIDE MUST BE LEFT OPEN FOR PROPER AIR FLOW.
oLEAVE A MINIMUM CLEARANCE OF 1¼ INCHES (3.0CM) ABOVE THE OVEN.
oDO NOT REMOVE THE LEGS FROM THE BOTTOM OF THE OVEN.
oDON’T LET ANYTHING BLOCK EITHER THE INTAKE OR THE OUTLET OPENINGS AS THIS
CAN DAMAGE THE OVEN.
oPLACE YOUR MICROWAVE OVEN AS FAR AWAY AS POSSIBLE FROM RADIOS AND TELEVISIONS -
YOUR OVEN MAY CAUSE SIGNAL INTERFERENCE.
o
UNLESS YOU ARE INSTALLING YOUR MICROWAVE IN ACCORDANCE WITH THE
INSTALLATION INSTRUCTIONS ON PAGE 10. DO NOT PUT YOUR OVEN ON TOP OF
ANY OTHER HEAT-PRODUCING APPLIANCE OR A RANGE COOKTOP.
DOING SO
COULD DAMAGE YOUR OVEN AND MAKE THE WARRANTY VOID.
Placin
g
Your Microwave Oven
NOTE:
For in-unit
installation,
please see
next page.

10

11

Built under installation for your microwave.
IMPORTANT: NO OTHER METHODS OF BUILDING UNDER THE
MICROWAVE ARE SANCTIONED BY BAUMATIC.
12

Built under installation for your microwave.
It is possible to build your microwave under a worktop;
however the following installation MUST be followed:-
1. The rear wall of the housing unit MUST be removed to allow
there to be the correct amount of ventilation.
2. The ventilation gaps below the support shelf and below the
worktop MUST be adhered to.
3. The appropriate Baumatic Microwave Building In Kit MUST be
fitted.
4. An induction hob MUST NOT be fitted above the microwave.
5. It is not necessary for there to be a storage drawer fitted
underneath the microwave; this is shown purely as an example
in the drawing on the preceding page.
6. WARNING: The microwave will get hot during operation;
care should be taken not to accidentally come into contact
with the outer surface.
7. WARNING: Children should not be allowed near to the
appliance unsupervised.
13

14
PLEASE REMEMBER: NOT ALL FOODS AND UTENSILS ARE SUITABLE for use in
MICROWAVE OVENS. Always check before putting a utensil in your oven.
FOODS THAT MUST NEVER BE MICROWAVED:
¾Eggs in their shell or whole
hard-boiled eggs since
they may explode,
even after your
Microwave has
stopped heating them.
¾Foods that need deep-
frying: your
Microwave cannot
deep-fry and is
liable to present a
fire hazard if you
attempt to deep fry
with it.
¾Foods that you intend to can
at home. There is no
way of ensuring that
foods intended for
home canning have
reached the required
boiling temperature.
¾Narrow-necked
containers like
syrup bottles – the
neck could explode.
¾Never use your
Microwave when it is
empty. This is a fire
hazard.
¾Sealed liquids and food
containers – these will
almost certainly
explode – NEVER
PLACE THEM IN YOUR
MICROWAVE!
_______________________
And please be careful with …
Heating liquids and drinks: when you heat liquid using a
Microwave, part of the liquid can exceed boiling point. Its surface
tension is such that it will be susceptible to upward surges. To avoid
the risk of being scalded, always handle bowls and cups of heated
liquid steadily and carefully. PLEASE SEE NEXT PAGE FOR FURTHER
ADVICE TO AVOID SCALDING!
Before
y
ou Start Cookin
g
with Your Microwave

15
You can reduce the chances of this happening further by
1. Avoiding using straight-sided containers with narrow necks.
2. Not overheating.
3. Stirring the liquid before placing the container in the oven and
again halfway through the heating time.
4. After heating, allow to stand in the oven for a short time, stirring
again before carefully removing the container, using a
cloth or oven glove.
ÂLikewise, if you are heating feeding bottles and baby food jars always
stir or shake them and then check the temperature before
you serve them, to avoid burns. Remember that babies
can be easily scalded!
ÂIf you are cooking bacon, do not place it directly on the
turntable as excessive heating may make the
turntable likely to break.
ÂBagged Popcorn – always read the manufacturer’s guidelines before
Microwaving bagged popcorn.
ÂAlways pierce foods with non-porous skins to reduce the risk of
them bursting from inside steam build-up; eg: apples,
potatoes, chicken livers and egg yolks.
ÂBe sure to make checks on your food during operation to avoid
burning and excessive cooking.
ÂAlways be careful when opening partially sealed containers –
there is the risk of steam escaping.
TO TEST WHETHER YOUR UTENSIL IS
MICROWAVE SAFE, YOU CAN CONDUCT
THE FOLLOWING TEST:
1. Fill a microwave-safe container with 1 cup of cold water
(250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute (no longer than
this).
3. Carefully feel the utensil; if it is warm, do NOT use it for
microwave cooking.
Before
y
ou Start Cookin
g
with Your Microwave

16
Materials that you CAN use in your microwave:
Utensil Remarks
Browning dish
Follow manufacturer’s instructions. The bottom of the
browning dish must be at least 3/16ths inch (5mm) above
the turntable. Incorrect usage may cause the turntable
to break.
Dinnerware Microwave-safe only. Follow the manufacturer’s
instructions. Do not use cracked or chipped dishes.
Glass jars Always remove lid. Use only to warm food. Most glass
jars are not heat resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is
no metallic trim. Do not use cracked or chipped dishes.
Oven cooking
bags
Follow manufacturer’s instructions. Do not close with
metal ties. Make slits to let steam escape.
Paper Towels Use to cover food for reheating and absorbing fat. Use
with supervision for short-term cooking only.
Paper Plates and
Cups
Use for short-term cooking/warming only. Do not leave
oven unattended while cooking.
Parchment Use as a cover to prevent splattering or a wrap for
steaming.
Plastic
Microwave-safe only. Follow the manufacturer’s
instructions. Should be labelled ‘Microwave Safe’. Some
plastic containers soften as the food inside gets hot.
‘Boiling bags’ and tightly closed plastic bags should be
slit, pierced or vented as directed by the package.
Plastic Wrap /
Cling Film
Microwave-safe only. Use to cover food during cooking
to retain moisture. Do not allow plastic wrap to touch
food.
Thermometers Microwave-safe only (meat & candy thermometers).
Wax Paper Use as a cover to prevent splattering and to retain
moisture.
Materials that
y
ou CAN use in
y
our Microwave

17
Materials that you CAN’T use in your Microwave:
Utensil Remark
Aluminium trays
& foil
May cause arcing. Transfer food into microwave-
safe dish.
Food carton with
metal handles
May cause arcing. Transfer food into microwave-
safe dish.
Metal / metal-
trimmed utensils
Metal shields the food from microwave energy.
Metal trim may also cause arcing.
Metal twist ties May cause arcing & could cause a fire in the oven.
Paper bags May cause a fire in the oven. Always be careful
with paper.
Plastic foam Plastic foam may melt or contaminate the liquid
inside when exposed to high temperatures.
Wood Wood will dry out and may split or crack when
used in your Microwave.
Remember -
You can always check the
packaging of utensils to confirm their
microwave suitability.
”If in doubt, leave it out!”
Materials that
y
ou CAN’T use in
y
our Microwave

18
Before you start using your Microwave, you may want to set the time on the
Clock and Preset times for cooking.
9Each time you press a button, a ‘beep’ will sound.
9Note that this is a 12 hour clock (1:00 – 12:59). It will read 1:00
when the oven is plugged in.
1. Clock setting – For example; to set time as ‘8:30’
1) Press the ‘CLOCK / TIMER’ button.
2) Turn the ‘TIME / MENU’ dial clockwise until the correct hour
is displayed (In this case: ‘8’).
3) Press the ‘CLOCK / TIMER’ button.
4) Turn the ‘TIME / MENU’ dial clockwise until the correct
minute is displayed (In this case: ‘30’).
5) Press the ‘CLOCK / TIMER’ button to set the time. It will
now read ‘8:30’.
To use the timer:
Press the timer feature, holding it down for at least 1 ½ seconds.
Turn the TIME / MENU dial to set a count down time of up to 95
minutes.
Settin
g
y
our Microwave’s Clock

19
oWhenever possible, always cook
food covered (but not
sealed!). Only pastry dishes
with crust should be cooked
without a cover.
oThere are several types of
covering suitable for
microwave use. Plastic film
or glass lids must always be
checked to ensure they can
be used for microwaving.
oPaper towels, napkins & wax
paper are useful loose covers
that can prevent ‘spitting’
and keep moisture in your
food.
oIf you can’t find cooking details
for a specific quantity of
food, base the cooking time
needed on a similar type of
food. You should adjust the
cooking time accordingly.
* Double quantity = almost
double time: half quantity =
about half the time.
oRemember that refrigerated
food will need longer
cooking times.
Frozen food
will require even more time
to cook.
oArrange food carefully. Always
place thickest areas towards
the outside of the dish.
oWatch the cooking time. Cook
for the shortest amount of
time indicated and only cook
for longer if needed after
checking your food.
Remember that severely
overcooked food can smoke
or ignite.
oTurn foods over once during
microwaving to speed
cooking of such foods as
chicken and hamburgers.
Turn large items like roasts
at least once.
oRearrange foods such as
meatballs halfway through
cooking, both from top to
bottom and from the centre
of the dish to the outside.
oSome soft vegetables (eg.
cauliflower, carrots, peas)
should be cooked with a
little water. However,
mushrooms, tomatoes and
peppers should be cooked
without water. Try to cut
larger vegetables into even-
sized pieces. Always cook
vegetables in a covered
container and stir them from
time to time.
oCook fatty pieces of meat (eg,
pork, poultry) on a non
metallic grid or upside-down
saucer inside a suitable
container. This will allow
the fat to drain away. Cook
leaner types of meat on a
browning skillet. Be sure to
turn once during the cooking
time.
oReady meals – always make
sure that these are marked
as being suitable for
microwaving. Follow the
instructions as printed on
the container such as
removing the foil lid or
pricking the plastic film.
Remember that you will need to
allow for standing time after you
take your food from your
Microwave Oven. Denser foods
will take longer to stand to cool
properly.
Notes on Microwavin
g
Food
