Baxi Fires Division 939 Assembly instructions

5116231/02
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.
Model 939
OPEN DECORATIVE GAS FIRE
(GC No. 32-032-54)
We trust that this guide gives
sufficient details to enable this
appliance to be installed and
maintained satisfactorily. However, if
further information is required, our
Baxi Fires Division Technical
Helpline will be pleased to help.
Telephone [phone] (National
call rates apply in the United
Kingdom)
In the Republic of Ireland
Telephone [phone].
THIS APPLIANCE IS FOR USE WITH
NATURAL GAS (G20).
WHEN CONVERTED USING
CONVERSION KIT NO. 0595211
THIS
APPLIANCE IS FOR USE WITH
PROPANE GAS (G31).
THIS APPLIANCE IS SUITABLE ONLY
FOR INSTALLATION IN THE UNITED
KINGDOM (GB) AND THE REPUBLIC
OF IRELAND (IE).
INSTALLER: Please leave this guide with the
owner

© Baxi Heating U.K. Limited 2006.
All rights reserved. No part of this publication may be reproduced in any material form
(including photocopying), stored in any medium by electronic means (including in any
retrieval system or database) or transmitted, in any form or by any means, whether
electronic, mechanical, recording or otherwise, without the prior written permission of
the copyright owner.
Applications for the copyright owner's permission to reproduce any part of this
publication should be made, giving details of the proposed use, to the following address:
The Company Secretary, Baxi Heating UK Limited, Pentagon House, Sir Frank Whittle
Road, Derby, DE21 4XA.
Warning: Any person who does any unauthorised act in relation to a copyright work
may be liable to criminal prosecution and civil claims for damages.
Baxi Fires Division, Erdington, Birmingham B24 9QP
www.firesandstoves.co.uk
Because our policy is one of constant development and improvement, details may vary slightly from those
given in this publication
Page 2
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.

Safety First.
Baxi Fires Division fires are CE Approved and designed to meet the appropriate British
Standards and Safety Marks.
Quality and Excellence.
All Baxi Fires Division fires are manufactured to the highest standards of quality and
excellence and are manufactured under a BS EN ISO 9001 quality system accepted by
the British Standards Institute.
The Highest Standards
Baxi Fires Division is a member of the Society of British Gas Industries which works to
ensure high standards of safety, quality and performance.
Careful Installation
Baxi Fires Division is a CORGI registered company. All our gas fires must be
installed by a competent CORGI Registered Installer in accordance
with our Installer Guide and should not be fitted directly on to a
carpet or floor of combustible material.
Page 3
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.

CONTENTS
Section Page
1. SAFETY 4
2. LIST OF ACCESSORIES 5
3. APPLIANCE DATA 6
4. GENERAL INSTALLATION REQUIREMENTS 7
5. UNPACKING 14
6. INSTALLATION OF APPLIANCE 15
7. BURNER AND SUPPLY PIPE INSTALLATION 17
8. FITTING THE FIREFRONT 19
9. FITTING THE CERAMIC FUEL EFFECT 20
10. FULL OPERATING CHECKS 21
11. SERVICING & PARTS REPLACEMENT 23
11.1 Checking the aeration setting of the burner. 23
11.2 To remove the complete burner unit. 24
11.3 To remove the pilot unit. 24
11.4 To remove the gas valve. 24
11.5 To remove the piezo generator. 25
11.6 To grease the control tap. 25
11.7 To replace the burner. 25
11.8 To remove the main burner injector. 26
1. SAFETY
Installer
Before continuing any further with the installation of this appliance please read
the following guide to manual handling:
!
The lifting weight of this appliance (DGF burner) is 2 kg. One person should be
sufficient to lift the fire. If for any reason this weight is considered too heavy then
obtain assistance.
!
When lifting always keep your back straight. Bend your legs and not your back.
!Avoid twisting at the waist. It is better to reposition your feet.
!Avoid upper body/top heavy bending. Do not lean forward or sideways whilst
handling the fire.
!
Always grip with the palm of the hand. Do not use the tips of fingers for support.
!Always keep the fire as close to the body as possible. This will minimise the
cantilever action.
!Use gloves to provide additional grip.
!Always use assistance if required.
Page 4
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.

2. LIST OF ACCESSORIES
Valor and B&Q models
Description Part Number
All Models
LPG Conversion kit 0595211
‘Quattro’ / ‘Anthem’, ‘Majestic’ and Models not supplied with a firefront
Replacement Chair brick 0552311
Replacement Chair brick Trims
! Flat Brass effect 0552321
! Flat Satin Chrome effect 0552331
! Flat Black 0552341
‘Azure’ Model
Replacement Chair brick 0552301
Wonderfire models
Wonderfire ‘Gasflame 3 Convector box’ and 16inch Wonderfire Models
Replacement Chair brick 0552311
Replacement Chair brick Trims
! Flat Brass effect 0552321
! Flat Satin Chrome effect 0552331
! Flat Black 0552341
Aspire trims with firefronts
! Satin Chrome effect 9820111
! Brass effect 9820112
! Black 9820113
! Copper effect 9820114
Bauhaus Firefront (16 inch Fret)
! Polished Brass effect 9800121
! Satin Chrome effect 9800122
! Charcoal Black 9800123
Page 5
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.

Description Part Number
Blenheim Firefront (16 inch Fret)
! Brass effect 9800040
! Antique (Black & Brass effect) 9800075
! Chrome effect 9800076
! Black Cast Iron with Brass Finials 9800039
Blenheim Firefront (18 inch Fret)
! Brass effect 9800082
! Antique (Black & Brass effect) 9800083
! Chrome effect 9800084
! Black Cast Iron with Brass Finials 9800081
3. APPLIANCE DATA
This product uses fuel effect pieces containing Refractory Ceramic Fibres (RCF),
which are man-made vitreous silicate fibres. Excessive exposure to these materials
may cause irritation to eyes, skin and respiratory tract. Consequently, it is
important to take care when handling these articles to ensure that the release of
dust is kept to a minimum. To ensure that the release of fibres from these RCF
articles is kept to a minimum, during installation and servicing we recommend that
you use a HEPA filtered vacuum to remove any dust and soot accumulated in and
around the fire before and after working on the fire. When replacing these articles
we recommend that the replaced items are not broken up, but are sealed within a
heavy duty polythene bag, clearly labelled as RCF waste. RCF waste is classed as a
stable, non-reactive hazardous waste and may be disposed at a landfill licensed to
accept such waste. Protective clothing is not required when handling these articles,
but we recommend you follow the normal hygiene rules of not smoking, eating or
drinking in the work area and always wash your hands before eating or
drinking.This appliance does not contain any component manufactured from
asbestos or asbestos related products.
This appliance does not contain any components manufactured from asbestos or
asbestos related products.
There are no specific thermal efficiency requirements appropriate to this type of
appliance as they are intended for decorative purposes only. For the purposes of SAP the
efficiency is classed as 20% for use in the Space Heating Requirements calculation, see
Table 4a of SAP.
Page 6
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.

*When converted using kit 0595211
4. GENERAL INSTALLATION REQUIREMENTS
4.1 The installation must be in accordance with these instructions.
For the user’s protection, in the United Kingdom it is the law that all gas appliances are
installed by competent persons in accordance with the current edition of the Gas Safety
(Installation and Use) Regulations. Failure to install the appliance correctly could lead
to prosecution. The Council for the Registration of Gas Installers (CORGI) requires its
members to work to recognised standards.
In the United Kingdom the installation must also be in accordance with:
All the relevant parts of local regulations.
All relevant codes of practice.
The relevant parts of the current editions of the following British Standards:-
BS 1251
BS EN 1856 Part 1 which replaces BS 4543 Part 2
BS 5440 Part 1
BS 5440 Part 2
BS 5871 Part 3
BS 6461 Part 1
BS 6891
BS 8303
Page 7
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.
Gas Natural (G20) Propane (G31) *
Inlet Pressure 20mbar 37mbar
Input - Max. (Gross) 6.85kW (23,400 Btu/h) 6.7kW (22,860 Btu/h)
Input - Min. (Gross) 2.3kW (7,850 Btu/h) 4.0kW (13,650 Btu/h)
Burner Test Pressure (Cold) 20.0 ± 1.0mbar (8.0 ± 0.4in
w.g.)
37.0 ± 1.0 mbar (14.85 ±
0.4in w.g.)
Gas Connection 8mm pipe 8mm pipe
Burner Injector Stereomatic Cat 82 - 074 Stereomatic Size 132
Pilot & Atmosphere Sensing
Device Copreci Ref. O.D.S
21500/166
Copreci Ref. O.D.S
21500/166 Fitted with RBM
180 -02 injector
Ignition Integral Piezo Spark Integral Piezo Spark
Aeration See section 11.1 Non-adjustable

In England and Wales, the current edition of the Building Regulations issued by the
Department of the Environment and the Welsh Office. In Scotland the current edition
of the Building Standards (Scotland) Regulations issued by the Scottish Executive. In
Northern Ireland, the current edition of the Building Regulations (Northern Ireland)
issued by the Department of the Environment for Northern Ireland. In the Republic of
Ireland the installation must also conform with the relevant parts of:
The current editions of:-
IS 813 “Domestic Gas Installations”
ICP3
IS327
All relevant national and local rules in force.
Where no specific instructions are given, reference should be made to the relevant
British Standard Code of Practice.
4.2
In the United Kingdom,as supplied the appliance can be installed in the following
situations: -
For installations without the Spanish basket casting.
! To a fireplace complete with surround and hearth as shown in figure 1 and
complying with BS1251.
For installations with the Spanish basket casting.
! To a fireplace complete with surround and hearth as shown in figure 2 and
complying with BS1251.
For fireplace openings having dimensions different to those shown in figure 2 refer to
Table 1 and BS 5871-Part 3 for flue sizes.
Into a fireplace that has a fireback of nominal size 400mm and conforming to BS1251.
Into a Replacement Chair Brick as below: -
! ‘Quattro’, ‘Anthem’, ‘Majestic’ and models not supplied with a firefront
Into a Baxi Fires Division Replacement Chairbrick. Part number 0552311
! ‘Azure’ model
Into a B&Q Replacement Chairbrick. Part number 0552301
Suitable flues and minimum flue sizes are as follows: -
225mm x 225mm conventional brick flue.
175mm diameter lined brick or stone flue.
200mm diameter factory made insulated flue manufactured to BS4543.
175mm diameter flue pipe. See BS6461 Part 1 for suitable materials.
The minimum effective height of the flue must be 3m.
Page 8
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.

Page 9
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.
Figure 1. Hearth and fireplace opening (See section 4.4)
Figure 2. Hearth and fireplace opening for installations using the
SPANISH BASKET CASTING ONLY (See section 4.4)

The flue must not be used for any other appliance or application.
Page 10
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.
Table 1. Flue sizing table.

Any chimney damper or restrictor should be removed. If removal is not possible, they
must be secured in the open position.
If the appliance is intended to be installed to a chimney that was previously used for
solid fuel, the flue must be swept clean prior to installation.
All flues should be inspected for soundness and freedom from blockages.
4.3 If the fireplace opening is an underfloor draught type, it must be sealed to stop
any draughts.
4.4 The appliance must be mounted behind a non-combustible hearth (N.B.
conglomerate marble hearths are considered as non-combustible). The appliance can be
fitted to a minimum class “O” – 100°C surround. The hearth material must be at least
12mm thick. The periphery of the hearth (or fender) should be at least 50mm above
floor level to discourage the placing of carpets or rugs over it (See figure 1 or 2).
The surface of the hearth must be sufficiently flat to enable the bottom of the front
surround and the bottom front cover to be aligned horizontally. Any excessive
unevenness (uneven tiles, Cotswold stone, etc.) should be rectified.
4.4.1. 'Hole-in-the-wall' Installations
For installation without the Spanish basket casting.
! It is recommended that a hearth should be installed as in figure 1.
For installation with the Spanish basket casting.
! It is recommended that a hearth should be installed as in figure 2.
For installation with and without the Spanish basket casting.
! If a hearth is not fitted or if a reduced depth hearth is fitted, the fire must be
installed so that the distance from the base of the fireplace opening in the wall to the
finished floor level is at least 75mm. Where there is no floor covering or carpet and the
floor is of a type that is likely to be covered in such a way in the future then the distance
from the base of the fireplace opening in the wall to the finished floor level should be
increased to at least 150mm.
! If the lower part of the fascia (the firefront) is free standing, the recommended
reduced hearth depth is 100mm. This is necessary to support the firefront.
!
To protect from the risk of burns and ignition of clothing a tactile separator shall be
used. The hearth detailed in section 4.4 meets the requirements for a tactile separator. If
this is not used then a 680mm long fender, kerb, horizontal bar, or other barrier, being
fixed not less than 50mm above floor level and positioned 300mm in front of the fixing
plane of the fire will meet the requirement.
The tactile separator can also take the form of a canopy, being fixed not more than
1000mm above floor level and positioned 300mm in front of and 150mm beyond the
edge of any naked flame or incandescent part of the fire bed.
Page 11
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.

4.5 If the Fireplace opening is greater than the acceptable dimensions given in this
guide, do not use the back of a fire surround or marble to reduce the opening. This may
cause cracking of the surround back or marble
4.6 The appliance must not stand on combustible materials or carpets.
4.7
The minimum height from the base of the firplace opening to the underside of any
shelf made from wood or other combustible materials is as follows: -
!For a shelf up to 150mm deep
Minimum height = 860mm.
!For a shelf deeper than 150mm
860mm + 12.5mm for every 25mm depth over 150mm
(See Graph 1).
4.8 Note that soft wall coverings (e.g. embossed vinyl, etc.) are easily affected by
heat. They may scorch or become discoloured when close to a heating appliance. Please
bear this in mind when installing.
4.9
This appliance must not be installed in any room that contains a bath or shower or
where steam is regularly present.
4.10
An extractor fan may only be used in the same room as this appliance, or in any
area from which ventilation for the appliance is taken, if it does not affect the safe
performance of the appliance. Note the spillage test requirements detailed further on in
this manual. If the fan is likely to affect the appliance, the appliance must not be
installed unless the fan is permanently disconnected.
Page 12
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.
Graph 1. Combustible shelf clearances

4.11 Normal adventitious ventilation is usually sufficient to satisfy the ventilation
requirements of this appliance. In GB
reference should be made to BS 5871 Part
2 and in IE reference should be made to
the current edition of IS 813 “Domestic
Gas Installations” which makes clear the
conditions that must be met to
demonstrate that sufficient ventilation is
available.
4.12 Propane gas appliances must not be
installed in a room that is built entirely
below ground level (see BS 5871 Part 3).
4.13 If the appliance is to be fitted
against a wall with combustible cladding,
the cladding must be removed from the
area shown in figure 3.
4.14
Combustible side projections up to 75mm forward of the fixing plane of the fire
are to be a minimum of 125mm from the fireplace opening (See figure 4)
4.14.1
Combustible side projections greater than 75mm forward of the fixing plane of
the fire are to be a minimum of 178mm from the fireplace opening (See figure 4).
4.14.2
Non-combustible side projections to be 75mm from the fireplace opening (See
figure 4)
4.15 The appliance is fitted with an A.S.D (Atmosphere sensing device). If the
appliance closes down after a period of operation for no apparent reason, the consumer
should be informed to stop using the appliance until the installation and appliance have
been thoroughly checked. The A.S.D will shut the appliance down if an unacceptable
amount of harmful products of combustion accumulate. Under no circumstances should
the A.S.D be altered or bypassed in any way. Only a genuine manufacturers replacement
part should be fitted. The individual A.S.D components are not replaceable.
4.16
A fireguard complying with BS 8423 should be fitted for the protection of young
children, the elderly, or the infirm.
Page 13
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.
Figure 3. Removal of combustible cladding

5. UNPACKING
Contents:
1Burner assembly
1Nut & olive for 8mm inlet pipe
4Screws
4Plastic screw plugs
1Fuel bed matrix support plate
2Self tapping screws
1Inlet ‘T’ connector / elbow
1Ceramic fuel effect pack.
1Burner tray trim (Not fitted to Anthem or Quattro models)
Page 14
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.
Firefront Dimension 'X' (mm) Dimension 'Y' (mm)
Azure 400 65
Quattro / Anthem 390 65
Majestic 400 50
Portland 390 60
Figure 4. Appliance dimensions (Firefront may differ from that shown)

For models supplied with a firefront
1Firefront and Cover
Carefully remove the contents. Take special care in handling the ceramic fuel effect
pieces. Check that all the listed parts are present and in good condition.
6. INSTALLATION OF APPLIANCE
INSTALLATION
6.1 Fireplace size.
The fireplace must comply with the requirements described in section 4.
6.2 Fireplace flue pull.
Visually inspect the flue for any obstruction, and that a smooth transition from the
fireplace opening into the flue is available. Close all doors and windows in the room in
which the appliance is to be installed. After confirming with a match that smoke is
drawn into the flue, light a 13 gram smoke pellet and check that there is a definite flow
through the flue. Verify outside that the smoke exits from one terminal only and that the
termination is suitable. Observe, where possible, upstairs rooms and loft spaces for signs
of escaping smoke indicating a defective flue. If there is not a definite flow warm the
flue for a few minutes and repeat the smoke pellet test. If there is still no definite flow
the flue may need remedial work –
Do not fit the appliance until there is a definite
flow through the flue.
IMPORTANT
Before continuing with the installation
of this gas fire the aeration setting on
the burner must be checked. This is
factory set. See section 11.1 (Servicing
and parts replacement).
6.3 Installation of the burner unit
6.3.1 Prior to installation of the burner the
rear ceramic support bracket must be fitted
(See figure 5). Secure with two self-tapping
screws but do not over-tighten as these will
have to be removed again when installing
the burner.
Page 15
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.
Figure 5. Fitting the rear support plate

6.3.2 Burner Tray trim.
! The trim is not to be fitted to
‘ Anthem’ or ‘Quattro’ models.
! The fire is supplied with a
burner tray trim. Fit the trim as in
figure 6.
6.3.3 Burner Positioning
! The two tags at the side of the
burner can be folded against the
side of the burner tray. This may be
required for installations where the
width of the fireplace opening is restricted or when
fitting into a ‘Spanish Basket’ casting (See figure 7).
For installations without the 'Spanish Basket'
casting.
! Place the burner unit centrally within the fireplace
opening. Position the burner to the rear of the
opening, this may be moved forward
providing the front of the burner tray trim
does not protrude beyond the front plane of
the fireplace opening by more than 33mm
(See figure 8).
For installations with the 'Spanish
Basket' casting.
! Place the casting centrally within the
fireplace opening. Position the casting to the
rear of the opening.
! Place the burner unit inside the casting.
! It is important that the burner tray trim
touches the inner front face of the casting.
This will give the customer greater access to
the control knob.
! The casting and burner may be moved
forward providing the front of the burner
tray trim does not protrude beyond the front plane of the fireplace opening by more than
33mm (See figure 8).
6.3.3 Locating the burner.
!
Mark onto the floor, the position of the two fixing holes in the front fixing bracket
Page 16
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.
Figure 8. Burner positioning
Figure 7. Burner tags
Figure 6. Burner tray trim

(See figure 9).
! Without disturbing the burner,
remove the two screws at the rear of the
burner tray (See figure 10). These secure
the rear ceramic support bracket to the
burner tray.
! Hold the ceramic support bracket in
place. Lift and remove the burner.
! The base of the rear ceramic support
bracket has two holes. Mark their
positions onto the floor.
! Drill all four marked hole positions
with a 6mm masonry drill bit.
! Insert a wooden plug into each hole.
! Unscrew the fixing bracket from the
front support leg of the burner.
! Using 4 screws secure the front fixing
bracket and ceramic support bracket to the
base of the floor.
! Locate the burner onto the rear ceramic
support bracket ensuring that the control
knob bracket sits in front of the front
support bracket. Secure the burner to the
ceramic support bracket using the two
screws removed previously. Secure the
burner to the front securing bracket using
the screw removed previously.
7. BURNER AND SUPPLY PIPE INSTALLATION
A nut and olive is provided for an 8mm-pipe inlet connection directly to the gas control.
The inlet ‘T’ connector / elbow can be rotated to allow a connection from any direction.
The inlet ‘T’ connector includes a valve for isolating the gas supply. Note that the centre
of the appliance inlet ‘T’ connector is 25mm above the fireplace floor. The inlet ‘T’
connector should be fitted to the supply pipe at this stage.
The supply pipe must be rigid material. Flexible pipe must not be used. Connect the
supply line to the appliance.
Turn on the gas supply and pressure check the installation pipework for gas soundness.
In the United Kingdom (GB) check in accordance with the current edition of BS 6891.
In the Republic of Ireland check in accordance with the current edition of IS 813
“Domestic Gas Installations”.
Page 17
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.
Figure 10. Screw removal
Figure 9. Locating the burner

7.1 Preliminary burner checks.
Some burner operations can be checked at this stage. Checking now will mean that less
disassembly will be required if any problems are found. A full check should still be
made, however, after final installation.
7.1.1 Lighting the fire
If closed,
open the isolating inlet ‘T’ connector. Depress the control knob and rotate it
anticlockwise to the pilot ignition position. A ‘click’
will be heard as the integral piezo
operates. A spark should be seen between the electrode and pilot tip. Turn the control
knob clockwise to the ‘Off’ position. Repeat this operation until a flame appears at the
pilot. There may be a delay before the pilot lights due to air being purged from the
system. When a flame appears at the pilot keep the control knob depressed and hold the
pilot ignition position for ten seconds. When the control knob is released the pilot flame
should remain lit.
7.1.2 Operating the burner.
When the pilot burner is operating properly, gradually turn the control knob anti-
clockwise to ‘HIGH’ (Depress the knob slightly to get past the pilot ignition position).
The main burner should now light. Depress the control knob slightly to release from the
‘HIGH’ position and turn back (clockwise) to ‘LOW’. While turning, the burner flames
should gradually become lower but remain alight. Depress the control knob slightly to
release from the ‘LOW’ position and turn back (clockwise) to the Pilot ignition position.
The main burner should extinguish but the pilot should remain alight. Depress the
control knob slightly and turn back (clockwise) to turn OFF.
This will extinguish the pilot.
7.1.3 Checking the inlet pressure.
The appliance is pre-set to give the correct heat input
at the inlet pressure shown in section 3 of this manual.
No adjustment is necessary.
1. Check the inlet pressure by fitting a pressure gauge
at the test point. The test point is on the inlet ‘T’
connector (See figure 11). Check the pressure with the
appliance alight and set at maximum output.
2. After checking, turn off the appliance. Remove the
pressure gauge and replace the test point sealing screw.
3. Relight the appliance. Turn to the maximum output
position and test around the sealing screw for gas
soundness with a suitable leak detection fluid.
Page 18
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.
Figure 11. Pressure test point

8. FITTING THE FIREFRONT
8.1 For models NOT supplied with a Firefront.
A slotted firefront with a minimum free area as shown in figure 12 must always be
used.
8.2 For models SUPPLIED with a firefront.
The firefront supplied with this fire has been tested and found to be satisfactory for use
with this fire. The open area may differ slightly from that shown in figure 12.
Place the decorative firefront on the hearth and central to the appliance.
‘Quattro’ / ‘Anthem’ firefront only
1. The Quattro / Anthem firefront is fitted with
a set of fixing brackets. Each bracket has two
threaded holes. As supplied the top threaded
hole should be fitted with a 25mm long
machine screw. Remove the machine screw and
locate to the threaded hole below.
2. The screw should be set at a distance of
7mm (Measured from the surface of the bracket
to the underside of the screw head). Adjust the
screw to this distance (See figure 13).
Page 19
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.
Figure 12. Firefront minimum open area requirements
Figure 13. Bracket locations

3. Locate the firefront as in figure 14. The
screw heads should locate into the slots in the
burner tray.
4. The lower 'ashpan' casting should be located
as in figure 15.
.
9. FITTING THE CERAMIC FUEL EFFECT
The installer and owner guide for the ceramic fuel effect is supplied with the ceramic
fuel effect. It is important that the fitting guide for the ceramic fuel effect be placed
inside or attached to this guide and handed to the customer following completion of the
‘Final review’ section.
Page 20
INSTALLER GUIDE
© Baxi Heating U.K. Limited 2006.
Figure 14. Hanging the firefront
Figure 15. Lower ‘ashpan’
location
