Baxi EcoBlue System 12 Manual

Installation and Service Manual
en
United Kingdom
These instructions include the Benchmark Commissioning Checklist and should be left with the
user for safe keeping. They must be read in conjunction with the Flue Installation Guide.
Gas Fired Wall Mounted Condensing System Boiler
EcoBlue System
12 - 15 - 18 - 24 - 28 - 32

2 EcoBlue System 7219708 - 01 (04/15)
You have just purchased one of our appliances and we thank you for the trust you have placed in our products. Please note that
the product will provide good service for a longer period of time if it is regularly checked and maintained. Our customer support
network is at your disposal at all times.
The Benchmark Scheme
Benchmark places responsibilities on both manufacturers and installers.
The purpose is to ensure that customers are provided with the correct
equipment for their needs, that it is installed, commissioned and
serviced in accordance with the manufacturer’s instructions by
competent persons and that it meets the requirements of the
appropriate Building Regulations. The Benchmark Checklist can be
used to demonstrate compliance with Building Regulations and should
be provided to the customer for future reference.
Installers are required to carry out installation, commissioning and
servicing work in accordance with the Benchmark Code of Practice
which is available from the Heating and Hotwater Industry Council who
manage and promote the Scheme. Visit www.centralheating.co.uk for
more information.
Building Regulations and the Benchmark Commissioning
Checklist
Building Regulations (England & Wales) require notification of the
installation of a heating appliance to the relevant Local Authority
Building Control Department. This can be achieved via a
Competent Persons Self Certification Scheme as an option to
notifying the Local Authority directly.
The Health & Safety Executive operates the ‘Gas Safe Register’, a self-
certification scheme for gas heating appliances.
This company is a member of the Benchmark initiative and fully
supports the aims of the programme. Its aim is to improve the
standards of installation and commissioning of central heating systems
in the UK and to encourage the regular servicing of all central heating
systems to ensure safety and efficiency.
Building Regulations require that installations should comply with
manufacturer's instructions. It is therefore important that the
commissioning checklist is completed by the installer. The relevant
section of Building Regulations only relates to dwellings. Therefore the
checklist only applies if the appliance is being installed in a dwelling or
some related structure.
The flowchart opposite gives guidance for installers on the process
necessary to ensure compliance with Building Regulations.
Model Range
Baxi EcoBlue 12 System ErP
G.C.No 41-070-23
Baxi EcoBlue 15 System ErP
G.C.No 41-070-24
Baxi EcoBlue 18 System ErP
G.C.No 41-070-25
Baxi EcoBlue 24 System ErP
G.C.No 41-070-26
Baxi EcoBlue 28 System ErP
G.C.No 41-070-27
Baxi EcoBlue 32 System ErP
G.C.No 41-470-28
Most illustrations in this document
show the 12/15/18/24/28 models.
Where the detail for 32 model differs
it is described in the text and see also
Section 14.1 ‘32 Model Supplement’.
