Baxton Studio 319C User manual

ASSEMBLY INSTRUCTION MODEL : 319C
Read this instruction carefully. Remove all wrapping material, staples and straps from the
carton. See hardware and furniture part list
For guidance. Be sure you have all wooden furniture parts on a clean and flat soft surface,
such as a carpet or rug, to prevent from being scratched.Follow the figure to start assembling.
CAUTION :
1. Do not FULLY - TIGHTEN the nut or screw untill all is ready to assemble.
2. Do not OVER - TIGHTEN the nut or screw to avoid causing damages to the thread.
3. Keep all hardware part out reach of children.
PART LISTNO QTY
ABACK REST
BFRONT LEG
CSIDE RAIL 2 PCS
DWOODEN SEAT WITH SCOOP 1 PC
1 PC
1 PC
5
1
4
DESRIPTIONNO QTY
1
2
3
4
5
JCBC SCREW M6 X 50MM
WOOD DOWEL Ø8 x 30MM
CSK SCREW M4 x 30MM
SPRNG WASHER M6
M4 ALLEN KEY
6 PCS
4 PCS
3 PCS
6 PCS
1 PC
COMPELETE ASSEMBLE
STEP 1
Attached C to B according to
the hole and tighten it using
hardware number 1,2,4, and 5 .
C
C
B
2
4
1
5
STEP 2
Align the whole part from STEP1
to A . Tighten the part of C and
A using hardware number 1,4
and 5 .
C
A
STEP 3
Stick D to the whole assemble
part and fully-tighten it with
hardware number 3 .
STEP 4
C
A
D
3 X 3PCS

ASSEMBLY INSTRUCTIONS
MODEL : 7008T
Read this instruction carefully, remove all wrapping material, staples and straps from the carton. See hardware and furniture part list.
For guidance. Be sure you have all wooden furniture parts on a clean and soft surface to prevent from being scratched. Follow the figure to
start assembling.
Caution:
1. Do not FULLY –TIGHTEN the nut or bolt until all nut or nut bolt is ready to assembled.
2. Do not OVER- TIGHTEN the nut or nut bolt to avoid causing damages to the thread.
3. Keep all hardware part out of reach of children.
PART LIST
No.
B
A
DESCRIPTION
TABLE TOP
TABLE LEG
QTY
1 PC
4 PCS
No.
4
3
2
1
STEP 1
HARDWARE LIST
DESCRIPTION
FLAT WASHER 6/19"
SPRING WASHER 6/13"
JCBC SCREW M6 X 70MM
M4 ALLEN KEY
QTY
8 PCS
8 PCS
8 PCS
1 PC
STEP 2
COMPLETED TABLE ASSEMBLY
