Baxton Studio LCF20202 User manual

Date last updated:08-17-2022
Sideboard

A B C D E
F G H
10 PCS 10 PCS 16 PCS 8 PCS4 PCS
24 PCS
N
4 PCS 2 PCS 4 PCS 16 PCS
2 PCS 2 PCS
L M
I J
K
4 PCS2 PC
1
2
3
4
5
6
7
8
9
10
11 11
11
11
12
13
14

Ax10
1
3
2
A
A
A
A
A
A
A
A
A
A
Insert quickfit screws (A) into parts 1, 2 and 3, as shown.
6
5
D
C
D
C
Cx2
Dx2
Attach part 6 to part 5 using wooden dowels (C) and screws (D), as shown.

Cx3
Bx3
3
5
6
B
C
B
C
B
Insert cam locks (B) and wooden dowels (C) into parts 5 and 6, as shown.
Fit parts 5 and 6 to part 3.Turn cam locks clockwise to tighten.
2
B
B
C
C
C
B
Cx3
Bx3
Insert cam locks (B) and wooden dowels (C) into parts 5 and 6, as shown.
Fit part 2 to parts 5 and 6.Turn cam locks clockwise to tighten.
5
6
3

9
2
5
3
Slide part 9 into grooves between parts 2, 5 and 3, as shown.
B
C
C
C
C
B
B
B
1
5
2
3
9
Cx4
Bx4
Insert cam locks (B) and wooden dowels (C) into parts 2 and 3, as shown.
Fit part 1 to parts 2 and 3, as shown.
Turn cam locks clockwise to tighten.

10
10
13
14
13 14
5
2
3
Insert parts 13 and 14 to part 10, as shown.
Slide parts 13 and 14 with part 10 into grooves between parts 2 and 3, as shown.
4
D
C
D
D
D
C
CC
2
3
Cx4
Dx4
Fix part 4 to assembled unit with wooden dowels (C) and screws (D), as shown.

STEP 9.
STEP 10.
Jx16
J
J
J
J
4
11
11
11
11
Fix legs 11 to part 4 using screws (J), as shown.
x4
F
G
F
H
H
IIII
78
Gx4
Hx2
Ix4
Fx8
Fix hinges (G) to doors 7 and 8 using screws (F), as shown.
Fix handles (H) to doors 7 and 8 using screws (I), as shown.

STEP 11.
STEP 12.
8
H
H
F
7
8
X4
E
E
E
E
Fx16
Ex4
Fix doors 7 and 8 to assembled unit with hinges and screws (F), as shown.
Fit shelf supports (E) into desired position in the assembled unit, as shown.
12
K
K
Kx2
Mx2
Nx2
M
N
M
N
Place shelf 12 on top of shelf supports, as shown.
Fix wall starps (N) on to part 1 using washers (M) and screws (K), as shown.
1

STEP 13.
9
D
LM
D
LM
Kx2
Mx2
Lx2
For extra stability, you must fix your Sideboard to the wall using hardwares (D, L and M), as shown.
Screws (D) are fixed through wall straps and washers (M) and into the wall plugs (L).
Should you choose not to affix the product to the wall,
serious injury may be caused if the product tips over.
