BAY SPORTS Hercules User manual

Hercules Electric
SUP pump
USER GUIDE

TABLE OF CONTENTS
WELCOME 
KEY FEATURES 
SPECIFICATIONS 
INSTRUCTIONS 
TIPS 
SAFETY PRECAUTIONS 

4
WELCOME
Thank you for purchasing Hercules - Bay Sports electric air
pump for inflatable kayak & sup. We hope you thoroughly
enjoy this product. Please take time to read the content in
this manual in order to optimise your satisfaction of this
product. We believe that a Bay Sports electric pump offers
incomparable value.
Visit our website at any time for more information.
www.baysports.com.au

5
YOUR PUMP
Bay Sports have one Electric Air pump: Hercules. And for
good reason. With so many on the market, we researched,
tested and chose this workhorse of an electric air pump. A
great alternative to using a hand pump to inflate your SUP
or Kayak, you can sit back and relax whilst it does all the
hard work getting your board ready for it’s next adventure.

6
KEY FEATURES
• Inflates your Inflatable SUP, Inflatable Kayak or Air Pontoon
up to the optimal pressure in 5-10 minutes
• Inflates from multiple sources: 12v port or your vehicles battery
using supplied Alligator Clips.
• Set and Forget - the pump will automatically switch off once
the desired pressure is reached.
• Lightweight so perfect for those who wish to travel with it.
• Capable of reaching 20psi - perfect for the larger SUPs (such as
our 11’ Mandala, 11’6 Tour, 12’6 Sprint whose optimal pressure
is 17psi) and our Inflatable Kayak range.
• Attached fittings Halkey-Roberts type fittings. Stern and Boston
currently NOT available.
Click on each word for more info

7
SPECIFICATIONS
• Power: 12V DC
• Adaper: Cigarette Lighter Plug-in
• Pump Dimensions: 16cm (H) x 29.5cm (L) x 13.5cm (W)
• Maximum Inflation Pressure: 20 PSI
• Inflate Time: 7 min to 15psi / 10 minutes to 20psi
• Deflate Time: About 5 minutes

8
INSTRUCTIONS
1. Connect car cigarette lighter plug into a DC 12V power source
or by connecting car cigarette lighter plug into an Alligator clips
battery terminal to draw power source from the car battery
(when it is clipped on).
2. To inflate: Connect one end of hose to “INFLATE” port of pump
and opposite end of hose nozzle adapter firmly into opened
valve or HR valve of product follow by pushing the UP arrow
button to the desired air pressure setting, then press the “ON”
button to begin inflation. Once the inflatable pressure reaches
the desire pressure setting from the pump, it will stop auto-
matically. (You may now detach the hose from the valve and
tightly close the valve cap). And if the desire pressure setting
is not enough and feel more air pressure needs to be added,
then please reset desire air pressure setting and repeat the
inflation process.
HR VALVE
3. To deflate: Connect one end of hose to “DEFLATE” port of pump
and opposite end of hose nozzle adapter firmly into opened
valve or HR valve of product follow by pushing the DOWN arrow
to number “1”, then press the “ON” button to begin deflation.
Once product deflation is complete, you may detach the hose
from the valve and tightly close the valve cap.

9
Note: Please do not leave the pump unattended while it is still
operating, and it must manually press the “OFF” button to stop
deflating process.
4. Anytime you wish to stop the pump while operating, you can
simply press the “OFF” button to stop and press the “ON” but-
ton to start.
5. When the pump is not in use, it is recommended to always
turn the pressure switch knob to number “0” position.
Press to select the desire reading unit then press
or to select the desire output pressure range from 1-20 PSI.
Press to start operation or to stop. This pump will stop auto-
matically when inflating pressure reaches its pressure setting value.
Anytime you wish to stop the pump you can simply press
button to stop and alternativevly press button to start again.
VISUAL INSTRUCTION GUIDE

10
TIPS
Here are our tips for best operation
1. The Vehicle should be on and running to avoid draining the
battery.
2. If using the alligator clips ensure that the sockets are pushed
in correctly to the car charger to power the pump.
3. Attach the hose securely to the pump, and rotate the Valve
Stem to the UP position on your inflatable product.
4. Push the hose down while turning clockwise until it won’t turn
any more on your inflatable product valve.
5. The pump will start making a ‘whirring’ sound while starting
inflation at low pressure, when the pressure gets near 1 PSI, the
pump will change gears and the pumping sound will change
to a loud sound. The needle will vibrate back and forth rapidly
during the second stage of pumping, this is normal behavior.
6. The inflation time can take up to 10-15 minutes to 15 PSI.
7. Once inflated, insert the valve cover to protect the valve stem
and prevent accidental deflation.
8. To begin deflation, push the valve stem and turn clockwise ¼
turn to put the valve in the open position.
9. After the air has escaped, which will create a loud noise due
to the pressure, the electric pump can be used in the deflate
function to remove any remaining air or simply roll the inflat-
able product up and push out the remaining air.
10. The pump will not cut off in the deflate mode, you will need
to manually do this.
11. Be sure to put the valve stem on the inflatable product back
to the UP position, ready for next use otherwise air will escape
when you remove the pump on next use causing it to deflate.

11
SAFETY PRECAUTIONS
IMPORTANT
1. Power supply must be 12 Volt DC.
2. This superior quality pump is specially designed to auto inflate
all popular types inflatable SUP Boards & Boats or any other
high pressure inflatable with HR valves, but not for filling tires
and continuous use
3. This pump is not designed for continuous use more than 20
minutes and extended operation can cause motor overheating
or damage the pump. (Recommend: pause 10 minutes for
cooling for every 20 minutes used.)
Caution- To reduce the risk of electric shock, do not operate under
wet conditions or expose to water. Always store in a cool dry area,
away from heat and moisture.
Caution- To prevent fuse from being blown, please do not use
cigarette lighter socket to provide power other than for the
pump own use, please make sure your protection fuse is 15 amp,
or above.
WARNINGS
1. Never attempt to disassemble or repair.
2. Do not leave children use this pump without adult supervision.
3. Never allow sand,small rocks or other articles to be sucked into
the inflating or deflation port while operating.
4. Use this unit only for its intended use as described in these
instructions. Do not use attachments not recommended by
the manufacturer.
5. Never leave the pump unattended while in use. Keep the cord
away from heated surfaces.
6. To disconnect, turn all controls to the off position, then remove
plug from outlet.
7. Do not touch the hose near ‘INFLATE‘ port while operating.
