Bayside CSC9PD-3 User manual

Date 2017-06-15 Rev. 0001-A Factory: UNVILT
9-piece Dining Set
ITM. / ART. 1158046
Model # CSC9PD-3
ASSEMBLY INSTRUCTIONS
IMPORTANT, RETAIN FOR FUTURE REFERENCE:
READ CAREFULLY
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the
store where it was purchased. Please call our toll-free customer service number and have your
instructions and parts list ready to provide the model name, part name or factory number:
1-877-494-2536 (English, French and Spanish)
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to Friday
(In U.S., Canada, and Mexico only)
Or visit our website www.baysidefurnishings.com
Or e-mail your request to [e-mail]

2
1. This product is for indoor domestic use only.
2. Please read the Assembly Instructions prior to assembling this product.
3. To avoid damage, assemble the product on a non-abrasive surface such as a carpet surface.
4. Make sure all bolts and screws are tightly fastened before the unit is used.
5. Check that all bolts and screws are tight at least every 3 months or as needed.
6. Refer to your assembly manual for maximum weight capacities.
7. Do not push furniture, especially on carpeted floor. Have someone help you lift the item and place it in its
new location.
1. Maximum load weight on chair is 136 kg / 300 lb
MAXIMUM RECOMMENDED WEIGHT LOADS
THIS UNIT IS INTENDED ONLY FOR USE WITHIN THE MAXIMUM
WEIGHTS INDICATED. USE WITH LOADS HEAVIER THAN THE MAXIMUM WEIGHTS
INDICATED MAY RESULT IN INSTABILITY
,
CAUSING POSSIBLE INJURY.
Please make sure you have all parts before beginning assembly. Do not fully tighten all bolts until you
finish assembling all parts. Once assembled, go back and fully tighten all bolts. This will make the assembly
easier. We recommend using two people for assembly.
GENERAL INFORMATION AND TIPS

3
Parts and Hardware List
PART # PART DESCRIPTION PART FIGURE QUANTITY
A Chair Backrest 2
B Seat Frame with Cushion 2
C Left Front Leg 2
D Right Front Leg 2
E Left Side Stretcher 2
F Right Side Stretcher 2

4
Parts and Hardware List
PART # PART DESCRIPTION PART FIGURE QUANTITY
AA Bolt 4+1 extra
BB Bolt 8+1 extra
CC Hex Nut 8+1 extra
DD Lock Washer 20+1 extra
EE Flat Washer
20+1 extra
FF Wood Screw 8+1 extra
Hex-key Wrench 1
Open Wrench 1
Tools required: Hex-key wrench and open wrench (included) and Phillips screwdriver (not included).

5
Assembly Instructions
1. Unpack the unit and confirm that you have all the hardware and required parts.
2. Remove the plastic caps from the hanger bolts of the front legs (C and D) for the following steps.
3. Attach one left front leg (C) to the left front corner block of the seat frame (B) by inserting the hanger
bolts through the drilled holes on the corner block and fit the flat washer (EE), lock washer (DD) and hex
nut (CC) onto each hanger bolt. Securely tighten the nuts with the provided open wrench.
NOTE: DO NOT fully tighten all the nuts until the chair has been adjusted and level all the legs so that
they do not wobble. Once adjusted then go back and tighten while making sure that the unit remains level.
4. Repeat the same procedure to attach one right front leg (D) to the right front corner block of the seat
frame (B).
5. Lay one backrest (A) on a smooth and protective surface with the threaded inserts facing up.
6. Insert the tenon of left and right side stretchers (E and F) into the mortises of the backrest (A). Make sure
the slant holes on the side stretchers will face the floor when the unit is turned upright.
7. Attach the assembled seat frame (B) to the middle rail of the backrest (A) and insert both side stretchers
(E and F) into the front legs (C and D) respectively. Insert four bolts (BB) with the washers (DD and EE)
through the drilled holes on the seat frame (B) at rear corner blocks and loosely tighten into the threaded
inserts on the backrest (A).
8. Secure the seat frame (B) to the backrest (A) by inserting two bolts (AA) with the washers (DD and EE)
into the drilled holes on the rear rail of the seat frame.
NOTE: DO NOT fully tighten the bolts.
EE
AA
DD
B
A
E/F
A
EE
BB
DD
A
E/F
C/D
E
F
C
D
B
B
EE
CC B
DD
C/D
C/D
C
D

6
Assembly Instructions
9. Position the assembled unit upside down on the carton or other support surface, as shown.
NOTE: Place a protective cover (like the bubble wrap packing material) over the carton or other support
surface to prevent from scratching.
10. Insert and screw four wood screws (FF) into the slant holes in the stretchers (E and F). Tighten the screws
with a Phillips screwdriver.
11. Stand the assembled unit upright on a flat surface. Press down the seat cushion (B) to even all legs. Now,
tightly fasten all bolts with the provided hex-key wrench.
12. Repeat the same process to assemble the other chairs.
A
E/F
FF
A/C/D
F
C
E
D
B

7
Care and Maintenance
From time to time please ensure there are no loose nuts on the product.
Use a soft, clean cloth that will not scratch the surface when dusting.
Use of furniture polish is not necessary. Should you choose to use polish, test first in an inconspicuous area.
Using solvents of any kind on your furniture may damage the finish.
Never use water to clean your furniture as it may cause damage to the finish.
Liquid spills should be removed immediately. Using a soft, clean cloth, blot the spill gently. Avoid rubbing.
In the event that your furniture is stained or otherwise damaged during use, we recommend that you call a
professional to repair your furniture.
Check bolts/screws periodically and tighten them if necessary.
Further Advice about Wood Furniture Care
It is best to keep your furniture in a climate-controlled environment. Extreme temperature and humidity
changes can cause fading, warping, shrinking and splitting of wood. It is advised to keep furniture away from
direct sunlight as sun may damage the finish.
Proper care and cleaning at home will extend the life of your purchase. Following these important and helpful
tips will enhance your furniture as it ages.
We hope you enjoy your purchase for many years.
Thank you for your purchase!
QUALITY GUARANTEE
We are confident that you will be delighted with your Bayside Furnishings
®
purchase.
Should this product be defective in workmanship or materials or fail under normal use, we will repair or
replace it for up to one (1) year from date of purchase. Every Bayside Furnishings
®
product is designed to meet
your highest expectations. We guarantee that you will immediately see the value of our fine furniture.
This warranty gives you specific legal rights and you may also have other rights which vary from State to
State or province to province.
AUSTRALIA: Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the
goods fail to be of acceptable quality and the failure does not amount to a major failure.
Customer Service: 1-877-494-2536 (English, French and Spanish)
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to Friday
(In U.S., Canada, and Mexico only)
www.baysidefurnishings.com
MADE IN VIETNAM / FABRIQUÉ AU VIETNAM / HECHO EN VIETNAM
