Wireless signal transmission system for safety edges
Translation of original operating instructions
General
1Safety instructions
2Common application
ENGLISH
290260G
10/18
Transmitter Receiver
Warning: Switch off the operating voltage before working on the
system. Only trained, qualied personnel may perform installation
and startup. The unit may only be repaired by the manufacturer. The
switching unit may only be used to protect against dangers on
crushing and shearing points and on automatic industrial doors and
gates (intended use). National and international regulations on
industrial door and gate safety must be complied with. Always
consider the safety functions of your application as a whole, never just in
relation to one individual section of the system. The installer is responsible
for carrying out a risk assessment and installing the industrial door system
correctly.
It is recommended to change the batteries every year.
2.1 Site entrance gate
Safety edges
Receiver
Safety edges
8.2kΩ
Transmitter
i
Up to 10 transmitters can be linked with
the same receiver
Transmitter
Transmitters and receivers (also among each others) must be at
least 0.5 m apart.
i

2
NC 2x
C B S
8K2
C B S
8K2
i
NC
1
ON
1 2
+
2032
2
ON
1 2
+
+
2032
2032
1 2
ON
8K2 8K2
1 2
ON
IN1 comon IN2 2) IN1 comon IN2 2) IN2 2) IN2 2)
1)
1 2
ON
IN1
1 2
ON
IN1
1)
C B S
VCC1 VCC2 COM OUT SOUT TEST
TEST
+/~ –/~
12/24V
AC/DC Test
C B S
VCC1 VCC2 COM OUT SOUT TEST
TEST
+/~ –/~
12/24V
AC/DC
Test

open
collector
3.2 Change input from NC to NO (factory setting = NC)
4.3 DIP switches
4Receiver
3Transmitter
2.
Insert
battery 1
5.
Insert
battery 2
3.
Status
4.
Change
6.
Change
stored
Press button on
transmitter
Status
changes
LED
ashes
LED
ashes 2x
LED
ashes 5x
> 1.5 sec.
After inserting the battery 1,
you have 10 seconds to change the logic
1 2 3 4
ON *Safety application
standard
according to EN ISO 13849-1
1 2 3 4
ON inactive ➔no safety function!
(Radio connection is not monitored)
12 3 4
ON Transmission frequency
869.85 MHz:
Set DIP-switch before pairing transmitter –
receiver
12 3 4
ON *868.95 MHz:
Set DIP-switch before pairing transmitter –
receiver
12 34
ON Test input type
NC
activated = contact open
12 34
ON *NO
activated = contact closed
12 3 4
ON Automatic frequency adjustment
active
used only in case of radio disturbances
12 3 4
ON *inactive
*= factory setting
Observe
the sequence
Relay contacts are shown unpowered
4.2 Wiring: Outputs and control
Gate control
with
NC input
Gate control
8.2 kOhm
input
4.1 Wiring: Power supply and test inputs
1) Change from NC to NO, see chapter 3.2
2)
i
IN2 has no function
RFGate 2.2.S RFGate 2.2.S.F
3.1 DIP switch setting according to sensor (safety edge, switch contact)
NO 5x
NO
DIP switch Sensor connection DIP switch Sensor connection DIP switch Sensor connection DIP switch Sensor connection
Status Terminals
C – B
Terminals
C – S
Sensor not activated (operating mode) 8K2 closed
Sensor activated (security system activated) closed open
No supply voltage closed open
Transmitter and receiver not paired closed open
Broken cable between sensor and transmitter closed open
Transmitter batteries low closed open
1.
Remove all
batteries

3
1
2
ON
1 2
+
+
2032
2032
ON
1 2
+
2032
1 2
ON
1 2 3 4
ON
i
ON
OK?
1 2 3 4
ON
2x
2x
i
i
6.1. RFGate 2.1, pairing transmitter with receiver
5Start-up
6Programming
2.
On the
transmitter
On
the
receiver
Press and
release button
Beep Wait 2
beeps
10 sec.
1.
On the receiver
Press
button
Beep
> 1.5 sec.
LED
lights up
6.
Transmitter:
install
Release
button
4.
Transmitter:
insert
batteries
1.
Check DIP
switch settings
5.
Programming (Chapter 6.1):
pair transmitter with receiver
Transmitters and receivers (also
among each others) must be at
least 0.5 m apart.
Observe
order
6.2 Clear pairings
6.3 Memory full
Press
button and hold
Keep pressed
the button
Short beepsBeep WaitRelease
button
10 sec.
> 1.5 sec. > 3 sec.
2
beeps
Code saved
LED goes out
Please observe the torque when
fastening the cover:
Max. 45 N cm
7.
Transmitter:
wire
3.
Turn on power
supply
2.
Install and wire
receiver
8.
System test of safety
edge on gate
On
the
receiver
All pairings
deleted
Beep
Beep Beep
Beep
Beep 10 sec.
Beep Beep Beep Beep
Transmitters and receivers (also among
each others) must be at least 0.5 m apart.

4
1234
ON
SELECT
REL21
1 2
4x
Designed in Switzerland / Made in EU
BBC Bircher Smart Access, BBC Bircher AG, Wiesengasse 20, CH-8222 Beringen, www.bircher.com
7Standard operation
8Technical data
7.1 Receiver LED indicators 7.2 Warning indicator for low battery voltage
Object
detected
LED off
LED
Receiver: Signal sounds at each activation
Receiver
Supply voltage 12/24 V ACDC
Transmitter memory 10
Output 1 relay 24 V, 1 A; micro switch-off 1B
Power consumption 0.5 W @ 12 V; 1.2 W @ 24 V
Test signal input See page 2, chapter 4.1, I = 3 mA
switching threshold: off = 0.6 V / on = 1.8 V
Transmitter
Battery power 2 x Lithium 3 V Type CR2032
Power consumption Transmitting: 17 mA standby: 16 µA
Safety
OK
LED on
Battery voltage
low
System
Frequency bands 868.95 MHz & 869.85 MHz
Range under optimum conditions up to 100 m
Protection class IEC
60529
IP55
Pollution degree 2
Working temperature -20 °C to +55 °C
Beep
9EU Declaration of Conformity
11 Contact
See attachment
10 WEEE
Devices with this symbol must be treated separately during disposal. This must be done in accordance with the laws of
the respective countries for environmentally sound disposal, processing and recycling of electrical and electronic equipment.
