BBC Bircher XRF-R1 User manual

1
ON
1 2
ON
1 2
XRF-R1
50
121
23
5
50
121
23
5.7
4.2
4.2
22
106
LED 1
Wireless single channel signal transmission system for safety edges
Original operating instructions
Intended use: Monitoring safety edges on doors and gates
1Safety instructions
ENGLISH
404169E
10/20
Receiver (Rx)
• Read these operating instructions thoroughly before putting the device into
operation and keep them for future reference.
• The assembly, commissioning, modications and extensions may only be comple-
ted by an experienced electrician.
• Before commencing work, remove the power supply from the device/installations!
• During the operation of electrical components
– e. g. in the case of a short circuit hot and ionised gases can be emitted
– protection covers must not to be removed.
• Pay attention to all local relevant electrical safety regulations.
• Disregard of the safety regulations can cause death, severe injuries or extensive
damage.
• Devices that are classied as Category 2 according to EN ISO 13849-1 must be
tested regularly – at least once per cycle.
• It is the responsibility of the equipment manufacturer to carry out a risk assess-
ment and to install both the detector and the equipment in compliance with
applicable national and international regulations and safety standards, as well as
the Machinery Directive 2006/42/EC, should this apply.
Receiver
Tx1 Tx2
Before commencing the installation or assembly complete the following safety
precautions:
• Check the voltage data on the label of the switching device.
• Ensure that the device/installations can not be switched on.
• Determine that the power supply is disconnected.
• Protect the device with a housing against contamination or aggressive
environments.
• Connect all operating and switching voltages to the same fuse.
• Connect the operating voltage to the same circuit as the industrial door controller.
• Disconnect device from mains in the event of a fault.
This equipment is not suitable for use in locations where children are likely to be
present.
Limited protection against accidental contact!
Receiver
Output
1
Transmitter Tx1 (input 1) corresponds to receiver output
Transmitter Tx2 (input 1) corresponds to receiver output
Push button
Space
to open cover
LED SYS
DIP-switch
Buzzer
visible through
cover
2Common application

2
i
  
50
121
23
5
1 2 3 4 5 6 7 8 910 11 12
8k2
8k2
i
i
3.1 Cable routing, strain relief 3.2 Space to open cover
Determine the cable routing
Break out the respective part of the cover if necessary
 Punch hole into the grommet
 Insert cable
… or use holes
in the base plate
Break out …
Hint:
or
3Installation
DIP switch test input
1
ON
Low-active
1
ON
*High-active
*= factory setting
VIN Test
Output
Power supply
(10–36 V
ACDC)
4Wiring
(Uth > 10 V ACDC,
< 11 mA @ 36 V)
Only to be wired
in case of a
Cat. 2 application
Cable Ø: 3.1 – 5.2 mm
36 V
1 A
Do not wire
3/4 and 5/6
simultaneously
Note: When using the NC outputs (5/6) in Cat. 3 set-up, the wiring with the control must be permanently installed and protected against external
damage according to EN ISO 13849-2 Tab.D.4 or else Cat. 2 applies and a test signal is needed.
Wire cross section
0.25 – 0.75 mm2

3
2x
LED SYS
OK?
LED 1 LED 1
LED 1 LED 1
5.1 Pairing transmitter with receiver only IN1 of the transmitter(s) will be evaluated
5Conguration
Press button
Transmitter TxReceiverReceiver Receiver Transmitter Tx
Release button … or wait
1 min.
Long press
button
Long press
button …
Flashes
orange
GreenRelease
button
Code saved
Beep Beep
Beep
7.1 Status output, LED
7Receiver
6System test, mandatory after each set-up!
2x5x
5.2 Clear pairings
All pairings
deleted
Receiver
… or wait
Press button
and hold
Long press
button …
Release
button
Flashes
orange
Beep Beep
1 min.5 s
Beep
Green Red
Press each
safety edge
LED LED 1 Output 1 Output 1 Buzzer
SYS 3–4 5–6
No power supply – – closed open
System ready, no sensor pressed green green 8k2 closed
Sensor pressed (main closing edge) orange red closed open
Wicket door open (XRF-TW) orange red closed open
Conguration (Pairing) orange
ashing
orange
ashing
closed open upon action
Conguration, memory full orange
ashing
orange
ashing
closed open 10x
Low battery green green 8k2 closed 3x every min.
Test input active green red closed open
Error
a = Broken cable between edge and input, resistor out of range
b = Tx lost or empty battery
c = System error
a = green
b = green
c = red
red closed open
(see also manual of transmitter)
Does the door/gate stop when the sensing
element is activated?

4
Designed in Switzerland / Made in China
BBC Bircher Smart Access, BBC Bircher AG, Wiesengasse 20, CH-8222 Beringen, www.bircher.com
OK?
LED SYS
OK?
LED SYS LED SYS
10 EU Declaration of Conformity
12 Contact
See attachment
11 WEEE
Devices with this symbol must be treated separately during disposal. This must be done in accordance with the laws of
the respective countries for environmentally sound disposal, processing and recycling of electrical and electronic equipment.
9Technical data
Receiver
Supply voltage 10–36 V ACDC
Power consumption 0.6 W @ 12 V / 0.7 W @ 36 V
Safety outputs (2 relays) max. 36 V ACDC; 1 A
Test input Uth > 10 V ACDC, < 11 mA @ 36 V
Sensor memory 7
System
Operating frequency 868.3 MHz
Reaction time Typ. 15 ms
Range 100 m (at optimal condition)
According to EN ISO 13849-1 PLd
for Cat. 3 applications
+ test input for Cat. 2 applications
Protection class IEC 60529 IP65
Working temperature –20 °C to +60 °C
8.1 Warning indicator for low battery voltage
To nd out which transmit-
ter has low battery
voltage: Press each edge.
Every minute Battery good Battery bad
Beep Beep
8.2 Error indication
To nd out which
transmitter causes
error indication:
Beep
LED SYS lights up red (only visible with open cover)
Red Stays red
Flashes orange
Transmitter good Transmitter with error
3x
8Trouble shooting
