BBQ GSS3219B User manual

GSS3219B
Owner’s Manual 0
5 Burner LP Gas Barbecue Grill
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
WARNING:
FOR YOUR SAFETY :
For Outdoor Use Only
(outside any enclosure)
PROP 65 WARNING:
Chemicals known to the state
of California to
cause cancer,
birth defects or other
reproductive harm are created
by the combustion of
propane.
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
MODEL# GSS3219B
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
[email protected] OR
CALL 1-877-885-8225 (TOLL-FREE), 10:00 A.M. – 19:00 P.M.
(EST), MONDAY-FRIDAY.
WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.

GSS3219B
Owner’s Manual 1
QUESTIONS, PROBLEMS, MISSING PARTS WITH THIS PRODUCT? DO NOT RETURN TO YOUR RETAILER.
PLEASE VISIT US AT WWW. BBQTEK.COM OR EMAIL US AT SERVICE@BBQTEK. COM
YOU CAN ALSO CALL OUR CUSTOMER SERVICE DEPARTMENT 10:00 A.M. TO 19:00 P.M. EASTERN STANDARD TIME,
MONDAY THROUGH FRIDAY, AT
1-877-885-8225.
Grill Operation 1-2-3
Before Grilling
Step 1 Keep your grill a safe distance away from your property.
Step 2 Always perform a Leak Test on all connections and hoses.
Step 3 Keep children away from the grill.
During Grilling
(To avoid tripping safety valves, please follow these instructions carefully!)
Step 1 First open lid and turn gas tank on slowly.
Step 2 Turn only one knob on at a time when lighting up the grill.
Step 3 Use protective gloves when grill gets hot.
Step 4 Never leave a lit grill unattended.
After Grilling
Step 1 Always burn grill for 10-15 minutes to burn off food residues after use.
Step 2 Wait until the grill is completely cooled before closing lid.
Step 3 Clean up grease build-up to avoid grease fire and cover your grill to prevent rust.
Always read and understand the WARNINGS and INSTRUCTIONS that are contained in this manual before attempting to use
this gas barbecue grill to prevent possible bodily injury or property damage.
NOTE : This grill must be used with propane gas only (propane gas cylinder not included).
Installer
: Leave this manual with the consumer.
Consumer : Retain this manual for future reference.
WARNING:
1. Do not store or use gasoline or other
flammable
liquids or vapor in the vicinity of
this or any other appliance.
2. An LP cylinder not connected for use shall not
be stored in the vi cinity of this or any other
appliance.
DANGER:
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance
and immediately call your gas
supplier or your fire department.

GSS3219B
Owner’s Manual 2
Table of Contents
For Your Safety ................................................................................................................ 3
Package Contents............................................................................................................ 5
Hardware Contents .......................................................................................................... 6
Assembly Instructions..................................................................................................... 7
Operating Your Grill ....................................................................................................... 16
Connecting Gas Cylinder .............................................................................................. 16
Checking for Leaks ........................................................................................................ 17
Lighting Your Grill ......................................................................................................... 17
Excess flow safety valve reset procedure .................................................................. 19
Care and Maintenance .................................................................................................. 20
Troubleshooting............................................................................................................ 21
Warranty Program.......................................................................................................... 23

GSS3219B
Owner’s Manual 3
For Your Safety
Dear Valued Customer,
Congratulations on your new barbecue grill purchase! You’ve made the right choice. In this manual, you will find assembly
instructions, suggestions for
grilling and helpful hints, as well as guidelines for the safe operation, proper care and use of your
grill. Our expert staff strives to provide
you with an easy-to-assemble product. Should you have any questions or problems with
this product, please call
our customer service department at 1-877-885-8225
10:00 am –
19:00 pm (EST), Monday through Friday.
NOTE: The use and installation of this product must conform to local codes. In the absence of local codes, use the National
Fuel Gas Code, ANSI Z223.1/ NFPA54. Reference to Natural Gas and Propane Installation code CSA B149.1 or Propane
Storage and Handling code B149.2
IMPORTANT NOTICE: READ ALL INSTRUCTIONS PRIOR TO ASSEMBLY AND USE.
Safety First!
Read and understand all warnings and precautions prior to operating your grill.
WARNING:
1. This grill is for outside use only. It should not be used in a building, garage or any other enclosed area.
2. The use of alcohol, prescription or non-prescription drugs may impair an individual’s ability to properly assemble or safely
operate this appliance.
3. Always open the grill lid carefully and slowly as heat and steam trapped within the grill could cause severe burns.
4. Always place your grill on a hard and level surface far away from combustible materials and structures. An asphalt or
blacktop surface may not be acceptable for this purpose.
5. Do not leave a lit grill unattended.
6. Keep children and pets away from the grill at all times.
7. This is not a tabletop grill. Do not place this grill on any type of tabletop surface.
8. Do not use the grill in high winds.
9. This grill must be used with propane gas only (propane gas cylinder not included).
10. Do not attempt to attach this grill to the self-contained propane system of a camper , trailer, motor home or house.
11. Do not use charcoal or lighter fluid.
12. Do not use gasoline, kerosene or alcohol for lighting. The LP-gas supply cylinder must be constructed and
marked
in accordance with the specifications for propane gas cylinders of the U.S. Department of Transportation (DOT)
CFR
49.
13. This outdoor gas appliance is not intended to be installed in or on recreation vehicles and / or boats.
14. Do not attempt to move the grill while it is lit.
15. Do not use the grill unless it is COMPLETELY assembled and all parts are securely fastened and tightened.
16. Keep combustible items and surfaces at least 50 inches (127cm) away from the grill at all times. DO NOT use this gas grill
or any
gas product under any overhead enclosure or near any unprotected combustible constructions.
17. Do not use in an explosive atmosphere. Keep grill area clear and free from combustible materials,
gasoline and other flammable vapors and liquids.
18. Do not attempt to use or assemble with missing or damaged parts. Contact customer service for replacement part.
CAUTION-Prevention of Burns
1.
To avoid burns, do not touch metal parts of the grill until they have completely cooled for at least 45 minutes or unless you
are wearing protective gear such as pot holders, protective gloves or mittens.
2.
Do not alter the grill in any manner.
3.
Clean and inspect the hose before each use. If there is evidence of abrasion, wear, cuts or leaks, the hose must be replaced
prior to
operation. The replacement hose assembly should be in accordance with the manufacturer’s specifications.
4.
Move gas hoses as far away as possible from hot surfaces and dripping hot grease.
5.
Never keep a filled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which could open
the relief valve and allow gas to escape.
Safe Locations For Use Of This Outdoor Grill

GSS3219B
Owner’s Manual 4
DANGER:
Never use this outdoor grill inside any building, garage, shed or breezeway, or inside any boat, trailer or recreational
vehicle to prevent a possible fire and to prevent the possibility of carbon monoxide poisoning or asphyxiation.
WARNING:
Do not use this appliance under overhead combustible surface or covered area (e.g., awnings, umbrellas, porches or gazeboes).
Always confirm that this grill is not positioned under the overhang of a house, a garage or other structure before lighting it. An
overhang will serve to deflect flare-ups and radiated heat into the structure itself, which could result in a fire.
Always confirm that this grill is positioned more than 50 inches (127cm) away from any
building or combustible materials or surface before lighting it, and that no gasoline
or other volatile substances are stored in the vicinity of this grill.
(See diagram to right). The temperature of a grease fire or of the radiated heat
might otherwise be sufficient to ignite nearby combustible or volatile substances.
Always locate this grill where there will be ample combustion and ventilation air,
but never position it in the direct path of a strong wind.
Never allow the grill to operate while unattended to prevent uncontrolled grease fires
from erupting.
Never attempt to move this grill while it is in operation or while it is still hot to prevent possible personal injury.
Never store or use gasoline or other flammable or volatile substances in the vicinity of this grill or in the vicinity of any other
heat-generating appliance because of the danger of starting a fire.
Always confirm that the installation of this grill conforms with the requirements of all local codes or, in the absence of applicable
local codes, with either the National Fuel Gas Code, ANSI Z223. NFPA 54 or CAN/CGA-B149.2.
DANGER – Gas Safety
Liquefied propane (LP) gas is flammable and hazardous if handled improperly. Become aware of its characteristics before using
any propane product.
 Propane Characteristics: Flammable, explosive under pressure, heavier than air and settles in pools in low areas.
 In its natural state, propane has no odor. For your safety, an odorant has been added.
 Contact with propane could cause freeze burns to the skin.
 This grill is shipped from the factory for propane gas use only.
 Never use a propane cylinder with a damaged body, valve, collar or footing.
 Dented or rusted propane cylinders may be hazardous and should be checked by your propane gas supplier.
CAUTION:
 It is essential to keep the grill’s valve compartment, burners and circulating air passages clean.
 Inspect the grill before each use .
Step 1. Inspect all hoses and connections and make certain they are secure.
Step 2. Check and clean the burner venturi tubes for insects and insect nests by removing the burner and inserting a bottle
brush cleaner into each tube to make sure the passage is clear.
*** A clogged tube can lead to a fire beneath the grill. ***
Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube.
General Information
1. A propane gas cylinder is required for operation.
2.
This gas grill is NOT intended for commercial u se.
50 inches
50 inches

GSS3219B
Owner’s Manual 5
Package Contents
Part Description QTY Part Description QTY Part Description QTY
A
Cart bottom 1 PC
J
Hook
10 PCS
S
Grease cup support
1 PC
B
Cart left side panel
1 PC
K
Right side shelf
1 PC
T
Grease cup
1 PC
C
Cart right side panel
1 PC
L
Body assembly
1 PC
U
Tank clip
1 PC
D
Cart back panel
1 PC
M
Side knob
1 PC
V
Partition board 1 PC
E
Front beam
1 PC
N
Side knob bezel
1 PC
W
Magnet 2 PCS
F
Brackt
1 PC
O
Side burner frame
1 PC
X
Bracket 1 PC
G
Door
2 PCS
P
Heat plate
3 PCS
Y
Led light 1 PC
H
Left side shelf
1 PC
Q
Cooking grid
3 PCS
I
Side bar tool hanger
2 PCS
R
Warming rack
1 PC

GSS3219B
Owner’s Manual 6
Hardware Contents
AA: M6 X 33 Bolt ... 2 PCS BB: M6 X 15 Bolt ... 17 PCS CC: M4 X 15 Bolt ... 14 PCS
DD: M4 X 10 Bolt ... 2 PCS EE: M6 Flat Washer ...17 PCS FF: M6 Spring Washer ... 14 PCS
GG: M4 Flat Washer ... 16 PCS HH: M4 Spring Washer ... 8 PCS II: M4 Nut ... 4 PCS
JJ: Battery ... 3 PCS KK: Screwdriver... 1 PC
Hardware listed above is not scaled to exact size.
(A screwdriver is required on assembly and is included for your convenience).

GSS3219B
Owner’s Manual 7
Assembly Instructions
Remove all contents from the carton packaging. Make sure all parts are present before attempting assembly. Once the grill is
fully assembled, go back and check to make certain all the bolts are secure. Tighten again
using the screwdriver provided if
necessary.
Estimated assembly
time: 30 minutes.
Step 1 (The Magnet assembly)
Note: Before beginning assembly, make
certain the two swivel casters on the
bottom assembly (A) are locked.
a) Align the holes on the
magnet s（W）
with the holes on the cart bottom.
b) Insert one bolt (CC), one spring
washer (GG) and one flat washer (HH)
into each pre-drilled hole. Tighten
bolts by hand until secured.
c) Go back and tighten all bolts using the
screwdriver provided.
Step 2 (The cart side panels assembly)
a) Loosen the six pre-installed bolts on bottom
assembly (A) and allow 1/4 bolt’s length to
extend from the bottom assembly.
b) Align the three large holes on the cart right
side panel (C) with the three bolts extended
from the bottom assembly.
c) Slide the cart right side panel (C) until it locks
into place. Tighten bolts by hand until
secured.
d) Repeat the procedure for the cart left side
panel (B) assembly.
e) Go back and tighten all bolts using the
screwdriver provided.
CC
M4X15 Bolt 4 PCS
GG
M4 Flat Washer 4 PCS
HH
M4 Spring Washer 4 PCS

GSS3219B
Owner’s Manual 8
Step 4 (Assemble the front beam to
the cart)
a) Place the front beam (E) on the
two cart side panels.
b) Align the two holes on the right
end of front beam (E) with the
top & side two holes on the
frame of cart right side panel.
c) Insert one M6 x 15mm bolt (BB)
with one M6 spring washer (FF)
and one M6 washer (EE) into
each pre-drilled hole. Tighten
bolts by hand until secured.
d) Repeat the procedure for the
frame of cart left side panel.
e) Go back and tighten all bolts
using the screwdriver provided.
Step 3 (The cart back panel
assembly)
a) Loosen the four pre-installed
bolts on the cart side panels
and allow 1/4 bolt’s length to
extend from the cart side
panels.
b) Align the four holes on the cart
back panel (D) with the four
bolts extended from the cart
right side panel and cart left
side panel.
c) Push down the cart back panel
(D) until it locks into place.
Tighten all bolts using the
screwdriver provided.
BB
M6X15 Bolt 4 PCS
FF
M6 Spring Washer 4 PCS
EE
M6 Flat Washer 4 PCS

GSS3219B
Owner’s Manual 9
Step 5 (Bracket assembly)
a) Align the two holes on the bracket
(F) with the two holes on the cart
left side panel.
b) Insert one M4 x 15mm bolt (CC)
with one M4 flat washer (GG) into
each pre-drilled hole. Tighten
bolts by hand until secured.
c) Align the two holes on the bracket
(F) with the two holes on the
bottom assembly.
d) Repeat the procedure b).
e) Align the two holes on the bracket
(X) with the two holes on the cart
right side panel.
f) Repeat the procedure b).
g) Go back and tighten all bolts using
the screwdriver provided.
Step 6 (Doo
r
assembly)
a) Insert the bottom pin of left
door (G-1) into the pre-drilled
hole on the cart bottom (A).
b) Push down the top pin of left
door (G-1) and insert it into
the pre-drilled hole on the
left end of front beam.
c) Repeat the procedure for the
right door (G-2).
d) Close the two doors.
CC
M4X15 Bolt 6 PCS
GG
M4 Flat Washer 6 PCS

GSS3219B
Owner’s Manual 10
Step 7 (Left side shel
f
assembly)
a) Pull out the drawer from the left side
shelf (H), then turn over it as shown.
b) String five hooks (J) with the side
bar tool hanger (I), then align the
holes on the end of side bar tool
hanger (I) with the holes on the left
side shelf.
c) Insert one M6 x 15mm bolt (BB) with
one M6 spring washer (FF) and one
M6 washer (EE) into each pre-drilled
hole. Tighten bolts by hand until
secured.
d) Go back and tighten all bolts using
the screwdriver provided.
Step 8 (Right side shelf assembly)
a) Turn over the right side shelf
(K).
b) String five hooks (J) with the
side bar tool hanger (I), then
align the holes on the end of
side bar tool hanger (I) with the
holes on the right side shelf.
c) Insert one M6 x 15mm bolt (BB)
with one M6 spring washer (FF)
and one M6 washer (EE) into
each pre-drilled hole. Tighten
bolts by hand until secured.
d) Go back and tighten all bolts
using the screwdriver provided.
BB
M6X15 Bolt 2 PCS
FF
M6 Spring Washer 2 PCS
EE
M6 Flat Washer 2 PCS
BB
M6X15 Bolt 2 PCS
FF
M6 Spring Washer 2 PCS
EE
M6 Flat Washer 2 PCS

GSS3219B
Owner’s Manual 11
Step 10 (Assemble the side shelfs with the body assembly)
a) Loosen the four pre-installed bolts on the left side of body assembly and allow 1/4 bolt’s length to extend from body
assembly.
b) Align the holes on the left side shelf (H) with the bolts extended from the left side of body assembly.
c) Push down the left side shelf until it locks into place. Tighten bolts by hand until secured.
d) Pull out the drawer from the left side shelf, then align the hole on left side shelf with the hole on the front control panel.Insert
one bolt (BB) into the pre-drilled holes.
e) Align the hole on the cart left side panel with the hole on the left side shelf ,then insert one bolt (AA) with one flat washer (EE)
into the pre-drilled hole towards into body assembly.
f) Tighten bolts by hand until secured.
g) Repeat the above procedure for the assembly of right side shelf (K) and body assembly (L).
h) Go back and tighten all bolts using the screwdriver provided.
Step 9 (Assemble the body to the cart)
a) Place the body assembly (L) on the
top of cart assembly.
b) Align the two holes on the left top of
cart assembly with the two holes on
the left of body assembly (L).
c) Insert one M6 x 15mm bolt (BB) with
one M6 spring washer (FF) and one
M6 flat washer (EE) into each
pre-drilled hole.
d) Tighten bolts by hand until secured.
e) Repeat the procedure for the right
assembly.
f) Go back and tighten all bolts using
the screwdriver provided.
BB
M6X15 Bolt 4 PCS
FF
M6 Spring Washer 4 PCS
EE
M6 Flat Washer 4 PCS
AA
M6 X 33 Bolt 2 PCS
BB M6X15 Bolt 2 PCS
EE
M6 Flat Washer 2 PCS

GSS3219B
Owner’s Manual 12
Step 12 (Side burner assembly)
a) Open the side burner lid and place
the side burner frame (O) on the
right side shelf. Make certain the
venturi tube is connected properly
with valve.
b) Align the four holes on the side
burner frame (O) with the four holes
on the right side shelf. Insert one
bolt (CC) into each hole and place
one flat washer (GG), one spring
washer (HH) and one nut (II) onto
each bolt from the bottom of right
side shelf, tighten all bolts by hand.
c) Connect the side burner ignition wire
by sliding it onto the electrode on the
side burner frame (O).
d) Go back and tighten all bolts using
the screwdriver provided.
Step 11 (Side knob & seat assembly)
a) Align the holes on the side knob bezel
(N) with the holes on the right side
shelf and the side burner valve. Screw
one M4x10mm bolt (DD) with one flat
washer (GG) into each pre-drilled hole
by hand.
b) Tighten the bolts using the screwdrive
r
provided.
c) Insert the side knob (M) onto the valve
shaft.
DD
M4X10 Bolt 2 PCS
GG
M4 Flat Washer 2 PCS
CC
M4X15 Bolt 4 PCS
GG
M4 Flat Washer 4 PCS
HH
M4 Spring Washer 4 PCS
II
M4 Nut 4 PCS

GSS3219B
Owner’s Manual 13
Step 14 (Heat plate, cooking grid and warming
rack assembly)
a) Place the heat plates (P) onto the heat plate
support.
b) Place the cooking grids (Q) upon the heat
plates.
c) Place the warming rack (R) on the warming
grid support as shown.
d) Close the top lid.
Step 13 (Partition board assembly)
Place the partition board (V) onto the end of
heat plate support as shown. Align the hole on
the partition board with the hole on the bottom
of fire box, then insert one M6X15 bolt (BB)
with one flat washer (EE),
tighten the bolt using
the screwdriver provided.
BB
M6X15 Bolt 1 PC
EE
M6 Flat Washer 1 PC

GSS3219B
Owner’s Manual 14
Step 16 (Grease cup & support
assembly)
a) Hook the grease cup support (S)
into the two holes on the grease
pan.
b) Place the grease cup (T) onto the
grease cup support.
Step 15 (Tank clip assembly)
a) Insert the tank clip (U) into the holes
on the tank holder.
b) Place the gas tank on the tank holder
and clip it using the tank clip (U).
c) Connect the
tank with regulator by
screwing the regulator collar onto the
tank valve.
(See diagram to right.)
d) Conduct
the leak test on page 16 to
make certain all connections are
connected securely.

GSS3219B
Owner’s Manual 15
Fully Assembled View
Left Side
Right Side
Step 17 (LED light assembly)
a) Align the two holes on the base of LED light
(Y) with the two holes on back of left side
shelf.
b) Insert one bolt (BB) with one spring wash
(FF) and one flat washer (EE) into each
pre-drilled hole. Tighten bolts by hand until
secured.
c) Go back and tighten all bolts using the
screwdriver provided.
d) Loosen battery cover on back of LED light.
Place three batteries (JJ) into the battery box
as shown below, make sure the anode and
cathode are placed correctly.
e) Re-cover the battery cover onto the LED
light.
BB
M6X15 Bolt 2 PCS
FF
M6 Spring Washer 2 PCS
EE
M6 Flat Washer 2 PCS
JJ
battery 3 PCS

GSS3219B
Owner’s Manual 16
Operating Your Grill
CAUTION:
Use only the regulator provided. If a replacement is necessary, call our customer service center. The use of
unauthorized parts
can create an unsafe condition and environment.
The propane gas supply cylinder used
must be constructed and marked in accordance with the Specifications for Propane
Gas Cylinders of the U.S. Department of Transportation (DOT). Only cylinders
with a listed overfill prevention device (OPD)
and marked
“propane” may be used. Cylinders with an OPD will have valve handles with three “lobes” (prongs).
The pressure regulator and hose assembly supplied with the outdoor cooking gas appliance must be used. Replacement
pressure regulators and hose assembly must be those specified by the outdoor cooking gas appliance manufacturer.
Use only
20-pound cylinders equipped with a cylinder connection device compatible with the connection for outdoor cooking
appliances.
The cylinder must include a collar to protect the cylinder valve. The gas cylinder should not be dropped or handled
roughly. If the appliance is not in use, the gas cylinder must be disconnected.
Storage
of the appliance indoors is permissible ONLY if the cylinder is disconnected and removed from the appliance.
Cylinders must
be stored outdoors and out of the reach of children. Cylinder must not be stored in a building, garage or other
enclosed areas.
Your cylinder must never be stored where temperatures can reach over 125°F.
Before connecting, make sure there is no debris caught in the head of the gas cylinder, regulator valve or in the head of the
burner and burner ports. Connect regulator valve and hand tighten firmly. Disconnect the propane cylinder from the regulator
valve when the
grill is not in use. DO NOT obstruct the flow of combustion air or ventilation air to the grill. The propane
cylinder
must be arranged for vapor withdrawal and equipped with a listed overfill prevention device (OPD).
DANGER:
A fire causing death or serious injury may occur if the following is not followed exactly:
Never store or use gasoline or other volatile substances in the vicinity of this grill .
Never store a spare propane cylinder in the vicinity of this grill, or in the vicinity of another potential heat source.
Never fill the propane cylinder beyond 80% full.
This grill is designed to connect to a standard 20 lb L.P. cylinder only, please refer to the Step 13 of assembly instructions for the
installation.
WARNING:
Don’t store spare gas cylinder in or near grill.
Connecting Gas Cylinder
LP (Propane) Gas Supply Connection
1. Always place the propane cylinder on the tank holder under the cart.
2. Always confirm that all burner control knobs are in the OFF position before activating the gas supply.
3. Before connection, be sure that there is no debris caught in the head of the gas cylinder, head of
the regulator valve, or in the head of the burner and burner ports.
4. Always connect the gas supply regulators as follows:
Insert the nipple of the valve coupling into the tank valve and tighten the connection collar
by turning it clockwise with one hand while holding the regulator with the other hand.
(See diagram to right.)
5. Disconnect the propane cylinder from the regulator valve when the grill is not in use.
6. Do not obstruct the flow of combustion air and ventilation air to the grill.
7. Keep ventilation openings of the cylinder enclosure free and clear from debris.
8. Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Install only the type of dust cap on cylinder valve
outlet that is provided with the cylinder valve. Other types of caps or plugs may result in leakage of propane.
DANGER:
To prevent fire or explosion hazard when testing for a leak:

GSS3219B
Owner’s Manual 17
1. Always perform the “leak test“ below before lighting the grill and each time the cylinder is connected for use.
2. Do not smoke or allow other sources of ignition in the area while conducting a leak test.
3. Conduct the leak test outdoors in a well-ventilated area.
4. Do not use matches, lighters or a flame to check for leaks.
5. Do not use grill until all leaks have been stopped. If you are unable to stop a leak, disconnect the propane supply, call for gas
appliance service or your local propane gas supplier.
Checking for Leaks
1.
Make 2-3 oz. of leak solution by mixing one part liquid dishwashing soap with three parts water.
2.
Make sure control knobs are in the “OFF” position.
3.
Spray some solution on the tank valve up to the regulator connection.
(See diagram to right.)
4.
Inspect the solution at the connections for bubbles. If no bubbles appear, the connection
issecure.
5.
If bubbles appear, you have a leak. Go to step 6.
6.
Disconnect the regulator from the tank and reconnect. Make sure the connection is tight and secured.
7.
Retest with solution.
8.
If you continue to see bubbles, replace the cylinder.
Lighting Your Grill
DANGER:
Failure to open lid while igniting the grill’s burners or not waiting five minutes to allow gas to clear if the grill does not light, may
result in an explosion, which could cause serious bodily injury or death.
WARNING:
Never stand with your head directly over the grill when preparing to light the main burners, to prevent possible bodily injury.
Lighting Main Burner
1. Open lid while lighting burners.
WARNING: Attempting to light the burner with the lid closed may cause an explosion.
Make
sure there are no obstructions of airflow to the gas unit. Spiders and insects can nest and
clog the burner/venturi tube at the
orifice. A clogged burner tube can lead to a fire beneath the
appliance.
2. All valves must be in the “OFF” position.
3. Open cylinder valve.
4. Ignite only the burners you wish to use, using the same method for each:
Push and turn desired burner valve knob and rotate slowly about 1/4 counterclockwise until a click
is heard. (See diagram to right.)The burner should be lit.
If the burner does not light, repeat 2 or 3 more
times. If ignition does NOT occur in 5 seconds turn the burner controls to OFF, wait 5 minutes, and repeat the
lighting procedure.
After burner is lit, repeat the procedure with any other burner desired.
5. Adjust valve knob(s) to desired cooking temperature.
Using the Lighting Stick to Light the Main Burners
1.
Insert a match into the end of lighting stick locked in the drawer. Light the match.
2. Once lit, put the lighting stick through the cooking grid and place
the flame next to the burner ports found along the sides of the
desired burner (See diagram to right.)
3. Press the valve knob and rotate it counterclockwise to the ‘’HIGH’’
position. The burner should light immediately. If more than one burner
is desired, repeat the procedure 2-3 until all desired burners are lit .
4. Adjust burners to the desired cooking temperature.

GSS3219B
Owner’s Manual 18
Precautions:
1. After lighting, observe the burner flame. Make sure all burner ports are lit.
2. If the burner flame goes out during operation, immediately turn the gas “OFF”. Open lid to let the gas clear for at least 5
minutes before re-lighting.
3. Before cooking on the grill for the first time and operate the grill for approximately 15 minutes with the lid closed and the
gas
turned on “HIGH”. This will “heat clean” the internal parts, dissipate odor from the manufacturing process and painted
finish.
4. Clean the grill after each use. DO NOT use abrasive or flammable cleaners. This may damage parts of the grill and cause
a
fire.
Lighting Side Burner
1.
Open lid while lighting the burner. Lid must remain open while burner is lit.
2.
Valve must be in the “OFF” position.
3.
Open cylinder valve.
Push the side burner valve knob and rotate slowly about 1/4 counterclockwise until a click is heard. The burner should be
lit.
If the burner does not light, repeat 2 or 3 more times. If ignition does NOT occur in 5 seconds turn the burner controls to OFF,
wait 5 minutes, and repeat the lighting procedure.
4.
Adjust valve knob to the desired cooking temperature .
Using the Lighting Stick to Light the
Side Burner
1.
Open lid while lighting the burner. Lid must remain open while burner is lit
2.
Remove the lighting stick then insert a match into the end of lighting stick.
Light the match.
3.
Once lit, place the flame to reach the burner ports. (See diagram to right.)
4.
Press the control knob and rotate it counterclockwise to the ‘’HIGH’’
position. The burner should light immediately.
5.
Adjust burner to the desired cooking temperature.
Observe flame height when lit: Flame should be a blue/yellow color between
1 to 2 inches
high.
Confirm that the burner is properly lit and that the flame pattern is as desired (see fig. A, B and C below for the proper flame
patterns). If the flame pattern is other than normal, consult the Troubleshooting on page 21 for corrective action.
FIG.A FIG.B FIG.C
2 in.
1 in.
0
in.
Normal: Soft blue flames with yellow
tips between I inch - 2 inches high.
Out of adjustment: Noisy hard blue
flames – too much air.
Poor combustion: Wavy, yellow
flames- too little air.

GSS3219B
Owner’s Manual 19
Burner installation and adjustment
Lighting Infrared Burner
1. Open lid while lighting burner.
2. Make sure the control knob is locked in the OFF position.
3. Open cylinder valve.
4. Push and turn control knob to HIGH setting. After lighting, please observe the ceramic plate on the surface of burner; it
should feel warm after 5-10 seconds and the color of the ceramic plate should turn red in 2-3 minutes.
5. If burner does not light on the first try, turn the control knob to its OFF position and wait 5 minutes for gas to clear before
trying again. If burner flame goes out during operation, immediately turn the gas OFF and open lid to let the gas clear for
about 5 minutes. Attempt to re-light.
6. Clean your grill after each use, DO NOT use abrasive or flammable cleansers, as it will damage the parts of this product and
may start a fire. Clean with warm soapy water.
Observing the Heat and Color of the Infrared Ceramic Burner when lit
●Flame of infrared burner might be visible in shaded area.
●After burner is lit, it should feel warm in 5-10 seconds and color of the ceramic plate turns red in approximately 2-3 minutes.
WARNING:
Adjusting the air-shutter while the grill is on operation. If it still hot, please wear protective gear and be careful. Failure to follow
this instruction could cause personal injury.
Flare-ups
“Flare-ups” sometimes occur when food drippings fall onto the hot heat distribution plate or burners and ignite. Some flaring is
normal and desirable as it helps impart the unique flavors associated with grilled foods. Controlling the intensity of the flare-ups is
necessary, however, in order to avoid burned or unevenly cooked foods and to prevent the possibility of accidental fire.
WARNING:
Always monitor the grill closely when cooking and turn the flame level down to LOW or OFF if flare-ups intensify.
Shutting Off Burners
1.
Always turn the valve knob(s) clockwise to the ‘’HIGH’’ position, and then press and turn it to ‘’OFF’’. Never force the knob
without pressing it. This could damage the valve.
2.
Promptly turn the gas supply to the “OFF” position at the propane cylinder.
3.
Close the lid of the grill.
Excess flow safety valve reset procedure
● The new regulators are equipped with a safety device that restricts the gas flow in the event of a gas leek. However,
unsafe practices of grill operation could activate the safety device without having a gas leak.
● A sudden shut off of the gas flow typically occurs if you open the LP tank valve rapidly, or if one or more of the burner
control knobs is in an open position when opening the LP tank valve.
● This procedure effective with all LP Tank sizes as well as Natural Gas. When performing the procedure on a Natural Gas
model, simply substitute "Natural Gas valve" for "LP Tank
● To ensure the procedure is safely and successfully performed, please carefully follow these instructions.
1. Close the LP tank valve.
2. Turn all burner control knobs to the OFF position.
3. Disconnect the regulator from the LP tank.
4. Open the lid of the grill.
5. Turn burner control knobs to HIGH.
1. Release the screw on venturi tube.
2. Adjust the flame by turning the
collar on head of venturi tube from
back side of the grill and do not take
apart the venturi tube.
3. Tighten the screw and make certain
it is secured.
1. Overlap 14 mm between
venturi tube and nozzle
when assembling.
2. Keep the center line of
venturi tube and nozzle
on one line.
End edge should face towards upside.
