OWNER’S MANUAL
Assembly & Operating Instructions
GARDEN MULCHER / CHIPPER
MODEL NO. BBT-CH-15
9000 Series Electric Start
Garden Mulcher / Chipper

2WWW.BBTA.COM.AU
To The Owner
Thank you for purchasing our Mulcher. It was carefully engineered to provide excellent performance when
properly operated and maintained.
Please read this entire manual prior to operating the Mulcher. It instructs you how to safely and easily set up,
operate and maintain your Mulcher. Please be sure that you and any other persons who will operate the Mulcher
carefully follow the recommended safety practices at all times. Failure to do so could result in personal injury or
property damage.
All information in this manual is relative to the most recent product information available at the time of printing.
Review this manual frequently to familiarise yourself with the machine, its features and operation. Please be
aware that this Owner’s Manual may cover a range of product specifications for various models. Characteristics
and features discussed and/or illustrated in this manual may not be applicable to all models. We reserve the right
to change product specifications, designs and equipment without notice and without incurring obligation.
All the power testing information used to establish the power rating of the engine equipped on this Mulcher can
be found in the engine manufacturer’s manual or website. If you have any problems or questions concerning the
machine, please contact our Customer Support Department.
Throughout this manual, all references to right and left side of the Mulcher are observed from the operating
position. The engine manufacturer is responsible for all engine-related issues with regards to performance,
power-rating, specifications, warranty and service. Please refer to the engine manufacturer’s Owner’s Manual
packed separately with your Mulcher for more information.
Customer Support
Please do NOT return the Mulcher without first contacting the Customer Support Department at
[email protected].
If you have difficulty assembling this product or have any questions regarding the controls, operation, or
maintenance of this Mulcher, please contact our Customer Support Department.
SAVE THESE INSTRUCTIONS
BBT-CH-15

3
WWW.BBTA.COM.AU
TABLE OF CONTENTS
Page(s)
To The Owner...................................................................................................... 2
Customer Support............................................................................................... 2
TABLE OF CONTENTS ............................................................................... 3
IMPORTANT SAFETY INFORMATION ....................................................4-5
Additional Information and Potential Changes................................................ 4
Key to Symbols.................................................................................................... 5
SAFETY INFORMATION ............................................................................ 6
Before Operating the Unit for the First Time ................................................... 6
Preparation ......................................................................................................... 6
Safety Label Locations ........................................................................................ 7
Safety Information.............................................................................................. 7
Operator Responsibility...................................................................................... 7
ASSEMBLY................................................................................................. 7
OPERATING GUIDELINES.......................................................................... 8
OPERATING INSTRUCTIONS ..................................................................... 9
Add Petrol and Oil .............................................................................................. 9
Starting the Engine............................................................................................. 9
Using the Chipper Shredder............................................................................... 9
ASSEMBLY..........................................................................................10-12
MAINTENANCE AND STORAGE........................................................ 13-15
Maintenance Schedule ..................................................................................... 13
Maintenance and Storage................................................................................ 13
Removing and Sharpening the Blade.............................................................. 14
Changing or Tightening the Belt ..................................................................... 14
Cleaning the Chipper/Shredder........................................................................ 15
Storing the Chipper/Shredder .......................................................................... 15
TROUBLESHOOTING............................................................................... 16
WARRANTY & SERVICE .......................................................................... 17
SPECIFICATIONS...................................................................................... 17
EXPLODED DIAGRAM & PARTS LIST.................................................18-19
YOU MAY ALSO LIKE ............................................................................. 20
BBT-CH-15

4WWW.BBTA.COM.AU
IMPORTANT SAFETY INFORMATION
Additional Information and Potential Changes
We reserve the right to discontinue, change, and improve our products at any time without notice or obligation
to the purchaser. The descriptions and sections contained in this manual were in effect at the time of printing.
Equipment described within this manual may be optional. Some illustrations may not be applicable to your
machine.
WARNING: Read and thoroughly understand all instructions in this manual and on the safety decals
before assembling or operating this Mulcher. Failure to do so may cause serious injury or death. Do
not allow anyone to operate this Mulcher who has not read this manual. As with all power equipment,
a Mulcher can be dangerous if assembled or used improperly. Do not operate this Mulcher if you
have any questions concerning its safe operation. To get answers to any questions, call our Customer
Support Department.
This SAFETY ALERT SYMBOL identifies important safety messages in this manual. Failure to follow
this important safety information may result in serious injury or death.
DANGER! This Mulcher was built to be operated according to the safe operation practices in this
manual. As with any type of power equipment, carelessness or error on the part of the operator can
result in serious injury. This Mulcher is capable of amputating hands and feet and throwing debris.
Failure to observe the following safety instructions could result in serious injury or death.
The following signals, words and meanings are intended to explain the levels of risk associated with this product.
DANGER indicates a hazardous situation which, if not avoided, will result in serious injury or
death.
WARNING indicates a hazardous situation which, if not avoided, could result in serious injury
or death.
CAUTION indicates a hazardous situation which, if not avoided, could result in minor or
moderate injury.
NOTICE is important information about the proper use of your Mulcher. Failure to follow this
instruction could result in damage to your Mulcher or property.
WARNING! Your Responsibility—Restrict the use of this power machine to persons who have read,
understood and will follow the warnings and instructions in this manual and on the machine.
SAVE THESE INSTRUCTIONS!
BBT-CH-15

5
WWW.BBTA.COM.AU
IMPORTANT SAFETY INFORMATION
Key to Symbols
Symbol Description
READ THE OWNER’S MANUAL(S)
Read, understand and follow all instructions in the manual(s) before attempting to
assemble and operate.
FACE PROTECTION
Always wear safety goggles or safety glasses with side shields or a face shield when
operating this product as well as ear protection.
WEAR GLOVES
Always wear non-slip, heavy-duty protective gloves when operating this product.
WEAR SAFETY FOOTWEAR
Always wear non-slip steel-toed safety footwear when operating this product.
BEWARE OF ROTATING BLADES
This machine has a rotating cutting blade capable of amputating hands and feet and
throwing objects. Keep hands and feet out of openings while machine is running.
Failure to observe these safety instructions could result in serious injury or death.
BEWARE OF FLYING OBJECTS
Beware of thrown objects, which can ricochet causing serious injury to the eyes.
Always wear eye & ear protection when operating.
CARBON MONOXIDE AND GAS
Exhaust contains poisonous carbon monoxide, a colourless and odourless gas.
Breathing exhaust fumes can cause loss of consciousness and may lead to death.
BYSTANDERS
Keep bystanders, helpers, pets, and children at least 25m from the machine while it
is in operation. Stop machine if anyone enters the area.
PETROL OIL
Petrol is extremely flammable and the vapours are explosive. Serious personal injury
can occur when petrol is spilled on you or your clothing, which can ignite. In the
event of a petrol spill, wash your skin and change clothes immediately.
NEVER wear loose clothes or long jewellery and keep your long hair secured when
operating machine. Never operate this machine in bare feet or sandals.
Never use machine on a slope or hard smooth floor.
DO NOT operate this machine unless the chute deflector has been installed properly.
DO NOT deposit branches larger than 85mm into the top chute.
DO NOT force the branches into this machine; allow the machine to automatically
feed through.
25M
BBT-CH-15

6WWW.BBTA.COM.AU
SAFETY INFORMATION
1. Read, understand, and follow all instructions on the machine and in the manual before attempting to
assemble and operate. Keep this manual in a safe place for future and regular reference and for ordering
replacement parts.
2. Make yourself familiar with all controls and their proper operation. Know how to stop the machine and
disengage them quickly.
3. NEVER allow children under 18 years old to operate this machine. Individuals 18 years old and over should
read and understand the operation instructions and safety rules in this manual prior to operation.
4. NEVER allow adults to operate this machine without proper instruction.
5. Keep bystanders, helpers, pets, and children at least 25 metres from the machine while it is in operation.
Stop the machine if anyone enters the area.
6. NEVER run an engine indoors or in a poorly ventilated area. Engine exhaust contains carbon monoxide, an
odourless and deadly gas.
7. DO NOT put hands or feet near rotating parts or in the feeding chambers and discharge opening. Contact
with the rotating impeller can amputate fingers, hands, and feet.
8. NEVER attempt to unclog either the feed intake or discharge opening, remove or empty bag, or inspect and
repair the machine while the engine is running. Shut the engine off and wait until all moving parts have
come to a complete stop. Disconnect the spark plug wire and ground it against the engine.
1. Thoroughly inspect the area where the chipper/shredder is to be used. Remove all rocks & foreign objects
which could be picked up or thrown and cause personal injury or damage to the machine.
2. Avoid discharging chipped material out of the discharge chute against a wall or on asphalt, concrete, or
other hard surfaces as material being ejected could ricochet, causing injury to you or bystanders.
3. Always wear protective eye gear during operation or while performing an adjustment or repair.
4. Wear sturdy, rough-soled work shoes and close fitting pants and shirts. Loose fitting clothing or jewellery
can be caught in movable parts. Wear leather work gloves when feeding material in the chipper chute.
5. Before starting the engine, check bolts and screws for proper tightness to be sure the machine is in safe
working condition. Also, visually inspect the chipper/shredder at frequent intervals for any damage.
6. Maintain or replace safety and instruction labels, as necessary.
7. To avoid personal injury or property damage use extreme care in handling fuel.
a. Use only an approved fuel container.
b. Extinguish all cigarettes, cigars, pipes, and other sources of ignition.
c. NEVER add fuel to machine indoors.
d. NEVER remove fuel cap or add fuel while the engine is hot or running.
e. Allow engine to cool for at least 2 minutes before refuelling.
f. NEVER over fill fuel tank. Leave at least 15mm of space below filler neck to provide space for fuel
expansion.
g. Tighten fuel cap securely.
h. If fuel is spilled, wipe it off the engine and equipment. Move machine to another area and wait 5 minutes
before starting the engine.
i. NEVER store machine or fuel container inside, near an open flame, spark, or pilot light (e.g. furnace,
water heater, space heater, clothes dryer, etc.).
j. To reduce the fire hazard, keep machine free of grass, leaves, or other debris build- up. Clean up oil or
fuel spills and remove any fuel soaked debris.
k. Allow machine to cool at least 5 minutes before storing.
8. NEVER attempt to make any adjustments while the engine (motor) is running (except where specifically
recommended by the manufacturer).
Before Operating the Unit for the First Time
Preparation
BBT-CH-15

7
WWW.BBTA.COM.AU
Safety Label Locations
These labels warn you of potential hazards that can cause serious injury. Read them carefully.
Safety Information
This product is designed to give safe and dependable service if operated according to instructions. Read and
understand this owner’s manual before operating your power equipment.
Operator Responsibility
Know how to stop your power equipment quickly in case of emergency. Understand the use of all controls and
connections. Be sure that anyone who operates this power equipment receives proper instruction.
DO NOT let children operate the power equipment.
1. Remove the chipper from its carton.
Cut strapping, remove corner supports including at base of unit, lift the carton to remove.
2. Remove all parts located inside mulching chute and around base of unit.
Ensure all parts are in the chipper carton.
• Engine and body (pre-assembled)
• Hopper
• 2 x Wheels
• Front Support Leg
• Hardware Bag
• Handle Bars
• Axle
3. Attach the handles
Remove the nut and one washer from each bolt provided with the handles. Insert the handle bolts into the
corresponding holes in the hopper. Secure the handles in place with the washer and nut on the inside of the
hopper. Tighten the nuts using the 13mm spanner provided.
4. Attach the axle
Remove the bolts, washers, spring washers and nuts from inside the axle holes. Line up the holes in the axle
with those in the mulcher base and secure with these nuts, bolts and washers. Tighten nuts using the 13mm
spanner provided.
5. Attach the Wheels
Remove the lock nuts on the axle. When installing wheels, ensure that the tyre inflation valves are on the
outside. Place wheels on axle and secure with lock nut
6. Attach the Front Support Leg
Remove the front support pin and tube. Open the bottom section of the discharge chute fully. Line up the
holes in the front support leg with those in the bottom discharge chute. Re-insert the front support tube and
pin with the bolts to secure the support leg. Tighten.
7. Attach Hopper and discharge chute.
SAFETY INFORMATION
ASSEMBLY
BBT-CH-15

8WWW.BBTA.COM.AU
OPERATING GUIDELINES
1. DO NOT put hands and feet near rotating parts or in the feeding chambers and discharge opening. Contact
with the rotating impeller can amputate fingers, hands and feet.
2. Before starting the machine, make sure the chipper chute, feed intake, and cutting chamber are empty and
free of all debris.
3. Thoroughly inspect all material to be shredded and remove any metal, rocks, or other foreign objects which
could cause personal injury or damage to the machine.
4. If it becomes necessary to push material through the shredder hopper, use a small diameter stick. Do not use
your hands or feet.
5. If the impeller strikes a foreign object or if your machine should start making an unusual noise or vibration,
immediately shut the engine off. Allow the impeller to come to a complete stop. Disconnect the spark plug
wire, ground it against the engine and perform the following steps:
a. Inspect for damage.
b. Repair or replace any damaged parts.
c. Check for any loose parts and tighten to assure continued safe operation.
6. DO NOT allow an accumulation of processed material to build up in the discharge area. This can prevent
proper discharge and result in kickback of material through the feed opening.
7. DO NOT attempt to shred or chip material larger than specified on the machine or in this manual. Personal
injury or machine damage could result.
8. NEVER attempt to unclog either the feed intake or discharge opening while the engine is running. Shut the
engine off, wait until all moving parts have stopped, disconnect the spark plug wire and ground it against
the engine before clearing debris.
9. NEVER operate without the hopper, chipper chute, or discharge chute properly attached to the machine.
10. NEVER empty or change discharge bag while the engine is running. Stop the engine when leaving the
operating position.
11. Keep all guards, deflectors and safety devices in place and operating properly.
12. Keep your face and body back and to the side of the mulcher chute while feeding material into the machine
to avoid accidental kickback injuries.
13. NEVER operate this machine without good visibility or light.
14. DO NOT operate on a non-level surface.
15. DO NOT operate in a confined space.
16. DO NOT operate this machine while under the influence of alcohol or drugs.
17. DO NOT touch the muffler and engine as they become hot and can cause a burn.
18. NEVER pick up or carry machine while the engine is running.
19. DO NOT leave the machine running while unattended.
20. Keep children, bystanders, and pets 25m away.
21. Use only manufacturer approved accessories/attachments.
READ THESE OPERATING GUIDELINES BEFORE YOU PROCEED ANY FURTHER
This machine was built to be operated according to the rules for safe operation in this manual. As with any
type of power equipment, carelessness or error on the part of the operator can result in serious injury.
Always wear hearing and eye protection while operating this machine or if you are within 25 metres of
this machine.
BBT-CH-15

9
WWW.BBTA.COM.AU
OPERATING INSTRUCTIONS
IMPORTANT: This unit is shipped without petrol or oil in the engine. Be certain to fill the engine with petrol
and oil as instructed before operating your machine.
Add Petrol and Oil
Step 1: Add petrol (recommended 95 - 98 unleaded)
Step 2: Add approximately 1.1 litres of SAE30 engine oil until the oil is about to overflow from the oil fill spout.
A low oil sensor will prevent the engine from running unless the oil is COMPLETELY FULL. Ensure both
oil fill plugs are secure after filling.
NEVER fill fuel tank indoors, with engine running or until the engine has been allowed to cool for at
least 2 minutes after running.
Using the Chipper Shredder
Yard waste such as leaves and pine needles should be feed through the chipper chute along with a branch to
help push it through the hopper for shredding.
It is important to let the chipper feed the branches through automatically.
Be careful not to overload the machine. If the machine becomes overloaded stop feeding the machine and allow
for the machine to clear itself.
DO NOT attempt to force the branches through. If the branches do not automatically feed through, gently push
the branch and then allow the chipper to automatically feed the branch through. Forcing branches into the side
chute may wear the belt prematurely.
Once material is shredded by the hammers on the impeller assembly, it is discharged through the open discharge
chute or into the chipper bag.
DO NOT attempt to shred or chip any material other than normal yard vegetation found (i.e., branches, leaves,
twigs, etc.)
IMPORTANT: For best performance, it is also important to keep the chipper blade sharp.
BBT-CH-15
Starting the Engine
Step 3: Attach spark plug wire to spark plug. Make certain the metal cap on the end of the spark plug is
fastened securely over the metal tip on the spark plug.
Step 4: Move choke lever on engine to CHOKE position. (A warm engine may not require choking).
Step 5: Turn the fuel valve to the ON position.
Step 6: Electric Start: Turn key to ON position, then to START.
Pull-Start: Turn Key to ON position. Grasp starter handle and pull rope out slowly until engine reaches
start of compression cycle (rope will pull slightly harder at this point). Pull rope with a rapid, continuous,
full arm stroke. Keep a firm grip on starter handle. Let the rope rewind slowly. Repeat the previous
steps until engine fires.
Rapid retraction of the recoil starter cord can pull the starter cord back faster than you can let go.
When starting the engine, pull the cord slowly until resistance is felt then pull rapidly to avoid kickback.
Step 7: When engine starts, move choke control gradually to the RUN position.
NOTE: A noise will be heard when finding the start of the compression cycle. This noise is caused by the
flails and fingers, which are part of the shredding mechanism, and should be expected until the impeller
reaches full speed.
Step 8: After engine is started, gradually release choke.

10 WWW.BBTA.COM.AU
ASSEMBLY
Attachment
Step 1: Attach the inflatable wheels (1) as shown in the picture. On the axle shaft by using bolt (3) and washer
(2), fix the shock pad (6) on the corresponding holes of frame by using bolt (7), washer (5) and nut (4).
DO NOT place hands or any other body parts within a radius of cutter wheel rotary. DO NOT touch the
blades with your hands or any other body parts.
1. Inflatable Wheels
2. Flat Washer
3. Bolt M8X20
4. Nut
5. Flat Washer
6. Shock Pad
7. Bolt M8X25
BBT-CH-15

11
WWW.BBTA.COM.AU
Pic 2. Hopper and Discharge Port Installation
Step 2: Connect the hinge of hopper (12) and discharge port (13) to the crusher room frame and affix with
bolt (7).
ASSEMBLY
8. Frame
9. Motor
10. Cutter Wheel
11. Belt Cover
12. Hopper
13. Discharge Port
14. Spring Washer
BBT-CH-15

12 WWW.BBTA.COM.AU
ASSEMBLY
Pic 3. Handley and Hand Wheel Installation
Step 3: Insert handle (16) into the corresponding holes on the frame, then through the holes of frame and
handle (16) by using knob (17) to fix it tightly. When fixing the Hand wheel (18) please ensure that the keyways
on both the handle (18) and the Frame are aligned and connect properly. Using both Bolt (3) Washer (2) to attach
the hand wheel in place (18).
15. Crusher Room 16. Handle 17. Knob 18. Hand Wheel
BBT-CH-15

13
WWW.BBTA.COM.AU
MAINTENANCE AND STORAGE
Maintenance Schedule
Before each use 20hrs or
every 3 months
50hrs or
every 3 months
100hrs or
every 6 months
300hrs or
every 1 years
Engine Oil (Check) X
Engine Oil (Change) X
Air Cleaner (Check) X
Air Cleaner Wash X
Fuel Filter Cap (Clean) X
Spark Plug (Clean) X
Spark Plug (Change) X
Check Chipper Blade X
Fuel Tank and Filter
(Clean)
X
Always stop engine, disconnect spark plug and ground against engine before cleaning, lubricating or
doing any kind of maintenance on your machine.
Maintenance and Storage
1. NEVER tamper with safety devices. Check their proper operation regularly.
2. Check bolts and screws for proper tightness at frequent intervals to keep the machine in safe working
condition. Also, visually inspect machine for any damage and repair, if needed.
3. Before cleaning, repairing or inspecting, stop the engine and make certain the impeller and all moving
parts have stopped. Disconnect the spark plug wire and ground it against the engine to prevent unintended
starting.
4. Maintain or replace safety and instruction labels as necessary.
5. Follow this manual for safe loading, unloading, transporting, and storage of this machine.
6. NEVER store the machine or fuel container inside where there is an open flame, spark or pilot light such as a
water heater, furnace, clothes dryer, etc.
7. Always refer to the owner’s manual for proper instructions on off-season storage.
8. If the fuel tank has to be drained, do this outdoors.
9. Observe proper disposal laws and regulations for petrol, oil, etc. to protect the environment.
Always stop engine, disconnect spark plug and ground against engine before cleaning, lubricating or
doing any kind of maintenance on your machine.
BBT-CH-15

14 WWW.BBTA.COM.AU
MAINTENANCE AND STORAGE
Removing and Sharpening the Blade
• Disconnect the spark plug wire and ground against the engine.
• Remove chute and rotate the blade to align with the access hatch.
• Remove the blade using an Allen key on the outside of the blade and an adjustable wrench on the impeller
assembly (through the discharge chute). Use a piece of pipe or wood to block the hammer blades, preventing
them from inadvertently turning.
• Replace or sharpen the blade as desired.
• When sharpening the blade, protect hands by using gloves.
Changing or Tightening the Belt
Occasionally, changing or tightening the belt is required.
To change the belt:
• Stop the engine and make certain the blades have come to a complete stop. Disconnect the spark plug wire
from spark plug and ground against the engine.
• Remove the belt guard.
• Loosen engine mount bolts and release belt tension.
• Pry the belt off the pulley using a screw driver shaft as a wedge as you rotate the pulley.
• Place a new belt on the pulleys in a similar fashion.
To tighten the tension on the pulleys, follow the above steps plus:
• Scribe a mark on the base plate along the edge of the engine.
• Remove the belt from the pulleys.
• Remove the upper discharge chute and mulcher screen.
• Loosen the four bolts securing the engine.
• Slide the engine about 1/8” further back.
• Tighten the engine mounting bolts securely.
• Re-install the belt and verify the tension. If the belt is still too loose, move the engine back another 3mm by
repeating the above steps.
• Reinstall guards and chute.
NOTE: Make certain the blade is reassembled with the sharp edge facing upward.
NOTE: The belt is designed to be the weakest link in the mechanical linkage between the engine and the
blade. This improves the safety and durability of the chipper/shredder.
BBT-CH-15

15
WWW.BBTA.COM.AU
MAINTENANCE & STORAGE
Cleaning the Chipper/Shredder
• Make sure engine is off.
• Wipe off machine with an oiled rag to prevent rust.
• If the fuel tank has to be drained, do so outdoors.
• Observe proper disposal laws and regulations for petrol, oil, etc., to protect the environment.
Storing the Chipper/Shredder
• Clean the equipment thoroughly.
• Wipe equipment with an oiled rag to prevent rust.
• Refer to engine manual for correct engine storage instructions.
• Store unit in a clean, dry area. Do not store next to corrosive materials such as fertilizer.
• NEVER store the machine or fuel container inside where there is an open flame, spark or pilot light such as a
water heater, furnace, clothes dryer, etc.
BBT-CH-15

16 WWW.BBTA.COM.AU
TROUBLESHOOTING
PROBLEM CAUSE REMEDY
Engine fails to start 1. Spark plug lead disconnected.
2. Fuel tank empty or stale fuel.
3. Throttle control lever not in
correct starting position.
4. Choke not in CHOKE position.
5. Fuel supply in OFF position.
6. Blocked fuel line.
7. Faulty spark plug.
8. Low oil level.
1. Connect lead to spark plug.
2. Fill tank with clean, fresh petrol.
3. Move throttle lever to FAST
position.
4. Move choke to CHOKE position.
5. Turn fuel to ON.
6. Clean fuel line.
7. Clean, adjust gap, or replace.
8. Fill.
Engine runs erratic 1. Spark plug lead loose.
2. Unit running on CHOKE.
3. Blocked fuel line or stale fuel.
4. Water or dirt in fuel system.
5. Dirty air cleaner.
6. Carburettor out of adjustment.
1. Connect and tighten spark plug
lead.
2. Move choke lever to OFF position.
3. Clean fuel line; fill tank with
clean, fresh fuel.
4. Drain fuel tank. Refill with fresh
fuel.
5. Clean or replace air cleaner.
6. See authorised service dealer.
Too much vibration 1. Loose parts or damaged impeller. 1. See authorised service dealer.
Engine overheats 1. Engine oil level low.
2. Dirty air cleaner.
3. Carburettor not adjusted properly.
1. Fill crankcase with oil.
2. Clean or replace air cleaner.
3. See authorised service dealer.
Occasional skip
(hesitates)
1. Spark plug gap too close. 1. Adjust gap.
Unit does not discharge 1. Hopper blocked.
2. Foreign object lodged in impeller.
3. Low engine RPM.
1. Stop engine immediately and
disconnect spark plug lead.
Remove hoppers and clear the
blocked material.
2. Stop engine and disconnect spark
plug lead. Remove lodged object.
3. Always run engine at full throttle.
Rate of discharge slows 1. Low engine RPM.
2. Chipper blade dull.
1. Always run engine at full throttle.
2. Replace chipper blade or see your
authorised service dealer.
BBT-CH-15

17
WWW.BBTA.COM.AU
SPECIFICATIONS
MODEL BBT-CH-15
Maximum RPM 3600 RPM
Horsepower 15 HP
Fuel Type Unleaded 95 Octane or higher
Fuel Capacity 6.5L
Oil Type SAE30
Oil Capacity 1,100ml
Engine Type JD
Displacement 420cc
Start Type Electric Start & Pull Start
Chipper YES
Mulcher NO
Maximum Cutting Thickness Diameter 85mm
Technical Data subject to change without notice.
WARRANTY & SERVICE
Warranties
Bigger Boyz Toyz offer a 1-year parts warranty on all products used for domestic use from the date of purchase.
For all commercial use, a 3-month parts warranty period applies, unless specified in the item listing. All conditions
below are based upon the product being faulty or not performing as described. In the instance where a return
is required, the purchaser is liable for any shipping cost. Warranties will only be determined by a Bigger Boyz
Toyz Technician upon inspection.
Warranties do not cover accidents, misuse, neglect, natural disaster or act of God or other external causes, or
damage caused by operating the equipment in a manner that is not described in the instructions.
Our products come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled
to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or
damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
Parts purchases, consumable components and accessories such as chains, carry bags, batteries, hoses, grinding
discs, covers, belts, cable, wheels and blades are not covered by standard warranty.
Spare Parts
Spare parts are available. Please see our website (www.bbta.com.au) or contact us at [e-mail] for more
details.
NOTE: Due to continuous product improvement, we reserve the right to
change the product without prior notice
BBT-CH-15

18 WWW.BBTA.COM.AU
EXPLODED DIAGRAM & PARTS LIST
BBT-CH-15
NO SKU DESCRIPTION QTY
1SP-CH-15-001 Base Components 1
2SP-CH-15-002 Wheel 2
3SP-CH-15-003 Washer 5
4SP-CH-15-004 Hexagon Head Bolt 16
5SP-CH-15-005 Rubber Blanket 2
6SP-CH-15-006 Support Frame 2
7SP-CH-15-007 Hexagon Head bolt 4
8SP-CH-15-008 Flat Washer 33
9SP-CH-15-009 Spring Washer 24
10 SP-CH-15-010 Lock Nut 20
11 SP - CH -15 - 011 Hexagon Head Bolt 7
12 SP-CH-15-012 Power Regulating plate assembly 1
13 SP-CH-15-013 Engine 1
14 SP-CH-15-014 Cup Head Screw 4
15 SP-CH-15-015 Screw Rod 1
16 SP-CH-15-016 Flat Washer 2
17 SP-CH-15-017 Regulating Handle 1
18 SP-CH-15-018 Hexagon Head Bolt 5
19 SP-CH-15-019 Flat Key 1
20 SP-CH-15-020 Flat Washer 1
21 SP-CH-15-021 Crusher Room Components 1
22 SP-CH-15-022 Hexagon Socket Screw 8
23 SP-CH-15-023 Top Plate Component 2
24 SP-CH-15-024 Hexagon Socket Screw 1
25 SP-CH-15-025 Blade Drum Components 15
26 SP-CH-15-026 Top Plate Component 1
27 SP-CH-15-027 Hexagon Head Bolt 8
28 SP-CH-15-028 Bearing Block 2
29 SP-CH-15-029 Bearing Sleeve 4
30 SP-CH-15-030 Big Belt Pulley 1
31 SP-CH-15-031 Flat Key 1
32 SP-CH-15-032 Washer 1
33 SP-CH-15-033 Hexagon Head Bolt 1
34 SP-CH-15-034 Vice Belt Cover Board Components 1
35 SP-CH-15-035 Belt 2
36 SP-CH-15-036 Hexagon Head Bolt 2
37 SP-CH-15-037 Flat Washer 4
38 SP-CH-15-038 Vice Belt Cover Board Fixed Plate 1
NO SKU DESCRIPTION QTY
39 SP-CH-15-039 Shaft Retaining Ring B Shape 1
40 SP-CH-15-040 Small Pulley Shaft Sleeve 1
41 SP-CH-15-041 Flat Key 1
42 SP-CH-15-042 Small Pulley Belt 1
43 SP-CH-15-043 Flat Washer 1
44 SP-CH-15-044 Hexagon Head Bolt 1
45 SP-CH-15-045 Blade Adjustment Block 1
46 SP-CH-15-046 Spring Washer 32
47 SP-CH-15-047 Flat Washer
48 SP-CH-15-048 Splash Plate Clamp 1
49 SP-CH-15-049 Splash Plate 1
50 SP-CH-15-050 Infeed Hopper Components
51 SP-CH-15-051 Handle 1
52 SP-CH-15-052 Knob 2
53 SP-CH-15-053 Locknut 21
54 SP-CH-15-054 Outlet Hopper Components 1
55 SP-CH-15-055 Outer Hopper Adjusting Block 1
56 SP-CH-15-056 Lock Nut 4
57 SP-CH-15-057 Hexagon Head Belt 2
58 SP-CH-15-058 Half- Round Head Square Neck Bolt 2
59 SP-CH-15-059 Bearing Block Cap 1
60 SP-CH-15-060 Belt Cover 1
61 SP-CH-15-061 Spring Washer 4
62 SP-CH-15-062 Spring Pin 2
63 SP-CH-15-063 Baffle Plate 2
64 SP-CH-15-064 Hexagon Head Bolt 2
65 SP-CH-15-065 Switch Board 1
66 SP-CH-15-066 Switch Box 1
67 SP-CH-15-067 Flat Washer 2
68 SP-CH-15-068 Hexagon Head Bolt 2
69 SP-CH-15-069 Emergency Stop Watch 1
70 SP-CH-15-070 Cable 1
71 SP-CH-15-071 Switch Box Cover 1
72 SP-CH-15-072 Tapping Screw 4
73 SP-CH-15-073 Screw Thread 1
74 SP-CH-15-074 Self-Lock Button 1
75 SP-CH-15-075 Hitch Trailer 1
76 SP-CH-15-076 Hexagon Head Bolt 1
Component Parts Diagram

19
WWW.BBTA.COM.AU
EXPLODED DIAGRAM & PARTS LIST
BBT-CH-15

Cultivators / Tillers
Lawn Mowers Log Splitters
YOU MAY ALSO LIKE
Chainsaws
COPYRIGHT © BIGGER BOYZ TOYZ AUSTRALIA PTY
Unit 2/3 Delta Place Albion Park Rail NSW 2527
BBT-CH-15-MNL1902
