Salsco HP11 Product manual

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 1 -

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 2 -
TABLE OF CONTENTS
MODEL HP11, GAS GREENS ROLLER
COVER & TABLE OF CONTENTS…………………………………………………………………………….
Page 1 – 2
STATEMENT OF FACT……………………………………………………………………………………………
Page 3
SPECIFICATIONS & FEATURES……………………………………………………………………………….
Page 4
MACHINE REGISTRATION……………………………………………………………………………………..
Page 5
SAFETY & OPERATING INSTRUCTIONS………………………………………………………………….
Page 6
SERVICE & MAINTENANCE INSTRUCTIONS……………………………………………………………
Page 7
PARTS DIAGRAMS…………………………………………………………………………………………………
Page 8 – 26
TORQUE CHARTS………………………………………………………………………………………………….
Page 27
WARRANTY POLICY/PROCEDURE………………………………………………………………………….
Page 28
WARRANTY CLAIM FORM…………………………………………………………………………………….
Page 28
DEALER DELIVERY REPORT & WARRANTY CARD…………………………………………………..
Page 30
SERVICE INTERVAL SCHEDULE………………………………………………………………………………
Page 31
SERVICE SCHEDULE LOG……………………………………………………………………………………….
Page 32
SALSCO, INC.
105 School House Road
Cheshire, CT 06410
800-872-5726, 203-271-1682
203-271-2596 (Fax)
www.salsco.com, [email protected]

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 3 -
STATEMENT OF FACT
You have just purchased the highest quality, most maneuverable,
dependable, GREENS ROLLER on the market today. This unit has the ability to
meet exact standards and perform for years with minimum downtime.
HOWEVER, it cannot read nor will it understand this manual no matter how
long you leave it on top of the machine.
It is your responsibility to read and understand this manual; it is also your
responsibility to be certain this information is passed along to anyone who is
expected to operate this equipment. Should you choose not to read,
understand and pass along the information provided you, please expect
equipment failure and possible injuries to persons around this equipment.
For the safety of the operator, it is imperative that this manual is carefully
read and understood.
Once you have read this manual, it is your responsibility to be sure that all
new operators read and understand this manual, especially all cautions
stated.
As a manufacturer of equipment, we have a responsibility to design a safe
piece of equipment. NOTE: The important safeguards and instructions in this
manual are not meant to cover all possible conditions and situations that may
occur. It must be understood that common sense, caution, and care are
factors, which cannot be built into any product. These factors must be
supplied by the person(s) caring for and operating this equipment.
ONLY YOU CAN PREVENT ACCIDENTS!!

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 4 -
SPECIFICATIONS AND FEATURES
GAS GREENS ROLLER – MODEL HP11
The Salsco Greens Roller is actually a multi-purpose tool, which, in a short time, has
become a must-have for many golf courses. Our unit can be used on GREENS, WET OR
DRY, and will increase speed an average of 1-2 feet. However, that's only part of the
story. We can ROLL SOD, CLAY TENNIS COURTS, CART PATHS, SUB BASE FOR NEW
GREENS CONSTRUCTION, WET GREENS, WET SPOTS ON FAIRWAYS, etc., etc. Because
of traction and maneuverability this machine is ready and able when you are.
Drive System
A 13HP Honda Engine, electric start, powers this unit. Power is delivered to a
Hydrostatic Pump through a love-joy coupling. Fluid power is then transmitted
through 2,500 P.S.I. (10,000-lb. burst) hoses to drive motors. Drive motors change
fluid power to mechanical power and transmit it through #50 chain to the rolls. We
drive both 10-3/4" diameter rolls. This gives us the best traction in the roller business.
Compaction is not an issue at 5.4 P.S.I. (a 200 lb. person = 12.5 P.S.I.)
Compaction is Never a Problem
5.4 P.S.I. puts compaction at the lowest possible level. We want to smooth out the
surface, not change it or compact it. Both rollers can be filled with water which will
add approximately 128 lbs. and 1.4 P.S.I. to the already 5.4 P.S.I. = 6.8 P.S.I. for rolling
out frost heaves, tees or after verti-draining.
The Salsco Roller is very user friendly, with automotive type steering and smooth pedal
controls. Operators spend very little time getting comfortable with this machine,
usually before the first green is done.
The Salsco Greens Roller comes standard with its own trailer. When not in use with
the Greens Roller, it can be used for many other tasks. An example would be for
transporting greens mowers from green to green.
03/2011

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 5 -
MACHINE REGISTRATION
MANUFACTURED BY: SALSCO, INC.
105 School House Rd., Cheshire, CT 06410
800-872-5726, 203-271-1682, 203-271-2596 (Fax)
[email protected] www.salsco.com
THIS MANUAL COVERS MODEL (s): MODEL HP11 - GAS GREENS ROLLER
This company reserves the right to discontinue, add improvements to, or change the design of
any model or product at any time without obligation to improve existing machines, either by
changing the design or adding new parts.
It has been and will continue to be the policy of SALSCO to update existing machines at its own
discretion. Whenever possible, new designs will be made in such a way that they can be "Retro
Fit" if so desired.
Record in the space provided below the model and serial number of this unit. Please retain
these numbers for future reference.
No parts orders will be accepted WITHOUT MODEL NUMBERS OR PART NUMBERS. All part
numbers are listed in this manual.
Serial Number ______________________________ Model Number___________
NOTE: Be sure to complete your warranty card. This will insure immediate processing of any
warranty claims.
READ AND UNDERSTAND THIS MANUAL BEFORE STARTING MACHINE
03/2011

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 6 -
SAFETY INSTRUCTIONS
1. NEVER leave unit running while unattended.
2. NEVER park on a green for any reason.
3. NEVER go down steep hills sideways. ALWAYS approach hills straight on.
4. NEVER change your mind mid-way down a steep incline. Once you've started down a steep
incline, change direction only with the greatest of care and gentlest touch.
5. Allow engine to cool for several minutes before filling with fuel, since fuel tank is over the
engine.
NOTE: HONDA ENGINES - ALWAYS TURN OFF THE FUEL SHUTOFF, WHEN THE ENGINE IS NOT
RUNNING, i.e. WHEN IN TRANSPORT, STORAGE, ETC.
OPERATING INSTRUCTIONS
1. Check that the unit has been serviced and all fluids are checked and topped off.
2. Check all hydraulic hose fittings.
3. Push fuel shut off switch to on position.
4. Push choke to full on position
5. Push throttle to just above idle.
6. Turn on/off switch to on position.
7. You should start engine from seat position. Just reach down to engine controls. Keep feet
off pedals. Hydrostatic drive should come to neutral when engine starts.
8. Pull rope and engine will come to life. Hydrostatic transmission should come to neutral
when engine is started. REMEMBER: RIGHT PEDAL TO GO RIGHT, LEFT PEDAL TO GO LEFT.
9. Slide choke to full off position.
10. Once unit is running at just above idle, push pedal down slowly. Unit will begin to move.
Drive it out of trailer on to grass area.
11. Since the unit is hydrostatic, engine should run at full R.P.M. and speed should be controlled
by pressure on the pedal.

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 7 -
SERVICE & MAINTENANCE INSTRUCTIONS
1. Check all hydraulic hoses DAILY, or before each scheduled use, for wear and any signs of
chaffing. REMINDER: Drive motor hoses should be treated as wear items and should be
replaced on a yearly basis.
2. Check all fittings for any signs of leaking DAILY, or before each scheduled use.
3. Check all grease fittings as listed below on a WEEKLY basis, and grease as necessary. (Add
grease till grease leaks slightly from fitting.)
Bearings on roll housings - Quantity 4
Pivot bearing on main housing - Quantity 2
U-Joint on steering shaft - Quantity 1
4. Check engine to manufacturers specifications and maintenance. THIS ENGINE HAS AN OIL
SHUT OFF SWITCH. CHECK OIL LEVEL FREQUENTLY AS THE UNIT WILL STALL ON INCLINES
IF OIL LEVEL IS LOW.
5. Fill hydraulic tank to 4-6" below filler cap. Be sure to tighten cap till cap seals.
6. After approximately 1 WEEK of use, and then every 2 WEEKS thereafter, check drive chains
- one on each side on roller drive motor. Pivot motor to tighten chain. NOTE: Check and
adjust the tension of both drive motor chains on a regular basis. If chains are not tight, this
could cause severe sprocket wear and possible breakage.
7. After approximately 1 WEEK of use, and then every 2 WEEKS thereafter, check chains on
steering. Adjust as needed.
8. Pivot for articulating steering should be tight, with no play, much the same as wheel
bearings on cars.
9. Keep unit clean. Should rust form on rolls, simply drive the unit on a rough area till rolls are
clean.
10. Oil & Filter Type - It has been determined that your Salsco machine will perform better by
using a 25 micron filter. Salsco recommends using Mobil DTE 26 or Citgo HYD 68, non-
detergent hydraulic oil, or their equivalents. The oil should have a viscosity rating of at least
100 SSU. While this is not a necessity, it will improve the overall performance of your
machine. Salsco is now using this filter and hydraulic oil on all our machines using
hydraulics.
SAFETY IS A PRIME CONCERN AT SALSCO AND THE SAFETY DECALS ON YOUR MACHINE ARE A
HIGHLY VISIBLE AND CONSTANT REMINDER TO ALL OPERATORS. REPLACEMENT SAFETY
DECALS MAY BE OBTAINED BY CALLING SALSCO @ 1-800-872-5726, OR THE DEALER IN YOUR
AREA.

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 8 -

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 9 -

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 10 -

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 11 -

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 12 -

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 13 -

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 14 -

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 15 -

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 16 -

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 17 -

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 18 -

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 19 -

O:\Manuals\G.G.R. HP11-2018\GGR_HP11_Manual_Rev.10.13.2020.doc
- 20 -
