BCE Pilot Task User manual

PILOT™SEATING
Operating Instructions
Pilot™Task, Pilot™L & Pilot™Stool

Deriving Maximum
Benefit From Your
Pilot™ Tas Chair,
Pilot™ XL Chair
and Pilot™ Stool
13.0052
A. Bac Angle Adjustment
Hold the lever p to change the
back angle; drop the lever to lock
the back angle.
B. Seat Height Adjustment
To lower the seat - remain seated in
chair and raise the lever. To raise the
seat - lift body weight slightly off the
chair and raise the lever.
C. Tilt Loc Adjustment (XL/Tas )
Raise and release the lever to allow
seat and back to rock; p sh the lever
down to lock angle in place.
C. Tilt Loc Adjustment (Stool)
No free float option. Lift lever to adj st
seat angle. When lever is released it will
lock into position.
D. Bac Height Adjustment
To raise the back - grasp the lower
edge of the back and raise the back
to the desired height. To lower the back
- first raise the back to its ppermost
limit and then allow the back to fall to its
lowest limit.
E. Seat Depth Adjustment
Lift or hold lever p for movement;
release the lever to lock the seat depth.
F. Tilt Tension Adjustment
T rn the knob clockwise to increase
tension and co nterclockwise to
decrease tension.
G. Arm Options
KR72 Adjus able Loop Arm - t rn dial on
o tside of arm to raise or lower arm
height. P sh the dial backward to adj st
arm height freely.
JR77 Adjus able T-Arm - lift b tton on
o tside of arm to raise or lower arm
height. Release to lock in place.
JRPD-LA Break-Away Arm - press trigger
b tton on front of arm to raise or lower
arm height. Release to lock in place. Lift
arm assembly to drop arm back. Lift
arm foreword to its pright position and
release to lock back in the normal position.
KR300 Pilo /KR200 Task & S ool Fully
Adjus able Arm - lift b tton on side of
arm to raise or lower arm height.
Release to lock in place. Horizontal
width adj stment located nder the
seat. Lift lever to move arm assembly
to desired position, release lever.
D. bac height
E. seat
depth
F. tilt tension
adjustment
C. tilt loc
adjustment
B. seat height
adjustment
A. bac angle
adjustment
