Onespace Essential 50-LD01CO User manual

7
Essential Computer Desk, Classic Oak
ASSEMBLY INSTRUCTIONS
MODEL # 50-LD01CO
SUPPLIER CODE: JNFF
For fastest service on claims, requests for replacment parts,
www.comfortproducts.net/support
e-mail: customerservice @comfortproducts.net
Keep your sales receipt as documentation of your ownership.
CUSTOMER SERVICE
or questions, please visit our website at:

ASSEMBLYOVERVIEW
2 of 16
Desktop maximum
weight capacity
= 165lbs
Middle shelf maximum
weight capacity
= 22lbs
Drawer maximum
weight capacity
= 11lbs
Hutch maximum
weight capacity
= 22lbs
Bottom shelf maximum
weight capacity
= 44lbs

# .
3 of 16
51-LD01CODT
51-LD01COLB
51-LD01CORB
51-LD01COMB
51-LD01COLBB
51-LD01CORBB
51-LD01COKT
51-LD01COMS
51-LD01COBS
51-LD01COSPB
51-LD01CODF

ITEMS ARE NOT SHOWN TO SCALE.
PARTSLIST2OF2
#
DESCRIPTION
SIDE 1 SIDE 2
STOCK #
QTY.
12
Left Drawer
Board
51-LD01COLDB 1
13
Right Drawer
Board
51-LD01CORDB 1
14 Drawer Back 51-LD01CODB 1
15 Drawer Bottom
51-LD01CODBM 1
16 Hutch Back 51-LD01COHB 1
17
Hutch Top
51-LD01COHT
1
18 Hutch Left 51-LD01COHL 1
19 Hutch Right
51-LD01COHR
1
20 Hutch Middle
51-LD01COHM
1
21a
Outer Drawer Rollers
51-LD01CODS
2 sets
of 4
22 Plastic Cap
51-LD01COCA
14
21b Inner Drawer Rollers
Left Right
Left Right
4 of 16

5 of 16
EXTRA HARDWARE INCLUDED FOR YOUR CONVENIENCE. ITEMS ARE NOT SHOWN TO SCALE.
HARDWARE LIST
PART DESCRIPTION QTY.
A M4 X 40MM 10
BM4 X 18MM 2
C M4 X 14MM 16
D
44
IF YOU ARE MISSING ANY OF THESE PARTS,
OR IF YOU HAVE A DAMAGED PART, PLEASE
VISIT WWW.COMFORTPRODUCTS.NET/SUPPORT
REFERENCE THE MODEL # ON THE FRONT OF
THIS MANUAL. SIMPLY COMPLETE THE INFORMATION,
INCLUDING THE PART YOU NEED. THE PART WILL
NORMALLY BE SHIPPED WITHIN 48 HOURS.
- READ THE INSTRUCTION MANUAL BEFORE ASSEMBLING.
- REMOVE ALL PIECES BEFORE BEGINNING INSTALLATION.
- OPEN THE HARDWARE AS NEEDED .
- ASSEMBLE IN AN AREA WITH PLENTY OF SPACE.
- READ EACH STEP BEFORE BEGINNING CONSTRUCTION.
- HAVE A SCREWDRIVER BEFORE YOU BEGIN ASSEMBLING
(NOT INCLUDED).
- NEVER FORCE THE SCREWS OR FITTINGS.
- KEEP THIS MANUAL FOR FUTURE REFERENCE.
- TIGHTEN ALL THE SCREWS EVERY 6 MONTHS.
CLEANING AND CARE
- CLEAN SURFACES WITH A DRY OR DAMP CLOTH.
- DO NOT USE ABRASIVE CLEANERS.
- DO NOT USE A POWER DRILL.
HARDWARE KIT
STOCK # 51-LD01COHA
E
F
G
H
Cam
Drawer Handle
Foot Pin
Shelf Support
44
6
1
4
Extra Hardware 1 set

ASSEMBLY INSTRUCTIONS
6 of 16
STEP 1
Use a hammer to attach foot pins (G) to the bottom of the left (2), middle (4), and right (3) boards.
H x 4

7 of 16
ASSEMBLY INSTRUCTIONS
STEP 2
Attach a left outer drawer roller (21a) to the left board (2) and a right outer drawer roller (21a) to the right board (3)
using small screws (C). Attach two rollers to the middle board (4), a right outer roller (21a) to the left side and a
left outer roller (21a) to the right side. Refer to drawing below for which holes in the roller to use.
Left Side Right Side
FIFTH TO
LAST HOLE
SECOND
HOLE
21a, right 21a, left
21a, left 21a, right
C x 8
C
C
C

D x 20
8 of 16
ASSEMBLY INSTRUCTIONS
STEP 3
screw
Do not overtighten bolts or cams will not lock properly.
Left Side Right Side

9 of 16
ASSEMBLY INSTRUCTIONS
Insert cams (E) into the bottom shelf (9) and into the two
support boards (10). Make sure the arrows are facing the
smaller holes which the bolts go into. First, attach shelf and
support boards to the middle board (4), and then attach
these to the right board (3) by aligning the bolts and cams.
With a screwdriver turn the cams about 1/2 turn clockwise
to lock into place. CAUTION: Do not overtighten cams.
STEP 4
10
10
10
9
3
4
6
CAUTION:
Do not over tighten
cams.
E x 16
Insert right back board (6) into grooves as shown.
STEP 5
D
E
E

CAUTION: Make sure these
holes are facing up.
ASSEMBLY INSTRUCTIONS
STEP 7
Screw minix bolts (D) into hutch top (17), hutch left board (18), and hutch right board (19).
STEP 6
Insert four cams (E) into the left back board (5). Make sure arrows are
facing the smaller holes. Attach back board (5) to left board (2) and
middle board (4). Turn the cams about 1/2 turn clockwise to lock into place.
CAUTION: Do not overtighten cams.
17
18
19
10 of 16
E x 4
D x 12
E

D x 8 A x 6
ASSEMBLY INSTRUCTIONS
STEP 8
Insert two cams into the hutch back board (16) and attach to the hutch top board (17). Insert ten cams into the
hutch back (16), hutch top (17), and hutch middle board (20). Attach hutch left (18), hutch middle (20), and
hutch right (19) to the back and top boards.
STEP 9
Screw eight minix bolts (D) into desktop (1). Attach hutch to desktop using six screws (A) as shown.
16
17
18
16
20
17
19
20
18
19
16
1
11 of 16
E x 12
E
D
A

E
E
STEP 10
Insert eight cams (E) into the left, middle, and right boards
and left back board as shown. Attach desktop (1) with hutch to
the lower part of the desk by aligning the eight bolts (D)
(already screwed into the desktop) with cams. Tighten
cams 1/2 turn.
1
12 of 16
ASSEMBLY INSTRUCTIONS
E x 8
D
D

E x 4
A x 4
STEP 14
Align groove in drawer back (14) with drawer bottom. Attach
drawer back (14) to left and right drawer boards using
four screws (A).
D x 4
STEP 13
Insert drawer bottom (15) into
grooves.
STEP 11 STEP 12
Insert cams into the left (12) and right (13) drawer boards
and attach both boards to the drawer front (11). Make
sure the grooves for the drawer bottom are aligned.
13 of 16
13
11
12
11
15
14
ASSEMBLY INSTRUCTIONS

21b, right
21b, right
21b, left
21b, left
B x 2
C x 4
STEP 16
Attach two inner drawer rollers (21b), one left and one
right, to the bottom of drawer using four screws (C) as shown.
Make sure rollers are oriented to the back of the drawer.
Refer to drawing below for which holes in the roller to use.
STEP 15
Attach drawer handle (F) to drawer front using
two screws (B).
STEP 17
Attach two inner drawer rollers (21b), one left and one right,
to the bottom of the keyboard tray (7) using four screws (C).
THIRD TO
LAST HOLE
THIRD
HOLE
7
ASSEMBLY INSTRUCTIONS
14 of 16
B
F
C x 4

H x 4
STEP 20
STEP 19
ASSEMBLY INSTRUCTIONS
STEP 18
Insert shelf supports (H) into any of the four sets of holes,
according to desired height. Place middle shelf (8)
on supports.
Align inner and outer rollers to insert
drawer and keyboard tray.
Place plastic caps (22) over cams at the back of the
desk and cams in the hutch middle board (20).
15 of 16

•
•
•
•
DO NOT stand on the desk. Do not use the desk as a stepladder.
ed.
Every 6 months, check all bolts and screws to ensure they are tight.
This product is California 93120 Compliant for Formaldehyde.
Comfort Products warrants this product to be free from defects in material and workmanship for one (1) year. This warranty is made by
Comfort Products only to the original end-user customer acquiring the product directly from Comfort Products’ authorized dealers
as shown by the original sales receipt. The end-user customer remedy pursuant to this warranty is limited to repair or replacement of
parts at Comfort Products’ option within a reasonable amount of time. Comfort Products reserves the right to require damaged parts
to be returned to Comfort Products upon request. Consent from Comfort Products must be obtained before any warranty work is
performed. This warranty applies under conditions of normal use and is not subject to defects caused by improper assembly or
disassembly; defects occurring after purchase due to product mo sure
to the elements; labor or assembly cost. This warranty does not cover the cost of transportation or labor. In no event shall Comfort
Products be liable in either tort or contract for any loss or direct, special, incidental, consequential or exemplary damages. This Limited
Warranty is NOT applicable to end-user customers who use Comfort Products for rental purposes. This warranty applies only to end-user
customers in the United States. All warranties are limited to t
165 pounds for the desktop, 11 pounds for the drawers, 22 pounds for the middle shelf, 44 pounds for the bottom shelf, and 22 pounds
for the hutch. For claims or questions concerning this warranty, please visit: www.comfortproducts.net or email us at:
[email protected]
MODEL: # 50-LD01CO
PLEASE VISIT WWW.COMFORTPRODUCTS.NET FOR WARRANTY INFORMATION
16 of 16
