BCM BC35Q User manual

1
ATX
BC35Q
Intel® 65nm
Core™ 2 Quad/ Core™ 2 Duo/
Pentium® Dual-Core/ Celeron 440
w/ 1333/1066/800MHz FSB
User’s Manual
Edition 1.04 – Jan, 2009

2
FCC Statement
THIS DEVICE SUPPORTS PART 15 FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE
THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS
"A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL
INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS
EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY ENERGY AND, IF NOT
INSTATLLED AND USED IN ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE
HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL
INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO CORRECT THE
INTERFERENCE AT HIS OWN EXPENSE.
Notice
This guide is designed for experienced users to setup the system within the shortest time.
For detailed information, please always refer to the electronic user's manual.
Copyright Notice
Copyright ©2008 BCM Advanced Research, ALL RIGHTS RESERVED.
No part of this document may be reproduced, copied, translated, or transmitted in any
form or by any means, electronic or mechanical, for any purpose, without the prior written
permission of the original manufacturer.
Trademark Acknowledgement
Brand and product names are trademarks or registered trademarks of their respective
owners.

3
Disclaimer
BCM Advanced Research reserves the right to make changes, without notice, to any product, including
circuits and/or software described or contained in this manual in order to improve design and/or
performance. BCM Advanced Research assumes no responsibility or liability for the use of the described
product(s), conveys no license or title under any patent, copyright, or masks work rights to these products,
and makes no representations or warranties that these products are free from patent, copyright, or mask
work right infringement, unless otherwise specified. Applications that are described in this manual are for
illustration purposes only. BCM Advanced Research makes no representation or warranty that such
application will be suitable for the specified use without further testing or modification.
Life Support Policy
BCM Advanced Research PRODUCTS ARE NOT FOR USE AS CRITICAL COMPONENTS IN LIFE
SUPPORT DEVICES OR SYSTEMS WITHOUT THE PRIOR WRITTEN APPROVAL OF BCM Advanced
Research.
As used herein:
1. Life support devices or systems are devices or systems which, (a) are intended for surgical implant into
body, or (b) support or sustain life and whose failure to perform, when properly used in accordance with
instructions for use provided in the labeling, can be reasonably expected to result in significant injury to
the user.
2. A critical component is any component of a life support device or system whose failure to perform can
be reasonably expected to cause the failure of the life support device or system, or to affect its safety
or effectiveness.
A Message to the Customer
BCM Customer Services
Each and every BCM product is built to the most exacting specifications to ensure reliable performance in
the harsh and demanding conditions typical of industrial environments. Whether your new BCM device is
destined for the laboratory or the factory floor, you can be assured that your product will provide the
reliability and ease of operation for which the name BCM has come to be known.
Your satisfaction is our primary concern. Here is a guide to BCM customer services. To ensure you get the
full benefit of our services, please follow the instructions below carefully.

4
Technical Support
We want you to get the maximum performance from your products. So if you run into technical difficulties,
we are here to help. For the most frequently asked questions, you can easily find answers in your product
documentation. These answers are normally a lot more detailed than the ones we can give over the phone.
So please consult the user’s manual first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.bcmcom.com.
If you still cannot find the answer, gather all the information or questions that apply to your problem, and
with the product close at hand, call your dealer. Our dealers are well trained and ready to give you the
support you need to get the most from your BCM products. In fact, most problems reported are minor and
are able to be easily solved over the phone.
In addition, free technical support is available from BCM engineers every business day. We are always
ready to give advice on application requirements or specific information on the installation and operation of
any of our products. Please do not hesitate to call or e-mail us.
BCM Advanced Research
7 Marconi,
Irvine, California, 92618
USA
Tel : [phone]
Fax : [phone]
http://www.bcmcom.com
E-mail: [email protected]
Product Warranty
BCM warrants to you, the original purchaser, that each of its products will be free from defects in materials
and workmanship for two years from the date of purchase.
This warranty does not apply to any products which have been repaired or altered by persons other than
repair personnel authorized by BCM, or which have been subject to misuse, abuse, accident or improper
installation. BCM assumes no liability under the terms of this warranty as a consequence of such events.
Because of BCM high quality-control standards and rigorous testing, most of our customers never need to
use our repair service. If any of BCM products is defective, it will be repaired or replaced at no charge

5
during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of
replacement materials, service time, and freight. Please consult your dealer for more details. If you think
you have a defective product, follow these steps:
1. Collect all the information about the problem encountered. (For example, CPU type and speed, BCM
products model name, hardware & BIOS revision number, other hardware and software used, etc.)
Note anything abnormal and list any on-screen messages you get when the problem occurs.
2. Call your dealer and describe the problem. Please have your manual, product, and any helpful
information available.
3. If your product is diagnosed as defective, obtain an RMA (return material authorization) number from
your dealer. This allows us to process your good return more quickly.
4. Carefully pack the defective product, a complete Repair and Replacement Order Card and a
photocopy proof of purchase date (such as your sales receipt) in a shippable container. A product
returned without proof of the purchase date is not eligible for warranty service.
Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer.
Manual Objectives
This manual describes in detail the BCM BC35Q Main board.
We strongly recommend that you study this manual carefully before attempting to interface with BC35Q or
change the standard configurations. Whilst all the necessary information is available in this manual we
would recommend that unless you are confident, you contact your supplier for guidance.
Please be aware that it is possible to create configurations within the CMOS RAM that make booting
impossible. If this should happen, clear the CMOS settings, (see the description of the Jumper Settings for
details).
If you have any suggestions or find any errors concerning this manual and want to inform us of these,
please contact our Customer Service department with the relevant details.

6
Safety Precautions
Warning!
Always completely disconnect the power cord from your chassis
whenever you work with the hardware. Do not make connections while
the power is on. Sensitive electronic components can be damaged by
sudden power surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before touching
the mainboard. Modern electronic devices are very sensitive to static
electric charges. As a safety precaution, use a grounding wrist strap at
all times. Place all electronic components in a static-dissipative surface
or static-shielded bag when they are not in the chassis.
Document Amendment History
Revision Date Comment
1st (1.00) June, 2008 Initial Release
2nd (1.01) July, 2008 1. Updated PCI-EX x4,and PCI-EX x16, DVI
applications.
2. Added BIOS flash application (warning) in
section3.
3rd (1.02) Nov, 2008 1. Updated Accessory Kit information in
section 1.2.
2. Updated headers “J1” and “J2”
information.
4th (1.03) Dec, 2008 1. Updated headers “J1” and “J2”
information.
5th (1.04) Jan, 2009 1. Updated headers information

7
Contents
Chapter 1: System Setup ..............................................................................................11
1.1 Welcome! ......................................................................................................................................11
1.2 Packing Contents..........................................................................................................................11
1.3 Special Features ...........................................................................................................................12
1.3.1 Product Highlights.........................................................................................................................12
1.4 Before you proceed.......................................................................................................................14
1.5 Mainboard Overview .....................................................................................................................15
1.5.1 Placement direction ......................................................................................................................15
1.5.2 Screw Holes ..................................................................................................................................15
1.5.3 Mainboard Layout .........................................................................................................................16
1.6 Central Processing Unit (CPU) .....................................................................................................17
1.6.1 Installing the CPU .........................................................................................................................18
1.6.2 Installing the CPU Heatsink and fan .............................................................................................20
1.6.3 Uninstalling the CPU Heatsink and fan.........................................................................................22
1.7 System Memroy ............................................................................................................................24
1.7.1 Overview .......................................................................................................................................24
1.7.2 Dual-Channel Mode Population Rule ...........................................................................................24
1.7.3 Installing DIMM .............................................................................................................................25
1.7.4 Removing a DIMM...................................................................................................26
1.8 Power Supply................................................................................................................................27
1.8.1 ATX 24-pin Power Connector: JPWR3.........................................................................................27
1.8.2 ATX 12V Power Connector: JPW1 ...............................................................................................27
1.9 Back Panel....................................................................................................................................29
1.10 Connectors/Headers .....................................................................................................................31
1.10.1 IDE Connector: IDE1 ....................................................................................................................31
1.10.2 Serial ATA Connectors: SATA1, SATA2, SATA3, SATA4, SATA6 ..............................................31
1.10.3 Fan Power Connector: CPUFAN1, AUXFAN1, SYSFAN1, SYSFAN2 ........................................32
1.10.4 Chassis Intrusion Switch Header: JCI1 ........................................................................................32
1.10.5 CD-In Connector: JCD_IN1 ..........................................................................................................32
1.10.6 S/PDIF-Out Connector: JSPDO1..................................................................................................33
1.10.7 Front Panel Audio Connector: JAUD1 ..........................................................................................33
1.10.8 Front USB Connectors: JUSB1, JUSB2, JUSB3..........................................................................34
1.10.9 Serial Port Connectors: COM1, COM2.........................................................................................34
1.10.10 COM Port Ring-in, Power Select: J1(for COM1), J2(for COM2) ..................................................35

8
1.10.11 LPT Port Connector: JLPT1..........................................................................................................35
1.10.12 Front Panel Connectors: JFP1......................................................................................................36
1.10.13 SM Bus Connector: JSMB ............................................................................................................36
1.11 Jumpers ........................................................................................................................................37
1.11.1 Clear CMOS Jumpers: JBAT1 ......................................................................................................37
1.11.2 The Header: JSPI1 .......................................................................................................................37
1.12 The Expansion Slots .....................................................................................................................38
1.12.1 Installation of expansion card .......................................................................................................38
1.12.2 Setup an expansion card ..............................................................................................................38
1.12.3 PCI (Peripheral Component Interconnect) Express Slot ..............................................................38
1.12.3.1 PCI-Ex16 Slot: PCI-E3, PCI-E4 ....................................................................................................39
1.12.3.2 PCI-E x1 Slot: PCI-E1, PCI-E2 .....................................................................................................39
1.12.4 PCI Slots: PCI1, PCI2, PCI3 .........................................................................................................39
Chapter 2: Starting Up the System .............................................................................40
2.1 Starting Up Your System ...............................................................................................................40
Chapter 3: BIOS Setup ..................................................................................................42
3.1 Introducing BIOS...........................................................................................................................42
3.2 Entering BIOS Setup Menu...........................................................................................................43
3.3 Getting Help ..................................................................................................................................43
3.4 The Main Menu .............................................................................................................................44
3.5 Standard CMOS Features ............................................................................................................46
3.6 Advanced BIOS Features .............................................................................................................49
3.7 Integrated Peripherals...................................................................................................................53
3.8 Power Management Setup ...........................................................................................................56
3.9 PnP/PCI Configurations ................................................................................................................59
3.10 H/W Monitor ..................................................................................................................................61
3.11 Frequency/Voltage Control ...........................................................................................................62
3.12 Load Fail-Safe/ Optimized Defaults ..............................................................................................63
3.13 BIOS Setting Password ................................................................................................................64

9
Mainboard Specifications
Model BC35Q
Processor Intel®65nm LGA 775 processors.
Supports Intel® Core™ 2 Quad/ Core™ 2 Duo/ Pentium® Dual Core / Celeron 440
w/ 1333/1066/800MHz FSB
North Bridge Intel®Q35
Memory DDR2 800/667 SDRAM
* Supports DDR2 667MHz (PC2-5300), DDR2 800MHz (PC2-6400) memory modules
up to 8GB max. (2GB max/ DIMM slot)
* DDR2 667MHz recommended for 8GB configuration
* 4 DDR2 DIMM slots (240-pin/ 1.8V), supports Non-ECC, un-buffered memory
Integrated Graphics Intel® GMA 3100 Engine; up to 256MB can be allocated for GFX
South Bridge Intel® ICH9DO
SATA 5 x SATA II connectors supports 3.0 Gbs transfer speed
PCI-E 2 x PCI-E x 16 slots
(slot PCI_E4 supports transfer rate up to x4 only. When PCI-E x1 slot is occupied,
the performance on PCI_E4 slot drops to PCI-E x1 only)
2 x PCI-E x 1 slots
PCI 3 x PCI Slots (PCI 2.2 compliant)
USB 12 x USB 2.0 ports (6 x Rear I/O, 6 x header)
iTE® IT8213F PCI to IDE ControllerIDE
Supports Ultra DMA 66/100/133 transfer rate
Infineon® TPMTPM
1 x TPM 1.2 Security Device
Super I/O Controller Fintek® F71882FG
Serial Ports 2 x RS232 ports (2 x header)
LPT 1 x LPT header
Watch Dog Timer 1 ~ 255 sec timer
HW Monitor Yes
Realtek® ALC888Audio
HD Audio Codec with auto jack sensing
Intel® 82566DM Gigabit LAN
1 x 10/100/1000 LAN
Intel® 82573L PCI-E Gigabit LAN
LAN
1 x 10/100/1000 LAN

10
AMI® BIOSBIOS
AMI Bios with 32Mb SPI ROM
Expansion Slots
PCI-E 2 x PCI-E x 16 Slots supports PCI-E x16 Graphic card
Slot “PCI_E4” supports up to 4x transfer rate (only when there is no card installed
on PCI_E1 and PCIE2 slots).
When PCI-E x1 slot (“PCI_E1” and/or “PCI_E2”) is occupied, PCI_E4 slot will only
support PCI-E x1 device )
2 x PCI-E x 1 slots
PCI 3 x PCI slot
Onboard I/O Headers
IDE 1 x IDE Connector
SATA 5 x Std. SATA Connectors
USB 3 x USB Headers (6 ports on headers)
RS232 2 x Header
COM Port Power Select 2 x Headers provides 12V or 5V to COM port
SPDIF 1 x Header
CD-IN 1 x Header
Front Audio 1 x Header
Front Panel 1 x Headers
Fan Header 4 x Headers ( 2 x 4-pins, 2 x 3-pins)
Chassis Intrusion Header 1 x Header
Back I/O Panel
PS/2 Keyboard Mouse 1 x DIN 6 Stack up Connector
VGA 1 x DB 15 Connector
DVI 1 x DVI Connector
USB 1 x Stack up USB Connector (2 USB ports)
LAN and USB 2 x Stack up RJ45 and USB Connectors (2 USB ports)
Audio 1 x 6 jacks Audio Connector
Power & Connector
1 x Std. 24 pin ATX Connector
1 x 4 pin ATX 12 Connector
Form Factor
ATX 12.0” x 9.6”

11
Chapter 1: System Setup
This chapter describes the motherboard features and the new technologies it supports
1.1 Welcome!
The motherboard delivers a host of new features and latest technologies, making it another line of
BCM long life motherboards! Before you start installing the motherboard, and hardware devices on it,
check the items in your package with the list below.
If any of the below items is damaged of missing, please contact your vendor.
1.2 Packing Contents
Motherboard
z1 x BC35Q
Cable
z1 x Serial ATA Signal Cable
z1 x Serial ATA Power Cable
z1 x Ultra DMA 100/66 IDE Cable
z1 x Dual-Serial Ports Cable
Accessories
z1 x BC35Q I/O Shield
Software CD
z1 x CD contains drivers, user’s manual, and QIG (Quick Installation Guide)
Documentation
z1 x Quick Installation Guide

12
1.3 Special Features
1.3.1 Product Highlights
Intel® CoreTM 2 Processor Ready
This mainboard supports the Intel® Intel® Core™ 2 Quad, and Core™ 2 Duo processors in the LGA775
package. With the new Intel® CoreTM2 micorarchitecture technology and 1066/800 MHz FSB, Intel®
CoreTM2 processor is one of the most powerful and energy efficient CPU in the world.
Intel® Q35 Express Chipset
The Intel® Q965 Express Chipset provides all business with more effective costs management, safer
computing environment, and deploys more responsive PCs. It features the integrated graphics engine,
Intel® Graphics Media Accelerator 3100.
DDR2 Memory Support
The mainboard supports DDR2 memory that features data transfer rates of 800/ 667MHz to meet the
higher bandwidth requirements of the latest 3D graphics, multimedia, and Internet applications. The
dual-channel DDR2 architecture doubles the bandwidth of your system memory to boost system
performance, and eliminating bottlenecks with peak bandwidths of up to 12.8GB/s.
Serial ATA 3.0Gb/s Technology
The mainboard supports the Serial ATA (SATA) technology through 5 Serial ATA II interface from Intel®
ICH8 chipset. The SATA II specification allows for thinner, more flexible cables with lower pin count,
reduced voltage requirement (compared to IDE specification), and provides up to 300MB/s data transfer
rate.
High Definition Audio
The mainboard came with the Realtek ALC888 high-definition audio CODEC that lets you enioy high
quality 7.1+2 channel audio without having to buy advanced sound cards.
PCI-E x16 support
The PCI-E x16 VGA interface specification enhances graphics performance with high bandwidth speeds up
to 2.5 Gb/s (PCI_E3 slot only).
USB 2.0 Technology
The mainboard implements the Universal Serial Bus (USB) 2.0 specification, dramatically increasing the
connection speed from the 12Mbps bandwidth on USB1.1 to a fast 480Mbps on USB2.0. USB2.0 is
backward compatible with USB1.1.

13
Trusted Platform Module (TPM) Support
By combining the onboard TPM 1.2 with TPM security software (provided by the third party), it will enhance
the security level of the system.
• PRECAUTION: When TPM is enabled and utilized through TPM software, there is
possibility that the encrypted data will not be accessible, or recoverable if one of the
following situations occurred:
1. Lost of TPM password.
2. System or board failure, or being replaced.
3. Hard Drive failure.

14
1.4 Before you proceed
Take note of the following precautions before you install motherboard components or change any
motherboard settings.
• Unplug the power cord from the wall socket before touching any component.
• Use a grounded wrist strap or touch a safely grounded object or to a metal object, such as the
power supply case, before handling components to avoid damaging them due to static
electricity
• Hold components by the edges to avoid touching the ICs on them.
• Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag
that came with the component.
• Before you install or remove any component, ensure that the ATX power supply is switched
off or the power cord is detached from the power supply. Failure to do so may cause severe
damage to the motherboard, peripherals, and/or components.

15
1.5 Mainboard Overview
Before you install the mainboard, study the configuration of your chassis to ensure that the motherboard fits
into it.
Make sure to unplug the power cord before installing or removing the mainboard. Failure
to do so can cause you physical injury and damage mainboard components.
1.5.1 Placement direction
When installing the mainboard, make sure that you place it into the chassis in the correct orientation. The
edge with external port goes to the rear part of the chassis as indicated in the image below.
1.5.2 Screw holes
Place the screws into the holes indicated by circles to secure the mainboard to the chassis.
Do not over-tighten the screws! Doing so may damage the mainboard.

16
1.5.3 Mainboard Layout

17
1.6 Central Processing Unit (CPU)
This mainboard supports Intel® 65nm Core™ 2 Quad (Q6x00 Series), Core™ 2 Duo (E6x00, E4x00
Series), Pentium® 4 (6x1 series), Pentium® D (9xx Series), Celeron 440 in LGA775 package (with
1333/1066/800MHz FSB only). When you are installing the CPU, make sure to install the cooler to prevent
overheating. If you do not have the CPU cooler, consult your dealer before turning on the system.
• Your boxed Intel® LGA775 processor package should come with installation instructions for the
CPU, fan and heatsink assembly.
• Upon purchase of the mainboard, make sure that the PnP cap is on the socket and the socket
pins are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any
damage to the PnP cap/socket pins/motherboard components. BCM will shoulder the cost of
repair only, if the damage is shipment/ transit-related.
• Keep the PnP cap after installing the mainboard. BCM will process Return Merchandise
Authorization (RMA) requests only if the mainboard comes with the cap on the LGA775 socket.
• The product warranty does not cover damage to the socket pins resulting from incorrect CPU
installation/removal, or misplacement/loss/incorrect removal of the PnP cap.
1. Overheating: Overheating will seriously damage the CPU and system. Always make
sure the cooling fan can work properly to protect the CPU from overheating. Make
sure that you apply an even layer of thermal paste between the CPU and the
heatsink to enhance heat dissipation.
2. Replacing the CPU: While replacing the CPU, always turn off the ATX power suppply
or unplug the power supply’s powr cord from the grounded outlet first to prevent
damage to the system and the system.

18
1.6.1 Installing the CPU
To install a CPU
1. Locate the CPU socket on the motherboard
2. Press the load lever with your thumb (A) and move it to the left (B) until it is released from the retention
tab.
To prevent damage to the socket pins, do not remove the PnP cap unless you have
installed the CPU.
3. Lift the load lever in the direction of the arrow to a 135°angle

19
4. Lift the load plate with your thumb and forefinger to a 100°angle (A), then push the PnP cap from the
load plate window to remove (B).
5. Position the CPU over the socket, making sure the gold triangle is on the bottom-left corner of the
socket. The socket alignment key should fit into the CPU notch.
6. Close the load plate (A), then push the load lever (B) until it snaps into the retention tab.
The CPU fits in only one correct orientation, DO NOT force the CPU into the socket to prevent
damage to the socket pins or CPU.

20
1.6.2 Installing the CPU heatsink and fan
The Intel LGA775 processor requires a specially designed heatsink and fan assembly to ensure optimum
thermal condition and performance.
• When you purchase a boxed Intel® processor, the package includes the CPU fan and
heatsink assembly. If you buy a CPU separately, make sure that you use only Intel®-certified
multi-directional heatsink and fan.
• Your Intel® LGA775 heatsink and fan assembly comes in a push-pin design and requires
no tool to install.
• If you purchased a separate CPU heatsink and fan assembly, make sure that you have
properly applied Thermal Interface Material to the CPU heatsink or CPU before you install
the heatsink and fan assembly.
Note: Make sure that you have installed the mainboard to the chassis before you install the CPU fan
and heatsink assembly.
To install the CPU heatsink and fan:
1. Place the heatsink on top of the installed CPU, making sure that the four fasteners match the holes
on the motherboard.
Note: Orient the heatsink and fan assembly such that the CPU fan cable is closest to the CPU fan
connector.
Make sure to orient each fastener with the narrow end of the groove pointing outward.
(The photo shows the groove shaded for emphasis.)
