BCM iX965GM Installation and operation manual


Intel® GM965 socket P Core™ 2 Duo / Core™ Duo /
Core™ 2 Solo /Core™ Solo mobile CPU Mini ITX Main
Board

Packing List
Before you begin installing your single board, please make sure that the
following parts have been shipped.
 1 x Intel GM965 Mini ITX Main board
 1 x CD-ROM contains the followings:
•User’s Manual in PDF file
•Drivers
 2 x COM cable
 3 x SATA cable kit (SATA/Power)
 1 x IDE HDD cable (40-pin)
 1 x Startup Manual
Disclaimer and Notice
The manufacturer reserves the right to make changes,
without notice, to any product, including circuits and/or
software described or contained in this manual in order to
improve design and/or performance. The manufacturer
assumes no responsibility or liability for the use of the
described product(s), conveys no license or title under
any patent, copyright, or masks work rights to these
products, and makes no representations or warranties
that these products are free from patent, copyright, or
mask work right infringement, unless otherwise specified.
For the detail product information, please refer to user’s
manual.
15GS0600052T26

Product Overview
Specifications
System
CPU Supports Intel socket P Core 2 Duo / Core Duo / Core 2 Solo / Core Solo mobile
CPU with 65nm process technology
FSB 533/800 MHz
BIOS AMI 16 Mb SPI BIOS
System Chipset Intel GME965/ICH8M
I/O Chipset Winbond W83627DHG-A
Memory 2 x 200-pin SODIMM socket supports up to 4 GB Dual channel DDR2 533/667
SDRAM
SSD One CompactFlash Type I/II socket
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
H/W Status Monitor Monitoring CPU temperature, voltage, and cooling fan status. Auto throttling
control when CPU overheats
Expansion Slots 1 x PCI slot (PCI Rev.2.2 compliant) supports 3 PCI master
S3 S3 Support
SmartFan Control Yes

I/O
MIO 1 x EIDE, 3 x SATA, 10 x USB, 4 x RS-232, 1 x K/B, 1 x Mouse (COM1~4 with
power output)
USB 10 x USB 2.0 ports
DIO 8-bit General Purpose I/O for DI and DO
Display
Chipset Intel Graphics Media Accelerator X3100
Display Memory Intel DVMT 4.0 supports 384 MB video memory
Resolution 2048 x 1536 @ 32 bpp(@ 60Hz)
Dual Display CRT + LVDS, or CRT + DVI-D
LVDS Dual-channel 24-bit LVDS
DVI / Onboard DVI
Chipset Chrontel CH7307C DVI transmitter up to 165M pixels/second
Audio
Audio Codec Realtek ALC888 Audio Code
5.1+2 CH. with two independent audio stream
Audio Interface Mic in, Line in, Line out
Audio Amplifier TPA3005D2 Stereo 5Watt per channel
Ethernet
LAN1 Realtek RTL8111B PCI-E Gigabit Ethernet Controller
LAN2 Realtek RTL8111B PCI-E Gigabit Ethernet Controller (optional)
Jumpers
Label Function Note
CCMOS1 Clear CMOS Normal *
Clear CMOS
JCOMPWR1,
JCOMPWR2
or
JCOMPWR3,
JCOMPWR4
COM1 RI/+5V/+12V Selection
COM3 RI/+5V/+12V Selection
JCOMPWR1
JCOMPWR2
JCOMPWR3
JCOMPWR4
+5V
(Default)
+
+12V
+
Ring
+

Jumpers
Label Function Note
JCOMPWR1,
JCOMPWR2,
or
JCOMPWR3,
JCOMPWR4
COM2 RI/+5V/+12V Selection
COM4 RI/+5V/+12V Selection
JCOMPWR1
JCOMPWR2
JCOMPWR3
JCOMPWR4
+5V
(Default)
+
+12V
+
Ring
+
SM_PWRBTN1
SM Power Connector ATX Mode (Default) AT Mode
Connectors
Label Function Note
AMPJ1 Amplifier Connector
FPIO1 System Panel Connector
JBKL1 LCD Inverter Connector
JLVDS1 LVDS Connector
