Siemens Nixdorf D970 User manual

System board D970
Technical Manual

Is there ...
... any technical problem or other
question you need clarified?
Please contact:
• one of our IT Service Shops
• your sales partner
• your sales office
The addresses of your service partners
are contained in the guarantee booklet
or in the service address booklet.
The latest information on our products,
tips, updates, etc., can be found on the
Internet under:
http://www.siemens.com/pc
... anything you want to tell us
about this manual?
Please send us your comments quoting
the order number of the manual.
Siemens AG
User Documentation Department
OEC BS2 OS ID 4
Otto-Hahn-Ring 6
D-81730 München

Your training needs?
The Siemens Training Centers offer you a wide range of training courses in
information technology and on IT products and other subjects - onsite near to your
workplace or offsite at one of our training centers.
Contact us for information on consulting, course schedules and selfstudy material -
Either fax (which is the fastest way):
Fax: ..[phone]
Or write to:
Siemens AG
Training Center, Beratungsservice
D-81730 München

System board D970 Techni
c
Dieses Handbuch wurde auf Recycling-Papier gedruckt.
This manual has been printed on recycled paper.
Ce manuel est imprimé sur du papier recyclé.
Este manual ha sido impreso sobre papel reciclado.
Questo manuale è stato stampato su carta da riciclaggio.
Denna handbok är tryckt på recyclingpapper.
Dit handboek werd op recycling-papier gedrukt.
Herausgegeben von/Published by
Siemens AG
D-81730 München
Bestell-Nr./Order No.: A26361-D970-Z120-3-7619
A26361-D970-Z120-3-7619A26361-D970-Z120-3-7619
A26361-D970-Z120-3-7619
Printed in the Federal Republic of Germany
AG 1198 11/98
A26361-D970-Z120-1-7619

System board D970
Technical Manual
Introduction
Important Notes
Settings in BIOS Setup
Settings in SCSI Setup
Settings on the system board
Extensions on the system
board
Error messages
Index
November 1998 edition

Intel and Pentium are registered trademarks and OverDrive is a trademark of Intel Corporation, USA.
Microsoft, MS, MS-DOS, Windows and Windows NT are Trademarks of Microsoft Corporation.
PS/2 and OS/2 Warp are registered trademarks of International Business Machines, Inc.
All other trademarks referenced are trademarks or registered trademarks of their respective owners,
whose protected rights are acknowledged.
Copyright ãSiemens AG 1998.
All rights, including rights of translation, reproduction by printing, copying or similar methods, even
of parts are reserved.
Offenders will be liable for damages.
All rights, including rights created by patent grant or registration of a utility model or design, are
reserved.
Delivery subject to availability. Right of technical modification reserved.

A26361-D970-Z120-3-7619
Contents
Introduction........................................................................................................... 1
Notational conventions............................................................................................ 1
Features................................................................................................................... 2
Interfaces and connectors........................................................................................ 3
Possible screen resolution....................................................................................... 1
Interrupt table.......................................................................................................... 5
Important Notes .................................................................................................... 7
Settings in BIOS Setup ......................................................................................... 9
Main menu ............................................................................................................ 10
System Time / System Date ........................................................................... 10
Diskette A / Diskette B .................................................................................. 11
Hard Disk x.................................................................................................... 11
Boot Options.................................................................................................. 14
Video Display................................................................................................ 15
Base Memory................................................................................................. 15
Extended Memory.......................................................................................... 15
Advanced menu - Making advanced system settings ............................................ 16
Cache Memory............................................................................................... 17
Shadow Memory............................................................................................ 19
Peripheral Configuration................................................................................ 20
PCI Configuration.......................................................................................... 23
Advanced System Configuration.................................................................... 27
Use Multiprocessor Specification.................................................................. 27
Plug & Play O/S - Plug&Play functionality................................................... 28
Reset Configuration Data............................................................................... 28
Large Disk Access Mode............................................................................... 28
Menu Security - Setting up the security features................................................... 29
Setup Password / System Password ............................................................... 29
Set Setup Password........................................................................................ 30
SetupPasswordLock..................................................................................... 30
Set System Password...................................................................................... 30
System Password Mode - Effect of the system password............................... 31
System Load................................................................................................... 31
Setup Prompt- Setup message........................................................................ 31
Virus Warning................................................................................................ 32
Diskette Write................................................................................................ 32

Contents
A26361-D970-Z120-3-7619
Flash Write.....................................................................................................32
Power On/Off.................................................................................................33
Menu Server - Set Server Management.................................................................36
Server management ........................................................................................37
O/S Boot Timeout ..........................................................................................37
ASR&R Boot Delay.......................................................................................38
Boot Retry Counter ........................................................................................38
Diagnostic System..........................................................................................38
Hardware Watchdog.......................................................................................39
Temperature Monitoring ................................................................................39
CPU Status - Processor status.........................................................................40
Memory Status ...............................................................................................41
Pager Configuration .......................................................................................42
VT100 Configuration.....................................................................................44
Storage Extension...........................................................................................47
Exit menu ..............................................................................................................50
Save Changes & Exit......................................................................................50
Discard Changes & Exit.................................................................................50
Get Default Values.........................................................................................50
Load Previous Values.....................................................................................50
Save Changes .................................................................................................50
Settings in SCSI Setup.........................................................................................51
Setting SCSI addresses (IDs).................................................................................51
Connecting SCSI devices ......................................................................................52
SCSI-Setup............................................................................................................53
Starting the SCSI Setup..................................................................................53
Terminating the SCSI setup............................................................................54
Default Settings in the SCSI setup.........................................................................55
SCSI Bus Interface Definitions .............................................................................56
Additional Options ................................................................................................57
Boot Device Options......................................................................................57
SCSI Device Configuration............................................................................58
Advanced Configuration Options...................................................................60
SCSI Disk Utilities ................................................................................................64
Verify .............................................................................................................64
Format Disk....................................................................................................64
Eliminating errors on the SCSI controller .............................................................65
SCSI BIOS messages.............................................................................................66
Settings on the system board ..............................................................................67

Contents
A26361-D970-Z120-3-7619
Recovering System BIOS - switch 1..................................................................... 68
Write protection for System BIOS - switch 3........................................................ 68
Write protection for floppy disk drive - switch 4.................................................. 69
Clock speed - switch 5, 6, 7 and 8......................................................................... 69
Extensions on the system board......................................................................... 71
Upgrading main memory....................................................................................... 72
Replacing the processor ........................................................................................ 73
Upgrading the video memory................................................................................ 74
Replacing the lithium battery ................................................................................ 75
Error messages.................................................................................................... 77
Messages d'erreur............................................................................................... 80
Mensajes de error ............................................................................................... 83
Messagi di errore................................................................................................. 86
Felmeddelanden................................................................................................... 89
Foutmeldingen..................................................................................................... 91
Index..................................................................................................................... 94

A26361-D970-Z120-3-7619 1
Introduction
This description applies for the system board D970 with PCI bus (Peripheral
Component Interconnect).
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
!Pay particular attention to texts marked with this symbol. Failure to
observe this warning endangers your life, destroys the system, or may
lead to loss of data.
i
This symbol is followed by supplementary information, remarks and tips.
Ê Texts which follow this symbol describe activities that must be performed in
the order shown.
ËThis symbol means that you must enter a blank space at this point.
Ú
ÚÚ
ÚThis symbol means that you must press the Enter key.
Texts in this typeface are screen outputs from the PC.
Texts in this bold typeface are the entries you make via the keyboard.
Texts in italics indicate commands or menu item.
"Quotation marks" indicate names of chapters and terms that are being
emphasized.

Introduction Features
2A26361-D970-Z120-3-7619
Features
• Dual processor system (second processor optional)
• Processor: Pentium Pro, 166 MHz and 200 MHz with integrated 16 Kbytes
first-level cache and 256 or 512 Kbytes second-level cache
• Voltage regulator which sets itself automatically to the required voltage range
(2.1 V to 3.5 V)
• Prepared for Pentium Pro OverDrive-Processor (OverDrive - ready)
• Intel 82440FX chipset with ISA bridge
• 72-bit data bus (64-bit data and 8-bit parity)
• 32 Mbyte to 1 Gbyte main memory for buffered DIM modules, EDC
protected (4 banks)
• 4MbitFlashBIOS
• 6 PCI slots, 2 ISA slots (1 slot shared)
• Monitor controller connected to PCI bus, graphics processor Cirrus Logic CL-
GD5436, 1 Mbyte DRAM video memory, upgrade to 2 Mbytes possible
• Siemens-ASIC for Server Management
• Ultra-Wide SCSI controller AIC 7880P
• IDE hard disk controller connected to PCI bus for two IDE drives
• Real-time clock/calendar with integrated battery backup
• Floppy disk controller (up to 2.88 Mbytes format)
• Connector for loudspeaker, two fans, remote-On/Off, wide SCSI drive, floppy
disk drive, IDE disk drive, control panel and service, temperature sensor
• Video connector
• Parallel interface (ECP- and EPP-compatible)
• Two serial ports (compatible 16550, 16-Byte-FIFO)
• PS/2 mouse port, PS/2 keyboard port
• CAN bus port for control of external drive cabinets
(CAN = Controller Area Network)
• Security functions in BIOS
• Server management support

Interfaces and connectors Introduction
A26361-D970-Z120-3-7619 3
Interfaces and connectors
6
7
8
9
10
11
12
14
17
18
1
26
22
23
24
25
23
4
5
13
15
16
19
20
21
1 = Power supply 5V and ±12V for
PRIMERGY 300 series
2 = Voltage converter for processor 1
3 = Voltage converter for processor 2
4 = ON/OFF switch
5 = Temperature sensor for processor 2
6 = Fan for processor 2 (optional)
7= Controlpanel1
8= Controlpanel1
9 = Fan for processor 1 (optional)
10 = Temperature sensor for processor 1
11 = Loudspeaker
12 = Fan 1
13 = Temperature sensor environment
14 = Fan 2
15 = Signaling/auxiliary voltage for
PRIMERGY 500/700 series
16 = Power supply for 500/700PRIMERGY
series +5 V, 3.3 V and ±12V
17 = SCSI indicator
18 = IDE drives
19 = Ultra wide SCSI drives
20 = Floppy disk drives
21 = Connector for modem on
22 = CAN bus controller 2
23 = CAN bus controller 1
24 = Keyboard and mouse
25 = Serial interface 1 and 2
26 = Parallel port and monitor port

Introduction Possible screen resolution
4A26361-D970-Z120-3-7619
Possible screen resolution
The screen resolutions in the following table refer to the monitor controller on the
system board.
If you are using an external monitor controller, you will find details of supported
screen resolutions in the Operating Manual or Technical Manual supplied with the
controller.
Screen
resolution Refresh rate (Hz) Horizontal- rate (kHz) ** Max. number of colors
640x350 70 31,5 16
640x480 60 31,5 16777216
640x480 75 37,5 16777216
640x480 85 43,4 16777216
640x480 100 50,6 16777216
720x400 70 31,5 16
720x400 84 38 16
800x600 60 38 65536
800x600 72 48 65536
800x600 75 47 65536
800x600 85 53,7 65536
800x600 100 63 65536
1024x768 60 48,4 256
1024x768 75 60 256
1024x768 85 68,7 256 *
1024x768 87 interlaced 36 256
1024x768 100 81 256 *
1280x1024 87 interlaced 49 16
* no 16 color mode
** The horizontal rate values may have a tolerance range of ± 0.3 kHz.

Interrupt table Introduction
A26361-D970-Z120-3-7619 5
Interrupt table
assi
g
ned IRQ
S
y
stem cloc
k
IRQ0
Ke
y
board IRQ1
not available IRQ2
Serial
p
ort COM 2 IRQ3
Serial interface COM1 IRQ4
free IRQ5
Flo
ppy
disk drive controller IRQ6
Parallel interface LPT1 IRQ7
Real-time clock (RTC) IRQ8
free IRQ9
free IRQ10
free IRQ11
Mouse controller IRQ12
Numeric
p
rocessor IRQ13
IDE controller/free IRQ14
free IRQ15
"Assigned IRQ" = interrupts assigned as shipped
i
Note that an interrupt cannot be used by two ISA boards or onboard
controllers at the same time.
The monitor controller of the system board does not require interrupt
IRQ9. If you are using a different monitor controller, it may need
interrupt IRQ9.

A26361-D970-Z120-3-7619 7
Important Notes
!
Be sure to read this
p
a
g
e carefull
y
and note the information before
y
ou
open the system.
Please note the information
p
rovided in the cha
p
ter "Safet
y
"inthe
Operating Manual of the system.
Incorrect replacement of the lithium battery may lead to a risk of
explosion. It is therefore essential to observe the instructions in the
section „Extensions on the system board“-„Replacing the lithium
battery“.
The lithium batter
y
must be re
p
laced with an identical batter
y
or a batter
y
type recommended by the manufacturer (CR2032).
Do not throw lithium batteries into the trashcan. Your vendor or dealer or
their authorized re
p
resentatives will take used batteries back free of
charge so that they can be recycled or disposed of in the proper manner.
ADVARSEL
!
Lithiumbatteri - Eks
p
losionsfare ved fe
j
la
g
ti
g
håndterin
g
. Udskiftnin
g
må
kun ske med batteri af samme fabrikat o
g
t
yp
e. Lever det bru
g
te batteri
tilba
g
e til leverandøren.
ADVARSEL
!
Eks
p
los
j
onsfare ved feilakti
g
skifte av batteri. Ben
y
tt samme batterit
yp
e
eller en tilsvarende t
yp
e anbefalt av a
pp
aratfabrikanten. Brukte batterier
kasseres i henhold til fabrikantens instruks
j
oner.
VARNING
!
Eks
p
losionsfara vid felakti
g
t batterib
y
te. Använd samma batterit
yp
eller
en ekvivalent t
yp
som rekommenderas av a
pp
arattillverkarenfabrikanten.
Kassera använt batteri enli
g
t fabrikantens instruktion.
VAROITUS
!
Paristo voi rä
j
ähtää,
j
os se on virheellisesti asennettu. Vaihda
p
aristo
ainoastaan laitevalmista
j
an suosittelemaan t
yypp
iin. Hävitä kä
y
tett
y
p
aristo valmista
j
an oh
j
eiden mukaisesti.
Store this technical manual close to the device. If you pass on the device to third
parties, you should also pass on the Operating Manual.

Important Notes
8A26361-D970-Z120-3-7619
Connecting cable for peripherals must be adequately insulated to avoid
interference.
Modules with electrostatic sensitive devices (ESD) may be identified by labels.
When you handle modules fitted with ESDs, you must observe the following
points under all circumstances:
• You must always discharge yourself (e.g. by touching a grounded object)
before working.
• Theequipmentandtoolsyouusemustbefreeofstaticcharges.
• Pull out the power plug before inserting or pulling out modules containing
ESDs.
• Always hold modules with ESDs by their edges.
• Never touch pins or conductors on modules fitted with ESDs.

A26361-D970-Z120-3-7619 9
Settings in BIOS Setup
In BIOS Setup you can set the system functions and the hardware configuration of
the system. In addition, the BIOS Setup displays technical information on the
system configuration.
When it is supplied, the system is set to factory default settings. You can change
these settings in BIOS Setup. Any changes you make take effect as soon as you save
the settings and quit the BIOS Setup.
The Operating Manual describes how to call the BIOS Setup and change menu
entries.
You can select the following settings in the BIOS Setup:
Main - system functions
Advanced - advanced system configuration
Security - security features
Server - Server management features
Exit -saveandquit
i
The various menus are described below with all settin
g
o
p
tions. Since the
settin
g
o
p
tions de
p
end on
y
our s
y
stem hardware confi
g
uration, some of
them ma
y
not be offered in the BIOS Setup.

Settings in BIOS Setup Main menu
10 A26361-D970-Z120-3-7619
Main menu
In the Main menu you can set up the following:
• Time (in the field marked System Time)
• Date (in the field marked System Date)
• Floppy disk drive (in the field marked Diskette A or Diskette B)
• Hard disk drive (in the submenus of Hard Disk)
• System boot (in the submenus of Boot Options)
• Display device (in the field marked Video Display)
PhoenixBIOS Setup
M
ain Advanced Security Server Exit
System Time: [07:42:19]
System Date: [01/08/1997]
Diskette A: [1.4M]
Diskette B: [None]
ÊHard Disk 1: None
ÊHard Disk 2: None
ÊBoot Options
Video Display: [EGA/VGA]
Base Memory: 640K
Extended Memory: 63M
Item Specific Help
——————————————————————
F1 Help ↑↓ Select Item -/+ Change Values F9 Setup Defaults
ESC Exit ← → Select Menu Enter Select ÊSub-Menu F7 Previous Values
Example for Main menu
System Time / System Date
The System Time field and the System Date field show the time and date respectively
according to the system. The time is shown in the format hh:mm:ss
(hours:minutes:seconds) and the date is shown in the format mm/dd/yyyy
(month/day/year). You can move the cursor between the System Time and System
Date fields (e.g. from hours to minutes) using the tabulator key.
!
If the settin
g
sintheSystem Time and System Date fields are fre
q
uentl
y
wron
g
when
y
ou
p
ower u
p
the com
p
uter, the lithium batter
y
is dead.
Chan
g
e the batter
y
as described in „Extensions on the s
y
stem board“-
„Re
p
lacin
g
the lithium batter
y
“).
