BCP SKY7106 User manual

Ver. 5
SKY1032 + SKY1033 + SKY5654 + SKY5923 + SKY5924 + SKY5925
SKY5926 + SKY5927 + SKY7106 + SKY7107 + SKY7108 + SKY7109
SKY7110 + SKY7111
Electric Guitar
INSTRUCTION
MANUAL

As shoppers, we’re always trying
to find the perfect balance between
quality & value. At BCP, we believe
we’ve achieved that. Our diverse
catalog of everyday essentials is
tailored especially to our customers
& guaranteed to hit that sweet
spot of high quality & low price.
Always.

| 3
PARTS
• This product is intended for residential use only.
• Repairs to amplifier or electrical components of guitar should be done by a professional.
• If replacing the fuse or conducting any repairs, unplug amplifier from electricity or electric mains before
replacing the fuse or conducting repairs.
• The fixed bolt should not be over 4 mm (Diameter) x 30 mm (Length) to prevent the fixed bolt from
touching the switch and fuse holder.
Please retain these instructions for future reference.
NOTICE
WARNING
• To avoid risk of electrical shock, do not expose to water or humidity.
• Always connect instrument cord to guitar before connecting cord to amplifier to avoid damage to speaker.
• Do not leave guitar unattended with volume level turned up.
• Neon or fluorescent lighting near the amplifier may cause a hum from amplifier.
• To avoid damaging your ears, turn down volume of amplifier before plugging in headphones or speakers.
• Plugging in a pair of headphones will turn o your amplifier speaker.
A
1 PC
E-TUNER B
1 PC
CARRYING
CASE
C
1 PC
STRAP WITH
PICKHOLDER
D
1 PC
10W AMP
E
1 PC
TREMOLO BAR
I
1 PC
CLOTH
F
1 PC
EXTRA STRINGS G
1 PC
8FT GUITAR
CABLE
H
6 PCS
GUITAR PICK

4|
GUITAR STRING MAINTENANCE
CHANGING STRINGS
If strings are dicult to play or do not play correctly:
Replacing guitar strings can remedy many problems involving poor sound. All strings can be changed at
once or strings can be changed individually. To change a guitar string, the old string should be
completely removed before attaching the new string. After the new string is attached, the guitar will
need to be re-tuned.
Removing Old Strings:
• To remove a guitar string, first, find the tuning machine and tuning peg that the string is attached to.
Loosen the string by winding the tuning peg until the string has no tension.
• Continue to wind the string loose until the string can be pulled loose from the top. The strings can be
pulled out via the bridge at the bottom of the guitar.
• If you do not wish to use the old string again, you can cut the string near the middle of the strings via wire
cutters. If you choose to do this, be careful and hold the string securely next to the cut; otherwise, the
string may pop up and can potentially harm you.
Installing New Strings:
• Attach strings to the bridge of your guitar. Locate the proper string to replace your old string. Then, from
the end of the string that does NOT have a ball at the end, feed the string through the bridge via the
open hole. The string should be pulled through until the ball is secure at the bottom of the bridge.
• Secure the string to the headstock end of your guitar via the tuning machine. To do so, make sure the
eye/hole of the tuning machine is parallel to the neck/headstock of the guitar. Feed the string through
the eye of the tuning machine, and pull the string fairly taut. The string should have a bit of slack (about
1-2 inches).
• Secure the string to the tuning machine by winding the part of the string that has come out through the
tuning machine back underneath the part of the string that is running between the bridge and tuning
machine. Then, pull the string back up and over the string running through the tuning machine (see
diagram). The string should now be secure.
• Begin to tune the string, winding the tuning peg until the desired sound is produced. After hearing the
desired tune, pull the string lightly. The string will go slightly out of tune. Readjust the tuning peg until
receiving the desired tune again. Repeat the process a few more times. This will ensure that your string
will stay in tune while playing.
• You may cut o the excess string, but it is important to leave some excess still attached (about ¼-1 inch)
in case the guitar string needs to be restrung again. Remember, it is easy to cut more o later, but
impossible to add string back.

| 5
Adjusting String Action:
If you feel that you have diculty in fretting or hear a buzzing noise, the strings may be set too high or too
low. In this case, the action (the space between the strings and the fretboard) will have to be adjusted.
Adjusting the action will let you achieve the desired string level. This can easily be remedied by lowering or
raising the string saddles located on the bridge. The saddles are the parts in front of the bridge where the
strings sit. You can raise or lower the saddle by turning the hex screws on the saddle with a hex wrench.
Turn the screw clockwise to raise the saddle and counterclockwise to lower it. If the saddle has two hex
screws, be sure to turn them the same amount.
Adjusting String Intonation:
If you notice that your strings are fretting sharp or fretting flat, or that your guitar is in tune near the
bottom of the guitar but loses tune the further up the frets you go, you may need to adjust the intonation.
First, determine if all strings are having the issue or a particular string. You can adjust the intonation of a
string by moving the saddle away from the nut if the string is fretting sharp, and toward the nut if the string
is fretting flat. Don’t forget that adjusting the saddle for a string only corrects that string. You may need to
adjust intonation for each string. Check the strings as you adjust the intonation to keep the guitar in tune.
Adjusting Truss Rod:
The neck of your guitar can go out of adjustment, or you may want to readjust the neck to get a dierent
sound. The neck on every guitar will eventually need to be readjusted – this is normal guitar maintenance.
Inside the neck of the guitar is a “backbone” of the guitar: a truss rod. This rod helps keep your neck
adjusted. If your strings are creating too high a sound and are hard to fret, or create a low, buzzing noise,
these can signal the guitar neck needs adjustment. If the sound is too high and the strings are hard to fret,
the truss should be tightened. If the sound is low or “buzzy,” it should be loosened.
You can adjust the truss rod with a nut located on one end. It should be located on the headstock, under a
cap just behind the nut or where the neck joins the body under the fingerboard. You may need a truss-rod
wrench to adjust it, which can be purchased at any local music store. To tighten the truss rod, turn the nut
clockwise a quarter-turn at a time, giving the neck a few minutes to adjust. To loosen the truss rod, turn
counterclockwise a quarter turn at a time, giving the neck a few minutes to adjust. Remember that
over-tightening or over-loosening a truss rod can potentially damage the neck and body, so please do so
with care!
CHANGING STRINGS
If there are any electrical components on your guitar which you think need to be fixed, please be aware
that we recommend taking your guitar to your local music store to fix it. Beginner musicians and people
unfamiliar with repairing the electrical parts of a guitar should not attempt to do so, especially without
supervision.
If you hear any rattling or buzzing noises while playing, some hardware may be loose. You can tighten any
hardware with the appropriate tool. It could be possible that a nut on the bridge post may be loose. If you
hear a rattling noise, try strumming the guitar with one hand to re-create the noise while touching various
parts with your other hand. The rattling should stop once you touch the aected part, and then you can
tighten the part that is loose.
Dust and other foreign matter can harm the quality of your electric guitar. Make sure to regularly clean and
maintain your guitar, including around the tuning pegs and bridge. Do not leave your guitar exposed to the
elements, and be aware that guitars are sensitive to changes in temperature, humidity, and altitude.
GUITAR HARDWARE & CARE

00 0
INPUT
DRIVE
VOLUME TREBLE BASS PHONE POWER
6|
GUITAR ANATOMY
67
12
89
34
10
5
1. Tuning Machine
2. Truss Rod
(behind the head)
3. String
4. Saddle
5. Bridge
6. Headstock/Head
7. Tuning Machine
8. Fret
9. Neck
10. Body
10-WATT AMP
1. INPUT
Input jack for your guitar. Plug in your guitar
here with an instrument cord
2. DRIVE
Turns overdrive on/o. Controls the
“distortion” eect
3. VOLUME
Adjusts the master volume level
4. TREBLE
Adjusts the high-frequency note range
5. BASS
Adjusts the low-frequency note range
6. PHONE
Output jack for speakers or headphones
7. POWER
On/O switch
1 2 3 4 567
