BD Alaris GW 800 Series Manual

s
Alaris™ GW 800 Volumetric
Pump
(with Set Detection Mode disabled)
Directions For Use
en

BDDF00160 Issue 1 1/40
Alaris™ GW Volumetric Pumps
Contents
Page
Introduction ..............................................................................................3
Intended Purpose. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Conditions for Use .................................................................................................3
Indications ........................................................................................................3
Contraindications..................................................................................................3
About This Manual ........................................................................................4
Conventions used in this manual ...................................................................................4
Features of the Alaris GW 800 Volumetric Pump ............................................................5
Controls and Indicators....................................................................................6
Controls ...........................................................................................................6
Indicators: (when illuminated)......................................................................................6
Symbol Definitions ........................................................................................7
Labelling Symbols:.................................................................................................7
Operating Precautions ....................................................................................8
Infusion Sets.......................................................................................................8
Mounting the Pump ...............................................................................................8
Operating Pressure ................................................................................................8
Alarm Conditions ..................................................................................................8
Using Collapsable bags, Glass Bottles & Semi Rigid containers.......................................................9
Operating Environment............................................................................................9
Earth Conductor ...................................................................................................9
Electromagnetic Compatibility and Interference .................................................................. 10
Hazards ......................................................................................................... 10
Getting Started ..........................................................................................11
Initial Set Up..................................................................................................... 11
Power Input ..................................................................................................... 11
Pole Clamp Installation .......................................................................................... 12
Docking Station/Workstation* or Equipment Rail Installation...................................................... 12
Loading an Infusion Set .......................................................................................... 13
Power On/Off ................................................................................................... 14
Battery Operation ............................................................................................... 14
Priming the Infusion Set ......................................................................................... 15
Automatic Set Detection ......................................................................................... 16
Starting the Infusion .....................................................................................17
Standard Mode .................................................................................................. 17
Standard Mode with VTBI / Time Infusion on...................................................................... 17
Micro Mode ..................................................................................................... 17
Micro Mode with VTBI / Time Infusion on ......................................................................... 17
Secondary / Piggyback Infusions..........................................................................18
Typical Secondary Infusions: ..................................................................................... 18
Basic Features ............................................................................................19
Rate Titration .................................................................................................... 19
Bolus Infusions .................................................................................................. 19
Panel Lock....................................................................................................... 19
Optimising the Pumps Performance.............................................................................. 19
Hold Mode ...................................................................................................... 19
KVO (Keep Vein Open) Rate ...................................................................................... 19
Changing the Infusion Set ....................................................................................... 20
Changing the Fluid Container .................................................................................... 20
SmartSite™ Needle-Free System Instructions...................................................................... 20
Clearing Air-In-Line .............................................................................................. 21

BDDF00160 Issue 1 2/40
Alaris™ GW Volumetric Pumps
User Selectable Options ..................................................................................22
Check the Battery Status ......................................................................................... 22
Setting the Occlusion Pressure Level ............................................................................. 22
Setting the Alarm Volume........................................................................................ 22
Setting a VTBI / Time Infusion .................................................................................... 22
Setting to Micro Mode ........................................................................................... 22
Configurable Options Sheet ..............................................................................23
Alarms ...................................................................................................24
Advisories................................................................................................25
Flow Sensor Operation ...................................................................................26
Flow Sensor Usage............................................................................................... 26
Model 180 Flow Sensor .......................................................................................... 26
Compatible Dedicated Infusion Sets ......................................................................27
Standard Sets.................................................................................................... 27
Blood Sets ....................................................................................................... 27
Filter Sets........................................................................................................ 28
Burette Sets ..................................................................................................... 28
Opaque Sets..................................................................................................... 28
Low Sorbing Sets ................................................................................................ 28
Secondary Sets .................................................................................................. 28
Filter Extension Sets ............................................................................................. 28
Oncology Sets ................................................................................................... 29
Compatible Non-Dedicated Infusion Sets .................................................................29
Standard Sets.................................................................................................... 29
Blood Sets ....................................................................................................... 29
The Alaris Gateway Workstation .................................................................................. 30
The Alaris DS Docking Station .................................................................................... 30
Maintenance.............................................................................................31
Routine Maintenance Procedures ................................................................................ 31
Battery Operation ............................................................................................... 31
Disposal ......................................................................................................... 31
Cleaning and Storage ....................................................................................32
Cleaning the Pump .............................................................................................. 32
Storing the Pump................................................................................................ 32
Cleaning and storing the Infusion set............................................................................. 32
Cleaning the Flow Sensor ........................................................................................ 32
Specifications ............................................................................................33
IrDA, RS232 and Nurse Call Specification ..................................................................36
RS232 / IrDA Feature ............................................................................................. 36
Nurse Call Feature ............................................................................................... 36
RS232 / Nurse Call Connection Data .............................................................................. 36
Trumpet and Flow Rate Curves ...........................................................................37
Technical Description ....................................................................................38
Power on Self-Tests .............................................................................................. 38
Air-in-Line ...................................................................................................... 38
Downstream Occlusion Pressure ................................................................................. 38
Upstream Occlusion Pressure .................................................................................... 38
Pump Based Free Flow Protection ................................................................................ 38
Anti-Bolus Function.............................................................................................. 38
Spare Parts ..............................................................................................39
Spare Parts ...................................................................................................... 39
Document History........................................................................................39
Contact Us ...............................................................................................40
Customer Service Information.................................................................................... 40

BDDF00160 Issue 1 3/40
Alaris™ GW Volumetric Pumps
Introduction
Introduction
The Alaris GW 800 Volumetric Pump (herein after referred to as 'Pump') is a small lightweight volumetric infusion Pump that provides
accurate and reliable infusions over a range of rates. The ideal Pump for general care and critical care.
This Directions for use can be used with the following Alaris GW 800 800 Volumetric Pumps:-
• 800TIG2BGN1
• 800TIG2CZN1
• 800TIG2DEN1
• 800TIG2FRN1
• 800TIG2NLN1
• 800TIG2TRN1
• 800TIG2RWN1
To achieve the nominal performance stated in this DFU, BD strongly recommends use of Alaris GW 800 branded dedicated infusion sets.
Facilities intending to use non-dedicated infusion sets with the set detection mode disabled are advised to assess performance prior to
clinical use. If adequate performance is not achieved, then Alaris GW 800 branded dedicated infusion sets should be used or the Alaris
GW 800 Volumetric Pump should be re-calibrated. The use of a flow sensor is mandatory when the automatic set detection mode on the
Pump is disabled.
wDISCLAIMER. This Pump has been tested and approved by BD for use only with BD dedicated infusion sets. In the
event the user is considering using infusion sets, not approved for use with the Alaris GW 800 Volumetric Pump,
the user should consult an authorized BD representative for compatibility and/or calibration information prior
to use. In no event, however, does BD make any representations or warranties concerning the adequacy and safe
performance of any non-dedicated infusion sets as it relates to the operation of the Pump and the accuracy of the
infusion.
In no event shall BD be liable for any damages of any kind or nature, including without limitation, direct or indirect,
special, consequential, or incidental damages arising from, or in connection with, the use of non-dedicated infusion
sets (Infusion sets not manufactured by BD), regardless of whether BD has been advised as to the possibility of such
use.
Intended Purpose
The Alaris GW 800 Volumetric Pump is intended for use by medical staff for the purpose of controlling infusion rate and volume.
Conditions for Use
The Alaris GW 800 Volumetric Pump should only be operated by medical staff competent in the use of automated volumetric pumps
and in the management of infusion therapy. Medical staff should determine the suitability of the device in their care area for its
intended purpose.
wThe user must be thoroughly familiar with the Pump and have been trained as per training document 0000CF02888.
Indications
The Alaris GW 800 Volumetric Pump is indicated for the infusion of fluids, medications, parenteral nutrition, blood and blood products
through clinically acceptable routes of administration; such as intravenous (IV), intra-arterial (IA), subcutaneous, epidural or irrigation of
fluid spaces. The Alaris GW 800 Volumetric Pump is indicated for use on adults and paediatrics.
Contraindications
The Alaris GW 800 Volumetric Pump is contraindicated for enteral therapies.

BDDF00160 Issue 1 4/40
Alaris™ GW Volumetric Pumps
About This Manual
About This Manual
The user must be thoroughly familiar with the Pump described in this manual prior to use.
All illustrations used in this manual show typical settings and values which may be used in setting up the functions of the Pump.
These settings and values are for illustrative use only. The complete range of settings and values are detailed in the specifications section.
wKeep this Manual for future reference during the Pump’s operational life.
It is important to ensure that you only refer to the most recent version of the Directions for Use and Technical Service
Manual for your BD products. These documents are referenced on bd.com. Paper copies of the Directions For Use can
be obtained free of charge by contacting your local BD representative. An estimated delivery time will be provided
when the order is placed.
Conventions used in this manual
BOLD Used for Display names, software commands, controls and indicators referenced in this manual, for
example, AC Power Indicator, E, ON/OFF button.
'Single quotes' Used to indicate cross-references made to another section of this manual.
Italics Used to refer to other documents or manuals and also used for emphasis.
wCaution: Wherever this symbol is shown an Important note is found. These notes highlight an aspect of
use that is important for the user to be aware of when operating the Pump.

BDDF00160 Issue 1 5/40
Alaris™ GW Volumetric Pumps
Features of the Alaris GW 800 Volumetric Pump
Features of the Alaris GW 800 Volumetric Pump
Main Display -
Displays the infusion rate, VTBI, VI
and time remaining for VTBI / Time
infusions. Display will flash when
Pump is operating on battery.
Tubing Guide -
Guide to assist in the loading
of the Infusion set.
Door Latch -
Press outer latch to
open the Pump door.
Flow Stop Mechanism -
When activated the mechanism
will stop fluid flow.
Flow Direction Label
Bevel -
Releases the flow
stop mechanism lever
arm when the door is
closed.
Keypad
Display Indicators
Air Sensor Pressure Sensor
Mute Indicator
Alarm Indicator
Infra Red
Communications
port (IrDA)
Folded Pole Clamp
Potential Equalisation
(PE) connector
Mains Inlet
Flow Sensor Interface
RS232 / Nurse call
Connector
Release Lever -
For Rotating cam.
Mains Fuses
Rotating Cam -
To lock onto the
rectangular bars.

BDDF00160 Issue 1 6/40
Alaris™ GW Volumetric Pumps
Controls and Indicators
Controls and Indicators
Controls
Symbol Description
a
ON/OFF button - Press once to switch the Pump on. Press and hold down for approximately 3 seconds to switch
the Pump off.
Note: Logs are maintained for power down events including when the Pump is powered down or
unexpected power loss.
dRUN/HOLD button - Press to start the infusion or to put the infusion on hold.
mCLEAR/MUTE button - Press to silence alarm or advisories for 1 minute. The audio from the alarm or advisories
will resound after this time. Resets numeric values to zero.
Note: To re-enable the alarm audio press any other button or key to unmute.
bPRIME/BOLUS button - Primes the Infusion set. Administers bolus during the infusion.
lPRIMARY/SECONDARY button - Switches the Pump between Primary and Secondary infusion modes. (If
enabled).
eENTER button - Scrolls between rate, time, VTBI and total volume infused (VI). Enters values for selected infusion
/ configuration parameters. Confirms the rate during an infusion titration.
hf CHEVRON keys - Increases or decreases the infusion rate, TIME limit and VTBI. Press and hold to increase the
selection speed. Used to adjust user selectable options
Indicators: (when illuminated)
Symbol Description
SAC POWER indicator - When illuminated the Pump is connected to an AC power supply.
RATE The Pump is displaying the infusion rate in millilitres per hour (ml/h).
VTBI The Pump is displaying the Volume To Be Infused (VTBI) in millilitres (ml).
VI The Pump is displaying the Volume Infused (VI) in millilitres (ml).
TIME The Pump is displaying the infusion time in hours : mins.
MICRO The Pump is operating in the Micro Mode. When not illuminated the Pump is in the Standard Mode.
SEC The Pump is operating in the Secondary Mode. When not illuminated the Pump is in the Primary Mode.
ml/h (Millilitres / hour) When ml is illuminated the Pump displays the rate, VTBI or VI. When the his illuminated the
Pump displays the rate or infusion time.
ALARM Indicator - When flashing indicates the Pump is in an alarm condition.
MUTE Indicator - When flashing indicates the Pump audio alarm is muted.

BDDF00160 Issue 1 7/40
Alaris™ GW Volumetric Pumps
Symbol Definitions
Symbol Definitions
Labelling Symbols:
Symbol Description
Consult accompanying documents
xPotential Equalisation (PE) Connector
>RS232/Nursecall Connector.
kType CF applied part. (Degree of protection against electrical shock)
IP32 Protected against direct sprays of water up to 15° from vertical and protected against solid objects greater
than 2.5mm.
rAlternating Current
sDevice complies with the requirements of Council Directive 93/42/EEC as amended by 2007/47/EC.
TDate of Manufacture
tManufacturer
+Connector for Flow Sensor
UNot for Municipal Waste
WFuse rating
XInfusion indicator - Displays fluid drops detected by the flow sensor when infusing in Standard mode.
YInfusion indicator - Displays fluid drops detected by the flow sensor when infusing in Micro mode.
,Battery Status indicator - Displays status of battery, battery has greater than 30 minutes run time.
.Battery Status indicator - Displays status of battery, battery is low and has approximately 30 minutes or less
run time.

BDDF00160 Issue 1 8/40
Alaris™ GW Volumetric Pumps
Operating Precautions
Operating Precautions
Infusion Sets
• To ensure correct and accurate operation, only use BD single use infusion sets described in the 'Compatible
Dedicated Infusion Sets' section of this Directions for Use. Use an infusion set with an anti-siphon valve
whenever possible. The anti-siphon valve prevents free flow from occurring if an infusion set is incorrectly
loaded or removed from the Pump.
• It is recommended that Infusion sets are changed in accordance with the Directions for Use.
Carefully read the Directions For Use supplied with the Infusion set prior to use. Use of non-specified Infusion
sets may impair the operation of the Pump and the accuracy of the infusion.
• When combining several apparatus and/or instruments with Infusion sets and other tubing, for example via
a 3-way tap or multiple Infusion, the performance of the Pump may be affected and should be monitored
closely.
j• Uncontrolled flow may result if the Infusion set is not properly isolated from the patient i.e. closing a tap in
the set or activating an in-line clamp/roller clamp.
• The Infusion set may be fitted with an in-line clamp, which can be used to occlude tubing in case it is
required to stop fluid flow.
• The Alaris GW 800 Volumetric Pump is a positive pressure Pump, which should use Infusion sets fitted with
Luer lock fittings or equivalent locking connectors.
• To infuse from a burette, close the roller clamp above the burette and open the clamp on the vent on top of
the burette.
• Discard Infusion set if the packaging is not intact or the protector cap is detached. Ensure sets are not kinked
as this may occlude the tubing.
• BD recommends the use of the IVAC® Model 180 Flow Sensor when using sets without anti-siphon valves or
the mandatory use of the IVAC® Model 180 Flow Sensor whenever the Pump set detection mode is disabled.
The flow sensor automatically monitors the infusion flow rate through the drip chamber and will cause the
Pump to alarm if a significant deviation from the infusion rate occurs. The flow sensor will detect empty
containers.
Mounting the Pump
^• The fluid height in the container must not be more than 1 metre above the patients heart.
%; • Do not mount the Pump in a vertical position with the AC power inlet pointing upwards as this could affect
electrical safety, in the event of a fluid spill over the Pump.
Operating Pressure
• The pumping pressure alarm system is not designed to provide protection against, or detection of, IV
complications which can occur.
Alarm Conditions
$• Several alarm conditions detected by this Pump will stop the infusion and generate visual and audible
alarms. Users must perform regular checks to ensure that the infusion is progressing correctly and no alarms
are operating.
• Alarm tone settings are preserved in the case of power loss, however some system faults will result in loss
of alarm settings. The new alarm tone settings will be stored when powering down from tech mode after a
change. The settings will be lost if a cold-start is performed, but should be saved for faults that don't require
a cold start.

BDDF00160 Issue 1 9/40
Alaris™ GW Volumetric Pumps
Operating Precautions
Using Collapsable bags, Glass Bottles & Semi Rigid containers
• It is recommended that the air vent be opened on the Alaris GW 800 Volumetric Pump set if using glass
bottles or semi-rigid containers, to reduce the partial vacuum formed as the fluid is infused from the
container. This action will ensure the Pump can maintain volumetric accuracy whilst the container empties.
The action of opening the air vent for semi-rigid containers should take place after the spiking of the
container and priming of the drip chamber.
Steps for Semi-rigid containers
4.
5.
3.
2.
Spike the
container
Fill drip
chamber to
fill line
Prime the set by
opening / closing the
roller clamp
1.
Close the
roller clamp
Open the air vent
to allow pressure
equalisation - ready
for infusion
Steps for the Collapsable bags
Follow steps 1 to 3 as shown for
the semi-rigid containers, however
do not open vent as in step 4, but
prime the set as per step 5. Ensure
the bag outlet is fully pierced
before filling the drip chamber.
Operating Environment
• When using any infusion Pump in conjunction with other pumps or devices requiring vascular access,
extra care is advised. Adverse delivery of medication or fluids can be caused by the substantial variation in
pressures created within the local vascular system by such pumps. Typical examples of those pumps are used
during dialysis, bypass or cardiac assist applications.
• This Pump is suitable for use in Hospital and clinical environments other than domestic establishments and
those directly connected to the public single phase AC mains power supply network that supplies buildings
used for domestic purposes. (Consult Technical Service Manual, appropriately trained Qualified Service
Personnel or BD for further information).
• This Pump is not intended to be used in the presence of a flammable anaesthetic mixture with air or oxygen
or nitrous oxide.
• Align all Alaris GW 800 Volumetric Pumps within a particular hospital or clinical environment to the same
automatic set detection mode (ie. All On or all OFF) to avoid potential confusion amongst users as to the
mode in which the Pump is operating under and hence to ensure that the appropriate recommendations for
flow sensor usage are followed.
Earth Conductor
d• The Alaris GW 800 Volumetric Pump is a Class I device, therefore must be earthed when connected to an AC
power supply.
• This Pump also has an internal power source.
• When connected to an external power source, a three-wire (Live, Neutral, Earth) supply must be used. If the
integrity of the external protective conductor on the AC power cable has been compromised, the Pump
should be disconnected from the AC power source and operated utilising the internal battery.
