Beamz professional LCB-320 User manual

‐1‐


Ref. No.: 150.556
LCB-320 LED COLORS 320X10MM
DMX 16SEG
MANUAL

‐2‐

Thank you for purchasing our company products.
Please read these instructions carefully to enjoy optimum performance and a longer service life before you start to
use.
CONTENTS
Unpacking Inspections............................................................................................................. 2
Unpacking instructions..................................................................................................... 2
Checking the contents of the carton:................................................................................ 2
Safety Instructions................................................................................................................... 2
Functions Introductions............................................................................................................ 3
Main Functions................................................................................................................. 3
System menu.................................................................................................................... 4
Operating instructions.......................................................................................................5
DMX channels..................................................................................................................6
Maintenance............................................................................................................................ 7
Specification ............................................................................................................................ 7
UNPACKING INSPECTIONS
Unpacking instructions
Please unpack the carton and check the goods carefully when you receive it , if discover packing
damage, shortage or quality problem, please notify the shipper and reject the goods.
Before using this product, please read the instructions carefully and keep it in a safe place for future
reference.
Checking the contents of the carton:
The product, Power cord, Instruction Manual, Mounting Brackets + screws
SAFETY INSTRUCTIONS
Safety and regulatory power socket with high quality output should be used .
Always connect the product to a grounded circuit to avoid the risk of electrocution.
Never put tiny metal objects such as a screwdriver, iron wire and coins, etc. into the internal or stretch into
the machine in case of short circuit .
Please make sure to connect the proper voltage and do not higher or lower than that stated on the decal
or rear panel of the product .
Avoid hitting, crashing or squeezing with other objects in transportation. Never carry the product from the
power cord or any moving part . Always use the hanging / mounting bracket or the handles.
The product is used in door only .
Never pull or tug on the cord and change it for another one , stop using it when it is damaged or becomes
hot .
Stop using the product once there is sparks when connecting with the power plug .

‐3‐

Make sure there are no flammable materials close to the fixture while operating . Always install it in a
location with adequate ventilation.
Never replace the lighting source with different specification and rating when the original one is damaged.
Make sure to power off before replacing the light source or the fuse. Never do it while it is on.
The ambient temperature is no more than 40°C(104°F) .
Never clean the fixture by water, thinner or other dissolved agent .
Stop using the product in case of a serious operating problem and send it to our maintenance agent
immediately. Never repair by non-professional workers .
Avoid direct eye exposure to the light source while the product is on.
SPECIFICATION
Colors RGB
No. of LEDs 320 x 10mm (128 red, 96 green, 96 blue)
No. of patterns 20
DMX channels 3-5-8-14-48 and 50
Power Supply 220-240Vac / 50Hz
Dimensions 993 x 63 x 80mm
Weight 2.7kg
MAINTENANCE
The unit should be cleaned periodically to ensure the optimum performance, the smudginess can decrease the
life of light and the output of light is affected by the dust which can make the machine overheating. In general,
make the maintenance at least two times a month. Be sure to power off the unit before cleaning .
Do not clean until the unit recovers normal temperature since high temperature for using, use the lens tissue or
soft cotton cloth with alcohol to wipe gently.
Cleaning frequency depends on the environment in which the fixture operates, damp, smoky or dirty surrounding
can cause greater accumulation of dirt on the optics. Never rub or press strongly on the panel.
FUNCTIONS INTRODUCTIONS
Main Functions
3, 5, 8, 14, 48 or 50 DMX channels .
Sound Active, DMX, master/slave mode .
320x 10mm LEDs
With static colors, strobe, dimmer, color mixing and changing effects.
Electronic dimming 0 – 100%

‐4‐

System menu
DMX Address – Set the DMX address
Press MENU, press the UP or DOWN button until “Addr” is displayed, press ENTER.
“Axxx” will now be displayed, (“xxx” represents the displayed address). Press the UP or DOWN button to find the
desired address. Press ENTER to confirm

‐5‐

Channel mode – Select the desired channel mode
Press MENU, press the UP or DOWN button until “Chnd” is displayed, press ENTER
“X Ch” will now be displayed, (“X” represents the displayed channel mode). Press the UP or DOWN button to find
the desired channel mode. Press ENTER to confirm.
Auto mode – This menu will let you select the desired auto mode.
Press MENU, press the UP or DOWN button until “Auto” is displayed, press ENTER.
There are 3 auto modes, press the UP or DOWN button to select the desired mode, press ENTER to confirm.
Color mode – Select the desired color mode
Press MENU, press the UP or DOWN button until “CoLo” is displayed, press ENTER.
“Colx” or ATF will now be displayed, (“X” represents a number between 1 – 9). Press the UP or DOWN button to
find the desired color mode. Press ENTER to confirm.
ATF: Make your own color by mixing and adjusting the Red, Blue and Green color.
Sound mode – In this mode you can select your desired sound active mode
Press MENU, press the UP or DOWN button until “soun” is displayed, press ENTER.
Select the desired sound mode and press ENTER
Slave mode – In this mode the unit functions as a slave
Press MENU, press the UP or DOWN button until “Slav” is displayed, press ENTER.
“Sla” will now be displayed, Slave mode is confirmed. The unit will now act as a slave in Auto, sound and chase
mode.
Version – Will display the software version of the unit.
Press MENU, press the UP or DOWN button until “ver” is displayed, press ENTER.
The software version of the unit will be displayed. Press MENU to leave this function
Operation Instructions
DMX connection.
Master / Slave connection.


‐6‐

DMX Channels:
Note: when the function is strobing, the LED will be dimmed by channel
3-50 for auto mode, sound mode and chase mode.

‐7‐

CE Declaration of Conformity
Importer: TRONIOS BV
Bedrijvenpark Twente 415
7602 KM - ALMELO
Tel : [phone]
Fax : [phone]
The Netherlands
Product number: 150.556
Product Description: LCB-320 LED Colors 320 x 10mm DMX 16 segments
Regulatory Requirement: EN 60598-1/-2-17
EN 55015
EN 61547
EN 61000-3-2/-3-3
The product meets the requirements stated in the above mentioned Standards.
13-12-2012
Signature :
