Bearon Aquatics Ice Eater P250 User manual

OWNER’S MANUAL
PLEASE READ ENTIRELY BEFORE OPERATING
☐P250 - .25HP Ice Eater
☐P500 - .5HP Ice Eater
☐P750 - .75HP Ice Eater
☐P1000 - 1HP Ice Eater

2
Safety Instructions page 3
 SpecicationSheet        page4
Installation & Operation page 5
 Maintenance&Troubleshooting     page6
Parts & Accessories page 7
Warranty Informtion page 8
CONTENTS
WARNING: This product contains lead, a chemical known to the State of California to cause cancer and birth
defects, or other reproductive harm.
Service Center
Paperwork
www.bearonaquatics.
com/service
Product
Registration
www.bearonaquatics.
com/resources/
warranty-registration/
Search for
Distributor or
Service Center
www.bearonaquatics.
com/search-for-a-
distributor/

3
CAUTION SHOULD BE USED WHEN DEALING WITH ANY ELECTRICAL EQUIPMENT WITH
MOVING PARTS.
NEVER LIFT OR DRAG THE UNIT BY THE POWER CORD. USE PROVIDED MOORING LINE TO
MOVE THE UNIT AS NECESSARY.
THIS MOTOR IS PROVIDED WITH A GROUND WIRE OR GROUNDING TYPE PLUG FOR
YOUR PROTECTION.
THE GROUND WIRE MUST BE SECURELY ATTACHED TO PROPER ELECTRICAL GROUND OR THE
GROUNDING TYPE PLUG MUST BE USED ONLY WITH A PROPERLY GROUNDED RECEPTACLE.
IN ADDITION, YOU SHALL USE GROUND FAULT INTERRUPTER PROTECTION IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE.
DO NOT UNDER ANY CIRCUMSTANCES CUT OR REMOVE THE GROUND PRONG FROM A
GROUNDING TYPE PLUG.
ANY REWORK OR DAMAGE TO THIS CORD MAY CREATE SHOCK HAZARD AND WILL VOID
THE WARRANTY.
A QUALIFIED ELECTRICAN MUST BE CONSULTED TO INSURE A SAFE INSTALLATION.
UNDER NO CIRCUMSTANCES SHOULD ANYONE ENTER THE WATER WITH THE ELECTRICAL
EQUIPMENT CONNECTED AND/OR IN OPERATION. IT IS NEVER RECOMMENDED TO ENTER
THE WATER WITH THE EQUIPMENT IN OPERATION.
ALWAYS DISCONNECT THE ICE EATER FROM THE POWER SOURCE BEFORE ANY SERVICING
OR CLEANING OR MOVING OF THE UNIT BY UNPLUGGING OR BY REMOVING FUSE OR
DEACTIVATING CIRCUIT BREAKER.
WHEN USING OUR ICE EATER AND OUR THERMOSTAT TOGETHER, UNIT WILL START
AUTOMATICALLY BY AIR TEMPERATURE.
ALWAYS DISCONNECT THE ICE EATER FROM POWER SOURCE BEFORE ANY SERVICING
OR CLEANING OR MOVING OF THE UNIT BY UNPLUGGING OR BY MOVING FUSE OR
DEACTIVATING CIRCUIT BREAKER.
DO NOT REMOVE END COVER PLATE. REMOVAL OF PLATE WILL VOID WARRANTY. ALL
REPAIRS MUST BE MADE AT FACTORY OR AN AUTHORIZED SERVICE STATION.
RECOMMENDED COMMERCIAL GRADE BREAKER. USE DEDICATED CIRCUIT PER UNIT.
WARNING WARNING WARNING WARNING WARNING WARNING WARNING WARNING
WARNING WARNING WARNING WARNING WARNING WARNING WARNING WARNING
10233 SOUTH DOLFIELD RD • OWINGS MILLS, MD 21117
410.654.9700 • [e-mail] • WWW.BEARONAQUATICS.COM
BEARON AQUATICS
POWER HOUSE AERATIONOLYMPUS FOUNTAINSICE EATERS

4
STATISTICS BY HORSEPOWER
• P250; .25 HP; Single Phase;
2.6 Amps (115V) / 1.3 Amps (230V);
360 Gallons per Minute (GPM).
• P500; .5 HP; Single Phase;
6 Amps (115V) / 3 Amps (230V);
1075 Gallons per Minute (GPM).
• P750; .75 HP; Single Phase;
6 Amps (115V) / 3 Amps (230V);
1250 Gallons per Minute (GPM).
• P1000; 1 HP; Single Phase;
7 Amps (115V) / 35 Amps (230V);
1400 Gallons per Minute (GPM).
ALL MOTORS
• 1,650 Rotations per Minute (RPM).
• 24 pounds of thrust.
• Fluid Cooled, Continuous Duty Rated.
• (2) Long Life Bearings.
• Thermal Overload Protection.
• Fully Utilized Heavy Duty Carbon
Ceramic Mechanical Seal.
• Series 300 Austenitic Stainless
Housing with Magnesium Bronze
End-Bell.
SHROUD
• Patented heavy-duty PVC Venturi
housing designed for superior water
ow and motor/propeller protection.
• Series 300 Stainless Steel Hardware.
• (2) 25’ long 3/8” thick hollow braided
polypropylene ropes.
POWER CABLE
• SJTOW UL & CSA Approved
Underwater Rated Cable, 3 Wire.
• Available in 50’, 100’, and 150’ in
115V with Quick Disconnect Power
Cord.
• Available in 50’, 100’, 150’, 200’, 250’,
300’, 350’, and 400’ in 230V with
Quick Disconnect Power Cord.
QUICK FACTS
• Agitate more fresh and salt water
than any other de-icer on the
market.
• 20’-25’ (.25Hp), 40’ (.5Hp), 60’ (.75Hp)
& 80’ (1Hp) are the average open
diameter under normal winter
conditions.
• Complete package includes
assembled motor unit, shroud, (2)
25’ long 3/8” thick hollow braided
polypropylene ropes, and SJTOW
rated 3 wire power cord and
Sacricial Aluminum Anode.
• Sacricial Aluminum Anode installed
for corrosion protection and use in
salt-water applications.
• Additional Sacricial Aluminum
Anode and Electrolysis Kit are
available for corrosion protection
and use in salt-water applications.
• Available in 115V or 230V.
• Able to operate in water as shallow
as 24” (41cm).
• 15 Amp Breaker Recommended.
• Total Component Listed to meet
UL and CSA Standards for Safety in
Water.
• UL Listed Water Circulating Pump
E481181.
• Met Listing No. E112360.
• Energy ecient with excellent
Gallons per Minute (GPM)/kW Rates.
• Industrial Strength Design.
• 3-Year Warranty.
• Made in the USA.
WARNING
 DoNotRuntheUnitOutofWater.
Ground Fault Circuit Interrupter
(GFCI) or Residual Current Device
(RCD) protected circuit required.
• Other cord lengths are available
through special order but will not
have a Quick Disconnect Power Cord.
• Potted Quick Disconnect Gauge
Cord.
• 16/3 gauge for 25’, 50’, and 100’ long.
• 14/3 gauge for 150’, 200’ and longer.
OPTIONAL THERMOSTAT
• Simple and easy to use. Plug in the
portable thermostat into the wall
outlet and then plug an Ice Eater
into the back of the thermostat’s
piggyback plug and set the
temperature.
• Not aected by surges and lightning
strikes or power outages like a digital
thermostat.
• Convenient ip open clear cover
protects from weather and damage.
• Moisture proof box.
• Made in the USA.
OPTIONAL TIMER
• Outdoor grade plastic.
• Timer: 24-hour with 23-1/2 hour
maximum on time. (2) “ON” & (2)
“OFF” trippers – standard.
• Dial will accept up to 12 sets of
trippers.
• Electrical Rating: 15 A (1800 W),
Resistive or Tungsten.
• Agency Approval: CSA/C-US.
• Outdoor grade cord with ground
plug, 3 wire, 22 inches.
OPTIONAL DOCK MOUNT
• Adjusts the Ice Eater angle in 20
degree increments from horizontal
to vertical with full 360 degree
positioning.
• Steel mounting base, bail & pipe
holder are all powder-coated twice
to protect against corrosion.
• Maximum pipe length is 6’ to provide
secure mounting & prevents pole
from bending.
• Made in the USA.
When water freezes, it expands, becoming lighter. This fact is the principle upon which Ice Eater functions.
Ice Eater’s propeller draws up warmer subsurface water and deects it to the surface creating a constant circulation of warmer
water that prevents ice formation and melts existing ice.
The Ice Eater is custom designed and engineered for maximum eciency and performance in all climates.
Ice Eater obtains its superior operating eciency through the use of an axial ow, shrouded propeller design. This design also
provides protection for the rotating propeller.
Ice Eater is shipped complete with suspension lines. It can be taken straight from its shipping carton, hung in place and
plugged in.
SPECIFICATION

5
INSTALLATION
• Immediately after delivery, inspect the Ice Eater shipment for
any visible damages. Report any damage to your dealer.
• The Ice Eater is completely assembled. You will not need
additional hardware unless you are installing it with an
optional dock mount or shallow water stand.
• Install the Ice Eater by hanging with provided mooring lines
in the area to be kept clear of ice. A dock mount and shallow
water stand are sold separately.
Ice Eater may be hung from a pier or from a boat.
Place Ice Eater at a depth which produces best results for
each specic location (2 - 3 feet is a good average
operating depth).
WARNING:DonotplaceIceEateronthebottom.Make
suretomaintainatleast1’clearancefromthebottom.
• If the Ice Eater is hung from a boat or oating pier, try to
guard against a falling tide depositing the unit on the bottom.
NOTE:
If a circular pattern of de-icing is desired, hang Ice Eater
straight (see gures 1A & 1B). For straight hanging, use top
rim holes A & B shown in gure 3.
If an elongated pattern of de-icing is desired, hang Ice Eater at
an angle (see gures 2A & 2B).
For angle hanging, use Rim Hole A and C, D, E, or F. The Ice
Eater operating angle will increase as the suspension line is
moved around the rim towards Hole F.
• Once your Ice Eater is properly installed and secured, you can
now plug the electrical cord into properly grounded and GFCI
protected circuit. Make sure to plug into corresponding 115
or 230 volt receptacle and proper voltage is available at the
unit’s motor.
WARNING:Whenanextensioncordisused,itmustbe
sized as follows:
Up to 100ft. - Use #12/3 wire cord.
Up to 200ft. - Use #10/3 wire cord.
OPERATION
• After installation, the Ice Eater is ready for immediate use.
• The Ice Eater is designed and engineered for continuous duty
in the harshest environments.
• Operating equipment should be observed on a regular basis
for any reduction or variation in the Ice Eater’s performance.
• Routinely inspect the sacrical anode, propeller, etc.
Replace parts as necessary.
WARNING: Do not run out of water. Unit must be
submerged.Keephandsclear.
• A thermostat is available as an additional accessory. This will
greatly reduce the amount of energy consumed by Ice Eater,
while still maintaining ice free conditions.
Figure 1A
Circular De-Icing Pattern
(Install Ice Eater as shown in Figure 1B)
Suspension Lines Figure 1B
Ice Eater Hanging Staight
Ice Eater
←
←
←
Figure 3
Top Rim of Ice Eater
Hole F
Hole E
Hole D
Hole C
Hole B Hole A
←
←
←
←
←
←
Ice Eater located
at head of pier
Elongated De-Icing Pattern
(install Ice Eater as shown in Figure 2B)
Figure 2A
←
←
Suspension Lines
Ice Eater
Ice Eater Hanging at an Angle
Figure 2B
←
←
INSTALLATION & OPERATION
10233 SOUTH DOLFIELD RD • OWINGS MILLS, MD 21117
410.654.9700 • [e-mail] • WWW.BEARONAQUATICS.COM
BEARON AQUATICS
POWER HOUSE AERATIONOLYMPUS FOUNTAINSICE EATERS

6
TROUBLESHOOTING TIPS
1) If unit does not start when plugged in or turned on:
a) Check power source to make sure that voltage is
available.
b) Make certain the power cord connections are fully
made. Check tightness at both the source end and at
the unit.
c) See if circuit breaker is tripped or has a blown fuse.
Check ground-fault interrupter. If any of these are
tripped or blown, have an electrician check your
installation.
d) Unplug unit and make certain the propeller turns
freely. Turn propeller through several full revolutions.
e) Plug the unit back in and try to start again.
2) If unit starts slowly or does not have full ow:
a) Check power source for voltage drop or undersized
service. If several pieces of equipment are operating
on the same circuit, they may need to be started
individually.
b) Unplug unit and make certain that prop turns freely.
Turn prop through several full revolutions. Try to start
unit again.
c) Unplug unit and make sure there is no debris around
prop or shaft.
d) Check screen to make sure it is clean. Algae or grass
accumulation must be removed.
3) If unit starts and stops then starts and stops:
a) Check power source for voltage drop or undersized
service. Unit may be overheating due to low voltage.
b) Unplug unit and make sure there is no debris around
prop or shaft. Unit may be overheating due to
overload.
MAINTENANCE
• The Ice Eater motor is lled and sealed with a special
non-toxic dielectric lubricating uid and does not require
additional lubrication.
• When storing your unit, clean it thoroughly and place it
propeller side down in a at, cool place.
Storing propeller side down will keep the
seals lubricated.
• Units placed in heavy weed or plant locations may need
to have the screen and prop cleaned occasionally. Before
removing or cleaning the unit, unplug or disconnect the
unit from the power source. Scrub with a sti, nylon
bristle brush. The unit will not be damaged by cleaners;
however, these products could leave a residue that may
damage plants and animals when the unit is put back in
service. If cleaners are used, ush and rinse thoroughly
with fresh, clean water.
• Routinely inspect the propeller, internal brackets and
shaft for accumulation of weeds, vines or string. Foreign
objects can damage the seals, prop and shaft. Keep the
shaft and propeller clear of debris. Inspect the brackets
and propeller for chips and cracks. Broken or damaged
brackets or propeller can be replaced easily in the eld
with factory parts.
• Inspect the power cord for breaks, nicks and abrasion.
Under normal conditions, the cord will be usable for many
years. However, physical abuse and rodent, animal or
equipment damage can result in safety hazards such as
electrical shock. If the outer jacket is cut deeply enough
that the inner conductors can be seen, the cord should
be replaced. If the copper wire is showing, immediately
remove the unit from service and replace the cord. Severe
shock could result.
• Units operated in brackish or salt water must have a
sacricial anode attached to the shaft. The anode must
be inspected periodically for deterioration. Operation
without the anode could result in metal deterioration and
contamination and may void the warranty.
• The motor can only be opened and assembled under
special conditions at the factory or authorized service
center. Do not attempt to repair the motor. Any tampering
or attempted repairs may void the warranty and could
result in equipment failure or bodily injury.
WARNING:Donotopenthesealedmotorunitforany
reason.
• For optimum operation, send the unit to the manufacturer
or authorized service center every four to ve years for
standard service. Commercial duty operations may wish
to service units more frequently.
Figure 3
Top Rim of Ice Eater
Hole D Hole A
Hole F
←
Hole E
←
←
Hole C
←
Hole B
←
←
←
←
Water Intake Holes
Dock Mount Holes
←
←
MAINTENANCE & TROUBLESHOOTING

7
Screen Kit
Small - ts P500
Large - ts P750, P1000
SacricialAnode
Aluminium - ts all models. 1
anode and 1 hex key included.
protects against corrosion and
electrolysis in salt water, high
electrical current and/or
warm water.
Electroylsis Kit
One Size - ts all Ice Eater
models. Additional protection
against corrosion and electrolysis
in areas of high salinity, high
electrical current and/or
warm waters.
Shackles (set of 2)
One Size - ts all Ice Eater models
1/4" stainless steel shackles with
a 9/64" short arm hex key
Mooring Lines
(3/8” thick hollow braided
polypropylene ropes)
(2) 25’ blue ropes
DockMount
The premium option to consider
for positioning your Ice Eater.
Make your placement more
secure than suspension lines, and
unaected by the current.
Small - ts P500
Large - ts P750 & P1000
IceEaterShrouds
Patented heavy-duty PVC Venturi
housing designed for superior
water ow and motor/propeller
protection.
Half - ts P250
Small - 10”x12”, ts P500
Large - 12”x15”, ts P750 &
P1000
Mini Blue Propeller - ts P250
Yellow Propeller - ts P500
Blue Propeller - ts P750
Green Propeller - ts P1000
Brackets (set of 4)
Small - ts P250
Large - ts P500, P750, P1000
P1101 Timer - for 115V Ice Eater
This grounded plug-in timer
utilizes an outdoor rated
raintight ip-open enclosure.
(2) On and (2) O settings make
this a perfect timer to control
your Ice Eater and keep your
costs low.
T104PTimer - for 230V Ice Eater
This heavy-duty timer stands
the test of time while providing
the highest horsepower ratings
in the industry for industrial,
commercial, and
residential applications.
Thermostat- 0°F - 80°F range.
An inexpensive way to control
the operation of your Ice Eater
by using ambient air
temperature. Set the
temperature to turn your Ice
Eater on when the temperature
drops below that setting.
115V & 230V
PARTS & ACCESSORIES
Replacement power cords,
critter sleeving, and motor
assemblies are available for
every Ice Eater model.
10233 SOUTH DOLFIELD RD • OWINGS MILLS, MD 21117
410.654.9700 • [e-mail] • WWW.BEARONAQUATICS.COM
BEARON AQUATICS
POWER HOUSE AERATIONOLYMPUS FOUNTAINSICE EATERS

8
Bearon Aquatics, a division of Bearon Manufacturing LLC (herein called “Bearon”), warrants products to be free from defects
in material and workmanship for the warranty period specied below from the date of manufacture by Bearon, under normal
use and service. This limited warranty does not include defects or failures due to mishandling, misuse, improper installation, or
improper electrical supply.
Bearon will replace any defective parts covered by its warranty without charge for parts or labor, provided that the full unit is
returned to Bearon (or an Authorized Service Center) within thirty (30) days after discovering the defect.
Thiswarrantyisinlieuofanyotherwarranty,expressorimplied,includingbutnotlimitedto,anyimpliedwarranty
ofmerchantabilityortnessforaparticularpurposeandanyotherobligationorliabilitywhatsoeveronthepartof
Bearon.innoeventshallBearonbeliableforincidentalorconsequentialdamages.
In addition to the product-specic limitations below, the warranty will be voided if any of the following occurs:
• Use of parts or products not manufactured by Bearon;
• The unit is damaged or altered by unauthorized tampering and/or repairs;
• The unit was subjected to abuse, negligence, accident, or misapplication;
• Example: chips/nicks and deterioration in propeller size
• The unit is not stored properly;
• The unit was run out of water; or
• An improper sized extension cord or circuit.
IMPORTANT: one unit per dedicated outlet
Standard maintenance services and the replacement of service items connected with such services are covered
by warranty.
Standard Service items include seals, bearings, dielectric uid, boot & capacitor. Standard Service is only available for Ice Eater,
Power House Aeration, & Weeds Away products.
All units must be shipped complete prepaid/brought to the attention of:
Bearon Aquatics
Attn: Service Center
10233S.DoleldRd.
Owings Mills, MD 21117
OR can be shipped complete prepaid/brought to an authorized service center of Bearon Aquatics.
There are no warranties beyond those contained herein, and no person is authorized to give any other warranties or assume
liabilities on behalf of Bearon. An evaluation fee (see specic product for details), plus return shipping, will be charged when a
unit is returned for repair and found to be in good working condition. The evaluation fee also applies for units customers decide
not to repair but wish to reclaim certain parts. The evaluation fee is waived if the unit is scrapped (at Bearon) or the unit is
repaired. After the original warranty period described below has ended, there is a thirty (30) day warranty period for a standard
repair by Bearon. A new, full warranty is only reissued if a customer purchases a brand new motor with service.
• Warranty Period: Three (3) years from the date of manufacture by Bearon.
• If a unit is used for purposes other than de-icing, then a one (1) year limited warranty shall apply.
• NOTE: There are certain conditions under which no circulator/de-icer can prevent ice damage, such as ice
that moves as a result of wind or current, extremely cold weather where ice forms all the way to the bottom,
and in some cases, where the bottom temperature is the same as the ice (very shallow water). The operation
eciency will be somewhat reduced when the ow is restricted by allowing too little bottom clearance.
• In areas of high salinity, high electrical current, and/or warm temperatures, a Bearon electrolysis kit must be mounted
to the stainless steel can.
• In addition to the limitations above, this limited warranty does not include any defects or failures of the sacricial
anode, ropes, power cord, propeller, or brackets. The warranty will be voided if the sacricial anode around
the propeller, shaft, and/or stainless steel can shows signicant deterioration. Failure to keep the shaft and can
clear of debris (including string, bags, calcium buildup, barnacles, etc.); or the propeller shows signs of excessive
or unusual wear and tear.
• Failure to inspect and replace anodes constitutes misuse.
• Complete units must be shipped for evaluation.
• The evaluation fee is $65.
**All units sent to Bearon or authorized repair center are considered abandoned,
if not claimed, after six (6) months. Bearon is no longer responsible for such units,
and units will be scrapped.**
WARRANTY
10233 SOUTH DOLFIELD RD • OWINGS MILLS, MD 21117
410.654.9700 • [e-mail] • WWW.BEARONAQUATICS.COM
BEARON AQUATICS
POWER HOUSE AERATIONOLYMPUS FOUNTAINSICE EATERS
