Beckhoff EPP4314-1002 Operator's manual

Documentation | EN
EPP4314-1002
2-channel analog input + 2-channel analog output
2023-11-29 | Version: 1.3

Table of contents
EPP4314-1002 3Version: 1.3
Table of contents
1 Foreword....................................................................................................................................................5
1.1 Safety instructions.............................................................................................................................5
1.2 Notes on the documentation .............................................................................................................6
1.3 Documentation Issue Status .............................................................................................................7
2 Product group: EtherCATPBox modules..............................................................................................8
3 Product overview ......................................................................................................................................9
3.1 Introduction .....................................................................................................................................10
3.2 Technical data.................................................................................................................................11
3.2.1 Digital inputs..................................................................................................................... 12
3.2.2 Analog inputs ................................................................................................................... 12
3.2.3 Analog outputs .................................................................................................................13
3.2.4 Measuring ranges ............................................................................................................ 14
3.2.5 Output signal ranges ........................................................................................................ 20
3.3 Scope of supply...............................................................................................................................23
3.4 Process image ................................................................................................................................24
4 Mounting and connections.....................................................................................................................26
4.1 Mounting .........................................................................................................................................26
4.1.1 Dimensions ......................................................................................................................26
4.1.2 Fixing................................................................................................................................ 27
4.1.3 Functional earth (FE) ....................................................................................................... 27
4.2 Connections ....................................................................................................................................28
4.2.1 Connector overview ......................................................................................................... 28
4.2.2 EtherCATP ......................................................................................................................29
4.2.3 Signal inputs and outputs................................................................................................. 33
4.3 UL Requirements ............................................................................................................................37
4.4 Disposal ..........................................................................................................................................38
5 Commissioning and configuration........................................................................................................39
5.1 Integrating into a TwinCAT project..................................................................................................39
5.2 Analog inputs ..................................................................................................................................40
5.2.1 Signal flow........................................................................................................................ 40
5.2.2 Measuring range ..............................................................................................................41
5.2.3 Filter .................................................................................................................................46
5.2.4 Limit value monitoring ......................................................................................................48
5.2.5 Calibration and scaling..................................................................................................... 49
5.3 Analog outputs ................................................................................................................................52
5.3.1 Signal flow........................................................................................................................ 52
5.3.2 Output signal range.......................................................................................................... 53
5.3.3 Diagnosis .........................................................................................................................54
5.3.4 Behavior in case of a communication interruption: Watchdog .........................................55
5.3.5 Calibration and scaling..................................................................................................... 58
5.4 Restore the delivery state ...............................................................................................................61
6 CoE parameters.......................................................................................................................................62
6.1 Object directory ...............................................................................................................................62

Table of contents
EPP4314-10024 Version: 1.3
6.2 Object description ...........................................................................................................................64
6.2.1 Objects for parameterization ............................................................................................ 64
6.2.2 Standard objects ..............................................................................................................66
6.2.3 Profile-specific objects ..................................................................................................... 72
7 Appendix..................................................................................................................................................76
7.1 General operating conditions ..........................................................................................................76
7.2 Accessories.....................................................................................................................................77
7.3 Continuative documentation for I/O components with analog in and outputs .................................78
7.4 Version identification of EtherCAT devices .....................................................................................79
7.4.1 General notes on marking................................................................................................ 79
7.4.2 Version identification of IP67 modules ............................................................................. 80
7.4.3 Beckhoff Identification Code (BIC) ................................................................................... 81
7.4.4 Electronic access to the BIC (eBIC)................................................................................. 83
7.5 Support and Service........................................................................................................................85

Foreword
EPP4314-1002 5Version: 1.3
1 Foreword
1.1 Safety instructions
Safety regulations
Please note the following safety instructions and explanations!
Product-specific safety instructions can be found on following pages or in the areas mounting, wiring,
commissioning etc.
Exclusion of liability
All the components are supplied in particular hardware and software configurations appropriate for the
application. Modifications to hardware or software configurations other than those described in the
documentation are not permitted, and nullify the liability of Beckhoff Automation GmbH & Co. KG.
Personnel qualification
This description is only intended for trained specialists in control, automation and drive engineering who are
familiar with the applicable national standards.
Signal words
The signal words used in the documentation are classified below. In order to prevent injury and damage to
persons and property, read and follow the safety and warning notices.
Personal injury warnings
DANGER
Hazard with high risk of death or serious injury.
WARNING
Hazard with medium risk of death or serious injury.
CAUTION
There is a low-risk hazard that could result in medium or minor injury.
Warning of damage to property or environment
NOTICE
The environment, equipment, or data may be damaged.
Information on handling the product
This information includes, for example:
recommendations for action, assistance or further information on the product.

Foreword
EPP4314-10026 Version: 1.3
1.2 Notes on the documentation
Intended audience
This description is only intended for the use of trained specialists in control and automation engineering who
are familiar with the applicable national standards.
It is essential that the documentation and the following notes and explanations are followed when installing
and commissioning these components.
The qualified personnel is obliged to always use the currently valid documentation.
The responsible staff must ensure that the application or use of the products described satisfy all the
requirements for safety, including all the relevant laws, regulations, guidelines and standards.
Disclaimer
The documentation has been prepared with care. The products described are, however, constantly under
development.
We reserve the right to revise and change the documentation at any time and without prior announcement.
No claims for the modification of products that have already been supplied may be made on the basis of the
data, diagrams and descriptions in this documentation.
Trademarks
Beckhoff®, TwinCAT®, TwinCAT/BSD®, TC/BSD®, EtherCAT®, EtherCATG®, EtherCATG10®, EtherCATP®,
SafetyoverEtherCAT®, TwinSAFE®, XFC®, XTS® and XPlanar® are registered trademarks of and licensed by
Beckhoff Automation GmbH. Other designations used in this publication may be trademarks whose use by
third parties for their own purposes could violate the rights of the owners.
Patent Pending
The EtherCAT Technology is covered, including but not limited to the following patent applications and
patents: EP1590927, EP1789857, EP1456722, EP2137893, DE102015105702 with corresponding
applications or registrations in various other countries.
EtherCAT® is registered trademark and patented technology, licensed by Beckhoff Automation GmbH,
Germany.
Copyright
© Beckhoff Automation GmbH & Co. KG, Germany.
The reproduction, distribution and utilization of this document as well as the communication of its contents to
others without express authorization are prohibited.
Offenders will be held liable for the payment of damages. All rights reserved in the event of the grant of a
patent, utility model or design.

Foreword
EPP4314-1002 7Version: 1.3
1.3 Documentation Issue Status
Version Comment
1.3 • EPP4314-1002 added
1.2 • EtherCATP status LEDs updated
1.1 • Technical data updated
• Structure update
1.0 • First release
Firmware and hardware versions
This documentation refers to the firmware and hardware version that was applicable at the time the
documentation was written.
The module features are continuously improved and developed further. Modules having earlier production
statuses cannot have the same properties as modules with the latest status. However, existing properties
are retained and are not changed, so that older modules can always be replaced with new ones.
The firmware and hardware version (delivery state) can be found in the batch number (D-number) printed on
the side of the EtherCAT Box.
Syntax of the batch number (D-number)
D: WW YY FF HH
WW - week of production (calendar week)
YY - year of production
FF - firmware version
HH - hardware version
Example with D no. 29 10 02 01:
29 - week of production 29
10 - year of production 2010
02 - firmware version 02
01 - hardware version 01
Further information on this topic: Version identification of EtherCAT devices [}79].

Product group: EtherCATPBox modules
EPP4314-10028 Version: 1.3
2 Product group: EtherCATPBox modules
EtherCATP
EtherCATP supplements the EtherCAT technology with a process in which communication and supply
voltages are transmitted on a common line. All EtherCAT properties are retained with this process.
Two supply voltages are transmitted per EtherCATP line. The supply voltages are electrically isolated from
each other and can therefore be switched individually. The nominal supply voltage for both is 24VDC.
EtherCATP uses the same cable structure as EtherCAT: a 4-core Ethernet cable with M8 connectors. The
connectors are mechanically coded so that EtherCAT connectors and EtherCATP connectors cannot be
interchanged.
EtherCATP Box modules
EtherCATP Box modules are EtherCATP slaves with degree of protection IP67. They are designed for
operation in wet, dirty or dusty industrial environments.
EtherCAT basics
A detailed description of the EtherCAT system can be found in the EtherCAT system documentation.

Product overview
EPP4314-1002 9Version: 1.3
3 Product overview
Module Measured variable and output value
EPP4304-1002 Voltage
EPP4314-1002 Current

Product overview
EPP4314-100210 Version: 1.3
3.1 Introduction
EtherCAT P
downstream connection
Signal connection
channel1
Signal connection
channel2
EtherCATP
input
Tx+ / GND
Rx+ / GND
Rx- / U
Tx- / U
1 |
2 |
3 |
4 |
S
P
P
S
1 |
2 |
3 |
4 |
5 |
+24 V U
Input +
GND
DI
Output +
P
P
2-channel analog input + 2-channel analog output, parameterizable, 16-bit
The EPP43x4-1002 EtherCATPBox modules have two analog inputs, two analog outputs and two digital
inputs. The analog inputs and outputs can be parameterized individually. The following measuring ranges
and output ranges are available:
• EPP4304-1002: ±10V
• EPP4314-1002: ±10mA or ±20mA
The resolution of the measuring signals and output signals is 16bit. The two output channels have a
common ground potential with the supply voltage 24VDCUP.
A digital type 3 input with 10µs input filter time and an analog input and an analog output are arranged on
one M12 socket each. Since the digital input as well as the analog inputs and outputs are arranged together
on one M12 socket each, complex end devices can be controlled with one connection cable. This saves
additional costs, cable channels and installation work.
Misinterpretation of the measured values possible
In the factory setting the "Extended Range" mode is enabled.
In "Extended Range" mode the measuring range is slightly larger than the nominal measuring
range. The value 0x7FFF corresponds to approximately 107% of the full scale value.
• Take the increased measuring range into account when evaluating the measured values.
See chapter Measuring ranges [}14].
-or-
• Set the "Legacy Range" mode.
See chapter: Nominal and technical measuring range [}43]
Quick links
Technical data [}11]
Dimensions [}26]
Connections [}28]

Product overview
EPP4314-1002 11Version: 1.3
3.2 Technical data
All values are typical values over the entire temperature range, unless stated otherwise.
EtherCATP
Connection 2xM8 socket, 4-pin, P-coded, red
Distributed Clocks yes
Supply voltages
Connection See EtherCATP connection
US nominal voltage 24VDC (-15%/ +20%)
US sum current: IS,sum max. 3A
Current consumption from US100mA
Rated voltage UP24VDC (-15%/ +20%)
UP sum current: IP,sum max. 3A
Current consumption from UPCurrent consumption of connected sensors and actuators
Signal inputs and outputs
Connection 2xM12 socket, 5-pin, A-coded
Cable length max. 30m
Reference ground GNDP (ground potential of the peripheral voltage UP)
Sensor power supply 24VDC from the peripheral voltage UP
max. 0.5A in total, short-circuit proof
Further specifications Digital inputs [}12]
Analog inputs [}12]
Analog outputs [}13]
Environmental conditions
Ambient temperature during operation -25 … +60°C
-25 … +55°C according to cULus
Ambient temperature during storage -40 … +85°C
Vibration resistance, shock resistance conforms to EN60068-2-6/ EN60068-2-27
Additional tests [}11]
EMC immunity / emission conforms to EN61000-6-2/ EN61000-6-4
Protection class IP65, IP66, IP67 (conforms to EN60529)
Housing data
Dimensions WxHxD 30mmx 126mmx 26.5mm (without connectors)
Weight approx. 165 g
Installation position variable
Material PA6 (polyamide)
Approvals/ markings
Approvals/ markings*) CE, cULus [}37]
*) Real applicable approvals/markings see type plate on the side (product marking).
Additional tests
The devices have undergone the following additional tests:

Product overview
EPP4314-100212 Version: 1.3
Test Explanation
Vibration 10 frequency sweeps in 3 axes
5Hz<f<60Hz displacement 0.35mm, constant amplitude
60.1Hz<f<500Hz acceleration 5g, constant amplitude
Shocks 1000 shocks in each direction, in 3 axes
35g, 11ms
3.2.1 Digital inputs
Technical data Digital inputs
Number 2
Characteristics Type 3 according to EN 61131-2, compatible with type 1
Nominal voltage high level 24V
Switching threshold 9.5V
Input current 2.2mA at 24V
Input filter 10µs
Electrical isolation Yes
3.2.2 Analog inputs
Technical data EPP4304-1002 EPP4314-1002
Number 2 2
Measuring ranges •-10… +10V [}14]
•0… 10V [}15]
•-10… +10mA [}16]
•-20… +20mA [}17]
•0… 20mA [}18]
•4… 20mA [}19]
Input type Single-ended
Input resistance > 200 kΩ 85 Ω typ.
Dielectric strength max. 30VDC
Digital resolution 16bit, including sign
Measurement uncertainty <0.3% of full scale value
Largest short-term deviation during a
specified electrical interference test
100% of full scale value
Analog input filter: cut-off frequency 5kHz

Product overview
EPP4314-1002 13Version: 1.3
3.2.3 Analog outputs
Technical data EPP4304-1002 EPP4314-1002
Number 2 2
Output signal ranges •-10… +10V [}20]
•0… 10V [}20]
•-10… +10mA [}21]
•-20… +20mA [}21]
•0… 20mA [}22]
•4… 20mA [}22]
Digital resolution 16bit, including sign 16bit, including sign
Output error < 0.1% of the full scale value
of the signal range
< 0.1% of full scale value of
the signal range at an ambient
temperature of 0...+55°C.
< 0.2% of full scale value of
the signal range at an ambient
temperature <0°C or >55°C
Load resistor / load > 5kΩ max.500Ω
Short-circuit proof Yes Yes
Largest short-term deviation during a
specified electrical interference test
5% of the full scale value of
the signal range
1.5% of the full scale value of
the signal range

Product overview
EPP4314-100214 Version: 1.3
3.2.4 Measuring ranges
3.2.4.1 Measuring range -10…+10V
Technical data Measuring range
Measuring range, nominal -10…+10V
Measuring range, end value (full scale
value)
10V
Measuring range, technically usable -10.737…+10.737V
PDO resolution 16-bit, including sign
PDO LSB (Extended Range) 327.68µV
PDO LSB (Legacy Range) 305.19µV
Factory setting: "Extended Range" mode
-10.737.. V
-32768
(0x8000)
Range Error
Limit (²
Underrange Area (¹ Overrange Area (¹
Range Error
Limit (²
Technical Range
Nominal Range
positive Range
negative Range
-10 V
-30518
(0x88CA)
+10 V
+30518
(0x7736)
+10.737.. V
+32767
(0x7FFF)
0 V
0
(0x0000)
Defined resolution: 327.68 µV /Step
² Range Error: Error Bit + Error LED (detection level adjustabel by user, default: technical range)
¹ Underrange/Overrange Limit/Area: corresponding bit is set when measurement value is out of nominal range
Optional: "Legacy Range" mode
Range Error
Limit (²
Range Error
Limit (²
0 V
0
(0x0000)
Calculated resolution: 305.19 µV /Step
positive Range
negative Range
Nominal / Technical Range
Underrange
Limit (¹
Overrange
Limit (¹
-10 V
-32768
(0x8000)
+10 V
+32767
(0x7FFF)

Product overview
EPP4314-1002 15Version: 1.3
3.2.4.2 Measuring range 0…10V
Technical data Measuring range
Measuring range, nominal 0…10V
Measuring range, end value (full scale
value)
10V
Measuring range, technically usable -0.093…+10.737V
PDO resolution 16-bit, including sign
PDO LSB (Extended Range) 327.68µV
PDO LSB (Legacy Range) 305.19µV
Factory setting: "Extended Range" mode
-0.093.. V
-305
(0xFECF)
Range Error
Limit (²
Underrange Area (¹ Overrange Area (¹
Range Error
Limit (²
Technical Range
Nominal Range
positive Range
+10 V
+30518
(0x7736)
+10.737.. V
+32767
(0x7FFF)
0 V
0
(0x0000)
Defined resolution: 327.68 µV /Step
² Range Error: Error Bit + Error LED (detection level adjustabel by user, default: technical range)
¹ Underrange/Overrange Limit/Area: corresponding bit is set when measurement value is out of nominal range
Optional: "Legacy Range" mode
Range Error
Limit (²
Range Error
Limit (²
Calculated resolution: 305.19 µV /Step
positive Range
Nominal / Technical Range
Underrange
Limit (¹
Overrange
Limit (¹
0 V
0
(0x0000)
+10 V
+32767
(0x7FFF)

Product overview
EPP4314-100216 Version: 1.3
3.2.4.3 Measuring range -10…+10mA
Technical data Measuring range
Measuring range, nominal -10…+10mA
Measuring range, end value (full scale
value)
10mA
Measuring range, technically usable -10.737…+10.737mA, overcurrent-protected
Fuse protection Internal overload limiting, continuous current resistant
PDO resolution 16-bit, including sign
PDO LSB (Extended Range) 327.68nA
PDO LSB (Legacy Range) 305.19nA
Factory setting: "Extended Range" mode
-10.737.. mA
-32768
(0x8000)
Range Error
Limit (²
Underrange Area (¹ Overrange Area (¹
Range Error
Limit (²
Technical Range
Nominal Range
positive Range
negative Range
-10 mA
-30518
(0x88CA)
+10 mA
+30518
(0x7736)
+10.737.. mA
+32767
(0x7FFF)
0 mA
0
(0x0000)
Defined resolution: 327.68 nA /Step
² Range Error: Error Bit + Error LED (detection level adjustabel by user, default: technical range)
¹ Underrange/Overrange Limit/Area: corresponding bit is set when measurement value is out of nominal range
Optional: "Legacy Range" mode
Range Error
Limit (²
Range Error
Limit (²
0 mA
0
(0x0000)
Calculated resolution: 305.19 nA /Step
positive Range
negative Range
Nominal / Technical Range
Underrange
Limit (¹
Overrange
Limit (¹
-10 mA
-32768
(0x8000)
+10 mA
+32767
(0x7FFF)

Product overview
EPP4314-1002 17Version: 1.3
3.2.4.4 Measuring range -20…+20mA
Technical data Measuring range
Measuring range, nominal -20…+20mA
Measuring range, end value (full scale
value)
20mA
Measuring range, technically usable -21.474…+21.474mA, overcurrent-protected
Fuse protection Internal overload limiting, continuous current resistant
PDO resolution 16-bit, including sign
PDO LSB (Extended Range) 655.35nA
PDO LSB (Legacy Range) 610.37nA
Factory setting: "Extended Range" mode
-21.474.. mA
-32768
(0x8000)
Range Error
Limit (²
Underrange Area (¹ Overrange Area (¹
Range Error
Limit (²
Technical Range
Nominal Range
positive Range
negative Range
-20 mA
-30518
(0x88CA)
+20 mA
+30518
(0x7736)
+21.474.. mA
+32767
(0x7FFF)
0 mA
0
(0x0000)
Defined resolution: 655.35 nA /Step
² Range Error: Error Bit + Error LED (detection level adjustabel by user, default: technical range)
¹ Underrange/Overrange Limit/Area: corresponding bit is set when measurement value is out of nominal range
Optional: "Legacy Range" mode
Range Error
Limit (²
Range Error
Limit (²
0
(0x0000)
Calculated resolution: 610.37 nA /Step
positive Range
negative Range
Nominal / Technical Range
Underrange
Limit (¹
Overrange
Limit (¹
-20 mA
-32768
(0x8000)
+20 mA
+32767
(0x7FFF)
0 mA

Product overview
EPP4314-100218 Version: 1.3
3.2.4.5 Measuring range 0…20mA
Technical data Measuring range 0...20mA
Measuring range, nominal 0…20mA
Measuring range, end value (full scale
value)
20mA
Measuring range, technically usable -0.186…+21.474mA, overcurrent-protected
Fuse protection Internal overload limiting, continuous current resistant
PDO resolution 16-bit, including sign
PDO LSB (Extended Range) 655.35nA
PDO LSB (Legacy Range) 610.37nA
Factory setting: "Extended Range" mode
-0.186.. mA
-305
(0xFECF)
Range Error
Limit (²
Underrange Area (¹ Overrange Area (¹
Range Error
Limit (²
Technical Range
Nominal Range
positive Range
+20 mA
+30518
(0x7736)
+21.474.. mA
+32767
(0x7FFF)
0 mA
0
(0x0000)
Defined resolution: 655.35 nA /Step
² Range Error: Error Bit + Error LED (detection level adjustabel by user, default: technical range)
¹ Underrange/Overrange Limit/Area: corresponding bit is set when measurement value is out of nominal range
Optional: "Legacy Range" mode
Range Error
Limit (²
Range Error
Limit (²
Calculated resolution: 610.37 nA /Step
positive Range
Nominal / Technical Range
Underrange
Limit (¹
Overrange
Limit (¹
0 mA
0
(0x0000)
+20 mA
+32767
(0x7FFF)

Product overview
EPP4314-1002 19Version: 1.3
3.2.4.6 Measuring range 4…20mA
Technical data Measuring range 4...20mA
Measuring range, nominal 4…20mA
Measuring range, end value (full scale
value)
20mA
Measuring range, technically usable 0…+21.179mA, overcurrent-protected
Fuse protection Internal overload limiting, continuous current resistant
PDO resolution 16-bit, including sign
PDO LSB (Extended Range) 524.28nA
PDO LSB (Legacy Range) 488.30nA
Factory setting: "Extended Range" mode
3.814 mA
-381
(0xFE83)
0 mA
-7629
(0xE233)
Range Error
Limit (²
Underrange Area (¹ Overrange Area (¹
Range Error
Limit (²
Technical Range
Nominal Range
positive Range
4 mA
0
(0x0000)
+20 mA
+30518
(0x7736)
+21.179.. mA
+32767
(0x7FFF)
Defined resolution: 524.28 nA /Step
² Range Error: Error Bit + Error LED (detection level adjustabel by user, default: technical range)
¹ Underrange/Overrange Limit/Area: corresponding bit is set when measurement value is out of nominal range
Optional: "Legacy Range" mode
Range Error
Limit (²
Range Error
Limit (²
Calculated resolution: 488.30 nA /Step
positive Range
Nominal / Technical Range
Underrange
Limit (¹
Overrange
Limit (¹
+4 mA
0
(0x0000)
+20 mA
+32767
(0x7FFF)

Product overview
EPP4314-100220 Version: 1.3
3.2.5 Output signal ranges
3.2.5.1 Output signal range -10…+10V
Technical data Output signal range -10...+10V
Full scale value of the signal range 10V
PDO resolution 16-bit, including sign
PDO LSB 305.19µV
0 V
0
(0x0000)
Calculated resolution: 305.19 µV /Step
positive Range
negative Range
Nominal / Technical Range
-10 V
-32768
(0x8000)
+10 V
+32767
(0x7FFF)
3.2.5.2 Output signal range 0…10V
Technical data Output signal range 0...10 V
Full scale value of the signal range 10V
PDO resolution 16-bit, including sign
PDO LSB 305.19µV
Calculated resolution: 305.19 µV /Step
positive Range
Nominal / Technical Range
0 V
0
(0x0000)
+10 V
+32767
(0x7FFF)
